X/Y coordinates of all the vertices. To display a Region's points (or bounds), click on the desired
Region in the Regions list box.

Resizing a Region

If you want to enlarge or shrink a Region:
1
the Region.
The Region is now active and handles appear. Vertices also appear for Contour AutoGate and
Polygon Regions
2
Hold the left mouse button down while moving the handle (or moving a vertex as in Contour
AutoGate and Polygon Regions).

Moving a Region

To move a Region to another position:
1
Mouse over the Region to get the
2
Hold the left mouse button down while moving the Region anywhere in the current window. If
the Region has been moved, the statistics automatically recalculate.
The Region name moves to the same relative position alongside the Region's new position.
See also:
View / Modify Regions

Editing and Moving a Region Name

To edit or move the Region name:
NOTE
Quadrant/FlexQuad region names can also be edited through the View/Modify Regions dialog.
1
Double click on or near the first letter of the Region name to activate the Region Name dialog
box.
NOTE
FlexQuad region name does not launch the Enter Region Information dialog.
773232AH
CAL and Quadrant/FlexQuad regions can not be renamed, therefore double clicking CAL or
cursor.
