Summary of Contents for Zte WF824
- Page 1 WF824 Let’s go Getting started with your device. ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Confidential and Proprietary Information of ZTE CORPORATION 1...
- Page 2 ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No.
-
Page 3: Getting To Know Your Device
1st Green LED: -123dBm <= RSRP < -118dBm RF Signal Strength 2nd Green LED: -118dBm <= RSRP < -114dBm (4LEDs) 3rd Green LED: -114dBm <= RSRP < -105dBm 4th Green LED: -105dBm <= RSRP Confidential and Proprietary Information of ZTE CORPORATION... - Page 4 CPE slightly to find the best signal direction. The CPE radio signal strength level can be observed from the RF LEDs mounted on the lower panel as shown below. The more LEDs on, the better the signal strength. Confidential and Proprietary Information of ZTE CORPORATION...
- Page 5 WF824 Getting Started Installing Outdoor Unit Mounting Bracket: Header Connection: Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 6: Connecting To Your Device
WF824 Getting Started Connecting to Your Device WF824 is a user-friendly wireless access terminal, and very easy to configure and setup. Subscribers can just connect the device to their computer or home switch/router and the device is ready to provide Internet Services. - Page 7 The LAN setting allows user to specify the DHCP server setting for the LAN devices, including the pool address, IP and MAC binging, and whether DHCP server should be enabled. User is advised to leave the default setting unchanged for quick configuration and smooth device operation. UPnP Setting Confidential and Proprietary Information of ZTE CORPORATION...
- Page 8 Once the upgraded is complete, the factory setting will be restored to the CPE device. User may need to reconfigure the device in order to get the device operational. Device Reset In case the user forgets the login password, user can also contact the operator. Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 9: Warning And Notice
Handle your device carefully. Do not drop, bend or strike it. Otherwise your device will be damaged. • No dismantling by non-professionals and only qualified technicians can undertake repair work. • Operating temperature range of -40 ~ +60 and humidity range of 5% ~ 95% are recommended. • Confidential and Proprietary Information of ZTE CORPORATION... -
Page 10: Limited Warranty
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages • resulting from or arising out of or in connection with using of this product, whether or not ZTE had been advised, knew or should have known of the possibility of such damages, including, but not limited to lost profits, interruption of business, cost of capital, cost of substitute facilities or product, or any downtime cost. -
Page 11: Federal Communication Commission Interference Statement
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Confidential and Proprietary Information of ZTE CORPORATION... -
Page 12: Radiation Exposure Statement
& your body. For more assistance, please: Send E-mail to mobile@zte.com.cn • Visit http://www.ztedevice.com • Call Service Hotline: +86–755–26779999（May generate long distance call charges） • US Customer Support: +1–877–387-6771 • Confidential and Proprietary Information of ZTE CORPORATION...
