AUDIO OUTPUTS

The IMS has stereo Front and Rear RCA-type output connectors, and a mono Sub RCA-type
output connector. All stereo sources appear at both the Front and Rear outputs, which are
controlled by the IMS' Balance and Fader controls (see Audio Adj, on page 8).
The Sub output connector is a pass-through for the Input 6 Woofer/Low input signal and
does not function for any other IMS input. The level of the Sub output is controlled by the
IMS' Volume Knob, and is balanced with the Front and Rear outputs by the Sub Level
control (see Sub Level, on page 8).
Connect the IMS' Front and Rear outputs to the system's front and rear amplifier inputs;
connect the IMS' Sub output to the system's subwoofer amplifier input. See Figure 6.
IMS
INPUT MANAGEMENT SYSTEM
WARRANTY VOID
USB
IMS OUTPUT
CHARGING
PORT
POWER
MIC INPUT
TO SUB
Junction Box
OUTPUT
Front
TO IMS
CONNECTION
TO IMS
CONNECTION
TO IMS
CONNECTION
F 6 : O
I G U R E
6
TO IMS OUTPUT
( )
IN PLACE OF AUDIO OUT CONNECTIONS
AUDIO OUT
L
R
SUB REAR FRONT
TO REAR TO FRONT
OUTPUTS OUTPUTS
4-Channel
Amp
Front
Speakers
Rear
Speakers
Subwoofer
Amp
Subwoofer
C
U T P U T O N N E C T I O N S
IMS OUTPUT
This RJ45 connector duplicates the signal found at the Audio Out connections (see above),
and can be used in place of the Audio Out RCA jacks when connecting the IMS to compati-
ble Infinity Reference Series amplifiers. Connection is made via standard CAT-5 cable with
RJ45 plugs. (See Figure 6.)
NOTE: W IMS O
HEN USING THE
+12V O
THE UT WIRING HARNESS WIRE
O
UTPUT CONNECTION INCLUDES AN AMPLIFIER TURN

USB CHARGING PORT

A standard USB connector that supplies charging voltage to compatible music players and
other components. See Figure 7. Use the USB charging cable included with the component.
IMS
INPUT MANAGEMENT SYSTEM
WARRANTY VOID
USB
IMS OUTPUT
CHARGING
PORT
POWER
MIC INPUT
F 7 : U S B C
I G U R E
NOTE: T USB C P
HE HARGING ORT ONLY SUPPLIES A CHARGING VOLTAGE
ENABLE ANY AUDIO OR CONTROL FUNCTIONS
UTPUT JACK IT IS NOT NECESSARY TO CONNECT
( F 5, 5),
SEE IGURE ON PAGE SINCE THE
- .
ON FUNCTION
AUDIO OUT
SUB REAR FRONT
USB Charging Port
P
H A R G I N G O R T
—
.
IMS
L
R
IT DOES NOT
