Thunderbolt Port Driver - Clevo N130WU User Manual

Thunderbolt Port Driver

If you have included the Thunderbolt 3 port (factory option) in your purchase
configuration then you need to install the driver.
Before installing the Thunderbolt driver it is necessary to initialize the port first.
To do so simply insert any USB Type C device (e.g. a USB flash drive) into the port
(see Figure 1 - 8 on page 1 -
1. Insert the Device Drivers & Utilities + User's Manual disc into an attached
DVD drive.
2. Click Option Drivers (button).
3. Click 3.Install TBT Driver > Yes.
4. Click the check box to accept the license and then click Install.
5. Click Finish.
6. See also "Intel (R)Thunderbolt Support (Advanced Menu > Intel(R)
Thunderbolt)" on page 5 - 11
BIOS.
14). You may then install the driver as below.
for Thunderbolt port configuration in the
Modules & Options
Thunderbolt Port Driver 6 - 21
6
