Summary of Contents for Haier HYCD-282
- Page 1 Service Manual Combined Refrigerator and Freezer Model：HYCD-282/282A/282C Pictures：...
-
Page 2: Table Of Contents
HYCD-282/282A/282C_Service Manual contents Definition of the Model ..............................3 Appearance and Parts ................................ 3 3. Product Technical Parameters..............................4 Electrical parts and circuit diagram ........................... 5 Spare parts of cooling system ............................6 Spare part list and exploded view ............................7 7. -
Page 3: Definition Of The Model
HYCD-282/282A/282C_Service Manual 1. Definition of the Model H（Haier）Y（Medical）CD（cooling and freezer）-282（capacity is 282L） 2. Appearance and Parts... -
Page 4: Product Technical Parameters
HYCD-282/282A/282C_Service Manual 3. Product Technical Parameters HYCD-282 HYCD-282A HYCD-282C Model upright 、 foam door 、 upright 、 foam + glass door 、 Type upright、foam door、air-cooling& air-cooling& forced cooling air-cooling& forced cooling forced cooling N（16℃~32℃） N（16℃~32℃） N（16℃~32℃） Climate class 2~8℃/-20~-40℃ 2~8℃/-20~-40℃... -
Page 5: Electrical Parts And Circuit Diagram
HYCD-282/282A/282C_Service Manual 4. Electrical parts and circuit diagram Part code Name Specification Applicable models 0271800009 Display board 0271800008 Control board 0271800064 USB board 10years HYCD-282C optional 0074091430 Battery 0274000232 Printer 8000 Pcs data Only in china 0064001173 0070401365 Transformer of... -
Page 6: Spare Parts Of Cooling System
HYCD-282/282A/282C_Service Manual 5. Spare parts of cooling system Part Code Name Specification Remark 0074091262 Cool compressor DB L88CY 220V/50Hz 0074000035 Cool compressor ACCGVY57AG 220V/60Hz 0074000149 Freeze compressor NL7CLX 220V/50Hz 0274000190 Freeze compressor SC12CLX.2 220V/60Hz 0070701944 Condenser 0270700046 Cool evaporator In the foam layer，can’t be replaced. -
Page 7: Spare Part List And Exploded View
HYCD-282/282A/282C_Service Manual 6. Spare part list and exploded view Code CN Name English name Remark 0270100499 电控箱上盖 Top cover of electrical box 0070107468 电池固定夹 The battery clip 0074091430 电池 Battery 0271800064 USB 板 Usb board HYCD-282C，optional 0034000993 继电器 Relay 0274000087A 机械温控器... - Page 8 HYCD-282/282A/282C_Service Manual 0074000149 冷冻压缩机 Freeze compressor NL7CLX，220V/50Hz 0274000190 冷冻压缩机 Freeze compressor SC12CLX.2，220V/60Hz 0074180002A 干燥过滤器 Drier filter 0270100482 机舱后护罩 Back cover of cabin 0270100486 冷冻压机底板 Fix board of freeze compressor 0270100485 冷藏压机底板 Fix board of cool compressor 0270101786 后脚轮支撑板 Back caster support 0270100483 前脚轮支撑板...
-
Page 9: Instruction Of Operation
HYCD-282/282A/282C_Service Manual short ） 0270200213 中梁密封条 Middle door seal 7. Instruction of operation Light：the switch of light which is in the cabinet.(HYCD-282A only) Refrigerator temperature zone： The temperature & parameters and alarm code for cool function; Freezer temperature zone：The temperature & parameters and alarm code for cool function;... - Page 10 HYCD-282/282A/282C_Service Manual Alarm test： in lock status， press this button to inquire alarm code； in unlock status， press this button， all the LEDs show“8”， which is used for checking LEDs； Silence ：alarm pause ； Defrost ：in unlock status，press this button for 5 s，the forced defrosting function will work；in unlock status press this button again to stop defrosting。...
- Page 11 HYCD-282/282A/282C_Service Manual the display screen and the second digit flashes (the default temperature set for low temperature alarm is -5℃ in the cabinet). If the set temperature is to be changed, press button “ ” to change the flashing digit and by pressing “...
- Page 12 HYCD-282/282A/282C_Service Manual Item Steps Display Msg Shows F0 and“0“bit ”for 5s，the refrigerator temp zone shows“F0” 1、press“ flash Shows ‘F1’ Unlock ”，the refrigerator temp zone shows“F1”； 2、short press“ The lock light turn off 3、short press “ “，unlocked。No operation in 10s，it will auto lock Unlock status，short press “...
- Page 13 HYCD-282/282A/282C_Service Manual a． Users parameter setting Parameter Name Range HYCD-282/A/C Remark default value Cool ：0~16 Temp set Freeze ：-10~-45 value -40（HYCD-282C:-30） Cool ：set value（L0+5）~+50 High temp Freeze ： set value （L0+5） ~+50 alarm value -35（HYCD-282C:-25） Cool ：-60~set value（L0-5） Low temp Freeze ：-60~set value（L0-5）...
- Page 14 HYCD-282/282A/282C_Service Manual “ ”for 5s at the same time. 2、press “ ”to adjust the value. 1P~5P 3、press “ ”，to select other parameters Notice：1P~5P means： Year / month /day /hour /min. e． Alarm code Alarm Code Instruction Alarm type Solution Ambient sensor failed...
-
Page 15: Replacement Of Main Parts
HYCD-282/282A/282C_Service Manual If the freezer includes USB board，Please adjust the system time of the USB board If the freezer includes printer, Please adjust the system time of the printer The blood bank freezer is Air cooling freezer, when put the goods into the freezer, not too dense, make sure... - Page 16 HYCD-282/282A/282C_Service Manual b. The position of the temp. sensor The position of the refrigerator temp. sensor (upper sensor) The freezer sensor(lower sensor): c. unpacking step1 Use a knife to cut down the packing belt and remove the box;...
-
Page 17: The Curve Of Temperature
Remove the pallet Remove the plates of pallet Step3. Remove the pallet Tilt the freezer and pull out the pallet, the angle of inclination should be less than 45 degree. 9．The curve of temperature HYCD-282、HYCD-282A、HYCD-282C temperature curve of refrigerator temp zone：... - Page 18 HYCD-282/282A/282C_Service Manual HYCD-282、HYCD-282A freeze temp.curve; HYCD-282Cfreeze temp curve...
- Page 19 HYCD-282/282A/282C_Service Manual Inspired living Haier Medical & Laboratory Products Co., Ltd. Room 403D, Brand Building, Haier Industrial Park, No.1 Haier Road Qingdao China Website: www.haiermedical.com...
