WIRE DIMENSIONS

Recommended minimum wire dimensions in mm²
WIRE 0.5 m
+IN 2.5 mm
+OUT 2.5 mm
+A 2.5 mm
+SIGNAL 1.5 mm
–GROUND 1.5 mm
20015884B D250TS, Manual, Print file 001.indd 7
MIN WIRE DIMENSIONS
1 m 2 m 5 m 10 m
2.5 mm 4 mm 4 mm 4 mm
2 2 2 2
2.5 mm 4 mm 6 mm 6 mm
2 2 2 2
2.5 mm 4 mm 6 mm 6 mm
2 2 2 2
1.5 mm 1.5 mm 1.5 mm 1.5 mm
2 2 2 2
1.5 mm 1.5 mm 1.5 mm 1.5 mm
2 2 2 2

TEChNICAL SPECIFICATIONS

Charger model
Model number
Input voltage
Charging voltage
2
Charging current
Equalization current
2
Equalization voltage
2
Back current drain
Current ripple
2
Ambient temperature
2
Status signal
Battery types
Battery capacity
Dimensions
Insulation class
Weight
CTEK D250TS
1048
14–30 V
28.8 V at 25°C, temperature compensated. Voltage reduced at
higher voltage, increased at lower.
10 A
Max 10 A, average pending time used for Starter battery
charging
50 % of input voltage
<1 Ah/month
<4 %
-20°C to +50°C, output power reduced automatically at high
temperatures
+24 V ON when D250TS is working properly. Max current
500 mA.
All types of lead-acid batteries
(WET, MF, Ca/Ca, AGM and GEL)
20–200 Ah
192 x 110 x 65 mm (L x W x H)
IP65
0.7 kg
