OPERATION

FRONT-PANEL CONTROLS
(see Figure 7)
R
LCD
Display
Power
Button
Answer Call/ Play/Pause
Skip Back Button
Button
F 7 : F - P
I G U R E R O N T A N E L
V K :Turn to raise and lower the IMS volume, and to highlight and adjust items
OLUME NOB
in menu screens.
NOTE: E
ACH TIME YOU SELECT A DIFFERENT INPUT THE VOLUME WILL CHANGE TO THE
LEVEL SETTING FROM THE PREVIOUS TIME THAT INPUT WAS ACTIVE
S B : During normal operation, press to enter the menu system. When menu
ELECT UTTON
screens are active, press to select items.
L S : The Light Sensor detects the amount of ambient light and automatically
IGHT ENSOR
sets the LCD Display for day or night viewing. See Figure 8.
Day
F 8 : L C D D
I G U R E I S P L A Y
+
Volume Knob
Vol
Select Button
-
Select
Light Sensor
Input 7 Jack
Hang-Up/ Voice Dial
Skip Ahead Button
Button
C C
O N T R O L S A N D O N N E C T I O N S
.
Night
D N V M
A Y A N D I G H T I E W I N G O D E S
kappa series
I 7 J : 3.5mm stereo jack that is is ideal for temporary input connections such as
NPUT ACK
game consoles and portable DVD players. See Figure 4, on page 4.
V D B : Activates voice-dialing when used with a VD-capable Bluetooth
OICE IAL UTTON
cell phone. See Using the IMS with a Cellular Phone, on page 9.
H -U /S A B
ANG P KIP HEAD UTTON
phone paired through Input 2 (see Using With A Cellular Phone, on page 9), pressing the
Hang-Up/Skip Ahead button disconnects the phone call.
When using the IMS to control a paired Bluetooth music player or cell phone's music play
functions, pressing the Hang-Up/Skip Ahead button skips ahead to the next music track.
P /P B : When using the IMS to control a Bluetooth music player or cell
LAY AUSE UTTON
phone's music play functions through Input 2, pressing the Play/Pause button pauses the
currently-playing track. Pressing the Play/Pause button again resumes play.
A C /S B B
NSWER ALL KIP ACK
through Input 2 (see Using With A Cellular Phone, on page 9), pressing the Answer Call/Skip
Back Button will answer an incoming phone call.
When using the IMS to control a paired Bluetooth music player or cell phone's music play
functions, pressing the Hang-Up/Skip Ahead button skips back to the beginning of the
current music track. Pressing the button multiple times skips to previous music tracks.
P B : Turns the IMS ON and OFF.
OWER UTTON
LCD D : Provides information about the IMS' operating status, and displays adjust-
ISPLAY
ment menus. During normal operation, the LCD display will look as shown in Figure 9:
Paired Bluetooth
Phone Icon
Bluetooth
Operation Icon

MP3 Player

F 9 : N
I G U R E O R M A L
: When making a telephone call on a Bluetooth cell
: When using a Bluetooth cell phone paired
UTTON
Paired Bluetooth
Music Player Icon
Input
Name
Active Input
Connector
In 3
Volume
Indicator
O D S
P E R A T I O N I S P L A Y C R E E N
7
