Installation
Special Requirements
Specifications
Height
Additional clearance above for servicing and lifting the Data Acquisition card cage
above the sensor
Total clearance needed
Width
Additional clearance on right for servicing
Additional clearance on left for servicing
Total clearance needed
Depth
Additional clearance behind instrument for sufficient cooling and room for
servicing
Total clearance needed

Electrical Input

CAUTION
Possible instrument damage could occur if you use an extension cord or a power
strip to connect the Supply Cart. Use a dedicated outlet with an isolated ground
for the Supply Cart plug.
The Supply Cart requires one dedicated outlet with an isolated ground The computer requires a
separate outlet, but it does not have to be a dedicated line.
Country
USA
2-2
Dedicated Lines with Isolated Grounds
One dedicated line at 115 Vac, 50/60 Hz
at 15 A for the Supply Cart.
60.5 cm (23.8 in.)
45.7 cm (18 in.) min.
106.2 cm (41.8 in.)
95.3 cm (37.5 in.)
15.2 cm (6 in.)
15.2 cm (6 in.)
125.7 cm (49.5 in.)
70.1 cm (27.6 in.)
3.8 cm (1.5 in.)
73.9 cm (29.1 in.)
Non-Dedicated Lines
Two non-dedicated lines at 115 Vac,
50/60 Hz at 15 A - one for the tower
computer and a second, for the
monitor. A third non-dedicated line
is required if the optional printer is
being installed.
773232AH
