Pharmaceutical Refrigerator
Operation Manual
Read the Operation Manual carefully before using your appliance.
Keep the Operation Manual in a safe place.
Appearance , color and layout of the door may vary.
Translation of the original instruction.
The scope of the Product Application: Pharmaceuticals and other related products
which need a storage environment of 2
Model:
HYC-1378
-8
。
℃
℃
Advertisement
Related Manuals for Haier HYC-1378
Summary of Contents for Haier HYC-1378
-
Page 1: Operation Manual
Pharmaceutical Refrigerator Operation Manual Model: HYC-1378 Certificate of Quality checker: Haier Medical and Laboratory Products Co., Ltd. Address: Haier Industrial Park, Economic Technology Development Zone. Qingdao 266510.P.R.China Web:www.haiermedical.com Version:1st,2017 Read the Operation Manual carefully before using your appliance. Dedicated code:0270501006 Keep the Operation Manual in a safe place. - Page 2 : Pharmaceutical Refrigerator Type Designation/Trademark: HYC-1378 Haier Manufactures Name : Haier Medical and Laboratory Products Co.,Ltd. Manufactures Address : Haier Industrial Park, Economic Technology Development Zone. Qingdao 266510.P.R.China Refer to in this declaration confirms with the following directive(s)/standards: 2006/42/EC, EN60335-1, EN60335-2-89 EN62233...
-
Page 3: Product Feature
Glass door with electric heat, multiple anti-condensation technologies Automatic evaporation of condensate water, safety door latch We apologize that the Haier pharmaceutical refrigerator provided for you may be a little different from the figure in the manual due to product improvement. The manual may be... -
Page 4: Table Of Contents
Packing List HYC-1378 Model Operation Manual Plastic bag Content: Handle kits Product Feature............Content..............Screw Safety Precautions........... Precautions for Use..........Note: Technical information may vary from the appliance that you have just purchased due to Product Installation ........... technical improvements. -
Page 5: Safety Precautions
Specification Safety Precautions Dear users: Specification Thanks for your choice of Haier pharmaceutical refrigerator; please make sure you have carefully read and observed the contents with following signs in the manual, for better understanding of this Name Pharmaceutical Refrigerator manual and better use of this product, so as to prevent personal injuries and refrigerator damage. - Page 6 Circuit diagram Do not place containers with water or heavy stuffs on the refrigerator. Personal injuries may be caused by falling articles and electrical leakage or shock may be caused by out flowed water due to deterioration of insulation. Do not ground the refrigerator through gas pipes, water supply pipes, telephone lines or lightning conductors as electric shock or other dangers may be caused.
- Page 7 Refrigeration Schematic & Circuit Diagram Schematic diagram Check refrigerator settings when restarting the refrigerator after power failure or the power is shut off. Changes of settings may damage the articles stored. The refrigerator shall be reconnected after more than 5 minutes once it is shut off, to prevent damage to compressor or system.
-
Page 8: Precautions For Use
Haier after-sales service.Do not Make sure the temperature inside the refrigerator has reached the set value and put articles in the maintain and dismantle the refrigerator by yourself! refrigerator by batch. -
Page 9: Product Installation
It is recommended to replace Input voltage: no greater than ±10% of rated voltage. the battery earlier. Please contact a Haier after-sales service technician for battery replacement. Normal operation will be impossible for refrigerator if it is installed in environments other than those described above as it is sensitive to ambient temperature. - Page 10 Cleaning and Maintenance Preparation before use Component Cleaning 1. Remove the packaging materials and strings To avoid electric shock or staff injuries, please switch off power of the Remove all packaging materials and strings refrigerator before conducting any repairment or maintenance. for transport.
- Page 11 In case of power failure, a fully charged backup battery enables the alarm 5. Standing function to keep working for 48 hours. The initial operation requires the Do not switch on the power after the refrigerator is placed, leveled and cleaned. Switch on the refrigerator to run at least 2days in a row, while the backup battery needs to be power after it is put on standing for more than 24h, to ensure normal performance of refrigerator.
- Page 12 Alarming Display Initial Power-on Alarming Conditions Beeping Flashing Remarks Events Requirements It is displayed on the Observe the rules below for initial start-up and continuous operation: display board that the Remote alarm startup The failure code for short upper and lower sensor when“beeping cancelled”...
- Page 13 Alarm The refrigerator possesses the alarming, safety and self-diagnosis functions listed in the table below. This product shall be managed by specially-assigned person and checked for operating conditions every day with appropriate records. For too high or too low temperature in the Alarming Display Alarming Conditions...
-
Page 14: Component Names Control Panel
Note During setting process of 1P-5P, the parameters that need to be adjusted may be adjusted HYC-1378 selectively by “ Minus ” button or “ Plus ” button. For example, if the inside temperature display area currently shows 1P(Year) and there is need to adjust Year(1P) or Month(2P) but date(3P),... - Page 15 USB interface functions: As featured with USB output function, the computer board is capable of exporting such test data as HYC-1378 temperature within the recent 10 years via a U disk. After the U disk is plugged in ,the computer board begins to automatically recognize and import data to the U disk.
-
Page 16: Application Method
Application method Temperature Display Parameter adjustment Enter the setting mode by pressing the “Set” button 5s, and parameters are as follows: The refrigerator can automatically reach the temperature set before ex-factory. Temperature Display Default Light on Light off Parameter Description Minimum Value Maximum Value Step/Unit...
