Panasonic KX-NS8290 Installation Manual

E1 trunk adaptor/pri adaptor
Hide thumbs

Advertisement

Quick Links

x
Download this manual
18
Basic System Construction
Table of Contents
Thank you for purchasing this Panasonic product.
Please read this manual carefully before using this product and save this manual for future use.
Compatible PBX:
KX-NS1000 PCMPR Software File Version 002.00000 or later
Installation Manual
E1 Trunk Adaptor/PRI Adaptor
KX-NS8188
Model No.
KX-NS8290

Advertisement

loading

  Also See for Panasonic KX-NS8290

Panasonic KX-NS8290 Important Safety Instructions Manual
Panasonic KX-NS8290 Important Safety Instructions Manual 48 pages

  Related Manuals for Panasonic KX-NS8290

  Summary of Contents for Panasonic KX-NS8290

  • Page 1 E1 Trunk Adaptor/PRI Adaptor KX-NS8188 Model No. KX-NS8290 Thank you for purchasing this Panasonic product. Please read this manual carefully before using this product and save this manual for future use. Compatible PBX: KX-NS1000 PCMPR Software File Version 002.00000 or later...
  • Page 2 This Installation Manual is designed to serve as an overall technical reference for the KX-NS8188 E1 Trunk Adaptor/KX-NS8290 PRI Adaptor (Trunk Adaptor) for KX-NS1000. A Trunk Adaptor provides an E1/PRI trunk interface to the KX-NS1000 and enables flexible trunk configuration. This manual provides instructions for installing the hardware, and programming the Trunk Adaptor using Web Maintenance Console.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents 1 Safety Precautions ...................5 For Your Safety .........................6 Important Safety Instructions ..................12 Precautions ........................13 Data Security ........................15 Additional Information ....................16 2 System Outline ..................17 Basic System Construction ...................18 2.1.1 Model Line-up .........................18 2.1.2 Optional Equipment ......................18 2.1.3 System Connection Diagram ..................18 2.1.4...
  • Page 4 Table of Contents Installation Manual...

  • Page 5: Safety Precautions

    Section 1 Safety Precautions This section provides important information intended to prevent personal injury and property damage. Installation Manual...

  • Page 6: For Your Safety

    1.1 For Your Safety 1.1 For Your Safety To prevent personal injury and/or damage to property, be sure to observe the following safety precautions. The following symbols classify and describe the level of hazard and injury caused when this unit is operated or handled improperly.
  • Page 7 1.1 For Your Safety WARNING • Do not install the system in the following locations: – Areas where shocks or vibrations are frequent or strong. Such activity may lead to the product falling over and causing injury, or may impair the product’s performance. –...
  • Page 8 1.1 For Your Safety • Disconnect the Trunk Adaptor from the AC outlet and disconnect the LAN cable if the Trunk Adaptor emits smoke, an abnormal smell, or makes unusual noise. These conditions can cause fire or electric shock. Confirm that smoke has stopped and contact an authorised service centre. •...
  • Page 9 1.1 For Your Safety CAUTION • Do not install the system in the following locations: – In direct sunlight and hot, cold, or humid places. (Temperature range: 0 °C to 40 °C) – Areas where sulphuric gases may be present, such as near thermal springs. –...
  • Page 10 1.1 For Your Safety • Unplug the system from its power source when wiring, and plug the system back in only after all wiring is completed. • Use cables that are fire-resistant or fireproof. • Make sure the cables are securely fastened to the wall. •...
  • Page 11 1.1 For Your Safety Notice SAFETY REQUIREMENTS • Before connecting the Trunk Adaptor, confirm that the Trunk Adaptor supports the intended operating environment. • If the Trunk Adaptor does not operate properly, disconnect the AC adaptor cord and LAN cable, then connect again.

  • Page 12: Important Safety Instructions

    1.2 Important Safety Instructions 1.2 Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • Do not use the product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool.

  • Page 13: Precautions

    1.3 Precautions 1.3 Precautions For users in the European Union only Information for Users on Collection and Disposal of Old Equipment and used Batteries These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste.
  • Page 14 1.3 Precautions company because the telephone numbers include the toll access digit and area code digit. A toll charge may be incurred. Please check with the toll carrier concerned. • APPLICABLE ONLY TO TELECOM CUSTOMERS WHO HAVE AUTOMATIC ACCESS TO OTHER CARRIERS FOR TOLL CALLS When calling back a number from the Caller ID list, all numbers prefixed with "0 + AREA CODE"...

  • Page 15: Data Security

    1.4 Data Security 1.4 Data Security In order to use the Trunk Adaptor safely and correctly, the Security Requirements below must be observed. Failure to do so may result in loss, leakage, falsification or theft of user information. What is User Information? User Information is defined as system data and error data information stored on the Trunk Adaptor.

  • Page 16: Additional Information

    1.5 Additional Information 1.5 Additional Information For Users in Canada Only This product meets the applicable Industry Canada technical specifications. This Class A digital apparatus complies with Canadian ICES-003. Notice Attachment of non-IC certified/registered equipment is illegal in some areas of Canada. Please consult your Telephone Company.

  • Page 17: System Outline

    Section 2 System Outline This section provides general information on the Trunk Adaptor, including the system capacity and specifications. Installation Manual...

  • Page 18: Basic System Construction

    "PQLV206xx/PSLP1662"). For users in Argentina, power can only be supplied by PoE. 2.1.3 System Connection Diagram The following diagram shows the connection configuration image of a system containing a KX-NS8188/ KX-NS8290. Multiple Trunk Adaptors can be connected to one KX-NS1000. Installation Manual...
  • Page 19 2.1.3 System Connection Diagram Note You can connect the Trunk Adaptor to the PBX without the need for activation keys. Pure IP-PBX E1 Trunk Adaptor (KX-NS8188)/ (KX-NS1000) PRI Adaptor (KX-NS8290) E1/PRI (23 ch/30 ch) DSU* SIP Phone (KX-UT series) Telephone...

  • Page 20: Service Feature

    2.1.4 Service Feature 2.1.4 Service Feature 2.1.4.1 E1 Gateway The Trunk Adaptor for E1 trunks allows a KX-NS1000 to connect to an E1 line as it converts data between the SIP and E1 protocols. PSTN IP Network E1 Line E1 Line E1 Trunk Adaptor KX-NS1000...
  • Page 21 2.1.4 Service Feature The Trunk Adaptor for PRI Trunks—Private Mode allows a KX-NS1000 to connect to a PRI QSIG network as it converts data between the H.323 and ISDN QSIG protocols. Public Mode Private Mode IP Network PSTN IP Network Private Network ISDN ISDN...

  • Page 22: Specifications

    2.2.2 System Capacity 2.2 Specifications 2.2.1 General Description ARM11 450 MHz Network port 1 port (RJ45 connector) IEEE802.3 10/100BASE-TX Auto Negotiation, Auto MDI/MDIX Status LED: LINK, 100 Line interface 1 port (RJ45 connector) Framer E1/T1 framer NT/TE mode E1/PRI Public mode: TE QSIG Master: TE QSIG Slave: NT Loop back mode...

  • Page 23: Installation

    Section 3 Installation This section describes the procedures to connect the Trunk Adaptor to the PBX. Installation Manual...

  • Page 24: Before Installation

    Please read the following notes concerning installation and connection before installing the Trunk Adaptor. Be sure to comply with all applicable laws, regulations, and guidelines. Notice Panasonic assumes no responsibility for injuries or property damage resulting from failures arising out of improper installation or operation inconsistent with this documentation. Installation Precautions The Trunk Adaptor can be mounted on a wall or placed on a desktop, and should be installed in a location where it is accessible for inspections and maintenance.

  • Page 25: Installation Of The Trunk Adaptor

    3.2.2 Names and Locations 3.2 Installation of the Trunk Adaptor 3.2.1 Unpacking Unpack the box and check the items below: Main Unit ´ 1 Screw ´ 2 Washer ´ 2 Notice After unpacking the product, dispose of the packing materials appropriately. 3.2.2 Names and Locations Front Side Front Side when Wall Mounted...

  • Page 26: Led Indications

    3.2.3 LED Indications Name Description LAN LED (100) Ethernet data transmission speed indication LINE Port E1 line interface (KX-NS8188X) PRI23 line interface (KX-NS8290X) PRI30 line interface (KX-NS8290CE) INITIALIZE System Initialise switch 3.2.3 LED Indications Indication Status Colour SYSTEM Power off Awaiting system initialisation Quick Amber Flashing (5 s) Off (2 s) ®...

  • Page 27: Types Of Connectors

    3.2.6 Wall Mounting 3.2.4 Types of Connectors Please refer to "Types of Connectors" in the Installation Manual of the KX-NS1000 PBX. The connector type for the Trunk Adaptor is RJ45. 3.2.5 Placing the Trunk Adaptor on a Desktop When placing the Trunk Adaptor on a desktop, make sure to follow these instructions. WARNING Be careful not to drop any components.
  • Page 28 3.2.6 Wall Mounting • Only use the wall-mounting equipment (screws, washers) included with the Trunk Adaptor. • Be careful not to drop any components. Dropping components may damage them or cause an injury. • When the Trunk Adaptor is no longer in use, make sure to detach it from the wall. CAUTION •...
  • Page 29 3.2.6 Wall Mounting Hook the Trunk Adaptor on the screw heads in any of the following 4 directions. Hook this part onto both screws. Washer Drive the screw to this point. Installation Manual...

  • Page 30: Wiring Requirement

    3.2.7 Wiring Requirement Reference for Wall Mounting Please copy this page and use as a reference for wall mounting. Install a screw here. 83 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here.

  • Page 31: Starting The Trunk Adaptor

    3.3.1 Installation Procedure and Connection Diagrams 3.3 Starting the Trunk Adaptor 3.3.1 Installation Procedure and Connection Diagrams This section describes the installation procedure for connecting the Trunk Adaptor and KX-NS1000 PBX. Requirements Power supply: AC adaptor Trunk Adaptor IP address: Static IP address WARNING When installing or testing a Trunk Adaptor with an external AC adaptor, the AC adaptor should be plugged into a wall outlet or floor-mounted AC outlet.
  • Page 32 3.3.1 Installation Procedure and Connection Diagrams Shutdown the Trunk Adaptor through Web Maintenance Console and disconnect the AC adaptor from the Trunk Adaptor. Change the Trunk Adaptor’s LAN cable connection from the PC to the switching hub, and then connect the AC adaptor to the Trunk Adaptor again.

  • Page 33: Programming With Web Maintenance Console

    Section 4 Programming with Web Maintenance Console This section describes the installation procedure, structure, and functions of Web Maintenance Console for programming the Trunk Adaptor. Installation Manual...

  • Page 34: Overview Of Web Maintenance Console

    4.1 Overview of Web Maintenance Console 4.1 Overview of Web Maintenance Console Web Maintenance Console of the Trunk Adaptor is designed to serve as an overall system programming reference for the Trunk Adaptor. You can programme and control the Trunk Adaptor over an IP network using Web Maintenance Console.
  • Page 35 4.1 Overview of Web Maintenance Console Setting Item Description Value Range Software Version Displays the Trunk Adaptor’s software version. 000.000.00–999.999.99 Installation Manual...

  • Page 36: Pc Connection

    4.2 PC Connection 4.2 PC Connection You can connect a PC to the Trunk Adaptor either directly or over a LAN using the appropriate method for the port being used. Direct Connection LAN Port System Initialise Switch To LAN Port To AC Adaptor Notice When connecting a PC to the Trunk Adaptor, a fixed IP address must be assigned to the PC.
  • Page 37 4.2 PC Connection Connection via Virtual Private Network (VPN) LAN Port System Initialise Switch Router To AC Adaptor Router Switching Hub Notice To access the Trunk Adaptor via VPN, the PC must be in the same VPN. Connection via Internet LAN Port System Initialise Switch Router...

  • Page 38: Starting Web Maintenance Console

    4.3 Starting Web Maintenance Console 4.3 Starting Web Maintenance Console System Requirements Required Operating System • Microsoft Windows XP, Windows Vista Business, or Windows 7 Professional operating system ® ® ® Recommended Display Settings • Screen resolution: XGA (1024 ´ 768) •...

  • Page 39: Programming The Trunk Adaptor

    3, below. Select the Area of KX-NS1000 from the drop-down list for the PBX you are connecting to. [KX-NS8290 only] Select a Network Type from the drop-down list (Public or Private). Specify SIP Authentication ID Plan, which is the header digits of the SIP authentication ID for connecting to a KX-NS1000 SIP trunk.

  • Page 40: Setting List

    4.4.2 Setting List Enter the preferred and alternative DNS IP addresses Click Next. Valid IP address range: "1.0.0.0" to "223.255.255.255" Valid subnet mask address range: "0–255.0–255.0–255.0–255" (except "0.0.0.0" and "255.255.255.255") In SNTP / Daylight Saving, enter information for Automatic Time Adjustment and Daylight Saving, and then click Next.
  • Page 41 4.4.2 Setting List Category Setting Item Value Range Default Value Incoming Call Inter-digit 0–30 s Timer - DDI/DID Incoming Call Inter-digit 3–30 s Timer - TIE PRI23/PRI30 Port Port – Property—Main Port Type CO (fixed when Network Type is set to Public) QSIG-Slave, Set during "4.4.1 Easy...
  • Page 42 4.4.2 Setting List Category Setting Item Value Range Default Value PRI23/PRI30 Port Port – Property—Network Port Type CO (fixed when Configuration Network Type is set to Public) QSIG-Slave, Set during "4.4.1 Easy QSIG-Master (when Setup Wizard" Network Type is set to Private) Connection INS, OUS, Fault...
  • Page 43 4.4.2 Setting List Category Setting Item Value Range Default Value Called Party Number— Unknown, International, Unknown Type of Number National, Network, (Private) Subscriber PRI23/PRI30 Port Port – Property—System Port Type CO (fixed when Option Network Type is set to Public) QSIG-Slave, Set during "4.4.1 Easy QSIG-Master (when...
  • Page 44 4.4.2 Setting List Category Setting Item Value Range Default Value Seizure ACK Wait Timer 0.5 × n (n=1–20) s 2.5 s LIU Send Option Mode-1 – Mode-8 Mode-8 LIU Receive Option Automatic, 6 dB, 12 dB, Automatic 18 dB, 24 dB RAI Signal Detection Type1, Type2 Type1...
  • Page 45 4.4.2 Setting List Category Setting Item Value Range Default Value E1 Card Property— ANI Service—Mode None, Incoming call None MFC-R2 Setting1 only, Outgoing call only, Both calls ANI Service—ANI Max. None, 1–16 None digits MFC-R2 Timer— 1–30 s 15 s Forward MFC-R2 Timer—...
  • Page 46 4.4.2 Setting List Category Setting Item Value Range Default Value MFC-R2 Group-1[*][#]— 11–15 E1 MFC-R2 Group1[*] code MFC-R2 Group-1[*][#]— 11–15 E1 MFC-R2 Group1[#] code E1 Card Property— Group-A Code 1–15 MFC-R2 Setting2 Assignment—Address Complete Group-A Code 1–15 Assignment—ANI Request Group-A Code 1–15 Assignment—ANI (N+1) Group-A Code...
  • Page 47 4.4.2 Setting List Category Setting Item Value Range Default Value Group-B Code Undefined, 1–15 Assignment— Unallocated Group-B Code Undefined, 1–15 Assignment— Congestion Group-B Code Undefined, 1–15 Assignment— Out-of-Service Group-B Code Undefined, 1–15 Undefined Assignment—No Billing Group-B Code Undefined, 1–15 Undefined Assignment—Collect Call Reject E1 Port Property...
  • Page 48 4.4.2 Setting List • Receive Digits • CPC Detection Time-Out, In • DTMF Width • Ringback Tone to Outside Caller • Answer Wait Timer (*60s) • Pause Time • Flash Time • Disconnect Time Configuration—IP Interface Category Setting Item Value Range Default Value VoIP Setting—Codec Voice Activity Detection...
  • Page 49 4.4.2 Setting List Category Setting Item Value Range Default Value VoIP Setting—DSP Jitter Compensation Disable, Enable Enable Option2 Operation for G.711 Jitter Compensation Disable, Enable Enable Operation for G.711 Jitter Compensation Disable, Enable Enable Operation for G.729A Jitter Buffer Delay Min. 10 ×...
  • Page 50 4.4.2 Setting List Category Setting Item Value Range Default Value GW Name(Secondary) Max. 20 characters Not stored GW IP 1.0.0.0– – Address(Secondary) 223.255.255.255 Protocol TCP, UDP Progress Tone Send External, Internal Internal Mode System Property— Call Signalling Model Direct, GateKeeper Direct IPGW Gatekeeper Connection...
  • Page 51 4.4.2 Setting List Category Setting Item Value Range Default Value T310 0–3000 1000 T313 0–600 T316 0–3000 T318 0–600 T319 0–600 T322 0–600 T3D3 0–3000 T3D9 0–3000 IP-GW Card Property— 1–48 – GK Settings Destination Number (30 Max. 30 digits Not stored Digits) Device Name...
  • Page 52 4.4.2 Setting List SIP Port Property Copy You can copy the Authentication Password setting value from one port to other ports by clicking the button on the SIP Port Property screen and configuring the SIP Port Property Copy screen. This feature is available only when the Activation Key mode setting is set to Yes. Configuration—Date &...
  • Page 53 4.4.2 Setting List Configuration—Maintenance Category Setting Item Value Range Default Value System Settings Installer Password 4–16 digits 1234 Web-MC Language English (US), English English (UK) (UK), French, German, Italian, Spanish, Russian, Others SIP Authentication ID 1–3 digits Plan Network Service—System Control Category Setting Item Value Range...
  • Page 54 4.4.2 Setting List Category Setting Item Value Range Default Value IP address/Ports— Assigned IP Address— 1.0.0.0– – Reference IP Address 223.255.255.255 Assigned IP Address— 00:00:00:00:00:00– – MAC Address FF:FF:FF:FF:FF:FF Assigned IP Address— 0–255.0–255.0–255.0– – Subnet Mask (Except 0.0.0.0 and 255.255.255.255) Assigned IP Address—...
  • Page 55 4.4.2 Setting List Category Setting Item Value Range Default Value Automatic logout Timer 5, 10, 30, 60 × n (n=1– (min) Network service—Client Feature Category Setting Item Value Range Default Value Connection 1–5— Max. 64 characters – Connection Name Connection 1–5—IP IP Address, Name IP Address Address/Name...
  • Page 56 4.4.2 Setting List Network service—Other Category Setting Item Value Range Default Value Security ICMP ECHO Reply— Enable, Disable Enable LAN Port ICMP ECHO Reply— Enable, Disable Disable Log output SSL/TLS—Encryption AES256-SHA, DES-CBC3-SHA suite DES-CBC3-SHA, AES128-SHA, DES-CBC-SHA System Control—Program Update Category Setting Item Value Range Default Value...
  • Page 57 4.4.2 Setting List File—File Delete Deletes files stored in the Trunk Adaptor. Log—Error Log Collects and displays system error information. Click Log Information to download the error log to the connected PC. Log—Syslog Displays a log of system events. Monitor/Trace—ISDN/QSIG Protocol Trace Displays protocol trace data from the PRI card.

  • Page 58: Programming For The Kx-Ns1000

    4.5 Programming for the KX-NS1000 4.5 Programming for the KX-NS1000 The following tables show the settings (items, value ranges, and defaults etc.) that you can configure using the KX-NS1000 Web Maintenance Console. IP-GW PBX Configuration—[1-1] Configuration—Slot—Virtual—V-IPGW16 Port Property Category Setting Item Value Range Setting Value Port Property - Virtual IP...
  • Page 59 4.5 Programming for the KX-NS1000 Category Setting Item Value Range Setting Value SIP Account / User 100–99999 Set the SIP Account / Name—From User Name start number for the Trunk Adaptor referring to the SIP Authentication ID (SIP Port Property) of the Trunk Adaptor’s first port.
  • Page 60 4.5 Programming for the KX-NS1000 Installation Manual...

  • Page 61: Troubleshooting

    Section 5 Troubleshooting This section provides information on the Trunk Adaptor troubleshooting. Installation Manual...

  • Page 62: Installation

    5.2 Error Messages 5.1 Installation PROBLEM PROBABLE CAUSE SOLUTION The SYSTEM LED of the A major system error has Turn the Trunk Adaptor off and then back on. Trunk Adaptor is lit or occurred in the Trunk If the problem is not resolved, consult your flashing red.

  • Page 63: Index

    Index Installation Manual...
  • Page 64 Index Connection Diagram, System Connector Types DDI/DID, Programming for the KX-NS1000 E1 Gateway Easy Setup Wizard Installation Precautions IP-GW, Programming for the KX-NS1000 Names and Locations Password Security PRI Gateway Programming for the KX-NS1000, DDI/DID Programming for the KX-NS1000, IP-GW Programming for the KX-NS1000, SIP-GW Programming the Trunk Adaptor Setting List, Web Maintenance Console...
  • Page 65 Panasonic System Networks Co., Ltd. declares that the KX-NS8290CE is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. Declarations of Conformity for the relevant Panasonic products described in this manual are available for download by visiting: http://www.doc.panasonic.de...
