Project Nursery PNM4N11 User Manual

With digital zoom camera
Hide thumbs Also See for PNM4N11:
Table of Contents

Advertisement

Quick Links

User Guide
What's inside
Welcome!................................................................. 2
Getting.started. . ..................................................... 3
Tour.of.the.system................................................ 7
Everyday.use. . ........................................................12
Cameras............................................................. 13
Motion/Alerts. . .................................................16
Sleep.Mode. . ................................................... 20
Lullabies............................................................. 21
Display...............................................................22
Settings.............................................................23
Troubleshooting./.FAQs...................................26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PNM4N11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Project Nursery PNM4N11

Summary of Contents for Project Nursery PNM4N11

  • Page 1: Table Of Contents

    What’s inside Welcome!..............2 Getting.started............3 Tour.of.the.system..........7 Everyday.use............12 Cameras............. 13 Motion/Alerts...........16 User Guide Sleep.Mode............. 20 Lullabies............. 21 Display...............22 Settings.............23 Troubleshooting./.FAQs........26...

  • Page 2: Welcome

    WELCOME! Step 1: Unpack This.baby.monitoring.system. makes.it.simple.to.keep.your. eyes.and.ears.on.your.little. one!.This.guide.takes.you. through.the.steps.to.get. started! Parent monitor Wireless camera See our setup videos Go.to.ProjectNursery.com/ Electronics.or.scan.the.QR.code. here. The accessories: Before you start... (2).10-foot.charging.cables (2).power.adapters Make.sure.you.read.the.Important.Information. sheet.included.in.this.package.

  • Page 3: Getting.started

    GETTING STARTED Step 2: Charge the monitor WARNING Strangulation Find.one.of.the.charging. cables.included.in.this. Hazard: package. Children.have. Plug.one.end.of.this.cable.into. STRANGLED. the.USB CHARGING.jack.on. in.cords..Keep. the.side.of.the.parent.monitor.. this.cord.out. of.the.reach.of.children.(more. than.3ft.(0.9m).away)..Never. Plug.the.other.end.of.the. use.extension.cords.with.AC. charging.cable.into.one.of.the. Adapters..Only.use.the.AC. included.charging.adapters.. Adapters.provided. Then.plug.the.adapter.into.an. outlet.or.surge.protector.
  • Page 4 Step 4: Plug in the camera(s) Step 3: Position the camera(s) Find.the.other.charging.cable(s).included.in. Find.a.location.for.the. this.package. camera.that.gives.you.the. best.view.of.your.baby.in.his. or.her.crib. Plug.one.end.into.the. CHARGING.jack.on.the. back.of.the.camera(s).. Place.the.camera.on.a.flat.surface,.like.a. dresser.or.shelf,.or.mount.the.camera.to.a.wall. Plug.the.other.end.into. using.the.keyhole.slots.on.its.bottom. a.charging.adapter..Then. plug.the.adapter.into.an. IMPORTANT: NEVER.place.the.camera.or.cords. outlet.or.surge.protector. of.any.kind.inside.the.crib..NEVER.place.the. camera.or.cords.within.reach.of.the.baby. Important Note About Camera Position Position.the.camera.as.shown.here,. with.the.neck.slanting.away.from. the.camera.face..This.gives.the. best.range.of.movement..
  • Page 5 Step 5: Turn on the camera Step 7: Set your preferred language (optional) Press.the.POWER.button.on. the.back.of.the.camera.to. You.can.change.the.language.of.the.menus. turn.the.camera.on. screens.in.the.Settings.menu. Press.the.MENU.button.on.the.parent. monitor..The.menu.appears.on.screen.. Use.the.arrows.to.highlight.SETTINGS..Press. OK/ZOOM.to.select.it..The.Settings.menu. Step 6: Turn on the monitor appears.on.screen. Press.the.down.arrow.to.highlight. Language..Press.OK/ZOOM.to.select.it.. Press.and.hold.the.POWER. button.on.the.parent.monitor. Use.the.up/down.arrow.buttons.to.English,. for.three.seconds.to.turn.the. Français,.or.Español..Press.OK/ZOOM. monitor.on. when.you’re.finished.. Congratulations! Your.system.is.ready.to.use!.The.camera(s). comes.pre-paired.with.your.parent.monitor.
  • Page 6 Step 8: Set the time on the monitor Press.the.MENU.button.on.the.parent. Press.the.down.arrow.to.highlight.Time Set.. monitor..The.menu.appears.on.screen.. Press.OK/ZOOM.to.select.it.. 72º 12:00AM Temperature Time Set Language Factory Reset Support Product Information Use.the.up/down.arrow.buttons.to.set.the. Use.the.arrows.to.highlight.SETTINGS..Press. hours,.minutes,.and.AM/PM..Press.OK/ OK/ZOOM.to.select.it..The.Settings.menu. ZOOM.when.you’re.finished.. appears.on.screen. 72º 12:00AM 72º 12:00AM Temperature Time Set Time: 12:00 AM Language Factory Reset Support...

  • Page 7: Tour.of.the.system

    TOUR OF THE SYSTEM Parent Monitor .accesses.the.system’s.menu.screens. .turns.the.monitor.on.and.off.(press.and. hold). and. .turn.the.volume.down/up..In.menu. screens,.these.navigate.left/right.. .zooms.the.camera.in/out.. .and. .navigate.up/down.in.menu.screens. SOUND LEVEL indicators show.you.the.level.of. sound.from.your.baby’s.room. Watching baby .lets.you.talk.through.the.camera’s. speaker..Press.and.hold.while.talking. You.can.turn.the.display.on.and.off.without. turning.the.monitor.off..You’ll.still.hear.your. baby,.but.the.display.and.SOUND LEVEL. .turns.the.screen.on.and.off..Press.and. indicators.will.be.asleep.until.you.awaken. hold.to.switch.cameras.(if.you.have.multiple. them. cameras). To turn the display on or off:.Press.the. VIDEO.button.on.the.parent.monitor.
  • Page 8 Parent monitor side and back panels Foldable antenna USB CHARGING jack plugs.into.your.charging.cable.to.recharge. or.power.the.parent.monitor.. Built-in easel stand lets.you.stand.the.unit.on.a.flat.surface. Built-in easel Foldable antenna improves.reception.from.the.wireless. stand camera—extend.it.to.increase.range. Zoom Talking to baby Listening to baby The.SOUND LEVEL. To zoom the active camera:. To talk through the speaker indicators.on.the.parent.
  • Page 9 Status Bar Indicators Parent monitor .shows.the.strength.of.the.current.camera’s.signal. Temperature reading.shows.the.temperature.in.Fahrenheit. 72º 2:35 PM at.the.active.camera..If.you.want.to.change.this.to.Celsius,. see.page.18.for.instructions.. Temperature .shows.the.camera.that.the.monitor.is.currently. reading displaying. .indicates.that.the.Low.Battery.Noise.alert.is.on..This. means.the.monitor.gives.an.audio.signal.when.it.needs.to. be.recharged..See.page.18.for.instructions.on.turning.this. on.and.off. .indicates.that.Motion.Activated.Video.Alert.is.on..This. means.the.monitor.automatically.switches.on.whenever. the.camera.detects.motion..See.page.16.for.instructions.on. turning.this.on.and.off. .indicates.that.Sound.Activated.Video.Alert.is.on..This. means.the.monitor.automatically.switches.on.whenever. the.camera.detects.sound..See.page.17.for.instructions.on. turning.this.on.and.off. .indicates.that.Temperature.Alert.is.on..This.means. the.monitor.shows.an.alert.message.if.the.temperature. at.a.camera.gets.too.high.or.too.low..See.page.18.for. instructions.on.setting.temperature.alerts..
  • Page 10 .indicates.the.Lullabies.are.playing.through.one.of.the.cameras..See.page.21.for.instructions.on. playing.lullabies. .indicates.that.the.camera.is.using.night.vision..The.cameras.automatically.switch.to.night.vision. when.they.detect.that.the.room.has.gotten.dark. .indicate.that.the.monitor.is.scanning.through.the.available.cameras..The.number. indicates.how.quickly.the.monitor.switches.cameras..See.page.15.for.information.on.turning. camera.scanning.on.and.off. .indicates.the.level.of.the.monitor’s.rechargeable.battery..If.you.see. .or. .in.this.space,. it’s.time.to.recharge..See.page.3.for.more.information. On-Screen Indicators appears.when.you’ve.pressed.the.TALK.button.and.are.talking.through.the.camera’s. speaker..See.page.8.for.more.information. appears.when.the.monitor.cannot.get.the.signal.from.the.active.camera..See.page.26.for. more.information.. appears.when.a.Temperature.Alert.has.been.triggered.because.your.baby’s.room.is.too.hot. or.cold.. appears.when.the.monitor’s.rechargeable.battery.has.less.than.10%.charge..
  • Page 11 Camera (front, back, and side) Microphone Nighttime sensor Important Note About Camera Position Thermal Position.the. sensor camera.as.shown. here,.with.the. neck.slanting.away. from.the.camera. face..This.gives. the.best.range.of. movement.. Mounting keyholes POWER (back) turns.the.camera.on.and.off.(press.and.hold). PAIR (back) links.the.camera.securely.with.the.monitor.(press.and.hold). CHARGING (back) plugs.into.your.charging.cable.to.recharge.or.power.the.camera. Mounting keyholes (bottom).let.you.mount.the.camera.on.a.wall.(mounting.hardware.not. included). Thermal sensor detects.the.temperature.around.the.camera.

  • Page 12: Everyday.use

    3. EVERYDAY USE This system’s menus let you set 72º 12:00AM up more cameras, set motion and temperature alerts, and much more. This section takes you through each menu. Parent Monitor Menu GETTING AROUND IN THE MENUS Press.MENU.to.access.the.menus. Use.the.arrows.to. highlight.items. Press.OK/ZOOM.to.

  • Page 13: Cameras

    Cameras The.Cameras.menu.lets.you.pair.additional.cameras.or.remove. them.from.your.list.of.cameras..If.you.have.multiple.cameras,. this.menu.also.lets.you.scan.through.them.one.by.one.. ACCESSING THE CAMERAS MENU Parent Monitor Front Press.MENU.on.the.parent.monitor..Use.the.arrow.buttons.to.highlight.the.Cameras.icon,.and. press.OK/ZOOM.to.select.it. PAIRING AN ADDITIONAL CAMERA 12:00AM 72º View Camera .. Before.you.start.pairing.the.monitor.with.your.new.camera,. Scan Cameras bring.the.camera.into.the.same.room.so.that.you.have.it. Pair Camera Delete Camera handy..You.can.put.it.back.in.the.baby’s.room.once.you’ve. finished.pairing..Make.sure.the.camera.is.plugged.in.and. turned.on.before.you.start. In.the.Cameras.menu,.press.the.down.arrow.to.highlight.Pair Camera..Press.OK/ZOOM.to.select.it..
  • Page 14 .. Press.the.Pair.button.on.the.bottom.of.the.new.camera. .. Use.the.up/down.arrows.to.select Camera 2,.Camera 3,.or. Camera 4..Press.OK/ZOOM.to.select.it..If.the.monitor.screen.shows.a.green.checkmark.next.to. Camera,.you’re.all.set.to.use.the.monitor.and.the.camera!.(If. it.shows.a.red.X,.put.the.camera.closer.to.the.monitor.and. try.again.) VIEWING AND SCANNING CAMERAS 72º 12:00AM You.can.customize.how.you.view.your.cameras.on.screen. View Camera Scan Cameras Pair Camera To view a different camera: Delete Camera .. In.the.Cameras.menu,.highlight.View Camera..Press.OK/ ZOOM.to.select.it.. 12:00AM 72º ..
  • Page 15 To scan through the cameras automatically: .. In.the.Cameras.menu,.highlight.Scan Cameras..Press.OK/ ZOOM.to.select.it. .. Use.the.up/down.arrows.to.select.how.quickly.you.want. to.switch.cameras:.every.5,.10,.or.15.seconds..Press.OK/ ZOOM.to.select.that.option..The.screen.switches.to.the.first. camera,.and.the.status.bar.at.the.top.of.the.screen.shows.an. indicator.for.scanning:. ,.or. ..It.also.shows.the. NOTE:.You.must.have.more. camera.you’re.viewing. than.one.camera.paired.with. To stop scanning cameras:.select.Scan Cameras.in.the. a.monitor.in.order.to.scan. Cameras.menu..Then.select.Scan: Off. cameras. REMOVING A CAMERA FROM THE LIST .. In.the.Cameras.menu,.highlight.Delete Camera..Press.OK/ ZOOM.to.select.it..

  • Page 16: Motion/Alerts

    Motion/Alerts The.Motion/Alerts.menu.lets.you.set.up.alerts.that.are.activated. by.motion,.sound,.or.temperature.in.your.baby’s.room..It.also. lets.you.set.up.an.alert.for.when.the.monitor’s.rechargeable. battery.needs.to.be.recharged.. Parent Monitor ACCESSING THE MOTION/ALERTS MENU Front Press.MENU.on.the.parent.monitor..Use.the.arrow.buttons.highlight.the.Motion/Alerts.icon,. and.press.OK/ZOOM.to.select.it. SETTING UP MOTION ACTIVATION 72º 12:00AM You.can.set.up.the.monitor.so.that.it.automatically.turns.on. Motion Activated Video: OFF Sound Activated Video: OFF video.when.the.camera.detects.that.your.baby.is.moving. Temperature Alert: OFF Low Battery Noise Alert: OFF Out of Range Alert: OFF In.the.Motion/Alerts.menu,.press.OK/ZOOM.to.select.
  • Page 17 .. Use.the.up/down.arrows.to.select.the.amount.of.sensitivity. 72º 12:00AM you.want.for.the.motion.sensor:.ON: Low,.ON: Medium,.or. Motion Activated Video ON: High..The.status.bar.at.the.top.of.the.screen.shows.an. Sound Activated Video: OFF ON: LOW Temperature Alert: OFF ON: Medium indicator.for.motion.activation:. Low Battery Noise Alert: OFF ON: High Out of Range Alert: OFF Notes:. •. You.might.want.to.test.different.levels.of.sensitivity.for. this.alert,.to.find.the.best.fit.for.your.environment.and. preference.
  • Page 18 SETTING TEMPERATURE ALERTS 12:00AM 72º These.alerts.tell.you.when.your.baby’s.room.is.too.hot.or.too. Motion Activated Video: OFF Sound Activated Video: ON cold. Temperature Alert High Temp: ON: 81 Low Battery Noise Alert: OFF Out of Range Alert: OFF In.the.Motion/Alerts.menu,.select.Temperature Alert.. Low Temp: ON: 63 .. Activate.the.temperature.alert.you.want.to.use,.then.set.it.. The.status.bar.at.the.top.of.the.screen.will.show.an.indicator. for.temperature.alerts:.
  • Page 19 SETTING AN OUT-OF-RANGE ALERT 12:00AM 72º This.alert.tells.you.when.the.monitor.is.disconnected.from.or. Motion Activated Video: OFF out.of.range.of.the.camera.(for.example,.if.the.camera’s.lost. Sound Activated Video: OFF Temperature Alert: OFF power). Low Battery Noise Alert: ON Out of Range Alert In.the.Motion/Alerts.menu,.highlight.Out of Range Alert.and. press.OK/ZOOM.to.select.it..Use.the.up/down.arrows.to.turn.the.out-of-range.alert.on. or.off..The.status.bar.at.the.top.of.the.screen.shows.an. indicator.for.the.out-of-range.alert:. ..

  • Page 20: Sleep.mode

    Sleep Mode You.can.set.up.your.monitor.to.turn.off.the.display. automatically.after.a.set.amount.of.time.. Parent Monitor ACCESSING THE SLEEP MODE MENU Front Press.MENU.on.the.parent.monitor..Use.the.arrow.buttons.to.highlight.the.Sleep Mode.icon,. and.press.OK/ZOOM.to.select.it. SETTING SLEEP MODE 72º 12:00AM Sleep Mode (video off, sound on) In.the.Sleep Mode.menu,.press.OK/ZOOM.to.turn.sleep. mode.on. ON: 5 mins ON: 30 mins ON: 60 mins ..

  • Page 21: Lullabies

    Lullabies This.Project.Nursery.system.comes.with.3.lullabies,.a.nature. sound,.and.white.noise.ready.to.play—simply.choose.the.one. you.want,.and.the.camera.you’re.on.will.play.it.back. PLAYING LULLABIES OR WHITE NOISE Parent Monitor Front Make.sure.the.monitor.is.displaying.the.camera.you.want.to. play.the.lullaby.on..If.you.want.to.play.on.a.different.camera,. press.the.MENU.button.and.select.CAMERAS..Then.press. OK/ZOOM.to.select.View Camera.and.choose.the.camera. you.want. .. Press.the.MENU.button.to.access.the.main.menu. .. Highlight.LULLABIES.and.press.OK/ZOOM.to.choose.it. .. Highlight.the.option.you.want.to.play.and.press.OK/ZOOM. 72º 12:00AM to.start.playing.it..The.status.bar.at.the.top.of.the.screen. “Mozart” shows.an.indicator.for.lullabies:. .. “Twinkle, Twinkle Little Star” “Brahms’ Lullaby” White Noise Waves Play All NOTE:.If.there’s.a.lullaby.currently.playing.on.a.camera,.a.green.arrow.

  • Page 22: Display

    Display You.can.adjust.the.brightness.of.the.display,.and.set.it.to. automatically.dim.after.a.set.amount.of.time.. ADJUSTING BRIGHTNESS Parent Monitor Press.MENU.on.the.parent.monitor.. Front .. Use.the.arrow.buttons.to.highlight.the.Display.icon,.and. press.OK/ZOOM.to.select.it. In.the.Display.menu,.highlight.Adjust Brightness,.and.press. OK/ZOOM.to.select.it. .. Use.the.up.and.down.arrows.to.adjust.the.brightness..Press. OK/ZOOM.when.you’ve.finished. SETTING AUTO DIMMING 72º 12:00AM In.the.Display.menu,.highlight.Auto Dimming..Press.OK/ Adjust Brightness ZOOM.to.select.it. Auto Dimming .. Use.the.up.and.down.arrows.to.choose.the.delay.for.auto. dimming.the.display:.5,.10,.or.30.minutes..Press.OK/ZOOM. to.select.

  • Page 23: Settings

    Settings The.Settings.menu.lets.you.customize.the.monitor.to.match. your.preferences..It.also.gives.you.technical.information.about. the.monitor.and.support.. ACCESSING THE SETTINGS MENU Parent Monitor Press.MENU.on.the.parent.monitor.. Front .. Use.the.arrow.buttons.to.highlight.the.Settings.icon,.and. press.OK/ZOOM.to.select.it. SETTING YOUR TEMPERATURE PREFERENCE 72º 12:00AM Temperature In.the.Settings.menu,.press.OK/ZOOM.to.select. Time Set Temperature. Language Factory Reset Support Product Information .. Use.the.up.and.down.arrows.to.select.how.you’d.like. temperature.to.be.displayed:.in.degrees.Fahrenheit.or. Celsius..Press.OK/ZOOM.when.you’ve.finished.
  • Page 24 SETTING THE TIME 72º 12:00AM In.the.Settings.menu,.press.the.down.arrow.to.highlight. Temperature Time Set Time: 12:00 AM Time Set..Press.OK/ZOOM.to.select.it.. Language Factory Reset Support .. Use.the.up/down.arrows.to.set.the.time..Press.OK/ZOOM. Product Information when.you’re.finished. SETTING YOUR PREFERRED LANGUAGE 72º 12:00AM Temperature .. In.the.Settings.menu,.press.the.down.arrow.to.highlight. Time Set Language..Press.OK/ZOOM.to.select.it.. Language English Factory Reset Français Español Support ..
  • Page 25 RESETTING TO FACTORY SETTINGS 72º 12:00AM If.you’ve.tried.all.of.the.troubleshooting.solutions.to.solve. Temperature Time Set a.problem,.and.nothing.seems.to.work,.you.might.need.to. Factory Reset Reset to Factory Default? Support reset.the.monitor.to.its.factory.settings.and.start.setup.again.. Product Information Cancel WARNING: Resetting to factory settings erases all of your custom settings. You will have to set up the monitor from scratch...

  • Page 26: Troubleshooting./.Faqs

    4. TROUBLESHOOTING / FAQS Most.issues.with.the.Project.Nursery.baby.monitoring.system.can.be.solved.by.following.one.of. the.troubleshooting.tips.below..For.additional.assistance,.please.call.1-844-393-7338. I don’t see video from the camera on my monitor. +. Make.sure.your.monitor.is.turned.on.(press.the.Power.button)..If.it.is,.press.the.VIDEO.button. to.make.sure.the.monitor’s.display.is.awake..Make.sure.the.camera.is.plugged.in.to.a.working. outlet.and.turned.on.. I see the icon on the screen. +. Make.sure.the.camera.you’re.trying.to.view.is.plugged.in.to.a.working.outlet.and.turned.on. +. Make.sure.the.monitor.is.within.range.(maximum.800.ft).of.the.camera.you’re.trying.to.display. (certain.kinds.of.signal.obstacles,.like.large.metal.objects,.might.shorten.the.range.somewhat). +. The.monitor.you’re.using.might.have.become.un-paired.with.the.camera..See.page.13.for. instructions.on.pairing.a.monitor.and.camera. I can’t hear sounds from baby’s room. +.
  • Page 27 The temperature alerts don’t work. +. Make.sure.you’ve.set.the.temperature.preference.to.the.system.you.use,.Fahrenheit.(standard. in.the.US).or.Celsius.(standard.outside.the.US)..To.switch.your.temperature.preference,.go.to. Settings.>.Temperature. +. Make.sure.you’ve.set.the.right.kind.of.temperature.alert—for.example,.if.you.want.to.make.sure. your.baby’s.room.does.not.get.below.68.degrees.Fahrenheit,.set.the.Low Temp Temperature Alert.to.68..If.you.want.to.make.sure.your.baby’s.room.doesn’t.get.above.a.certain. temperature,.set.the.High Temp Temperature Alert.to.that.temperature. Motion alerts don’t work. +. You.might.need.to.adjust.the.sensitivity.of.the.alerts—for.example,.if.Motion Activated Video. is.set.to.ON: Low,.the.monitor.will.not.come.on.as.often.as.when.Motion Activated Video.is. set.to.ON: Medium.or.ON: High..To.adjust.this.setting,.go.to.Motion/Alerts.>.Motion Activated Video.. +. If.you.have.multiple.cameras,.motion.activation.turns.on.the.monitor.to.the.last.displayed. camera..It.doesn’t.automatically.switch.to.the.camera.where.motion.was.detected. Sound alerts don’t work. +.
  • Page 28 ©2017.Voxx.Accessories.Corp.. 3502.Woodview.Trace,.Suite.220. Indianapolis,.IN.46268 PNM4N11.UG.03...
