Aspire T160/E360 AcerPower M6
Service Guide
Service guide files and updates are
available on the AIPG/CSD web. For more
information, please refer to
http://
csd.acer.com.tw

Advertisement

Table of Contents
loading

Related Manuals for Acer AcerPower APM6

Summary of Contents for Acer AcerPower APM6

  • Page 1 Aspire T160/E360 AcerPower M6 Service Guide Service guide files and updates are available on the AIPG/CSD web. For more information, please refer to http:// csd.acer.com.tw...
  • Page 2 PRINTED IN TAIWAN...

  • Page 3: Revision History

    Revision History Please refer to the table below for the updates made on Aspire T160/E360 and AcerPower M6 service guide. Date Chapter Updates...
  • Page 4 Copyright Copyright © 2005 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 5 Acer is a registered trademark of Acer Corporation. Intel is a registered trademark of Intel Corporation. Athlon 64 / Athlon 64x2 / Sempron are trademarks of AMD Corporation. Other brand and product names are trademarks and/or registered trademarks of their respective holders.
  • Page 6 Conventions The following conventions are used in this manual: Screen messages NOTE WARNING CAUTION IMPORTANT Denotes actual messages that appear on screen. Gives bits and pieces of additional information related to the current topic. Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 7 DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 8: Table Of Contents

    Acer disc-to-disc Recovery ........
  • Page 9 Table of Contents Remove the PCI ..........60 Detach the CPU Cooler .

  • Page 10: Chapter 1 System Specifications

    System Specifications Overview AMD Athlon 64 / Athlon 64x2 / Sempron (939) Chipset C51G + MCP51 Memory Dual Channel DDR1 266/333/400, four DDR1 DIMM (Max. four GB) supported System BIOS Feature LCP-4MB (wake on LAN boot) Award BIOS code ACPI supported; S3 will be defaulted. Hardware monitor supported Super I/O ITE8712F with hardware monitor...

  • Page 11: Main Board Specifications

    Main Board Specifications Size Processor System Chipset Memory PCI Express / PCI Slots FDD Interface IDE Interface Audio USB (AcerPower M6) Description Max. 244 mm x 244 mm, Micro ATX Processor type: AMD Athlon 64 / Athlon 64x2 / Sempron Socket type: AMD Socket 939 Socket quantity: one North bridge: Nvidia C51G...
  • Page 12 USB (Aspire E360/T160) I/O Ports All On-Board Connector / Device List Chapter 1 Description Controller: MCP51 Connectors Quantity: eight Rear connectors: four On-board header: three (2*5 pin) One for front daughter board (2*5 pin Intel EPIO) One for Multi Card Reader (2*5 pin) One for cable (leverage rear USB ports) Data transfer rate support: USB 2.0/1.1 Dual stack PS/2 keyboard / mouse...

  • Page 13: Wake-Up Event Specifications

    Wake-up Event Specifications Device Power button PS/2 keyboard USB keyboard Modem (Ring) System LED Definition Power state LED HDD state LED LAN state LED Power state LED HDD state LED LAN state LED S3 (Suspend S1 (Idle) to RAM) Enabled Enabled Enabled Enabled...

  • Page 14: Block Diagram

    Block Diagram Chapter 1...

  • Page 15: Main Board Placement

    Main Board Placement Chapter 1...
  • Page 16 KB / MS COM1 1394_USB NIC_USB Audio SYS_FAN F_Audio CD_IN AUX_IN SPDIF_OUT SPEAKER F_1394 F_USB1 F_USB2 TBL_EN CLR_CMOS INTR Chapter 1 Label CPU socket North bridge South bridge Audio codec Super I/O controller LAN controller TV OUT port Keyboard and mouse COM1 Printer 1394 USB...
  • Page 17 SATA_1 (from left SATA_2 to right) SATA_3 SATA_4 SIDE PIDE Floppy PWR1 DIMM1 DIMM2 DIMM3 DIMM4 CPU_FAN Label SATA_1 SATA_2 SATA_3 SATA_4 Secondary IDE port Primary IDE port Floppy drive connector 24-pin power connector DIMM socket 1 DIMM socket 2 DIMM socket 3 DIMM socket 4 CPU fan connector...

  • Page 18: Aspire T160 Front Panel

    Aspire T160 Front Panel Chapter 1 Description Optical device Floppy drive Power button Microphone jack Speaker/Headphone jack USB ports...

  • Page 19: Aspire E360 Front Panel

    Aspire E360 Front Panel NOTE: The picture left is the front bezel with cover slided down. Description Optical driver Optical drive eject button Power button USB ports Speaker/Headphone jack Microphone jack Indicators Floppy disk drive Card reader IEEE 1394 port Chapter 1...

  • Page 20: Acerpower M6 Front Panel

    AcerPower M6 Front Panel Chapter 1 Description Optical drive Floppy disk drive Card reader Indicators USB ports Microphone jack Speaker/Headphone jack Power button...

  • Page 21: Acerpower M6 Rear Panel

    AcerPower M6 Rear Panel Description Power supply Power cord socket Voltage select switch PS/2 Mouse port PS/2 Keyboard port Serial port Printer port VGA port USB Ports RJ45 port Audio jacks Expansion slots Lock handle SPDIF port Recovery switch holder Chapter 1...

  • Page 22: Aspire T160/E360 Rear Panel

    Aspire T160/E360 Rear Panel Chapter 1 Description SPDIF port SPDIF port Lock handle PS/2 Mouse port PS/2 Keyboard port Serial port Printer port VGA port IEEE 1394 port LAN port USB ports Audio jacks...

  • Page 23: System Peripherals

    System Peripherals The Aspire T160/E360 and AcerPower M6 computer consist of the system itself, and system peripherals, like a mouse, keyboard and a set of speakers (optional). This section provides a brief description of the basic system peripherals. Mouse (PS/2 or USB, manufacturing option) The included mouse is a standard two-button wheel mouse.

  • Page 24: Acer Erecovery

    Acer eRecovery Acer eRecovery is a tool to quickly backup and restore the system. Users can create and save a backup of the current system configuration to hard drive, CD, or DVD. Acer eRecovery consists of the following functions: Create backup...

  • Page 25: Change Password

    In the Recovery settings window, select Reinstall applications/drivers and click Next. Select the desired driver/application and follow the instructions on screen to re-install. At first launch, Acer eRecovery prepares all the needed software and may take few seconds to bring up the software content window.

  • Page 26: Acer Disc-To-Disc Recovery

    It is important to back up all data files before you use this option. Restart the system. While the Acer logo is showing, press <Alt>+<F10> at the same time to enter the recovery process. The message "The system has password protection. Please enter 000000:" is displayed.

  • Page 27: Hardware Specifications And Configurations

    Hardware Specifications and Configurations Major Chips Item System Core Logic Super I/O Controller LAN Controller Memory Controller IDE Controller Audio Controller VGA Controller Keyboard Controller Processor Item Type Slot Speed Bus Frequency Voltage BIOS Item BIOS code programmer BIOS version BIOS ROM size BIOS ROM package Support protocol...
  • Page 28 System Memory Item Memory Slot Number Memory Size per Slot Supported Maximum Memory Size Supported Memory Speed Supported memory voltage Support memory module package Support to parity check feature Support to Error Correction Code (ECC) feature Memory module combinations VRM (Voltage Regulator Module) Function VRM Specification CPU VRM...
  • Page 29 IDE Interface Item IDE Controller IDE Controller Resident Bus Number of 40-pin PATA slot Number of STAT IDE slot LS-120 Bootable CD-ROM Function Control Diskette Drive Interface Item Diskette Drive Controller Diskette Drive Controller Resident Bus Supported Diskette Drive Formats Function Control Serial Port Item...

  • Page 30: Environment Requirements

    Special Design Specifications Thermal Power On / Wake-Up Event Environment Requirements Temperature Operating Non-operating Humidity Operating Non-operating Vibration Operating (unpacked) Non-operating (packed) Shock Operating Drop Test Definition The protection ability of packing & cushion must be capable of withstanding, with no physical or functional damage, mechanical impact from height-specific drops.
  • Page 31 Input / Output Map Assignment 1 Address Device Chapter 1...
  • Page 32 Input / Output Map Assignment 2 Address Device Chapter 1...
  • Page 33 Memory Map Assignment Address Device Chapter 1...

  • Page 34: Power Management Function (Acpi Support Function)

    Power Management Function (ACPI support function) Device Standby Mode Independent power management timer for hard disk drive devices (0-15 minutes, time step=1 minute). Hard disk drive goes into Standby mode (for ATA standard interface). Disable V-sync to control the VESA DPMS monitor. Resume method: device activated (Keyboard for DOS, keyboard &...

  • Page 35: Chapter 2 System Utilities

    System Utilities BIOS (Basic Input and Output System) includes a CMOS SETUP utility which allows users to configure required setting or to activate certain system features.The CMOS SETUP saves the configuration in the CMOS SRAM on the main board. When the power is off, the battery on the main board supplies the necessary power to the CMOS SRAM.

  • Page 36: Entering Setup

    Entering Setup Power on the computer and the system will start POST(Power On Self Test) process. When the message of “Press DEL to enter SETUP” appears on the screen, press the key of [Delete] to enter the setup menu. Once enter Award BIOS CMOS Setup Utility, the Main Menu (as figure below) will appear on the screen.

  • Page 37: Product Information

    System BIOS ID BIOS Release Date Chapter 2 Phoenix - Award BIOS CMOS Setup Utility Product Information AST160/ASE360/APM6 FC51GM Acer Acer 6.00 PG R01-A3 10/27/2005 F7:Optimized Defaults This item lists the product name This item lists the system serial number...

  • Page 38: Standard Cmos Features

    Standard CMOS Features Date (MM:DD:YY): System Time IDE Channel 0 Master IDE Channel 0 Slave IDE Channel 1 Master IDE Channel 1 Slave IDE Channel 2 Master IDE Channel 3 Master IDE Channel 4 Master IDE Channel 5 Master Floppy Drive A Video Setting Halt On Setting Base Memory Setting...
  • Page 39 Parameter IDE Primary/Secondary Allows you to configure the hard disk drive Master, Slave connected to the master port of IDE channel. To enter the IDE Master or Slave setup, press [Enter]. The IDE CD-ROM is always automatically detected. Drive A The category identifies the types of floppy disk drive A that has been installed in the computer.

  • Page 40: Advanced Bios Features

    Advanced BIOS Features The following screen shows the Advanced BIOS Features: Hard Disk Boot Priority Virus Warning Quick Power on Self Test First Boot Device Second Boot Device Third Boot Device Boot From Other Device Swap Floppy Drive Boot Up Floppy Seek Boot Up Numlock Status Gate A20 Option Typematic Rate Setting...
  • Page 41 Parameter Boot From Other Devices This item allows user to enable or disable to boot from other device Swap Floppy Drive This field is effective only in systems with two floppy drives. Selecting Enabled assigns physical drive B to logical drive A, and physical drive A to logical drive B.

  • Page 42: Advanced Chipset Features

    Advanced Chipset Features This page sets up more advanced information about your system. Handle this page with caution. Any changes can affect the operation of your computer. Dual Monitor Support Frame Buffer Size CPU Frequency Err94 Enh Spread Spectrum HT Spread Spectrum SSE/SSE2 Instructions System BIOS Cacheable :Move Enter:Select...
  • Page 43 Parameter Err94 Enh Spread Spectrum HT Spread Spectrum SSE/SSE2 Instructions System BIOS Cacheable DRAM Configuration LDI & PCI Bus Control UMA Frame Buffer Size Chapter 2 Description Also called Errata 94 Enhancement. Errata 94 refers to the 94th bug identified in AMD Athlon and Opteron processors.

  • Page 44: Integrated Peripherals

    Integrated Peripherals IDE Function Setup Onboard Device Setup Onboard I/O Chip Setup :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help Parameter IDE Function Setup Onboard Device Setup Onboard I/O Chip Setup Phoenix - Award BIOS CMOS Setup Utility Integrated Peripherals [Press Enter] [Press Enter] [Press Enter] F5:Previous Values F7:Optimized Defaults...

  • Page 45: Ide Function Setup

    IDE Function Setup OnChip IDE Channel0 Primary Master Primary Slave Primary Master UDMA Primary Slave UDMA OnChip IDE Channel1 Secondary Master PIO Secondary Slave Secondary Master UDMA Secondary Slave UDMA IDE DMA Transfer Access Serial-ATA 1 Serial-ATA 2 IDE Prefetch Mode IDE HDD Block Mode SATA PORT Speed Settings :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help...
  • Page 46 Parameter IDE Primary/ Secondary Master/ Slave UDMA IDE DMA Transfer Access Serial-ATA 1/2 IDE Prefetch Mode IDE HDD Block Mode SATA PORT Speed Settings Description UDMA (Ultra DMA) is a DMA data transfer protocol that utilizes ATA commands and the ATA bus to allow DMA commands to transfer data at a maximum burst rate of 33 MB/s.

  • Page 47: Onboard Device Setup

    Onboard Device Setup OnChip USB USB Memory Type USB Keyboard Support USB Mouse Support AC97 Audio MAC Lan MAC Lan Boot ROM :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help Parameter OnChip USB USB Memory Type USB Keyboard Support USB Mouse Support AC 97 Audio MAC Lan MAC Lan Boot ROM...

  • Page 48: Onboard I/O Chip Setup

    Onboard I/O Chip Setup Onboard FDC Controller Onboard Serial Port 1 UART Mode Select UR2 Duplex Mode Onboard Parallel Port Parallel Port Mode ECP Mode Use DMA :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help Parameter Onboard FDC Controller Onboard Serial Port 1 UR2 Duplex Mode Onboard Parallel Port Phoenix - Award BIOS CMOS Setup Utility...
  • Page 49 Parameter Description Options Parallel Port Mode Select an operating mode for the onboard parallel (printer) port. Select Normal, Compatible, or SPP unless you are certain your hardware and software both support one of the other available modes. For information about parallel port modes, see http://www.fapo.com/ 1284int.htm Chapter 2...

  • Page 50: Power Management Setup

    Power Management Setup The Power Management menu lets you configure your system to most effectively save energy while operating in a manner consistent with your own style of computer use. ACPI Function ACPI Suspend Type Power Management Video Off Method HDD Power Down HDD Down In Suspend Soft-Off by PWR-BTTN...
  • Page 51 Parameter HDD Power Down HDD Down In Suspend Soft-off by PWR/BTTN WOL (PME#) From Soft- USB Resume from S1/S3 Enable or Disable USB device (USB K/B or Resume by Alarm POWER ON Function PWRON After PWR-Fail Chapter 2 Description This setting controls how long a hard disk drive must be left idle before it spins down.

  • Page 52: Pnp/Pci Configuration

    PnP/PCI Configuration Init Display First Reset Configuration Data Resources Controlled By x IRQ Resources Pci/VGA Palette Snoop ** PCI Express relative items ** Maximum Payload Size :Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help Parameter Init Display First Reset Configuration Data Resources Controlled By Phoenix - Award BIOS CMOS Setup Utility PNP/PCI Configurations...
  • Page 53 Parameter IRQ Resources PCI/VGA Palette Snoop Maximum Payload Size PCI1/2 IRQ Assignment Chapter 2 Description When resource are controlled by manually, assign each system interrupt a type, depending on the type of device using the interrupt. Option: PCI Device: Assign this IRQ for PCI device.

  • Page 54: Pc Health Status

    PC Health Status This section indicates the hardware information of the system including the CPU temperature, Ambient Temperature, CPU FAN, and System FAN speed. Shutdown Temperature CPU Vcore +3.3V +12V +5USB Voltage Battery Current CPU Temperature Current SYSTEM Temperature CPU FAN Speed System FAN Speed :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help The following table describes the parameters found in this menu.

  • Page 55: Load Default Settings

    Load Default Settings Selecting the field loads the factory defaults for BIOS and Chipset Features which the system automatically. detects. THis option opens a dialog box that lets you install optimized defaults for all appropriate items in the Setup Utility. Press <OK> and then <Enter> to install the defaults. Press <Cancel> and then <Enter> to not install the defaults.

  • Page 56: Set Supervisor/User Password

    Set Supervisor/User Password When this function is selected, the following message appears at the center of the screen to assist you in creating a password. ENTER PASSWORD Type the password, up to eight characters, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory.

  • Page 57: Save & Exit Setup

    Save & Exit Setup Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu.

  • Page 58: Exit Without Saving

    Exit Without Saving Highlight this item and press <Enter> to discard any changes that you have made in the Setup Utility and exit the Setup Utility. When the Exit Without Saving dialog box appears, press <Y> to discard changes and exit, or press <N> to return to the main menu.

  • Page 59: Chapter 3 Machine Disassembly And Replacement

    Machine Disassembly and Replacement This chapter displays the disassembly procedure of Aspire T160/E360 and AcerPower M6. To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge Wire cutter Phillips screwdriver (may require different size) NOTE: The screws for the different components vary in size.

  • Page 60: General Information

    General Information Before You Begin Before proceeding with the disassembly procedure, make sure that you do the following: Turn off the power to the system and all peripherals. Unplug the AC adapter and all power and signal cables from the system. Chapter 3...

  • Page 61: Aspire T160 And Acerpower M6 Disassembly Procedure

    Aspire T160 and AcerPower M6 Disassembly Procedure This section tells you how to disassemble the system when you need to perform system service. NOTE: Before you proceed, make sure you have turned off the system and all peripherals connected to it. Open the Computer Place the system unit on a flat and steady surface.
  • Page 62 Disconnect the USB and Front LED ASSY cables. Disconnect the System fan connector and 12V power connector from the main board connector. Disconnect the P1 power cable and ODD data cable from the main board connector. Chapter 3...
  • Page 63 Disconnect the FDD data cable from the main board connector. Disconnect the ODD data cable and power cable from the rear of ODD. Disconnect the FDD data cable and power cable from the rear of FDD. Chapter 3...

  • Page 64: Detach The Hdd, Fdd, And Card Reader (If Equipped)

    Disconnect the HDD data cable and power cable from the rear of HDD and main board. Detach the HDD, FDD, ODD and Card Reader (if equipped) Rail the holder shown below, then take the HDD out from the chassis. Release the three latches on the front bezel, then remove the front bezel. Chapter 3...
  • Page 65 Rail the holder shown below, then take the ODD out from the chassis. Rail the holder shown below, then take the FDD out from the chassis. Rail the holder shown below, then take the Card Reader out from the chassis. Chapter 3...

  • Page 66: Detach The Usb Module

    Detach the USB Module Release the screw shown bellow, then take off the USB module altogether with the USB & Audio cable. Detach the CPU Cooler Disconnect the CPU cooler power cable. Release the CPU Cooler latch, then remove it. Chapter 3...

  • Page 67: Remove The Memory

    Remove the Memory Push and release those two latches to remove the memory. Remove the System Fan Release those four screws on back panel to remove the fan. Remove the Main board Release those eight screws marked to remove the main board. Chapter 3...

  • Page 68: Remove The Power Supply

    Remove the Power Supply Release those four screws marked to remove the Power Supply. Remove the CPU Release the CPU latch on the Socket and remove the CPU. Chapter 3...

  • Page 69: Aspire E360 Desassembly Procedure

    Aspire E360 Disassembly Procedure Open the Computer Place the system unit on a flat and steady surface. Release the lock handle and slide the left cover out. Remove the PCI Lift the PCI lock up and remove it. Pull out the VGA card. Chapter 3...

  • Page 70: Detach The Cpu Cooler

    Pull out the CD_IN cable from TV tuner card. Pull out the TV tuner card. Pull out the Modem card. Detach the CPU Cooler Disconnect the CPU Cooler power cable. Chapter 3...

  • Page 71: Remove The Memory

    Release the CPU Cooler latch then remove it. Remove the Memory Press those latches on the left and right sides to pop up the four memories. Disconnect the Cables Disconnect the Audio cable and CD_IN cable. Chapter 3...
  • Page 72 Disconnect the USB, Card Reader and Front LED ASSY cables. Disconnect the 12V power cable, System Fan cable and 1394 cable from the main board connectors. Disconnect the P1 power cable and ODD data cable from the main board. Disconnect the FDD data cable from the main board connector. Chapter 3...
  • Page 73 Pull out the FDD data cable and power cable from the FDD and disconnect the IR cable between the front bezel and Card Reader module. Pull out the slave ODD power cable and data cable. Disconnect the bezel LED cable and the ODD power cable. Pull out the master ODD data cable and power cable.

  • Page 74: Disassemble The Hdd, Odd, Fdd And Card Reader

    10. Disconnect the HDD data cables and power cables from the rear of the HDD. 11. Disconnect the HDD data cables from the main board. Disassemble the HDD, ODD, FDD and Card Reader Release the HDD rails to disassemble the two HDDs. Chapter 3...
  • Page 75 Release the three latches marked to separate the front bezel from the housing case, then lead the cables out. Release the ODD rails and disassemble the two ODDs. Release the FDD rail and disassemble the FDD. Release the rail and remove the Card Reader. Chapter 3...

  • Page 76: Disassemble The Usb Module

    Disassemble the USB Module Release the screw marked as arrow indicates, then detach the USB module altogether with the USB & Audio cables. Remove the System Fan Release the four screws marked as photo, then detach the fan. Remove the Main Board Release the eight screws marked as photo, then take out the main board.

  • Page 77: Remove The Power Supply

    Remove the Power Supply Release the four screws marked as photo, then detach the power supply. Separate the CPU from the Main Board Release the CPU latch on the socket, then remove the CPU. Chapter 3...

  • Page 78: Chapter 4 Troubleshooting

    Chapter 4 Troubleshooting This chapter provides troubleshooting information for the Aspire T160/E360 and AcerPower M6 Power-On Self-Test (POST) Index of Error Message Index of Error Symptoms Undetermined Problems Chapter 4...
  • Page 79 Power-On Self-Test (POST) Each time you turn on the system, the Power-on Self Test (POST) is initiated. Several items are tested during POST, but is for the most part transparent to the user. The Power-On Self Test (POST) is a BIOS procedure that boots the system, initializes and diagnoses the system components, and controls the operation of the power-on password option.
  • Page 80 Checkpoint Reserved Initial Superio_Early _Init switch Reserved 1. Blank out screen 2. Clear CMOS error flag Reserved 1. Clear 8042 interface 2. Initialize 8042 self-test 1. Test special keyboard controller for Win bond 977 series Super I/O chips. 2. Enable keyboard interface. Reserved 1.
  • Page 81 Checkpoint 1. Check validity of RTC value: e.g. a value of 5Ah is an invalid value for RTC minute. 2. Load CMOS settings into BIOS stack. If CMOS checksum fails, use default value instead. 3. Prepare BIOS resource map for PCI & PnP use. If ESCD is valid, take into consideration of the ESCD’s legacy information.
  • Page 82 Checkpoint Reserved Test 8259 interrupt mask bits for channel 2 Reserved Reserved Test 8259 functionality Reserved Reserved Reserved Initialize EISA slot Reserved 1. Calculate total memory by testing the last double word of each 64K. 2. Program writes allocation for AMD K5 CPU. Reserved Reserved Reserved...
  • Page 83 Checkpoint Reserved Reserved Reserved Reserved Initialize PS/2 Mouse Reserved Prepare memory size information for function call: INT 15h ax=E820h Reserved Turn on L2 cache Reserved Program chipset registers according to items described in Setup & Auto- configuration table. Reserved 1. Assign resources to all ISA PnP devices. 2.
  • Page 84 Checkpoint 1. Call chipset power management hook. 2. Recover the text fond used by EPA logo (not for full screen logo) 3. If password is set, ask for password. Save all data in stack back to CMOS. Initialize ISA PnP boot devices. 1.

  • Page 85: Post Error Messages List

    POST Error Messages List If you cannot run the diagnostics program tests but did receive a POST error message, use “POST Error Messages List” to diagnose system problems. If you did not receive any error message, look for a description of your error symptoms in Error Symptoms List NOTE: When you have deemed it necessary to replace an FRU, and have done so, you must run a total system check to ensure that no other activity has been affected by the change.
  • Page 86 BIOS Messages Keyboard Error Or No Keyboard Present Keyboard is locked out - Unlock the key Memory Test: Memory test fail Override enabled - Defaults loaded Press TAB to show POST screen Primary master hard disk fail Primary slave hard disk fail Secondary master hard disk fail Secondary slave hard disk fail Chapter 4...

  • Page 87: Error Symptoms List

    Error Symptoms List NOTE: To diagnose a problem, first find the error symptom in the left column. If directed to a check procedure, replace the FRU indicated in the check procedure. If no check procedure is indicated, the first Action/ FRU listed in right column is the most likely cause.
  • Page 88 Error Symptom Diskette drive read/write error. Diskette drive LED comes on for more than 2 minutes when reading data. Diskette drive LED fails to light, and the drive is unable to access for more than 2 minutes. Diskette drive test failed. NOTE: Ensure hard disk drive is configured correctly in BIOS Setup, cable/jumper are set correctly before diagnosing any hard disk drive problems.
  • Page 89 Error Symptom CD/DVD-ROM drive does not read and there are no messages are displayed. CD/DVD-ROM drive can play audio CD but no sound output. Real-time clock is inaccurate. Audio software program invokes but no sound comes from speakers. Modem ring cannot wake up system from suspend mode.
  • Page 90 Error Symptom Display problem not listed above (including blank or illegible monitor). Chapter 4 Action/FRU 1. “Monitor" 2. Load default settings (if screen is readable). 3. Main board...
  • Page 91 Error Symptom Execute “Load BIOS Default Settings” in BIOS Setup to confirm ports presence before diagnosing any parallel/serial ports problems. Serial or parallel port loop-back test failed. Printing failed. Printer problems. Some or all keys on keyboard do not work. Pressing power switch does not turn off system.

  • Page 92: Undetermined Problems

    Check all cables and connectors for proper installation. If the jumpers, switches and voltage settings are correct, remove or disconnect the following, one at a time: 10. Non-Acer devices External devices Any adapter card (modem card, LAN card or video card, if installed)

  • Page 93: Jumper And Connector Information

    Jumper and Connector Information Connectors Introduction Item Description ATX_12V ATX (Power Connector) CPU_FAN SYS_FAN IDE1 / IDE2 SATA1 / SATA2 / SATA3 / SATA4 F_PANEL F_AUDIO CD_IN 11, 17 F_USB1 / F_USB2/F_USB3 Chapter 5 Chapter 5 Item Description F_1394 SPDIF_OUT CLR_CMOS INTR SPEAKER...

  • Page 94: Atx_12V/Atx (Power Connector)

    ATX_12V / ATX (Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the main board. Before connecting the power connector, please make sure that all components and devices are properly installed.
  • Page 95 Illustration Jumper / Header Name Pin No. and Definition ATX Power Header 1: 3.3V 2: 3.3V 3: GND 4: +5V 5: GND 6: +5V 7: GND 8: Power Good 9: 5V SB (stand by +5V) 10: +12V 11: +12V 12: 3.3V (only for 24-pin ATX) 13: 3.3V 14: -12V 15: GND...

  • Page 96: Cpu Fan/System Fan (Cooler Fan Power Conncetor)

    CPU FAN / SYSTEM FAN (Cooler Fan Power Connector) The cooler fan power connector supplies a +12V power voltage via a 3-pin/4-pin (only for CPU FAN) power connector and possesses a fool-proof connection design.Most coolers are designed with color-coded power connector wires.

  • Page 97: Fdd (Floppy Connector)

    FDD (Floppy Connector) The FDD connector is used to connect the FDD cable while the other end of the cable connects to the FDD drive. The types of FDD drives supported are 1.44MB and 2.88MB.Please connect the red power connector wire to the pin1 position.

  • Page 98: Ide1/Ide2 (Ide Connector)

    Illustration IDE1 / IDE2 (IDE Connector) An IDE device connects to the computer via an IDE connector. One IDE connector can connect to one IDE cable, and the single IDE cable can then connect to two IDE devices (hard drive or optical drive). If you wish to connect two IDE devices, please set the jumper on one IDE device as Master and the other as Slave.
  • Page 99 Illustration SLOT_IDERST IDE_PDD7 IDE_PDD8 IDE_PDD6 IDE_PDD9 IDE_PDD5 IDE_PDD10 IDE_PDD4 IDE_PDD11 IDE_PDD3 IDE_PDD12 IDE_PDD2 IDE_PDD13 IDE_PDD1 IDE_PDD14 IDE_PDD0 IDE_PDD15 IDE_DREQ_P IDE_IOW_P* IDE_IOR_P* IDE_IORDY_P IDE_DACK_P* IDE_INTR_P IDE_ADDR_P1 CBLE_DET_P IDE_ADDR_P0 IDE_ADDR_P2 IDE_CS1_P* IDE_CS3_P* P_HDLED* Chapter 5 Jumper / Header Name IDE Header Pin No. and definition 1: SLOT_IDERST 3: IDE_PDD7 5: IDE_PDD6...

  • Page 100: Sata1/Sata2/Sata3/Sata4 (Serial Ata Connector)

    Illustration SATA1 / SATA2 / SATA3 / SATA4 (Serial ATA Connector) Please refer to the BIOS setting for the Serial ATA and install the proper driver in order to work properly. Illustration SP_TX0P SP_TX0M SP_RX0M SP_RX0P Jumper / Header Name Jumper / Header Name Pin No.

  • Page 101: F_Panel (Front Panel Jumper)

    F_PANEL (Front Panel Jumper) Please connect the power LED, PC speaker, reset switch and power switch of the chassis front panel to the F_PANEL connector according to the pin assignment below. Illustration FP_1 Orange Green Orange Green G ND Blue FP_RESET*_FP Blue FP_9...

  • Page 102: F_Audio (Front Audio Panel Connector)

    F_AUDIO (Front Audio Panel Connector) If you want to use Front Audio connector, you must remove 5-6 and 9-10 Jumpers. In order to utilize the front audio header, your chassis must have front audio connector. Make sure the pin assignment on the cable is the same as the pin assignment on the main board header.

  • Page 103: Cd_In (Cd In Connector, Black)

    CD_IN (CD In Connector, Black) Connect CD-ROM or DVD-ROM audio out to the CD_IN connector. Illustration F_ USB1 / F_USB2 / F_USB3 (Front USB Connector) Be careful with the polarity of the front USB connector. Check the pin assignment carefully while you connect the front USB cable, incorrect connection between the cable and connector will make the device unable to work or even damage it.

  • Page 104: F_1394 (Ieee 1394 Connector)

    Illustration VCC 1 D0- 3 D0+ 5 GND 7 F_1394 (IEEE 1394 Connector) Serial interface standard set by Institute of Electrical and Electronics Engineers, which has features like high speed, high bandwidth and hot plug. Be careful with the polarity of the IEEE1394 connector. Check the pin assignment while connecting the IEEE 1394 cable.

  • Page 105: Spdif_Out (Spdif Out)

    Illustration SPDIF_OUT (SPDIF Out) The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby Digital Decoder. This feature works only when your stereo system has digital input function. Be careful with the polarity of the SPDIF_OUT connector. Check the pin assignment while connecting the SPDIF_OUT cable.

  • Page 106: Clr_Cmos (Clear Cmos)

    CLR_CMOS (Clear CMOS) You may clear the CMOS data to its default values by this jumper. To clear CMOS, temporarily short 1-2 pin. Default doesn't include the shunter to prevent from improper use this jumper. Illustration 3 VCC_RTC 2 RTC_RSTJ 1 GND INTR (Intruder, Case Open Header) This 2-pin header allows the system to enable or disable the “Case Open”...

  • Page 107: Bat(Battery)

    Illustration BAT(Battery) Illustration How to erase CMOS Turn OFF the computer and unplug the power cord. Remove the battery, wait for 30 seconds. Re-install the battery. Plug the power cord and turn ON the computer. Chapter 5 Jumper / Header Name Pin No.

  • Page 108: Chapter 6 Fru (Field Replaceable Unit) List

    NOTE: To scrap or to return the defective parts, you should follow the local government ordinance or regulations on how best to dispose it, or follow the rules set by your regional Acer office on how to return it.You can access to the web site for the latest Parts version http://aicsl.acer.com.tw/spl/...

  • Page 109: Aspire E360 Exploded Diagram

    Aspire E360 Exploded Diagram Item Description 5.25 Rotate Cover A451 Bezel Optical Drive FDD with Panel Motherboard HDD Lock Slide FDD Lock Slide CDROM Lock Slide USB Board USB Bracket Right Cover Chassis Power Supply PCI Bracket Left Cover Chapter 6...

  • Page 110: Acerpower M6 Exploded Diagram

    AcerPower M6 Exploded Diagram Item Chapter 6 Description 3.5” Cover 5.25” Cover Front Bezel Optical Drive FDD with Panel Motherboard HDD Lock Slide FDD Lock Slide CDROM Lock Slide USB board USB bracket Right Cover Chassis Power Supply PCI Bracket Left Cover...

  • Page 111: Parts

    FRU parts for the repair and service of customers’ machines. NOTE: To scrap or to return the defective parts, please follow the local government ordinance or regulations on how to dispose it, or follow the rules set by your regional Acer office on how to return it. Aspire T160...
  • Page 112 SOHW-1633S (black) SHOW-1673S DVD DUAL DRIVE 16X DOUBLE-LAYER BLACK LF HLDS GWA-4164B 16X DVD DUAL (DL), PIONEERDVR-109RA. LF, BLACK COLOR FANSINK PKP280G01K12 FAN PV763DJ4DK6341 PKP280 W/I FAN DUCT KDE1209PTV3-A Acer Part No. 60.V20VF.004 60.V20VF.005 60.V20VF.006 42.V19VF.005 42.V19VF.006 42.V19VF.007 42.V19VF.008 42.V02VF.503 33.RC9VF.004 PZ.P3108.001...
  • Page 113 SDA3000DIO2BP SDA3200DIO3BP FDD,PANASONIC,JU-256A198P BLACK VGA CARD LTK LR2A13 GF 6200TC SE 64M (32BIT) 256MB VGA+TVO PAL W/ATX BKT LEADTEK LR2A1J LR2A1J Pro-Nets HPI56MIII with ATX bkt 1024-7C50-1A-AC Acer Part No. KC.A3802.X26 KC.A4202.X26 KC.A4402.X20 KC.A4602.X26 KC.A4802.X20 KC.A3802.X24 KC.A4202.X20 KC.A4602.X20 KC.A3002.E39 KC.A3202.E39 KC.A3402.E39...
  • Page 114 WINTV-HVR1100 DVB-T PAL OXFORD 94500 REV C2A0 WINTV-HVR1100 DVB-T PAL OXFORD 94500 REV C2A0 LF WINTV-HVR1300 DVB-T PAL DOVER 96559 (C1A0) KYE MOUSE,PS/2 MOUSE, 2 BUTTON+WHEEL MOUSE PS2 2B WHEEL SI+BK POWRSCOLL Acer Part No. 54.ATIX3.H23 54.ATIX3.H03 54.ATIX6.H01 54.ATIX6.H02 54.ATIX6.H13 FX.56I02.010 TU.61302.001 TU.61102.001...
  • Page 115 STK LABEL, BLACK PS/2 OPTICAL MOUSE, SBF96 PS/2 OPTICAL MOUSE, SBF96, LEAD-FREE MOUSE USB WHEEL STANDARD POWERSCROLL ACER (002) MOUSE SCROLL WHEEL USB BK KYE ACER MOUSE USB WHEEL OPTICAL POWERSCROLL EYEUSB ACER (002) KEYBOARD WIRELESS, KBR0355, EN, CHICONY KEYBOARD WIRELESS, KBR0355, TC, CHICONY LOGITECH WIRELESS KB, COCOON,US VER.,...
  • Page 116 PS/2 KEYBOARD,KB 2971,US VER.,104KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,ARABIC VER.,104KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,INT'L US VER.,104KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,UK VER.,104KEYS,JAPAN ABS (WITH EKEY) Acer Part No. KB.KBP03.163 KB.KBP03.164 KB.KBP03.165 KB.KBP03.166 KB.KBP03.167 KB.KBP03.168 KB.KBP03.169 KB.KBP03.170 KB.KBP03.171...
  • Page 117 VER.,104KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,ITALIAN NEW LAYOUT,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,ROMANIAN VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,TURKEY/FRENCH VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 Keyboard,KB2971,US Ver.,104KS(with eKey), LF Acer Part No. KB.KBP03.190 KB.KBP03.191 KB.KBP03.192 KB.KBP03.193 KB.KBP03.194 KB.KBP03.195 KB.KBP03.196 KB.KBP03.197 KB.KBP03.198...
  • Page 118 VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,BELGIUM VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,DUTCH VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,HOLLAND VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,SPANISH VER.,105KS,JPN ABS(WITH EKEY),LF BLACK Acer Part No. KB.KBP03.217 KB.KBP03.218 KB.KBP03.219 KB.KBP03.220 KB.KBP03.221 KB.KBP03.222 KB.KBP03.223 KB.KBP03.224 KB.KBP03.225 KB.KBP03.226...
  • Page 119 PS/2 KEYBOARD,KB2971,ROMANIAN VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,TURKEY/FRENCH VER.,105KS,JPN ABS(WITH EKEY),LF BLACK USB KEYBOARD,KU-0355,US VER.,104KS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,T.CHINESE VER.,104KS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD, KU-0355, S.CHINESE, 104KS(WITH EKEY),LF SILVER+BLACK Acer Part No. KB.KBP03.238 KB.KBP03.239 KB.KBP03.240 KB.KBP03.241 KB.KBP03.242 KB.KBP03.243 KB.KBP03.244 KB.KBP03.245 KB.KBP03.246 KB.KBP03.247...
  • Page 120 SILVER+BLACK USB KEYBOARD,KU-0355,UK VER.,104KS,JPN ABS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,SPANISH VER.,105KS,JPN ABS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,DUTCH VER.,105KS,JPN ABS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,PORTUGESE VER.,105KS,JPN ABS(WITH EKEY),LF SILVER+BLACK Acer Part No. KB.KUS03.180 KB.KUS03.181 KB.KUS03.182 KB.KUS03.183 KB.KUS03.184 KB.KUS03.185 KB.KUS03.186 KB.KUS03.187 KB.KUS03.188 KB.KUS03.189 KB.KUS03.190 KB.KUS03.191 KB.KUS03.192...
  • Page 121 SILVER+BLACK USB KEYBOARD,KU-0355,ITALIAN NEW LAYOUT,105KS,JPN ABS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,ROMANIAN VER.,105KS,JPN ABS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,TURKEY/FRENCH VER.,105KS,JPN ABS(WITH EKEY),LF SILVER+BLACK PS/2 KEYBOARD, KBP2971, US VER., 104KEYS Acer Part No. KB.KUS03.199 KB.KUS03.200 KB.KUS03.201 KB.KUS03.202 KB.KUS03.203 KB.KUS03.204 KB.KUS03.205 KB.KUS03.206 KB.KUS03.207 KB.KUS03.208 KB.KUS03.209 KB.KUS03.210...
  • Page 122 PS/2 KEYBOARD, KBP2971, SLOVENIAN VER., 105KEYS PS/2 KEYBOARD, KBP2971, SLOVAKIAN VER., 105KEYS PS/2 KEYBOARD, KBP2971, TURKEY VER., 105KEYS PS/2 KEYBOARD, KBP2971, RUSSIAMVER., 104KEYS PS/2 KEYBOARD, KBP2971, HUNGARIA VER., 105KEYS Acer Part No. KB.KBP03.067 KB.KBP03.068 KB.KBP03.069 KB.KBP03.070 KB.KBP03.071 KB.KBP03.072 KB.KBP03.073 KB.KBP03.074 KB.KBP03.075 KB.KBP03.076...
  • Page 123 105KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, RUSSIAMVER., 104KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, HUNGARIA VER., 105KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, GREEK VER., 104KEYS, JAPAN ABS BLACK Acer Part No. KB.KBP03.094 KB.KBP03.095 KB.KBP03.097 KB.KBP03.098 KB.KBP03.099 KB.KBP03.101 KB.KBP03.102 KB.KBP03.103...
  • Page 124 USB KEYBOARD, KU0355, HEBREW VER., 105KEYS USB KEYBOARD, KU0355, POLISH VER., 105KEYS USB KEYBOARD, KU0355, SLOVENIAN VER., 105KEYS USB KEYBOARD, KU0355, SLOVAKIAN VER., 105KEYS USB KEYBOARD, KU0355, TURKEY VER., 105KEYS Acer Part No. KB.KBP03.123 KB.KBP03.124 KB.KUP03.034 KB.KUP03.035 KB.KUP03.036 KB.KUP03.037 KB.KUP03.038 KB.KUP03.039 KB.KUP03.040 KB.KUP03.041...
  • Page 125 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, POLISH VER., 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, SLOVENIAN VER., 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, SLOVAKIAN VER., 105KEYS, JAPAN ABS SLIVER+BLACK Acer Part No. KB.KUS03.021 KB.KUS03.022 KB.KUS03.023 KB.KUS03.024 KB.KUS03.058 KB.KUS03.062 KB.KUS03.063...
  • Page 126 HDD,160G 7200RPM,SATAII,WD1600JS- 22MHB0,WD HDD,200G 7200RPM,SATAII,WD2000JS- 22MHB0,WD HDD,250G 7200RPM,SATAII,WD2500JS- 22MHB0,WD HDD 80GB 7200RPM PATHFINDER ROHS SATA 2.08M HGST IV HDT722516DLA380 HDD,160G 7200RPM,SATAII,HDT722516DLA380,HGST HDD,250G 7200RPM,SATAII,HDT722525DLA380,HGST HDD,400G/7200RPM SATA2,HDS724040KLSA80,HGST Acer Part No. KB.KUS03.082 KB.KUS03.083 KB.KUS03.084 KB.KUS03.085 KB.KUS03.086 KB.KUS03.087 KH.08001.009 KH.12001.011 KH.16001.010 KH.20001.005 KH.25001.002 KH.30001.004 KH.40001.002 KH.25001.004...
  • Page 127 SCREW M3X8(VFD BRACKET/UPPER COVER) SCREW #6-32 SPEAKER SPEAKER 2.0 USB M-1118B ACER LOGO SPEAKER 2.0 USB M-1118B ACER LOGO W/ STK LABEL 2.0 SPEAKER, S100, 230V W/ ACA PLUG TYPE, ACER LOGO SPEAKER USB 3" *2 NEOSONICA 510 THYME510 WHITE SPEAKER USB 3"...
  • Page 128 (EUROPE EXCLUDE UK) 2.1 SPEAKER, VS2221, 230V, UK PLUG TYPE 2.1 SPEAKER, VS2221, 230V, CHINA PLUG TYPE 2.0 SPEAKER, S100, 110V W/ US PLUG TYPE, ACER LOGO Aspire E360 Partname BOARD DAUGHTER BOARD USB/AUDIO SPDIF BOARD W/ CABLE USB RF RECEIVER BOARD GUPPY W/O...
  • Page 129 EMPTY COVER POWER BUTTON ODD COVER 1 W/ HOLDER ODD COVER 2 W/ HOLDER TOP COVER ASSY FRONT COVER WITH ACER LOGO FILLER COVER FOR 3 1/2” DEVICE CHASSIS W/O SIDE DOOR W/O I/O SHIELD H401 SIDE DOOR-LEFT SIDE DOOR-RIGHT...
  • Page 130 ADA4600DAA5BV ADA3000DAA4BP ADA3200DAA4BP ADA3400DAA4BZ ADA3500DAA4BP ADA3500DKA4CG ADA3800DAA4BP ADA3500DAA4BN ADA3200DKA4CG ADA3700DAA5BN ADA4000DAA5BN ADA3000DAA4BW ADA3200DAA4BW ADA3400DAA4BY ADA3500DAA4BW ADA3700DKA5CF ADA3800DAA4BW ADA4000DKA5CF SDA3000DIO2BW Acer Part No. KV.0160D.007 KU.0160D.007 KU.01604.002 KU.01604.005 KU.0160D.006 KU.01605.002 HI.2800C.001 HI.P260C.001 HI.P310F.001 KC.A3802.X26 KC.A4202.X26 KC.A4402.X20 KC.A4602.X26 KC.A4802.X20 KC.A3802.X24 KC.A4202.X20 KC.A4602.X20 KC.A3002.E39 KC.A3202.E39...
  • Page 131 TV with H/W MPEG2 encoder, PAL Leadtek MCE compliance TV card+ FM + analog TV with H/W MPEG2 encoder, NTSC LR306 TV TUNER CARD W/I(ATX/FM ANT- TENA/AV IN CABLE/PAL-NTSC DUAL TV TUNER CARD(ATX/FM ANTTENA/AV/ PAL-NTSC/DVB-T ANTENNA) Acer Part No. KC.S3202.9E6 KC.S3402.9E6 KC.S3502.9E6 KC.S3002.90E KC.S3202.90E KF.25602.003 VG.62SET.C01...
  • Page 132 PS/2 BALL MOUSE M-SBJ96 BLACK W/ STK LABEL LOGITECH PS/2 BALL MOUSE, SBJ69, LEAD-FREE, BLACK PS/2 BALL MOUSE, SBJ69, LEAD-FREE, W/ STK LABEL, BLACK PS/2 OPTICAL MOUSE, SBF96 PS/2 OPTICAL MOUSE, SBF96, LEAD-FREE Acer Part No. TV.HAU11.001 TV.AMITY.H21 TV.AMITY.H22 TV.AMITY.H23 TV.HAUDV.BT1 TV.HAUDV.BT2 TV.HAUDV.BT3 TV.HAU13.HV1...
  • Page 133 PS/2 KEYBOARD,KB 2971,PORTUGESE VER.,105KEYS (WITH EKEY) Description MOUSE USB WHEEL STANDARD POWER- SCROLL ACER (002) MOUSE SCROLL WHEEL USB BK KYE ACER MOUSE USB WHEEL OPTICAL POWER- SCROLL EYEUSB ACER (002) KEYBOARD WIRELESS, KBR0355, EN, CHI- CONY KEYBOARD WIRELESS, KBR0355, TC, CHI- CONY LOGITECH WIRELESS KB, COCOON,US VER.,...
  • Page 134 VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,SWEDISH VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,BELGIUM VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,DUTCH VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,HOLLAND VER.,105KEYS,JAPAN ABS (WITH EKEY) Acer Part No. KB.KBP03.174 KB.KBP03.175 KB.KBP03.176 KB.KBP03.177 KB.KBP03.178 KB.KBP03.179 KB.KBP03.180 KB.KBP03.181 KB.KBP03.182...
  • Page 135 VER.,104KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,ARABIC VER.,104KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,THAI VER.,104KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,INT'L US VER.,104KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,CANADIAN/FRENCH VER.,105KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,BRAZILIAN VER.,107KS(WITH EKEY),LF BLACK Acer Part No. KB.KBP03.198 KB.KBP03.199 KB.KBP03.200 KB.KBP03.201 KB.KBP03.202 KB.KBP03.203 KB.KBP03.204 KB.KBP03.205 KB.KBP03.206 KB.KBP03.207 KB.KBP03.208...
  • Page 136 VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,SLOVENIAN VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,SLOVAKIAN VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,TURKEY VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,RUSSIAM- VER.,104KS,JPN ABS(WITH EKEY),LF BLACK Acer Part No. KB.KBP03.223 KB.KBP03.224 KB.KBP03.225 KB.KBP03.226 KB.KBP03.227 KB.KBP03.228 KB.KBP03.229 KB.KBP03.230 KB.KBP03.231 KB.KBP03.232...
  • Page 137 USB KEYBOARD,KU-0355,US VER.,104KS,JPN ABS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,IN'L US VER.,104KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,ARABIC VER.,104KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,GERMANY VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK Acer Part No. KB.KBP03.247 KB.KBP03.248 KB.KBP03.249 KB.KBP03.250 KB.KBP03.251 KB.KBP03.252 KB.KBP03.253 KB.KUS03.177 KB.KUS03.178 KB.KUS03.179 KB.KUS03.180...
  • Page 138 VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,SLOVENIAN VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,SLOVAKIAN VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,TURKEY VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK Acer Part No. KB.KUS03.192 KB.KUS03.193 KB.KUS03.194 KB.KUS03.195 KB.KUS03.196 KB.KUS03.197 KB.KUS03.198 KB.KUS03.199 KB.KUS03.200 KB.KUS03.201 KB.KUS03.202 KB.KUS03.203...
  • Page 139 PS/2 KEYBOARD, KBP2971, BRAZILIAN VER., 107KEYS PS/2 KEYBOARD, KBP2971, UK VER., 104KEYS PS/2 KEYBOARD, KBP2971, FRENCH VER., 105KEYS PS/2 KEYBOARD, KBP2971, GERMANY VER., 105KEYS PS/2 KEYBOARD, KBP2971, ITALIAN VER., 105KEYS Acer Part No. KB.KUS03.209 KB.KUS03.210 KB.KUS03.211 KB.KUS03.212 KB.KUS03.213 KB.KUS03.214 KB.KUS03.215 KB.KUS03.216 KB.KBP03.066 KB.KBP03.067...
  • Page 140 104KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, INT'L US VER., 104KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, UK VER., 104KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, FRENCH VER., 105KEYS, JAPAN ABS BLACK Acer Part No. KB.KBP03.078 KB.KBP03.079 KB.KBP03.080 KB.KBP03.081 KB.KBP03.082 KB.KBP03.083 KB.KBP03.084...
  • Page 141 105KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, CZECH VER., 104KEYS, JAPAN ABS BLACK USB KB(SILVER), KU0355, US VER., 104KEYS USB KB(SILVER), KU0355, T.CHINESE VER., 104KEYS USB KB(SILVER), KU0355, INT'L US VER., 104 KEYS Acer Part No. KB.KBP03.104 KB.KBP03.105 KB.KBP03.106 KB.KBP03.107 KB.KBP03.108 KB.KBP03.109 KB.KBP03.110 KB.KBP03.111...
  • Page 142 USB KEYBOARD, KU0355, SLOVENIAN VER., 105KEYS USB KEYBOARD, KU0355, SLOVAKIAN VER., 105KEYS USB KEYBOARD, KU0355, TURKEY VER., 105KEYS USB KEYBOARD, KU0355, RUSSIAMVER., 104KEYS USB KEYBOARD, KU0355, HUNGARIA VER., 105KEYS Acer Part No. KB.KUP03.037 KB.KUP03.038 KB.KUP03.039 KB.KUP03.040 KB.KUP03.041 KB.KUP03.042 KB.KUS03.001 KB.KUS03.002 KB.KUS03.003 KB.KUS03.004...
  • Page 143 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, SLOVENIAN VER., 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, SLOVAKIAN VER., 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, TURKEY VER., 105KEYS, JAPAN ABS SLIVER+BLACK Acer Part No. KB.KUS03.023 KB.KUS03.024 KB.KUS03.058 KB.KUS03.062 KB.KUS03.063 KB.KUS03.064 KB.KUS03.065...
  • Page 144 22MHB0,WD HDD,160G 7200RPM,SATAII,WD1600JS- 22MHB0,WD HDD,200G 7200RPM,SATAII,WD2000JS- 22MHB0,WD HDD,250G 7200RPM,SATAII,WD2500JS- 22MHB0,WD HDD 80GB 7200RPM PATHFINDER ROHS SATA 2.08M HGST IV HDT722516DLA380 HDD,160G 7200RPM,SATAII,HDT722516DLA380,HGST HDD,250G 7200RPM,SATAII,HDT722525DLA380,HGST Acer Part No. KB.KUS03.083 KB.KUS03.084 KB.KUS03.085 KB.KUS03.086 KB.KUS03.087 KH.08001.009 KH.12001.011 KH.16001.010 KH.20001.005 KH.25001.002 KH.30001.004 KH.40001.002 KH.25001.004 KH.30001.006...
  • Page 145 SCREW#6-32UNC SCREW M3X8(VFD BRACKET/UPPER COVER) SCREW #6-32 SPEAKER SPEAKER 2.0 USB M-1118B ACER LOGO SPEAKER 2.0 USB M-1118B ACER LOGO W/ STK LABEL 2.0 SPEAKER, S100, 230V W/ ACA PLUG TYPE, ACER LOGO SPEAKER USB 3" *2 NEOSONICA 510 THYME510 WHITE SPEAKER USB 3"...
  • Page 146 A2.1 110V SPEAKER A2.1 WITH CCC STICKER NEOSON- ICA A2.1 220V 2.0 SPEAKER, S100, 230V W/ EUROPE PLUG TYPE, ACER LOGO 2.0 SPEAKER, VS2220, 230V, A PLUG TYPE 2.1 SPEAKER, VS2221, 230V, E PLUG TYPE (EUROPE EXCLUDE UK) 2.1 SPEAKER, VS2221, 230V, UK PLUG TYPE 2.1 SPEAKER, VS2221, 230V, CHINA PLUG...
  • Page 147 LF W/ DASP 52X COMBO, HLDS GCC-4522B LF, BLACK GCC-4522B, LF w/ DASP SOHC-5236V, LF w/ DASP DVD-122CHG 16X DVD-ROM, LITEON SOHD-16P9S, LF, BLACK COLOR DVD-ROM DRIVE 16X/52X HLDS GDR-8163B BLACK Acer Part No. 50.V14VF.001 50.V20VF.001 50.V20VF.002 50.V19VF.003 50.PSPVF.003 50.P06VF.002 60.P22VF.001 60.V20VF.004 60.V20VF.005...
  • Page 148 ADA4600DAA5BV ADA3000DAA4BP ADA3200DAA4BP ADA3400DAA4BZ ADA3500DAA4BP ADA3500DKA4CG ADA3800DAA4BP ADA3500DAA4BN ADA3200DKA4CG ADA3700DAA5BN ADA4000DAA5BN ADA3000DAA4BW ADA3200DAA4BW ADA3400DAA4BY ADA3500DAA4BW ADA3700DKA5CF ADA3800DAA4BW ADA4000DKA5CF SDA3000DIO2BW Acer Part No. KV.0160D.007 KU.0160D.007 KU.01604.002 KU.01604.005 KU.0160D.006 KU.01605.002 HI.2800C.001 HI.P260C.001 HI.P310F.001 KC.A3802.X26 KC.A4202.X26 KC.A4402.X20 KC.A4602.X26 KC.A4802.X20 KC.A3802.X24 KC.A4202.X20 KC.A4602.X20 KC.A3002.E39 KC.A3202.E39...
  • Page 149 Leadtek MCE compliance TV card+ FM + analog TV with H/W MPEG2 encoder, PAL Leadtek MCE compliance TV card+ FM + analog TV with H/W MPEG2 encoder, NTSC LR306 TV TUNER CARD W/I(ATX/FM ANTTENA/ AV IN CABLE/PAL-NTSC Acer Part No. KC.S3202.9E6 KC.S3402.9E6 KC.S3502.9E6 KC.S3002.90E KC.S3202.90E KF.25602.003...
  • Page 150 USB OPTICAL MOUSE, UV69A, SILVER+BLACK USB OPTICAL MOUSE, UV69A, SILVER+BLACK, W/ STK LABEL MOUSE PS2 BALL M-SBJ96 BK LOGITECH PS/2 BALL MOUSE M-SBJ96 BLACK W/ STK LABEL LOGITECH PS/2 BALL MOUSE, SBJ69, LEAD-FREE, BLACK Acer Part No. TU.30605.002 TV.HAU11.001 TV.AMITY.H21 TV.AMITY.H22 TV.AMITY.H23 TV.HAUDV.BT1 TV.HAUDV.BT2...
  • Page 151 LABEL, BLACK PS/2 OPTICAL MOUSE, SBF96 PS/2 OPTICAL MOUSE, SBF96, LEAD-FREE MOUSE USB WHEEL STANDARD POWER- SCROLL ACER (002) MOUSE SCROLL WHEEL USB BK KYE ACER MOUSE USB WHEEL OPTICAL POWERSCROLL EYEUSB ACER (002) KEYBOARD WIRELESS, KBR0355, EN, CHI- CONY...
  • Page 152 VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,ITALIAN VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,SWISS VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,SWEDISH VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 KEYBOARD,KB 2971,BELGIUM VER.,105KEYS,JAPAN ABS (WITH EKEY) Acer Part No. KB.KBP03.172 KB.KBP03.173 KB.KBP03.174 KB.KBP03.175 KB.KBP03.176 KB.KBP03.177 KB.KBP03.178 KB.KBP03.179 KB.KBP03.180...
  • Page 153 VER.,105KEYS,JAPAN ABS (WITH EKEY) PS/2 Keyboard,KB2971,US Ver.,104KS(with eKey),LF PS/2 KEYBOARD,KB2971,S.CHINESE VER.,104KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,ARABIC VER.,104KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,THAI VER.,104KS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,INT'L US VER.,104KS(WITH EKEY),LF BLACK Acer Part No. KB.KBP03.196 KB.KBP03.197 KB.KBP03.198 KB.KBP03.199 KB.KBP03.200 KB.KBP03.201 KB.KBP03.202 KB.KBP03.203 KB.KBP03.204 KB.KBP03.205 KB.KBP03.206...
  • Page 154 VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,HEBREW VER.,104KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,POLISH VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,SLOVENIAN VER.,105KS,JPN ABS(WITH EKEY),LF BLACK PS/2 KEYBOARD,KB2971,SLOVAKIAN VER.,105KS,JPN ABS(WITH EKEY),LF BLACK Acer Part No. KB.KBP03.221 KB.KBP03.222 KB.KBP03.223 KB.KBP03.224 KB.KBP03.225 KB.KBP03.226 KB.KBP03.227 KB.KBP03.228 KB.KBP03.229 KB.KBP03.230...
  • Page 155 USB KEYBOARD,KU-0355,CANADIAN/FRENCH VER.,105KS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,BRAZILIAN VER.,107KS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,JPNESE,109KS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,US VER.,104KS,JPN ABS(WITH EKEY),LF SILVER+BLACK USB KEYBOARD,KU-0355,IN'L US VER.,104KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK Acer Part No. KB.KBP03.245 KB.KBP03.246 KB.KBP03.247 KB.KBP03.248 KB.KBP03.249 KB.KBP03.250 KB.KBP03.251 KB.KBP03.252 KB.KBP03.253 KB.KUS03.177 KB.KUS03.178...
  • Page 156 VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,NORWEGIAN VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,HEBREW VER.,104KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK USB KEYBOARD,KU-0355,POLISH VER.,105KS,JPN ABS(WITH EKEY),LF SIL- VER+BLACK Acer Part No. KB.KUS03.190 KB.KUS03.191 KB.KUS03.192 KB.KUS03.193 KB.KUS03.194 KB.KUS03.195 KB.KUS03.196 KB.KUS03.197 KB.KUS03.198 KB.KUS03.199 KB.KUS03.200 KB.KUS03.201...
  • Page 157 PS/2 KEYBOARD, KBP2971, THAI VER., 104KEYS PS/2 KEYBOARD, KBP2971, SPANISH/US VER., 105KEYS PS/2 KEYBOARD, KBP2971, INT'L US VER., 104KEYS PS/2 KEYBOARD, KBP2971, CANADIAN/ FRENCH VER., 105KEYS PS/2 KEYBOARD, KBP2971, BRAZILIAN VER., 107KEYS Acer Part No. KB.KUS03.206 KB.KUS03.207 KB.KUS03.208 KB.KUS03.209 KB.KUS03.210 KB.KUS03.211 KB.KUS03.212 KB.KUS03.213 KB.KUS03.214 KB.KUS03.215...
  • Page 158 105KEYS PS/2 KEYBOARD, KBP2971, GREEK VER., 104KEYS PS/2 KEYBOARD, KBP2971, DENMARK VER., 105KEYS PS/2 KEYBOARD, KBP2971, CZECH VER., 104KEYS PS/2 KEYBOARD, KBP2971, US VER., 104KEYS, JAPAN ABS BLACK Acer Part No. KB.KBP03.074 KB.KBP03.075 KB.KBP03.076 KB.KBP03.077 KB.KBP03.078 KB.KBP03.079 KB.KBP03.080 KB.KBP03.081 KB.KBP03.082 KB.KBP03.083...
  • Page 159 104KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, HUNGARIA VER., 105KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, GREEK VER., 104KEYS, JAPAN ABS BLACK PS/2 KEYBOARD, KBP2971, DENMARK VER., 105KEYS, JAPAN ABS BLACK Acer Part No. KB.KBP03.099 KB.KBP03.101 KB.KBP03.102 KB.KBP03.103 KB.KBP03.104 KB.KBP03.105 KB.KBP03.106...
  • Page 160 USB KEYBOARD, KU0355, ICELAND VER., 105KEYS USB KEYBOARD, KU0355, NORWEGIAN VER., 105KEYS USB KEYBOARD, KU0355, HEBREW VER., 105KEYS USB KEYBOARD, KU0355, POLISH VER., 105KEYS USB KEYBOARD, KU0355, SLOVENIAN VER., 105KEYS Acer Part No. KB.KBP03.124 KB.KUP03.034 KB.KUP03.035 KB.KUP03.036 KB.KUP03.037 KB.KUP03.038 KB.KUP03.039 KB.KUP03.040 KB.KUP03.041 KB.KUP03.042...
  • Page 161 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, ICELAND VER., 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, NORWEGIAN VER., 105KEYS, JAPAN ABS SLIVER+BLACK USB KEYBOARD, KU-0355, HEBREW VER., 105KEYS, JAPAN ABS SLIVER+BLACK Acer Part No. KB.KUS03.019 KB.KUS03.020 KB.KUS03.021 KB.KUS03.022 KB.KUS03.023 KB.KUS03.024 KB.KUS03.058...
  • Page 162 (ROHS) SEAGATE ST3400832AS 160G WD 3.5" 7200RPM XL80IIWD1600JD- 22HBC0 ROHS SATA 8M HDD,80G 7200RPM,SATAII,WD800BD- 22LRA0,WD HDD,80G 7200RPM,SATAII,WD800JD- 22LSA0,WD HDD,120G 7200RPM,SATAII,WD1200JS- 22MHB0,WD HDD,160G 7200RPM,SATAII,WD1600JS- 22MHB0,WD HDD,200G 7200RPM,SATAII,WD2000JS- 22MHB0,WD Acer Part No. KB.KUS03.079 KB.KUS03.080 KB.KUS03.081 KB.KUS03.082 KB.KUS03.083 KB.KUS03.084 KB.KUS03.085 KB.KUS03.086 KB.KUS03.087 KH.08001.009 KH.12001.011 KH.16001.010 KH.20001.005...
  • Page 163 POWER SUPPLY 300W W/ PFC LITEON PS- 6301-08AP SCREW CHASSIS SCREW SCREW#6-32UNC SCREW M3X8(VFD BRACKET/UPPER COVER) SCREW #6-32 SPEAKER SPEAKER 2.0 USB M-1118B ACER LOGO Description HDD,250G 7200RPM,SATAII,WD2500JS- 22MHB0,WD HDD 80GB 7200RPM PATHFINDER ROHS SATA 2.08M HGST IV HDT722516DLA380 HDD,160G 7200RPM,SATAII,HDT722516DLA380,HGST HDD,250G...
  • Page 164 Partname SPEAKER 2.0 USB M-1118B ACER LOGO W/ STK LABEL 2.0 SPEAKER, S100, 230V W/ ACA PLUG TYPE, ACER LOGO SPEAKER USB 3" *2 NEOSONICA 510 THYME510 WHITE SPEAKER USB 3" *2 NEOSONICA THYME510 BLACK SPEAKER 2+1 SUB-WOOFER NEOSONICA A2.1 220V SPEAKER 2+1 SUB-WOOFER NEOSONICA A2.1 110V...

This manual is also suitable for:

Acerpower m6Aspire ase360Aspire ast160Aspire t160Aspire e360

Table of Contents
