Page 3
In this Guide This SonicWall™ NSA 2650 Getting Started Guide provides instructions for basic installation and configuration of SonicWall NSA 2650 appliance. Topics: • Overview on page 3 • Contents on page 4 • Getting Started Task Overview on page 7 Overview The SonicWall NSA 2650 appliance represents the continuing evolution of SonicWall’s vision for a deeper level of network security without a performance penalty. The NSA 2650 addresses the growing trends in web encryption and mobility by delivering a solution that meets the need for high‐speed threat prevention. The NSA 2650 appliance features the following: • Increased port density to accommodate customer deployment needs • increased processor speeds and counts for fast deep packet inspection performance SonicWall NSA 2650 Getting Started Guide...
Page 4
• Enhanced processor architecture that aids Stateful and Deep Packet inspections • Increased connections • Pre‐populated, upgradeable storage module • Redundant power supplies • Added expansion module slot for future capabilities For more product information, visit https://www.sonicwall.com. Contents Chapter 1 Sections included: In this Guide on page 3 • Overview on page 3 • Contents on page 4 • Getting Started Task Overview on page 7 Chapter 2 Sections included: Hardware Overview on page 9 • NSA 2650 Package Contents on page 9 • NSA 2650 Front Panel on page 12 • NSA 2650 Back Panel on page 13 SonicWall NSA 2650 Getting Started Guide...
Page 5
Chapter 3 Sections included: Initial Setup on page 15 • Determining the WAN Type on page 16 • System Requirements on page 17 • Recording Configuration Information on page 17 • Initial Configuration on page 19 • Connecting to the Internet on page 26 • Troubleshooting Connections on page 29 Chapter 4 Sections included: Registering, Licensing, and Upgrading on • Using MySonicWall on page 32 page 31 • Creating a MySonicWall Account on page 32 • Registration Overview on page 33 • Registering in SonicOS on page 33 • Alternative Registration Options on page 33 • Licensing Security Services on page 35 • Activating Licenses Using a Key on page 36 • Upgrading Firmware on page 37 SonicWall NSA 2650 Getting Started Guide...
Page 6
Chapter 5 Sections included: Support and Training Options on page 43 • Customer Support on page 44 • Knowledge Base on page 44 • Training on page 44 • Related Documentation on page 44 • Additionally Supported Languages on page 45 Chapter 6 Sections included: Safety Instructions on page 48 • Safety Instructions on page 48 • Sicherheitsanweisungen on page 50 安全說明 on page 52 • • Declaration of Conformity on page 54 • Warranty Information on page 54 台灣 RoHS/ 限用物質含有情況標示資訊 on page 55 • For general support information, see SonicWall Support on page 57. SonicWall NSA 2650 Getting Started Guide...
Page 7
Getting Started Task Overview The following flow chart illustrates the necessary steps for getting started with your new SonicWall NSA appliance. Configuration Verify Start Up Perform Initial Pre-Configuration Management Setup Requirements Computer Registration, Licensing, and Deployment Create a Register Complete MySonicWall Appliance in Deployment Account SonicOS Configuration SonicWall NSA 2650 Getting Started Guide...
Page 8
SonicWall NSA 2650 Getting Started Guide...
Page 9
Hardware Overview This section describes the items shipped with the NSA 2650 appliance and provides front and rear illustrations of it. • NSA 2650 Package Contents on page 9 • NSA 2650 Front Panel on page 12 • NSA 2650 Back Panel on page 13 NSA 2650 Package Contents Before you begin the setup process, verify that your package contains the following items: 1 One SonicWall NSA 2650 appliance 2 One SonicWall NSA 2650 Getting Started Guide 3 One serial console cable 4 One Ethernet cable SonicWall NSA 2650 Getting Started Guide...
Page 10
5 One power cord* 6 Two rack mount ears with six screws 7 One Safety, Environmental, and Regulatory Information document *The included power cord is approved for use only in specific countries or regions. Before using a power cord, verify that it is rated and approved for use in your location. The power cord is for AC mains installation only. See Installation Requirements on page 48 for more information. If any items are missing from your package, contact SonicWall Support at: https://www.sonicwall.com/en‐us/support/contact‐ support. SonicWall NSA 2650 Getting Started Guide...
Page 12
NSA 2650 Front Panel SafeMode Button CONSOLE Port 2.5/1GE 2.5/1GE CONSOLE NSA 2650 NSA 2650 MGMT MGMT Ports Port System Status LEDs 2.5/1 Gigabit Ethernet SFP Ports 2.5/1 Gigabit Ethernet Ports 1 Gigabit Ethernet Ports POWER Button SonicWall NSA 2650 Getting Started Guide...
Page 13
NSA 2650 Back Panel Expansion Module Storage Module Slot for Power Supply Fans Redundant Power Supply SonicWall NSA 2650 Getting Started Guide...
Page 14
SonicWall NSA 2650 Getting Started Guide...
Page 15
Initial Setup This section provides an overview of available WAN types, a section to record configuration information, and initial setup information and procedures. • Determining the WAN Type on page 16 • System Requirements on page 17 • Recording Configuration Information on page 17 • Initial Configuration on page 19 • Connecting to the Internet on page 26 • Troubleshooting Connections on page 29 SonicWall NSA 2650 Getting Started Guide...
Page 16
Determining the WAN Type • Wire Mode (2‐Port Wire)—Inserts the appliance into the network using two paired interfaces. Available Wire Mode types include Bypass, Inspect, and Secure. Bypass mode Before configuring your SonicWall NSA appliance, you need to allows for quick and non‐disruptive insertion into the data determine the type of WAN connection that your setup uses. path. Inspect mode extends Bypass mode with traffic SonicWall supports the following types: inspection for classification and flow reporting. Secure • Static—Configures the appliance for a network that uses mode provides full SonicWall ReAssembly‐Free Deep static IP addresses. Packet Inspection™ (RF‐DPI) and control of network traffic. • DHCP—Configures the appliance to request IP settings Secure Mode also affords the same level of visibility and from a DHCP server on the Internet. enforcement as conventional NAT or L2 Bridged Mode deployments, but without any L3/L4 transformations, and • PPPoE—Point‐to‐Point Protocol over Ethernet (PPPoE) is with no alterations of ARP or routing behavior. If Wire typically used with a DSL modem. If your ISP requires Mode is not available in the Setup Wizard, you can desktop software with a username and password, select configure it later in the SonicOS management interface. NAT with PPPoE mode. NOTE: When operating in Wire Mode, the firewall’s • PPTP—Point‐to‐Point Tunneling Protocol (PPTP) is used to MGMT interface is used for local management. To connect to a remote server. PPTP typically supports older enable remote management and dynamic security Microsoft Windows implementations that require services and application intelligence updates, a WAN tunneling connectivity. interface (separate from the Wire Mode interfaces) ...
Page 17
System Requirements Recording Configuration Information Before beginning the setup process, verify that you have: • An Internet connection Use this section to record your configuration information. Be sure to keep it for future reference. • A Web browser supporting Java Script and HTTP uploads NOTE: The default MGMT interface IP address is Supported Browsers 192.168.1.254. Accepted Browser Browser Version Number Internet Explorer 10.0 and higher or IE Edge Registration Information Chrome 45.0 and higher Serial Number: Record the serial number found on the sticker on the top panel of Firefox 25.0 and higher your SonicWall NSA appliance. Authentication Code: Record the authentication code Safari 10.0 and higher found on the sticker on the top panel of your SonicWall NSA appliance. SonicWall NSA 2650 Getting Started Guide...
Page 18
Networking Information Administrator Information LAN IP Address: Select a static IP address for your Admin Name: Select an administrator account SonicWall NSA appliance that is within name. (default is admin) the range of your local network. (default Admin Password: Select an administrator password. for X0 is 192.168.168.168) (default is password) Subnet Mask: Record the subnet mask for the local network (default mask is 255.255.255.0). Internet Service Provider (ISP) Client devices connecting through the appliance LAN interface are assigned IP Information addresses in this network (default client addresses assigned by the SonicOS DHCP Record the following information about your current Internet server are on the 192.168.168.0/24 service: subnet). WAN IP Address: Select a static IP address for your If you are No information is usually required. However, Ethernet WAN interface (X1). This setting connecting some providers may require a host name. only applies if you are using an Internet with DHCP Host Name: Service Provider (ISP) that assigns a static If you are IP Address: _____._____._____._____ IP address.
Page 19
Initial Configuration The diagram below illustrates how to connect your management computer to the SonicWall NSA appliance. SonicWall Appliance 2.5/1GE 2.5/1GE CONSOLE NSA 2650 NSA 2650 120V AC (U.S.) MGMT M M GMT MGMT Management Computer SonicWall NSA 2650 Getting Started Guide...
Page 20
Applying Power to the NSA The following sections provide initial configuration information and instructions for connecting your SonicWall NSA appliance for initial setup: Connect the AC power cord from the SonicWall NSA appliance into an appropriate power outlet. • Connecting to the MGMT Port on page 20 For further information regarding power requirements, refer • Applying Power to the NSA on page 20 to Installation Requirements on page 48 of this document. • SonicWall NSA LED Activity on page 20 • Using the Setup Wizard on page 23 SonicWall NSA LED Activity The system LEDs provide essential status information about Connecting to the MGMT Port the NSA 2650. The MGMT port is a dedicated 1 gigabit Ethernet interface for LED/Color Description appliance management and SafeMode access. Power 1 and Power 2 1 Using the provided Ethernet cable, connect one end of Blue Respective power supply is on and the cable to the computer you are using to manage the operating properly. SonicWall NSA appliance. Yellow Respective power supply is bad, not 2 Connect the other end of the Ethernet cable to the connected to an AC source, or switched MGMT port on your SonicWall NSA appliance. off. NOTE: There may be a 10‐20 second delay ...
Page 21
Respective power supply is not detected Blinking or Major or critical system alarm (thermal, in the chassis. If both power supply LEDs solid red fan, etc) are off, the system is not powered on. Module 0/Module 1 NOTE: When the optional power supply is Module is not detected in respective slot. not installed, it might take 1 to 2 minutes Solid green Module is present in the slot and until the system detects the absence of operational. the optional power supply. The LED may appear yellow at first, but will turn off Solid yellow Module warning. once booting is finished. Test/Wrench System booted and is operational. Solid Yellow System booting is in progress. Slow blinking System is in SafeMode. yellow Rapid System is shutting down. blinking CAUTION: Do not remove power during yellow the shutdown process. You risk damaging your appliance. Alarm No alarms present. Blinking or Minor system alarm. solid yellow SonicWall NSA 2650 Getting Started Guide...
Page 22
The ethernet ports have LEDs that provide status of the port, including link status and activity. LED Type Color Description MGMT port Speed/link Green/amber Solid green: linked at 100Mbps Solid amber: linked at 1Gbps Off: no link or 10Mbps Activity Yellow Blinking: traffic is present 1 GE Copper Port Speed/link Green/amber Solid green: linked at 100Mbps Solid amber: linked at 1Gbps Off: no link or 10Mbps Activity Yellow Blinking: traffic is present 2.5 GE Copper Ports Speed/link Green/amber Solid green: linked at 1Gbps Solid amber: linked at 2.5Gbps Off: no link or 100Mbps Activity Yellow Blinking: traffic is present SonicWall NSA 2650 Getting Started Guide...
Page 23
LED Type Color Description 2.51/1GE SFP Ports Speed/link Green/amber Solid green: linked at 1Gbps/100Mbps Solid amber: linked at 2.5Gbps Off: no link Activity Yellow Blinking: traffic is present Using the Setup Wizard When you are ready to begin initial setup, configure your management computer with a static IP address on the 192.168.1.0/24 subnet, such as 192.168.1.20. This allows your computer to connect to SonicOS via the MGMT interface. NOTE: Be sure to disable pop‐up blocking software, or set your web browser to allow pop‐ups and cookies. To configure initial settings using the Setup Wizard: 1 With your computer connected to the appliance MGMT port, start your web browser and navigate to the default MGMT interface IP address: http://192.168.1.254 The initial screen displays the options to launch the Setup Wizard or configure the appliance manually. SonicWall NSA 2650 Getting Started Guide...
Page 24
2 Launch the SonicOS setup wizard by selecting the first 3 Click Next. link, To launch the SonicWall Setup Guide, click here. 4 Follow the on‐screen prompts to configure the admin This wizard helps you quickly configure the SonicWall password and network settings. appliance to secure your Internet connection. 5 Click Next. SonicWall NSA 2650 Getting Started Guide...
Page 25
6 Configure the IP address. 8 Select EXIT GUIDE. The firewall reboots and asks that you be patient as your are being redirected to the login If a DHCP server is available on the network, the wizard banner. requests IP settings from it. You can click Next to accept these or manually enter a static IP address and other 9 Log in with the username and password that you set up network settings and then click Next. in Step 4. The default view after login is the Dashboard on the MONITOR view. In the Manual Configuration screen, click Retry to revert to DHCP. 10 Log out and a summary of your environment is displayed, noting that setup is complete. 7 Once configuration is complete, confirm whether you want to enable Automatic secure crash analysis 11 If the data is correct, click APPLY to apply the settings; reporting and Periodic secure diagnostic reporting for otherwise you can select BACK to make corrections. support purposes. 12 Click CLOSE on the final window after reviewing the reminder to register your firewall. SonicWall NSA 2650 Getting Started Guide...
Page 26
Connecting to the Internet After initial setup is complete, physically connect the SonicWall NSA LAN and WAN interfaces to the appropriate network devices in your environment to provide access to external networks or the Internet. NOTE: Internet connectivity is needed for the recommended product registration process. For initial Internet access, connect your computer to the NSA X0 interface or to the LAN subnet. You cannot reach the Internet or other external destinations while connected to the MGMT interface without first configuring a default gateway in its interface settings. The Internet Access diagram illustrates how to connect your computer to the SonicWall NSA appliance for Internet access. Topics: • Connecting the LAN Port on page 28 • Connecting the WAN Port on page 28 • Testing Your Internet Connection on page 28 SonicWall NSA 2650 Getting Started Guide...
Page 27
Internet Access SonicWall Appliance 2.5/1GE 2.5/1GE CONSOLE NSA 2650 NSA 2650 120V AC (U.S.) MGMT X0 (LAN) X1 (WAN) Ethernet Internet SonicWall NSA 2650 Getting Started Guide...
Page 28
1 After you exit the Setup Guide, connect your computer to the LAN subnet or directly to the X0 (LAN) port. 2 Connect the other end of the Ethernet cable to the X0 (LAN) port on your SonicWall NSA appliance. 2 Point your browser to the X0 IP address configured during initial setup (default: 192.168.168.168). Connecting the WAN Port 3 When the login page appears, log into the SonicOS management interface with the administrator account 1 Connect one end of an Ethernet cable to your Internet (default: admin), using the configured password connection. (default: password). If you have a router, DSL modem, or cable modem, 4 Open a command prompt window on your computer connect the Ethernet cable to a LAN port on the router and enter the command: ping sonicwall.com. or modem. If configured correctly, you receive a reply from the ping 2 Connect the other end of the Ethernet cable to the X1 request. (WAN) port on your SonicWall NSA appliance. 5 Open another web browser window and navigate to: https://www.sonicwall.com NOTE: If X1 is configured in Wire Mode, configure a different interface with one of the other WAN types for If you can view the SonicWall home page, you have use in this step. configured your SonicWall NSA appliance correctly. SonicWall NSA 2650 Getting Started Guide...
Page 29
• Verify that the Local Area Connection settings on your Use the suggestions in this section to troubleshoot your MGMT computer are set to use either DHCP or a static IP on and LAN connections. the LAN subnet. • Verify that the WAN interface being used for Internet Troubleshooting Your MGMT connectivity is not configured in Wire Mode or Tap Mode. Connection • Renew your computer’s DHCP address or restart your computer to accept new network settings from the If you cannot connect to the SonicWall NSA appliance or the DHCP server in the SonicWall appliance. Setup Guide does not display, consider the following: • Restart your Internet router to communicate with the • Did you correctly enter the SonicWall NSA management IP DHCP client in the SonicWall appliance. address beginning with “http://” or “https://” in your web browser? Troubleshooting Connections on page 29 provides more suggestions. • Did you try restarting your management station while it is connected to the SonicWall appliance? NOTE: WAN connectivity issues are unrelated to • Are the Local Area Connection settings on your computer completion of the MySonicWall registration process. set to a static IP address on the 192.168.1.0/24 subnet? • Is the Ethernet cable connected to your computer and to the MGMT port on your appliance? • Is the connector clip on your network cable properly seated in the port of the security appliance?
Page 30
Troubleshooting Your LAN Connection If you do not see the SonicOS login prompt when you point your browser to the X0 (LAN) IP address, consider the following: • Did you correctly enter the IP address for the SonicWall NSA X0 interface into your web browser, beginning with “http://” or “https://”? • Did you try restarting your management station while it is connected to the SonicWall appliance? • Are the Local Area Connection settings on your computer set to one of the following: • Obtain an IP address automatically using DHCP • A static IP address on the default LAN subnet (192.168.168.0/24) • A static IP address on the configured LAN subnet, if you changed it during initial setup • Is the Ethernet cable connected to your computer and to the X0 (LAN) port on your appliance? • Is the connector clip on your network cable properly seated in the port of the security appliance? SonicWall NSA 2650 Getting Started Guide...
Page 31
Registering, Licensing, and Upgrading This section provides instructions for registering on MySonicWall, licensing security services, and upgrading firmware on your SonicWall NSA appliance. • Using MySonicWall on page 32 • Creating a MySonicWall Account on page 32 • Registration Overview on page 33 • Registering in SonicOS on page 33 • Alternative Registration Options on page 33 • Licensing Security Services on page 35 • Activating Licenses Using a Key on page 36 • Upgrading Firmware on page 37 Registration is an important part of the setup process and is necessary in order to receive the benefits of SonicWall security services, firmware updates, and technical support. SonicWall NSA 2650 Getting Started Guide...
Page 32
Using MySonicWall To create a MySonicWall account: 1 In your Web browser, navigate to: SonicWall requires a MySonicWall account prior to configuring https://www.mysonicwall.com your appliance. If you already have a MySonicWall account, 2 In the login screen, click the Register Now link. you can continue to Registration Overview on page 33. MySonicWall is used during registration of your SonicWall appliance and to activate or purchase licenses for security services, support, or software specific to your SonicWall device. For a High Availability configuration, MySonicWall provides a way to associate a secondary unit that can share security service licenses with your primary appliance. NOTE: MySonicWall registration information is not sold or shared with any other company. Creating a MySonicWall Account 3 Complete the Registration form, and then click Register. 4 Verify that the information is correct, and then click Follow these procedures to set up a MySonicWall account, if Submit. you don’t already have one. 5 To confirm your account was created, click Continue. SonicWall NSA 2650 Getting Started Guide...
Page 33
5 Acknowledge the registration completion notification by clicking Continue. This section describes how to register and license your appliance through SonicOS, as well as describing the alternate On the MANAGE view under Updates, the Licenses options available on MySonicWall. page now shows your appliance as Licensed. NOTE: If you haven’t created a MySonicWall account, see Creating a MySonicWall Account on page 32. Alternative Registration Options Registering in SonicOS If you have already registered your SonicWall appliance through the SonicOS interface, you can continue to Licensing Security Services on page 35. After you have completed the Setup Guide and can successfully connect to your SonicWall NSA appliance, you are Although SonicWall strongly recommends registering your ready to register the security appliance. appliance using the SonicOS interface, you can optionally use MySonicWall to register your appliance. 1 Log into your SonicWall appliance using the administrator account. Registering on MySonicWall 2 Click the Register link. 3 Enter your MySonicWall username (your email address) and password in the appropriate fields. To register your appliance directly on MySonicWall: 4 Click Submit. 1 Log into your MySonicWall account. If you do not have an account, create one at as described in Creating a SonicWall NSA 2650 Getting Started Guide...
Page 34
MySonicWall Account on page 32. Type the SonicWall 2 Select Updates / Licenses page. appliance serial number in the Register a Product field. 3 In the Manage Security Services Online section, click To find the serial number: the SYNCHRONIZE button to synchronize licenses with a Go to the MONITOR view. MySonicWall. b Under Current Status, select System Status. Using the License Keyset c Look in the System Information section of the page to find the serial number. MySonicWall provides an encrypted license keyset for each 2 Click Next. registered appliance. You can use the license keyset to manually apply all active licenses to your SonicWall appliance. 3 Type a Friendly Name for the appliance. 4 Select the Product Group from the drop‐down list, if To obtain and apply the license keyset: available. 1 Log into your MySonicWall account and click the link for 5 Enter the appliance Authentication Code. The your appliance. authentication code is displayed in the System Status 2 On the Services Management page, click the View page and is also on the bottom panel of your appliance. License Keyset link. 6 Click Register.
Page 35
1 To access the Service Management page, do one of the following: Applicable Services and Software • Log into your appliance, navigate to Manage / Updates / Licenses, select the link in Step 2 in On the Service Management page in MySonicWall, the Manage Security Online Services. , and then Applicable Services section lists the services available for your enter your MySonicWall credentials. product. • Point your browser to https:// The Status column indicates whether the service is Licensed, www.mysonicwall.com and enter your Not Licensed, or Expired. The Action column lets you purchase MySonicWall credentials, navigate to My or activate additional services. Products / Product Management and select your appliance name or serial number. The following products and services are available for your SonicWall NSA appliance: 2 Next, scroll down to the Applicable Services section to select a free trial or purchase the service: • Cloud Services • Free Trial of Service—Click the Try icon in the • Cloud GMS Management and Reporting Action column for the security service you wish • Cloud GMS Management to try for a 30‐day free trial. The free trial immediately activates and notifies you of the • Cloud GMS Basic Management trial expiration date. The Service Management SonicWall NSA 2650 Getting Started Guide...
Page 36
• Software and Firmware Updates • Capture Advanced Threat Protection • Hardware Warranty • External IDS Support • Consulting Services • Deep Packet Inspection for SSH (DPI‐SSH) • Remote Implementation Services • Comprehensive Anti‐Spam Service (CASS) NOTE: Applicable services per platform sometimes change. Please check MySonicWall for the current list of • Deep Packet Inspection for SSL (DPI‐SSL) services available for your appliance. • Application Visualization and Control • Desktop & Server Software: Activating Licenses Using a Key • Kaspersky, McAfee: Enforced Client Anti‐Virus and Anti‐ Spyware If you registered your appliance through SonicOS, all licensed • Global VPN Client services are already activated. You can continue to Upgrading Firmware on page 37. • WAN Acceleration Software If you purchased a service subscription or upgrade from a sales • Content Filtering Client representative separately, you received an Activation Key for SonicWall NSA 2650 Getting Started Guide...
Page 37
Upgrading Firmware the service. This key is emailed to you after online purchases, or is on the front of the certificate that was included with your purchase. SonicWall recommends that you run the latest available firmware on your security appliance. You need to upgrade the To activate your service licenses using the key: factory‐installed firmware to the latest version available on MySonicWall. 1 Log into your MySonicWall account. See the following sections to upgrade an existing SonicOS 2 In the My Products/ Products Management page, click firmware image to a newer version: the appliance name to open the Service Management page. • Saving a Backup and Exporting Settings on page 37 The Applicable Services table displays a list of services • Obtaining the Latest Firmware on page 38 that are already licensed or are available to license on • Upgrading the Firmware on page 38 your SonicWall appliance. Your initial purchase may have included security services or other software • Using SafeMode to Upgrade Firmware on page 39 bundled with the appliance. These licenses are enabled on MySonicWall when the appliance is delivered to you. Saving a Backup and Exporting 3 Locate the service in the Applicable Services section Settings and click the key icon. 4 Type or paste your key into the Activation Key field, and Before beginning the update process, make a system backup then click Submit. ...
Page 38
You can also export the configuration settings (preferences) to 6 In the popup window, click Export. The file is exported to your Downloads folder. a file on your local management station. This file serves as an external backup of the configuration settings, and can be imported back into the SonicWall security appliance if it is Obtaining the Latest Firmware necessary to reboot the firmware with factory default settings. To save a system backup on your appliance and export To obtain a new SonicOS firmware image file: configuration settings: 1 In a browser on your management computer, log into 1 Navigate to the MANAGE view and select Updates / your MySonicWall account at: Firmware & Backups. https://www.mysonicwall.com. 2 Under the Firmware Management section, click Create 2 In MySonicWall, click Downloads in the left navigation Backup / Local Backup. pane to display the Download Center screen. 3 Confirm whether you want to proceed. 3 In the Software Type field, select NSA 2650 Firmware. 4 Monitor the status of the command in the bottom left‐ 4 Locate the firmware version you want, and click the link hand corner. to download it to a location on your computer. You can download the Release Notes and other associated files SonicOS takes a snapshot of your current system state, in the same way. firmware, and configuration settings, and makes it the new System Backup firmware image. Creating a new ...
Page 39
To upload new firmware to your SonicWall appliance • Boot uploaded firmware with Factory Default Configuration and reboot with current configuration settings: Deletes any custom configurations and uploads 1 Download the SonicOS firmware image file from the new firmware with the original factory MySonicWall and save it to a convenient location on defaults. your local computer. 8 In the confirmation dialog box, click OK. The appliance 2 Point your browser to the appliance IP address and log restarts and then displays the login page. in as an administrator. 9 Enter your user name and password. The new SonicOS 3 Select the MANAGE view. image version information is displayed on the Monitor 4 Under Updates, select Firmware & Backups. / Current Status / System Status page. 5 From the options across the top of the page, click Upload Firmware. Using SafeMode to Upgrade Firmware 6 Browse to the location where you saved the SonicOS firmware image file, select the file and click the Upload If you are unable to connect to the SonicOS management button. interface, you can restart the security appliance in SafeMode. The SafeMode feature allows you to recover quickly from After the firmware finishes uploading, it is displayed in uncertain configuration states with a simplified management the table.
Page 40
To use SafeMode to upgrade firmware on a SonicWall • Uploaded Firmware with Factory Default Settings ‐ New! security appliance: Use this option to restart the appliance with 1 Connect your computer to the MGMT port on the factory default configuration settings. appliance and configure your computer with an IP address on the 192.168.1.0/24 subnet, such as 6 In the confirmation dialog box, click OK to proceed. 192.168.1.20. CAUTION: Do not power off the appliance while it is 2 Use a narrow, straight object, like a straightened paper rebooting, or you may damage your appliance. clip or a toothpick, to press and hold the SafeMode button for more than 20 seconds (possibly in the range After successfully booting the firmware, the login of 90 seconds). screen displays. The Test light begins blinking when the appliance has After a factory reset, you see the initial login screen, rebooted into SafeMode. which displays options to launch the Setup Wizard or to log into SonicOS and configure the appliance manually. 3 Point your browser to http://192.168.1.254 to access If you choose the latter, enter the default user name the SafeMode management interface. and password (admin / password) to access the NOTE: Use http rather than https in SafeMode. SonicOS management interface. 7 Continue to manage the appliance from the MGMT 4 Click Upload New Firmware, and then browse to the interface at 192.168.1.254.
Page 41
Connect the computer to your network or to the desired interface on the appliance. d Point your browser to the WAN or LAN IP address of the appliance. SonicWall NSA 2650 Getting Started Guide...
Page 42
SonicWall NSA 2650 Getting Started Guide...
Page 43
Support and Training Options This section provides overviews of customer support and training options for your SonicWall NSA appliance. SonicWall offers a variety of online support and training options for your convenience. • Customer Support on page 44 • Knowledge Base on page 44 • Training on page 44 • Related Documentation on page 44 • Additionally Supported Languages on page 45 SonicWall NSA 2650 Getting Started Guide...
Page 44
Customer Support Training SonicWall offers telephone, email and web‐based support to SonicWall offers an extensive sales and technical training customers who have a valid warranty or support contract. curriculum. SonicWall Training provides E‐Training, instructor‐ led training, custom training, technical certifications, and uses Designed for business‐critical environments, SonicWall 24x7 authorized training partners. Support is an around‐the‐clock support service that includes phone, email and web‐based technical support, ongoing For more information, visit: https://www.sonicwall.com/ software and firmware updates, direct access to a team of support/sonicwall‐training‐certification. highly trained senior support engineers, advance exchange hardware replacement in the event of failure, and access to Related Documentation electronic support tools. For more information, visit: https://www.sonicwall.com/ SonicWall technical documentation is available for download. support. Release Notes are available on MySonicWall and the following documents are available on the Support portal at https:// www.sonicwall.com/support/technical‐documentation Knowledge Base • SonicOS Administration Guides The SonicWall Knowledge Base allows you to search by queries • SonicOS Upgrade Guides containing unique keywords, symptoms or details, filter results, view, rate, email and print articles. • SonicOS Configuration Guides For more information, visit: https://www.sonicwall.com/ • SonicOS Deployment Guides support/knowledge‐base. • SonicOS Reference Guides...
Page 46
펌웨어 및 문서 한글화 안내 Notificação de Firmware e Documentação Localizada SonicWall Getting Started 가이드 , Quick Start 가이드 , 사용 자 가이드 , 어플라이언스 펌웨어 및 다양한 엔드유져 클라 As Guias de noções básicas, Guias de início rápido, Guias de 이언트가 다국어를 지원합니다 . 다음에서 사용 가능한 한 Usuário, firmware de aplicações, e varios clientes de usuário 국어 문서를 찾아 보세요 . final de SonicWall estão agora disponíveis em varias línguas. Pode encontrar a documentação disponível em Português em Getting Started 가이드 또는 Quick Start 가이드에 있는 절차 https://www.sonicwall.com/en‐br/support/technical‐ 에 따라 https://www.mysonicwall.com 에서 제품 등록을 하 documentation. 세요 . 제품 등록 후 , MySonicWall 에서 적용 가능한 한국어 Siga as instruções da Guia de noções básicas ou Guia de início 펌웨어 또는 사용자 클라이언트 소프트웨어를 확인할 수 rápido para registrar seu produto em MySonicWall no 있습니다 . 새로운 버젼은 사용 가능할 때 등록됩니다 . 그 https://www.mysonicwall.com. Depois de registrar o produto, 러므로 , 추가되는 한국어 펌웨어 , 소프트웨어와 문서가 있 você pode procurar firmaware ou clientes de usuário final 는지 주기적으로 체크하세요 . aplicáveis em MySonicWall. Novos lançamentos são publicados tão pronto estejam disponíveis, assim que por favor visite periodicamente esta página para ver firmware, software ...
Page 47
Product Safety and Regulatory Information This section provides product safety, regulatory, and warranty information. • Safety Instructions on page 48 • Sicherheitsanweisungen on page 50 安全說明 on page 52 • • Declaration of Conformity on page 54 • Warranty Information on page 54 台灣 RoHS/ 限用物質含有情況標示資訊 on page 55 • Regulatory Model/Type Product Name 1RK38‐0C8 NSA 2650 SonicWall NSA 2650 Getting Started Guide...
Page 48
6 Mount in a location away from direct sunlight and • Lithium Battery Warning on page 49 sources of heat. A maximum ambient temperature of • Cable Connections on page 49 104º F (40º C) is recommended. 7 If installed in a closed or multi‐rack assembly, the Installation Requirements operating ambient temperature of the rack environment may be greater than the room ambient. Therefore, consideration should be given to installing WARNING: the equipment in an environment compatible with the The following conditions are required for proper installation: maximum recommended ambient temperature. 1 The SonicWall appliance is designed to be mounted in a 8 Mount the SonicWall appliances evenly in the rack in standard 19‐inch rack mount cabinet. order to prevent a hazardous condition caused by uneven mechanical loading. 2 Use the mounting hardware recommended by the rack manufacturer and ensure that the rack is adequate for 9 Four mounting screws, compatible with the rack design, the application. must be used and hand‐tightened to ensure secure installation. Choose a mounting location where all four 3 Ensure that no water or excessive moisture can enter mounting holes line up with those of the mounting bars the unit. of the 19‐inch rack mount cabinet. 4 Allow unrestricted airflow around the unit and through ...
Page 49
• Always disconnect the power cords from the be maintained. Particular attention must be given to power supplies when installing or removing the power supply connections other than direct power supply. Never install or remove a power connections to the branch circuits, such as power strips. supply with the AC power cord attached. 13 The included power cord is approved for use only in specific countries or regions. Before using a power cord, Lithium Battery Warning verify that it is rated and approved for use in your location. The Lithium Battery used in the SonicWall internet security 14 Minimum power cord rating for European Union (CE): appliance may not be replaced by the user. The appliance must Certified power supply cord not lighter than light PVC be returned to a SonicWall authorized service center for sheathed flexible cord according to IEC 60227, replacement with the same or equivalent type recommended designation, or H05 VV‐F or H05 VVH2‐F2, and rated for by the manufacturer. If, for any reason, the battery or at least 3G 0.75 mm². SonicWall security appliance must be disposed of, do so following the battery manufacturer's instructions. 15 The following statement applies only to rack‐installed products that are GS‐Marked: This equipment is not intended for use at workplaces with visual display units, Cable Connections in accordance with §2 of the German ordinance for workplaces with visual display units. All Ethernet and RS232 (Console) cables are designed for intra‐ building connection to other equipment. Do not connect these 16 When shipped from the factory, this SonicWall product has a single power supply installed. A second power SonicWall NSA 2650 Getting Started Guide...
Page 50
• Hinweis zur Lithiumbatterie on page 52 6 Wählen Sie für die Montage einen Ort, der keinem • Kabelverbindungen on page 52 direkten Sonnenlicht ausgesetzt ist und sich nicht in der Nähe von Wärmequellen befindet. Die Anforderungen an die Installation Umgebungstemperatur darf nicht mehr als 40 °C betragen. Verwarnung: 7 Wenn das Gerät in einem geschlossenen 19"‐Gehäuse Für eine ordnungsgemäße Montage sollten die folgenden oder mit mehreren anderen Geräten eingesetzt ist, wird Hinweise beachtet werden: die Temperatur in der Gehäuse höher sein als die Umgebungstemperatur. Achten Sie darauf, daß die 1 Das SonicWall Modell ist für eine Montage in einem Umgebungstemperatur nicht mehr als 40° C beträgt. standardmäßigen 19‐Zoll‐Rack konzipiert. 8 Bringen Sie die SonicWall waagerecht im Rack an, um 2 Vergewissern Sie sich, dass das Rack für dieses Gerät mögliche Gefahren durch ungleiche mechanische geeignet ist und verwenden Sie das vom Rack‐Hersteller Belastung zu vermeiden. empfohlene Montagezubehör. 9 Verwenden Sie für eine sichere Montage vier passende 3 Stellen Sie sicher, dass das Gerät vor Wasser und hoher Befestigungsschrauben, und ziehen Sie diese mit der Luftfeuchtigkeit geschützt ist. Hand an. Wählen Sie einen Ort im 19‐Zoll‐Rack, wo alle SonicWall NSA 2650 Getting Started Guide...
Page 51
Sicherung, sollte Bestandteil der Haus‐Installation sein. mindestens 3G 0,75 mm². Bitte folgen die den lokalen Richtlinien beim Einkauf von Material oder Komponenten. 15 Der folgende Hinweis gilt nur für rackmontierte Produkte mit GS‐Kennzeichen: Dieses Gerät ist nicht zur 11 Prüfen Sie den Anschluss des Geräts an die Verwendung an Arbeitsplätzen mit visuellen Stromversorgung, damit der Überstromschutz sowie Anzeigegeräten gemäß § 2 der deutschen Verordnung die elektrische Leitung nicht von einer eventuellen für Arbeitsplätze mit visuellen Anzeigegeräten Überlastung der Stromversorgung beeinflusst werden. vorgesehen. Prüfen Sie dabei sorgfältig die Angaben auf dem Aufkleber des Geräts. Überlasten Sie nicht den 16 Bei Versand ab Werk ist in diesem SonicWall‐Produkt Stromkreis. ein einzelnes Netzteil installiert. Es kann ein zweites Netzteil für eine redundante Wechselstromversorgung 12 Eine sichere Erdung der Geräte im Rack muss und zusätzliche Funktionssicherheit bestellt und gewährleistet sein. Insbesondere muss auf nicht direkte installiert werden. Bei der Installation des zweiten Anschlüsse an Stromquellen geachtet werden wie z. B. Netzteils: bei Verwendung von Mehrfachsteckdosen. • Beide Stromkabel müssen abgezogen werden, 13 Das im Lieferumfang enthaltene bzw. die im um das Gerät von der Wechselstromversorgung Lieferumfang enthaltenen Netzkabel sind nur für die zu trennen. Verwendung in bestimmten Ländern und Regionen ...
Page 52
• verwendete Lithiumbatterie darf nicht vom Benutzer ausgetauscht werden. Zum Austauschen der Batterie muss die 鋰電池警告 on page 54 • SonicWall in ein von SonicWall autorisiertes Service‐Center 纜線連結 on page 54 • gebracht werden. Dort wird die Batterie durch denselben oder entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt. Beachten Sie bei einer Entsorgung der Batterie oder 安裝要求 der SonicWall Security Appliance die diesbezüglichen Anweisungen des Herstellers. 需要滿足以下條件以進行正確安裝: 1 SonicWall 設備被設計成安裝在一個標準的 19 吋機 Kabelverbindungen 架安裝櫃。 2 使用機架製造商推薦的裝載硬體,確認機架足夠裝 Alle Ethernet‐ und RS232‐C‐Kabel eignen sich für die 置所需 Verbindung von Geräten in Innenräumen. Schließen Sie an die Anschlüsse der SonicWall Appliance keine Kabel an, die aus 3 請確認裝置內不會滲入水分或過多的濕氣。 dem Gebäude in dem sich das Gerät befindet herausgeführt 4 裝置週邊請保持通風,特別是裝置通風口側。建議 werden. 裝置與牆壁間至少要有 1 英吋 (25.44 公釐 ) 的淨空。 5 纜線的路徑應遠離電源線、日光燈,以及會產生雜 訊的來源,如無線電、發送器與寬頻放大器。 6 架設位置需遠離陽光直射與熱源。建議周圍溫度最...
Page 54
Declaration of Conformity 鋰電池警告 使用者不得自行更換 SonicWall 網際網路安全性裝置中使用 A “Declaration of Conformity” in accordance with the 的鋰電池。必須將 SonicWall 裝置送回 SonicWall 授權的服 directives and standards has been made and is on file at: 務中心,以更換相同的鋰電池或製造商推薦的同類型鋰電 SonicWall International Limited, City Gate Park, Mahon, Cork, 池。若因任何原因必須丟棄電池或 SonicWall 網際網路安全 Ireland. 性裝置,請嚴格遵守電池製造商的指示。 CE declarations can be found online at: https://www.sonicwall.com/support 纜線連結 NOTE: Additional regulatory notifications and information for this product can be found online at: 所有乙太網路與 RS232 ( 主控台 ) 線路都是為與其他裝置進 https://www.sonicwall.com/support 行內建連接所設計的。請不要將這些連接埠直接連接至通 訊線路,或其他連出 SonicWall 裝置所在建築的線路。 Warranty Information All SonicWall appliances come with a 1‐year Limited Hardware Warranty which provides delivery of critical replacement parts for defective parts under warranty. Visit the Warranty Information page details on your product’s warranty https:// www.sonicwall.com/support. SonicWall NSA 2650 Getting Started Guide...
Page 56
SonicWall NSA 2650 Getting Started Guide...
Page 57
SonicWall Support Technical support is available to customers who have purchased SonicWall products with a valid maintenance contract and to customers who have trial versions. The Support Portal provides self‐help tools you can use to solve problems quickly and independently, 24 hours a day, 365 days a year. To access the Support Portal, go to https://www.sonicwall.com/support. The Support Portal enables you to: • View knowledge base articles and technical documentation • View video tutorials • Access MySonicWall • Learn about SonicWall professional services • Review SonicWall Support services and warranty information • Register for training and certification • Request technical support or customer service To contact SonicWall Support, visit https://www.sonicwall.com/support/contact‐support. SonicWall NSA 2650 Getting Started Guide...
Page 58
SonicWall NSA 2650 Getting Started Guide...
Page 59
NSA 2650 Getting Started Guide Updated ‐ August 2017 232‐003394‐50 Rev A ...
