SAFERA Connection Hub User Manual page 5

4.1 Testing AUX-channles with home automation systems
1. Make a factory reset for the sensor
unit: while pressing and holding
the adjustment mode button ❼,
press first the OK-button ❷ and
then the child proof lock button
❶. After a couple of seconds, the
indicator light panels ❽ should lit
purple.
2. While the indicator light panels ❽
are lit purple, test the AUX-chan-
nels:
• To activate AUX1 (alarm), press and hold the child proof lock button ❶
• To activate AUX2 (cooking on), press and hold the OK-button ❷
3. When you have finished testing, press the adjustment mode button ❼ and pair
the sensor unit again with the PCU normally according to the installation manual.
5. Removing the Connection Hub or CTU
from a Safera System
Connection Hub and CTU cannot be removed by normal means. The system's oper-
ating principle is that once they are installed, their removal will always raise an error
event. In a special case where removal is necessary, contact local Safera Support for
instructions.
8
2 5 6 1
9
4 3
8
7
