Bluesound Powernode N150 Owner's Manual page 12

IDENTIFICATION OF CONTROLS
4 SPEAKERS
• • • • Connect the right speaker to the terminals marked "R +" and "R-" ensuring that "R+" is connected to the "+"
terminal on your loudspeaker and "R-" is connected to the loudspeaker's "-" terminal.
• • • •
Connect the left speaker to the terminals marked "L +" and "L-" ensuring that "L+" is connected to the "+"
terminal on your loudspeaker and "L-" is connected to the loudspeaker's "-" terminal.
• • • •
Use extra care to ensure that no stray wires or strands cross between posts or terminals at either end.
5 SUBW (SUBWOOFER) OUT
A Subwoofer can also be connected directly to the N150. Connect SUBW OUT to a powered ("active") subwoofer.
6 USB (TYPE A)
• • • •
Connect a USB mass storage device to the USB input. Typical USB mass storage devices compatible with
POWERNODE N150 include portable flash memory devices and external hard drives (FAT32 formatted).
7 USB (TYPE B MINI)/SERVICE
• • • •
Use SERVICE in conjunction with USB (Type B Mini) for servicing purposes only. Not for consumer use. Only
authorized Bluesound service personnel can access this USB port and SERVICE control button.
8 LAN
LAN connection must be setup for Wired connection to be established. Set up a Wired Ethernet broadband router
with broadband internet connection. Your router or home network should have a built-in DHCP server to
consummate the connection.
• • • •
Using the supplied standard straight-through Ethernet cable, connect one end of the Ethernet cable to the
LAN port of your wired Ethernet broadband router and the other end to POWERNODE N150's LAN port.
12
