Summary of Contents for Bernafon SoundGate 3
- Page 1 GUIDE FOR WIRELESS CONNECTIVITY SoundGate 3 SoundGate Mic TV Adapter 2 Phone Adapter 2 RC-N Remote Control...
- Page 2 Purpose In this guide, you will find detailed instructions for SoundGate 3 operation with a Bluetooth -enabled ® mobile telephone, SoundGate Mic, and accessories for television and landline telephone use. You will also find instructions for how to set up the demo version of the RC-N remote control.
- Page 3 GUIDE FOR WIRELESS CONNECTIVITY · One SoundGate Mic and the following accessory delivered within its original packaging – Power adapter · One TV Adapter 2 and the following accessories delivered within its original packaging – Power adapter – SCART adapter –...
- Page 4 Equipment Required for RC-N Operation Before you begin, ensure the RC-N remote control has two (2) AAAA batteries inserted and the following components are readily available for use: · One, or a pair of hearing aids that offer wireless connectivity ·...
- Page 5 Ensure the SoundGate 3 is fully charged and powered ON. Then follow the fitting software instructions to complete the pairing between the SoundGate 3 and the connected hearing aids. 1. Press the Volume Up key on the SoundGate 3 while holding it approximately 30 – 50 cm (1– 1½ feet) from the hearing aids 2.
- Page 6 ® · Press and hold the SoundGate 3 Power key for 5-6 seconds · The LED indication will begin flashing rapidly blue. This indicates that the SoundGate 3 is in pairing mode. Pairing mode will be active for two minutes.
- Page 7 3. When the other party answers the phone call, the conversation can begin 4. To end the phone call at any time, press the SoundGate 3 Phone key. The Phone key will no longer illuminate and the previous listening program will resume.
- Page 8 Using the SoundGate App A secure connection between the SoundGate 3 and mobile telephone must be established prior to Bluetooth streaming (see page 6). ® If an iPhone (SoundGate App supports iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, and iPhone 4) is used, the hearing aid volume, program, and more can alternatively be controlled via the SoundGate App.
- Page 9 GUIDE FOR WIRELESS CONNECTIVITY Using SoundGate 3 with the SoundGate Mic A secure connection between the SoundGate 3 and SoundGate Mic must be established. Follow the instructions below to prepare the devices for use. Setting Up the SoundGate Mic Ensure the SoundGate Mic is fully charged. To charge the microphone, connect the power adapter to the mini USB connector at the bottom of the microphone.
- Page 10 Pairing the SoundGate 3 and SoundGate Mic Ensure the SoundGate Mic is fully charged, and the SoundGate 3 battery is charged and powered ON. The power indicator on the SoundGate Mic and the status indicator on the SoundGate 3 should be illuminated green.
- Page 11 10 – 20 cm (4 – 8 inches). Streaming distance between the SoundGate Mic and SoundGate 3 is up to 15 m (49 feet). 1. Ensure SoundGate 3 is turned on by giving a 1 – 2 second press of the Power key. The SoundGate 3 LED indicator will illuminate green.
- Page 12 Using SoundGate 3 with the Phone Adapter 2 A secure connection between the SoundGate 3 and Phone Adapter 2 must be established. Follow the instructions below to prepare the devices for use. Setting Up the Phone Adapter 2 1. Ensure the Phone Adapter 2 is connected to 2.
- Page 13 Pairing the SoundGate 3 with the Phone Adapter 2 Ensure the Phone Adapter 2 is connected to a power outlet, and the SoundGate 3 battery is charged and powered ON. The status indicator on the Phone Adapter 2 and the SoundGate 3 should be illuminated green.
- Page 14 Make a Phone Call 1. Press the SoundGate 3 Phone key. The user will hear a dial tone in the hearing aids and the green light will illuminate in the SoundGate 3 Phone key. The Phone indicator on the Phone Adapter 2 will also illuminate green when streaming a call.
- Page 15 GUIDE FOR WIRELESS CONNECTIVITY Using SoundGate 3 with the TV Adapter 2 A secure connection between the SoundGate 3 and TV Adapter 2 must be established. Follow the instructions below to prepare the devices for use. Setting Up the TV Adapter 2 1.
- Page 16 Optional – A separate TOSLINK digital cable is included within the TV Adapter 2 packaging for use with home theater and surround sound systems. This cable can be used in place of the RCA cable only when you are using a TV and digital sound system which support TOSLINK cable inputs. 1.
- Page 17 Pairing the SoundGate 3 with the TV Adapter 2 Ensure the TV Adapter 2 is connected to a power outlet, and the SoundGate 3 battery is charged and powered ON. The status indicator on the TV Adapter 2 and the SoundGate 3 should be illuminated green.
- Page 18 SoundGate 3 TV key will illuminate steady orange when streaming is active. SelectMe 36.1 With SoundGate 3, you can use multiple TV Adapter 2 devices (e.g., one in the living room and one in the bedroom). SN2_ILLU_TelevisionKeyNoLight_HI To Switch Between Multiple TV Adapter 2 Devices 1.
- Page 19 GUIDE FOR WIRELESS CONNECTIVITY Preparing the RC-N Remote Control and Hearing Aids With the hearing aid(s) connected to the Oasis fitting software, choose Options and select Start Pairing in the area of the screen designated for SoundGate / Remote control. Ensure the RC-N remote control is fully charged and powered ON.
- Page 20 Our aim is to provide extra value to our partners every day. Bernafon representatives and employees in over 70 countries fulfi ll our vision to help people with impaired hearing communicate again without limitation.
