  • Page 1 Avaya Installation Guide P117F(R) TACKABLE THERNET WITCH WITH PLINK...

  • Page 3: Safety Precautions

    SICHERHEITSVORKEHRUNG ACHTUNG – ZUR VERHINDERUNG DES RISIKOS VON ELEKTRISCHEM SCHLAG UND FEUER 1. Die Geräte enthalten keine Bauteile, die außerhalb des Avaya Servicezentrums gewartet oder repariert werden können. Die Wartung darf NUR von qualifiziertem, technischem Personal durchgeführt werden. 2. NIEMALS ein beschädigtes Gerät einschalten, oder versuchen es zu bedienen.
  • Page 4 Stromzufuhr wo sich auch der Sicherungskasten befindet. 5. Bedienen Sie das Gerät NICHT an einer Stelle an der die Umgebungstemperatur 50ºC übersteigt. 6. Ziehen Sie das Netzkabel raus, BEVOR Sie versuchen die Hauptsicherung zu kontrollieren oder auszutauschen. Preface Safety Instructions P117F(R) Stackable Switch Installation Guide...
  • Page 5 Overview This guide is divided into four main sections: • Overview: A general description of the features of the Avaya Stackable Switch and P117FR (jointly referred to as the P117F(R)). • Installation: Instructions for getting the P117F(R) Stackable Switch and P110 stack up and running.
  • Page 6 Chapter 1 Description P117F(R) Stackable Switch Installation Guide...

  • Page 7: Installation

    “Basic” version. The Basic version is factory loaded. Ensure the Use Switch is set to the OFF position. Once you have set the DIP switch, you may proceed with the physical installation of the switch. Table 1...
  • Page 8 1. Turn off the main power to the stack, by individually switching off each switch. 2. Place the P110 NMA in the top switch of the stack if it is not already there. 3. If the P110 NMA and P117F(R) on-board agent contain the latest software version, go to step 4.
  • Page 9 P110 Exoplane cables (part number 108362203, with white connectors and marked C/S:B) of the type supplied with the new P110 switch. Extra cables can be ordered from your local Avaya representative. Figure 2 Rear view of a P110 stack, showing how the switches are linked via the P110 Exoplane cables.
  • Page 10 Chapter 2 Installation The P110 NMA and the on-board agent in all P110 switches (e.g., P117F(R) and P113F) must have the same version number. P117F(R) Stackable Switch Installation Guide...
  • Page 11 3 Stacking them in this way will allow the switches to be easily connected using the Exoplane cables. 3. Secure the switch in the rack using the screws. Use one screw on each side. Do not overtighten the screws to avoid damaging the plastic.
  • Page 12 Chapter 2 Installation Diagnostics Tables 2 and 3 explain the meaning of the P117F diagnostic LED indicators. Figure 4 The P117F Front Panel LEDs and Buttons Figure 5 The P117FR Front Panel LEDs and Buttons P117F(R) Stackable Switch Installation Guide...
  • Page 13 Press and hold both buttons simultaneously for two seconds to reset the entire P110 stack. In a Reset, all LED indicators turn on. Pressing Reset does not affect configuration settings. Table 3 Meaning of the P117F(R) Stackable Switch front panel LEDs LED Indicator Function Power...
  • Page 14 LEDs (see ATM ports Table 3) Redundancy is disabled. Upper port active Redundancy is enabled. Upper port Blink active Redundancy is enabled, and secondary port (Lower ATM connector) is active P117F(R) Stackable Switch Installation Guide...

  • Page 15: Connecting The Console Terminal

    You must first update the P110 NMA before you add the P117F(R) to the stack. Connecting the Console Terminal Software download to a P117F(R) Stackable Switch can be performed via a console terminal connected to the serial port labeled Console on the P117F(R).

  • Page 16: Setup Menus

    Instructions for each item in the list can be found in the pertinent sections of this guide. If necessary, enter an IP address for the P117F(R), and reset the switch. If you’re using routers, set up a default gateway.
  • Page 17 13. (10.) ATM Redundancy... 14. (11.) Set ATM port parameters to their default values 15. (12.) Set Ethernet Ports’ parameters to their default values >>>Enter your choice: P117F(R) Stackable Switch Installation Guide Setup Main Menu Slot #: ____ Chapter 3...
  • Page 18 Type <y> to save parameter changes. If you type <n> all changes will be lost. Agent must be reset in order to activate IP changes. Reset may be done after each change or at the end of the entire Setup session. P117F(R) Stackable Switch Installation Guide...

  • Page 19: Parameter Configuration

    After setting ATM port parameters to their default values Change in the “Use switch” or any other DIP switch of any other switch After changing the LSV DIP Switch position Resetting does not affect any other parameters. You will be asked to confirm the reset before it is executed.
  • Page 20 Caution: Download the Basic version only when the new Application version is working correctly. This will ensure that if there is a problem with the application version, the agent will be able to switch to a valid Basic version. P117F(R) Stackable Switch Installation Guide...
  • Page 21 4. Start Software Download process 5. Monitor Software Download process >>>Enter your choice: 2. Select TFTP Server and File parameters from the Software Download menu. This opens the menu shown below. P117F(R) Stackable Switch Installation Guide Chapter 3 Configuration Slot #:_____...
  • Page 22 *** Warning – Perform Software Download ***, Confirm [y/n]? 8. Select “y”. 9. Keep track of the progress of the software download by selecting Monitor Software Download process. Press Enter to get an update of the download process. 135.49.60.115 P117F(R) Stackable Switch Installation Guide...
  • Page 23 Failure of TFTP Get server is Failed to find the unreachable server after 1 minute P117F(R) Stackable Switch Installation Guide Slot #: ____ TFTP Server: 135.49.60.115 File Name: c:/home/v16155 Suggested action Ensure that the correct agent software file is being downloaded to...
  • Page 24 2. Select InBand Interface. The following prompt line displays: InBand Interface IP address: 149.049.150.101, netmask: 255.255.255.0. >>> Enter InBand Interface IP address [149.49.150.101]: 149.49.39.85 >>> Enter InBand Interface netmask [255.255.255.0]: 255.255.0.0 Agent Access Addresses Slot #: ____ Netmask 255.255.255.000 P117F(R) Stackable Switch Installation Guide (0xffffff00)
  • Page 25 6. Type 0 to return to the main menu. Changes to IP Addresses and Netmasks require you to reset the agent. You may reset the agent now, or at the end of the entire Setup session. P117F(R) Stackable Switch Installation Guide Chapter 3 Configuration...
  • Page 26 To define an IP route, you must supply: • The IP address of the station or the network (not subnet) • The IP address of the gateway (router). P117F(R) Stackable Switch Installation Guide...
  • Page 27 List - static routing table --------------------------------- Add[] Delete[] >>>Enter your choice: 2. Select Add to define a new IP Route. Select Delete to remove an existing IP Route. P117F(R) Stackable Switch Installation Guide IP Routes menu Slot #: ____ Chapter 3 Configuration...
  • Page 28 6. To save your changes select Save the Session. 7. Type 0 to return to the Setup main menu. Changes to IP Routes do not require you to reset the agent. IP Route parameters menu Slot #: ____ P117F(R) Stackable Switch Installation Guide...
  • Page 29 5 – SNMP Community (Not applicable for P117F(R) Stackable Switch in a stack) This parameter defines the trap, read-only and read-write communities. The community name can be up to 24 characters in length. The default community for all three options is public.
  • Page 30 4. Select “1. Save the Session” to save the changes, then “0. Return to Previous Menu” to return to the previous menu. A similar procedure is used to change the Read-Only and Read-Write communities. Trap Community Menu Slot #: ____ P117F(R) Stackable Switch Installation Guide...
  • Page 31 6 – Permanent Managers (Not applicable for P117F(R) Stackable Switch in a stack) This option allows you to define up to ten management stations which can receive alarms. Visage 16155(R) S/W Version: ____ <CR> Refresh the screen 0. Return to Previous Menu 1.
  • Page 32 2. Select the index number (1 - 10) of the permanent manager you wish to update and press Enter. 3. Enter the new IP address and press Enter. 4. Press Enter to return to the Permanent Managers Menu. P117F(R) Stackable Switch Installation Guide...
  • Page 33 7 – Module Advanced Configuration (Not applicable for P117F(R) Stackable Switch in a stack) This option is not currently implemented. 8 (5) – UNI Version This option determines the UNI version used for the P117F(R). Before changing the UNI Version check that the ATM switch supports this version.
  • Page 34 This option allows you to change the ATM media to be SONET or SDH. To access the ATM physical media menu select ATM Physical Media. Before choosing the ATM Physical Media, check that the ATM switch supports this media type. Visage 16155(R) S/W Version: ____ <CR>...
  • Page 35 You can define the ATM address in two ways: either • Type 0 for the P117F(R) to use the ILMI protocol to obtain the 13-byte ATM prefix from the ATM switch, or • Enter 19 bytes manually: the 13-byte ATM prefix and the 6-byte ATM ESI. The manual option is intended for switches that do not support the ILMI protocol.
  • Page 36 Configured LECS ATM address : using ILMI/WKA/PVC Default LECS ATM address >>> Enter LECS ATM address (xx.xx ... 20 bytes, 0 for using ILMI/WKA/PVC) : 0 >>> PRESS Enter to continue: LECS ATM address menu Slot #: ____ : using ILMI/WKA/PVC P117F(R) Stackable Switch Installation Guide...
  • Page 37 4. Reset the module for the changes to take effect (press 0 to return to Main Menu and then 1 to Reset). Enter a specific address only for an ATM switch that does not support ILMI protocol or P.V.C.’s and its LECS address is not Well-Known Address (WKA).
  • Page 38 Operational Active Operational Active Operational Active Operational Active Operational Active Operational Active Operational Active Operational Active Operational • Initial Registration • BUS Connect • Operational P117F(R) Stackable Switch Installation Guide IfIndex 1028 1029 1030 1031 1032 1033 1034 1035 1036...
  • Page 39 IfIndex: 1028 >>> Enter new default ELAN name: alpha >>>Enter CR to continue: 2. Enter the new default name and press Enter. 3. Press Enter to return to the ELAN configuration menu. P117F(R) Stackable Switch Installation Guide Chapter 3 Configuration...
  • Page 40 To display Default redundancy parameters, select 2. • To set redundancy parameters to their default values, select 3. You must Reset the module after changing to the default values. • To change redundancy mode, select 4. Slot #: 1 P117F(R) Stackable Switch Installation Guide...
  • Page 41 Ethernet port to which the management station is connected you will no longer be able to contact the P117F(R) from the device manager. >>>Enter your choice: ***WARNING*** Port parameters were changed. Reset the agent!!! >>>PRESS Enter to continue: P117F(R) Stackable Switch Installation Guide Chapter 3 Configuration...
  • Page 42 Chapter 3 Configuration P117F(R) Stackable Switch Installation Guide...

  • Page 43: Terminal Connector Pin Assignments

    Chapter 4 Terminal Connector Pin Assignments Figure 6 Terminal port – RS-232 Wiring Connection to Console Terminal P117F(R) Stackable Switch Installation Guide...
  • Page 44 © 2003 Avaya Inc. All rights reserved. All trademarks identified by the ® or TM are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. Document number: 130001 Rev. A...
