HIDE: Naming an input Hide removes it from the Input Select rotation (so you don't have to
cycle-through unused inputs). To return the input to the rotation use the Input Label
function to assign a different name to it.
RADIO: Whenever the IMS is turned OFF via the Accessory power wire (such as when the
vehicle's ignition is switched off while the IMS is ON), when the IMS is turned back ON it will
automatically default to whichever input is labeled Radio.
USING THE IMS WITH A CELLULAR PHONE
Since different Bluetooth-enabled cellphones operate differently, please read your cell-
phone's instructions manual before using your cellphone with the IMS.
B B l l u u e e t t o o o o t t h h P P a a i i r r i i n n g g
The exact connection procedure may vary somewhat among different Bluetooth-enabled
phones. When attempting to pair the IMS to a cellphone for the first time, be sure to follow
any screen prompts on Bluetooth-enabled phone.
1. Put the cellphone in pairing mode. Note: The Bluetooth pairing code for the IMS is 0–0–0–0.
2. Press the Select button on the IMS. The main menu will appear. (See Figure 10, on page 8.)
3. Use the Volume Knob to highlight BT Pairing and press the Select button. The IMS will
enter the pairing mode. The display will read IMS Pairing, and the word Pairing will flash.
see Figure 14.
BT
Pairing
F
1 4 : B
I G U R E
L U E T O O T H
4. Once pairing has been completed the screen will change to Pairing Complete
(see Figure 14). The Bluetooth Operation and Paired Bluetooth Phone icons will appear on
the normal operation screen (see Figure 9, on page 7).
P P l l a a c c i i n n g g V V o o i i c c e e - - D D i i a a l l e e d d C C a a l l l l s s
1. Press the Press-To-Talk button (see Figure 7, on page 7).
2. The IMS will automatically switch to Input 2 and you will hear your phone's voice-dial
prompts through the audio system.
3. Follow the prompts to complete dialing the call.
4. You will hear the other party's voice through the audio system's speakers and the IMS'
Hands-Free Microphone will pick-up your voice.
5. When the call is completed, press the Hang-Up/Skip Ahead button (see Figure 7, on page 7).
Pairing
Complete
P
S
A I R I N G
C R E E N S
kappa series
P P l l a a c c i i n n g g N N u u m m e e r r i i c c a a l l l l y y - - D D i i a a l l e e d d C C a a l l l l s s
1. Switch the IMS to Input 2.
2. Dial the call directly through your cellphone.
3. You will hear the other party's voice through the audio system's speakers and the IMS'
Hands-Free Microphone will pick-up your voice.
4. When the call is completed, press the Hang-Up/Skip Ahead button (see Figure 7, on page 7).
A A n n s s w w e e r r i i n n g g I I n n c c o o m m i i n n g g C C a a l l l l s s
1. When you receive a call the IMS will automatically switch to Input 2 and play a ring tone
through the audio system's speakers.
2. Press the Answer Call/Skip Back button (see Figure 7, on page 7).
3. You will hear the other party's voice through the audio system's speakers and the IMS'
Hands-Free Microphone will pick-up your voice.
4. When the call is completed, press the Hang-Up/Skip Ahead button (see Figure 7, on page 7).
C C o o n n t t r r o o l l l l i i n n g g C C e e l l l l p p h h o o n n e e M M u u s s i i c c P P l l a a y y F F u u n n c c t t i i o o n n s s
Since different cellphones operate differently, please read your cellphone's instruction
manual before using your cellphone's music play features with the IMS.
PLAY
<<
Skip Back
Skip Back
Play/Pause
Icon
Button
Icon
F
1 5 : C
I G U R E
E L L P H O N E
1. Place your cellphone in its music play mode.
2. Press the IMS' Play/Pause button to play and pause the currently-playing song. An icon
will appear on the LCD display (see Figure 15).
3. Press the IMS' Skip Ahead button to skip to the next song in the queue. An icon will appear
on the LCD display (see Figure 15).
4. Press the IMS' Skip Back button once to skip to the beginning of the currently-playing
song. Press the Skip Back button multiple times to skip to previous songs in the queue. An
icon will appear on the LCD display (see Figure 15).
Vol
-
>>
Select
Play/Pause
Skip Ahead
Skip Ahead
Button
Button
Icon
M
P
C
U S I C
L A Y
O N T R O L S
9
