- Page 1 Avaya Installation Guide P118SX/LX TACKABLE THERNET WITCH...
-
Page 3: Safety Precautions
Preface Important information SAFETY PRECAUTIONS CAUTION – TO REDUCE THE RISK OF ELECTRIC SHOCK AND FIRE 1. All servicing should be undertaken ONLY by qualified personnel. The parts inside the unit CANNOT be serviced or repaired by the end user. Please call your service representative for assistance. - Page 4 Preface Safety Instructions 4. Austauschen einer durchgebrannten Sicherung NUR mit der gleichen Sorte und Belastbarkeit wie sie auf der Sicherheitsaufschrift markiert ist. Die Aufschrift befindet sich neben der Stromzufuhr wo sich auch der Sicherungskasten befindet. 5. Bedienen Sie das Gerät NICHT an einer Stelle an der die Umgebungstemperatur 50ºC übersteigt.
-
Page 5: Laser Product
Regulatory Approvals and Safety Information for the P118SX/LX Products LASER SAFETY The P118SX multi-mode transceiver and the P118LX single mode transceiver are a Class 1 laser product. They comply with IEC 825-1 and Food and Drug Administration (FDA) 21 CFR 1040.10 and 1040.11. - Page 7 Chapter 1 Overview This guide is divided into the following main sections: • Overview: A general description of the features of the P118. • Installation: Instructions for getting the P118 and P110 stack up and running. P118 Installation Guide...
- Page 8 Chapter 1 Overview Description The P118SX and P118LX are part of the P110 family of switches. The P110 family is composed of high-performance stackable switches which may be used singly or stacked in any combination. The P118 has eight Ethernet/Fast Ethernet (10/100BASE-T) ports and two Gigabit Ethernet (1000BASE-X) ports.
- Page 9 Chapter 2 Preliminary Settings Fiber Optic Specifications Two auto-negotiation 1000BASE-X ports. P118SX 1000Base-SX ports • 220m over 62.5 µm MMF or • 550m over 50 µm MMF. P118LX 1000Base-LX ports • 5 km over SMF or • 550m over MMF with special patch cord.
-
Page 11: Installation
Before you install the P118, check Table 1 which shows the default values for key parameters and how you can change them. The default values are set at the factory to enable smooth interoperability with other Avaya switches. Table 1 Default Values... -
Page 12: Setting The Dip Switches
Chapter 2 Installation Setting the DIP switches First, set the DIP switches. The position of the switches depends on the P110 application. The drawing below shows the default positions of the DIP switches on the rear panel of the P110 switch. Figure 1 The P118 Rear Panel Showing the DIP Switches in their Default Positions Note: The DIP switches described below function only when the USE SWITCH... - Page 13 Chapter 2 Installation • TAG 1, TAG 2 –802.1Q VLAN Tagging mode (TAG 1 is for port 1 and TAG 2 is for port 2). VLAN Tagging transfers across the backbone packets with VLAN and priority. By carrying this information across the inter-switch link, VLAN Tagging makes it possible to distribute VLANs across the organization.
- Page 14 Chapter 2 Installation Installing the P118 The procedure for getting the P118 up and running depends on whether the switch is to operate standalone or as part of a stack. First, attach the adhesive rubber legs to the base of the P110 switch. If the switch is to be rack mounted, do not attach the legs.
- Page 15 When using the P114T or P114F in the stack, make sure all switches in the stack are connected using Exoplane cables. Extra cables can be ordered from your local Avaya representative. Figure 2 Rear view of a P110 switch stack, showing how the switches are linked via the Exoplane cables.
- Page 16 Chapter 2 Installation • When a new version of agent software becomes available, you should perform software download to benefit from the extra capabilities provided. Please refer to the P110 NMA Installation Guide for details. P118 Installation Guide...
- Page 17 Chapter 2 Installation Rack Mounting P110 switches slot into a standard 19-inch rack. Remove the rubber legs from the base of any switch that is to be rack mounted. Place the switches in the rack, and then connect the Exoplane, as follows: 1.
- Page 18 Chapter 2 Installation Diagnostics Table 3 and Table 4 explain the meaning of the P118 diagnostic LED indicators. Figure 4 The P118 Front Panel LEDs and Buttons Table 3 Meaning of the P118 Front Panel Buttons Button Function Meaning Select The buttons determine what function will be displayed by the 18 Port LEDs (the top two rows of LEDs).
- Page 19 Chapter 2 Installation Table 4 Meaning of the P118 front panel LEDs LED Indicator Function Status Meaning Power Mains power not connected Mains power connected Blink Working on back-up power supply Agent No agent in switch Switch contains an active agent RED NMA Function LED Port LED...
- Page 20 © 2003 Avaya Inc. All rights reserved. All trademarks identified by the ® or TM are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. Document number: 130010 Rev.A...
