Assembly and Operating Instructions for Outback®
Jupiter Stainless steel Patio Heater
Drawings are not to scale.
Specifications subject to change
without prior notice.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, immediately call your
gas supplier or your fire Department.
OUT370610/PH200T
1. Do not store or use gasoline or other flammable
2.An LP cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
FOR YOUR SAFETY
vapors and liquids in the vicinity of this or any
other appliance.
0063
Advertisement
Table of Contents
Related Manuals for Outback OUT370610/PH200T
Summary of Contents for Outback OUT370610/PH200T
- Page 1 Assembly and Operating Instructions for Outback® Jupiter Stainless steel Patio Heater Drawings are not to scale. Specifications subject to change OUT370610/PH200T 0063 without prior notice. FOR YOUR SAFETY FOR YOUR SAFETY If you smell gas: 1. Do not store or use gasoline or other flammable 1.
- Page 2 WARNlNG SAFETY RULES PLEASE READ THE FOLLOWING SAFETY RULES PRlOR TO OPERATION OF THE HEATER. • This appliance must be installed and the gas cylinder stored in accordance with the regulations in force; • Do not obstruct the ventilation holes of the cylinder housing; •...
-
Page 3: Assembly Parts
ASSEMBLY PARTS Quantity varies according to model purchased. Specifications subject to change without prior notice. Tools needed: Open end wrench 10 & 13 mm • Adjustable opening wrench (2) 20 cm long • Slip joint pliers 23 cm long • Philips screwdriver w/ medium blade •... - Page 4 PARTS Quantity varies according to model purchased. Specifications subject to change without prior notice. 813 mm Table 460 mm...
- Page 5 ASSEMBLY IMPORTANT! Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present. Please read the Important Information section carefully before assembly. Square metal support Bolt Stand 1-1. Put the 3 pcs post brackets on each position on the base as shown in the picture.
- Page 6 Tank housing Place the tank housing on the stand. Fastening nut Table Tightening spacer 4-1. Table Installation. Slide fastening nut down the pole with the rounded side faced downwards. 4-2. Next, slide the tightening spacer down the pole with the smaller side facing downwards.
- Page 7 Screw Coupler 5-1. Insert the screw coupler on the pole, inserting it through the middle of the table on the pole. Thread the tightening spacer on the bottom of the table counterclockwise onto the screw coupler. 5-2. Tighten securely to hold the table to the screw coupler. Thread the fastening nut counterclockwise.
- Page 8 Reflector Spacer 7-1. Check whether the connection of vertical post and burner are assembled according to instructions, and all bolts and nuts are tightened. 7-2. Put 6 pcs Large Flat Washers on 3 Reflector Spacers. Wing nut Reflector Fasten the reflector with 3 pcs Large Flat Washers and 3 pcs Wing Nuts.
-
Page 9: Leakage Test
Gas tank Regulator 9-1. Loose the table connection then lift it to the top of main pole and tight again. 9-2. Bring up the tank housing and rest it on the post plate. 9-3. Connect the regulator to the gas tank and tighten it with adjustable wrench. - Page 10 CAUTION PLEASE READ CAREFULLY THE FOLLOWING SAFETY GUIDELINES BEFORE OPERATION. • Do not use the patio heater for indoors, as it may cause personal injury or property damage. • This outdoor heater is not intended to be installed on recreational vehicles and/or boats.
-
Page 11: Heater Stand And Location
• Adults and children should stay away from high temperature surface to avoid burns or clothing ignition. • Children should be carefully supervised when they are in the area of the heater. • Clothing or other flammable materials should not be hung on the heater or placed on or near the heater. -
Page 12: Gas Requirements
GAS REQUIREMENTS • Use propane or butane gas only. • The pressure regulator and hose assembly to be used must conform to local standard codes. • The installation must conform to local codes, or in the absence of local codes, with the standard for the storage and handling of liquid petroleum gases. - Page 13 TO TURN OFF THE HEATER 1. Turn the variable control knob to PILOT position. 2. Press and turn the variable control knob to OFF position. OFF: the heater stop work HI: maximum temperature position Variable LO: minimum temperature position control knob IGNITER Igniter 3.
-
Page 14: Characteristics And Specifications
CHARACTERISTICS AND SPECIFICATIONS A. Construction and characteristics • Transportable terrace/garden heater with tank housing • Casing in steel with powder-coating or stainless steel • Gas hose connections with metal clamp (screw caps for Germany) • Heat emission from reflector B. Technical Specifications •... -
Page 15: Problems Check List
Control not ON Turn valve to ON Thermocouple bad Replace thermocouple Pilot light assembly bent Place pilot properly Not in correct location Position properly and retry Outback International UK Ltd Unit 4, Sigeric Business Park Holme Lacy Road, Hereford, HR2 6NS... - Page 16 OUTBACK® WARRANTY OUTBACK® heater are warranted for a period of one (1) year from the date of purchase to the original purchaser against defects in materials and workmanship, OUTBACK® will supply replacements for defective parts free of charge provided that: •...
