  • Page 1 N140WU / N141WU...
  • Page 3 Preface Notebook Computer N140WU / N141WU Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the N140WU / N141WU series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup °...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Bottom ................... A-4 LCD ....................A-5 Overview ..................1-1 MB ....................A-6 Specifications ..................1-2 Schematic Diagrams......... B-1 External Locator - Top View with LCD Panel Open ......1-4 External Locator - Front & Right Side Views .........1-5 System Block Diagram ..............B-2 External Locator - Left Side &...
  • Page 12 Preface WLAN/BT, 3G ................B-28 M Key PCIE SSD ................. B-29 SATA, LED, LID, SW ..............B-30 USB Port / TPM ................B-31 Conn, CCD, Fan, TP, LED KB ............ B-32 3V, 5V, 3VS, 5VS, 1.8VS CTL ........... B-33 VDD3, VDD5 ................B-34 VDDQ, VDDQ_VTT, 1.5VS, 1.8VA ..........

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the N140WU / N141WU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Video Adapter Intel® Core™ i7 Processor Intel Integrated GPU i7-8550U (1.80GHz) Intel HD Graphics 620 8MB Smart Cache, 14nm, DDR4-2400MHz, TDP 15W Dynamic Frequency  Intel® Core™ i5 Processor Intel Dynamic Video Memory Technology Latest Specification Information i5-8250U (1.60GHz) Microsoft DirectX®12 Compatible 6MB Smart Cache, 14nm, DDR4-2400MHz, TDP 15W...
  • Page 15 Introduction M.2 Slots Communication Slot 1 for WLAN and Bluetooth Combo Module Built-In 10/100/1000Mb Base-TX Ethernet LAN Slot 2 for SATA/PCIe Gen3 x4 SSD (Processor Dependent) 1.0M HD PC Camera Module (Factory Option) Slot 3 for 3G/4G Module (Factory Option) Infared Camera Module Card Reader (Factory Option) 3G or 4G M.2 Module Embedded Multi-In-1 Card Reader...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Microphone 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View 1. USB 3.0 (USB 3.1 Gen 1) Type-C Port RIGHT SIDE VIEW (Factory Option) Thunderbolt 3 Combo Port (Type- 2.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. USIM Card Reader (for 3G/4G LEFT SIDE VIEW USIM Cards) - Factory Option 3. USB 3.0 (USB 3.1 Gen 1) Type-A Port 4.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU 2. Memory Slots DDR4 SO-DIMM 3. KBC-ITE IT8587 Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. USB Board Connector 2. Keyboard Cable Connector 3. White LED Keyboard Connector 4. RJ-45 LAN Jack 5. HDMI-Out Port 6. Mini Display Port 7. USB Port 3.0/3.1 Type A Port 8.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Multi-in-1 Card Reader 2. Fan Connector 3. LCD Cable Connector 4. Speaker Connector 5. HDD Connector 6. Battery Connector 7. M.2 Card Connector (SSD) 8. 3G/4G Connector 9. WLAN Connector 10.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the N140WU / N141WU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a removal and/or replacement job, take the following precautions: Power Safety Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other components Warning could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Keyboard: To remove and install the M.2 SSD Module: 1.

  • Page 29: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 1 1. Turn off the computer, turn it over. Keyboard Removal 2. Remove screws from the bottom case (Figure 1a). 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- cific eject stick to do this) while releasing the keyboard in the direction of the arrow...

  • Page 30: Removing The Battery

    Disassembly Removing the Battery Figure 2 Battery Removal 1. Turn off the computer, turn it over to remove the keyboard (page 2 - 2. Remove screws (Figure 2a). a. Remove the screws. 3. Remove screws on the bottom case (Figure 2b).

  • Page 31: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 3 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7.0mm Removal (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 32 Disassembly 4. Slightly lift to pull the hard disk assembly in the direction of arrow (Figure 4c Figure 4 5. Lift the hard disk out of the bay (Figure 4d HDD Assembly 6. Reverse the process to install a new hard disk (do not forget to replace all the screws and bottom cover). Removal (cont’d.) c.

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 260 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR4 2133MHz. The main memory can be expanded up to 32GB. The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 34 Disassembly 5. Pull the latches to release the second module if necessary. 6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 7. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.

  • Page 35: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 6 Wireless LAN 1. Turn off the computer, turn it over to remove the keyboard (page 2 - 5) and battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 6a).

  • Page 36: Wireless Lan, And Combo Module Cables

    Disassembly Wireless LAN, and Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 37: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 7 3G Module Removal Procedure 3G Module Removal 1. Turn off the computer, turn it over to remove the keyboard (page 2 - 5) and battery (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 7a b.

  • Page 38: Removing And Installing The M.2 Ssd Module

    Disassembly Removing and Installing the M.2 SSD Module Figure 8 M.2 SSD-1 Module M.2 SSD-1 Removal Procedure Removal 1. Turn off the computer, turn it over to remove the keyboard (page 2 - 5) and battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 8a).
  • Page 39 Disassembly M.2 SSD-2 Removal Procedure Figure 9 1. Turn off the computer, turn it over to remove the keyboard (page 2 - 5) and battery (page 2 - M.2 SSD-2 Module 2. The M.2 SSD module will be visible at point on the mainboard (Figure 9a).
  • Page 40 Disassembly M.2 SSD Installation Procedure Figure 10 M.2 SSD Module 1. Place the thermal pad on the module as shown (Figure 10a). Installation 2. Insert the module in the computer Figure 10b 3. Tighten the screw to secure the module in place (Figure 10c) a.

  • Page 41: Removing The Ccd

    Disassembly Removing the CCD Figure 11 CCD Removal 1. Turn off the computer, turn it over to remove the keyboard (page 2 - 5) and battery (page 2 - 2. Lift up the inner frame and run your fingers around the inner frame of the LCD panel at the points as indicated by a.
  • Page 42 Disassembly 4. Disconnect the cable (Figure 12c). Figure 12 5. Remove the CCD module (Figure 12d). CCD Removal 6. Reverse the process to install a new CCD module. (cont’d.) c. Disconnect the cable. d. Remove the CCD mod- ule.  7.

  • Page 43: Part Lists

    Appendix A:Part Lists This appendix breaks down the N140WU / N141WU series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 44: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 page A - 6 A - 2...

  • Page 45: Top

    Figure A - 1 Top A - 3...

  • Page 46: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 47: Lcd

    Figure A - 3 LCD A - 5...
  • Page 48 Figure A - 4 A - 6 MB...

  • Page 49: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the N140WU / N141WU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...
  • Page 50 Schematic Diagrams System Block Diagram 6 IN 1 6-7P-N13W6-002 N140WU KABY LAKE RU4+2/U2+2 (HDCP2.2) System Block Diagram MAIN BOARD SHEET 1~39 6-71-N13W0-D02 USB BOARD 3V,5V,3VS,5VS,1.8VS 1866/ 2133 MHz 6-71-N13W3-D02 SHEET 40 DDR4 SHEET 32 DDR4 AUDIO BOARD SO-DIMM A SHEET 14...
  • Page 51 Schematic Diagrams Processor 1/10 M_A_DQ[63:0] M_B_DQ[63:0] AU53 DDR0_CKN[0] M_A_CLK_DDR#0 M_A_DQ0 M_B_DQ0 AL71 AT53 AF65 AN45 M_A_CLK_DDR0 M_B_CLK_DDR#0 DDR0_DQ[0] DDR0_CKP[0] DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKN[0] M_A_DQ1 AL68 AU55 M_B_DQ1 AF64 AN46 M_A_CLK_DDR#1 M_B_CLK_DDR#1 M_A_DQ2 DDR0_DQ[1] DDR0_CKN[1] M_B_DQ2 DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[1] AN68 AT55 AK65 AP45 DDR0_DQ[2] DDR0_CKP[1] M_A_CLK_DDR1 DDR1_DQ[2]/DDR0_DQ[18]...
  • Page 52 Schematic Diagrams Processor 2/10 17,18 MDP_D#0 DDI1_TXN[0] EDP_TXN[0] EDP_TXN_0 15,16 17,18 MDP_D0 DDI1_TXP[0] EDP_TXP[0] EDP_TXP_0 15,16 DIFF=85ohm, L <=2~10" 17,18 MDP_D#1 EDP_TXN_1 15,16 DDI1_TXN[1] EDP_TXN[1] 17,18 MDP_D1 EDP_TXP_1 15,16 DDI1_TXP[1] EDP_TXP[1] DIFF=85ohm, L <=6.9" 17,18 MDP_D#2 DDI1_TXN[2] EDP_TXN[2] EDP_TXN_2 17,18 MDP_D2 DDI1_TXP[2] EDP_TXP[2]...
  • Page 53 Schematic Diagrams Processor 3/10 SSIC / USB3 PCIE/USB3/SATA USB3_1_RXN USB3_1RXN USB3_1RXP USB3_1_RXP port1(2.0+3.0) USB3_1TXN PCIE_RXN1_TBT PCIE1_RXN/USB3_5_RXN USB3_1_TXN PCIE_RXP1_TBT USB3_1TXP PCIE1_TXN PCIE1_RXP/USB3_5_RXP USB3_1_TXP C437 0.22u_10V_X5R_04 PCIE_TXN1_TBT PCIE1_TXN/USB3_5_TXN PCIE1_TXP C435 0.22u_10V_X5R_04 PCIE_TXP1_TBT PCIE1_TXP/USB3_5_TXP USB3_2_RXN/SSIC_1_RXN USB3_2RXN USB3_2RXP USB3_2_RXP/SSIC_1_RXP USB3_2TXN PCIE_RXN2_TBT PCIE2_RXN/USB3_6_RXN USB3_2_TXN/SSIC_1_TXN PCIE_RXP2_TBT USB3_2TXP PCIE2_TXN PCIE2_RXP/USB3_6_RXP...
  • Page 54 Schematic Diagrams Processor 4/10 24Mhz SO C o r PC H V I A XTAL P OWE R or (For CPU U (15W) STUFF ) CLOCK SIGNALS C429 CPU U CLKOUT_PCIE_N0 12p_50V_NPO_04 CLKOUT_PCIE_P0 PCIECLKRQ0# AR10 GPP_B5/SRCCLKREQ0# GN D CLKOUT_ITPXDP_N CLKOUT_PCIE_N1 CLKOUT_ITPXDP_N R374 CLKOUT_ITPXDP_P...
  • Page 55 Schematic Diagrams Processor 5/10 STRAP PIN AUDIO Flash Descriptor Security Overide Low = Enable security measures defined in the Flash Descriptor. (Default) R381 33_04 HDA_SYC BA22 3.3VS TBT Detect HDA_SYNC High = Disable Flash Descriptor Security (override) HDA_BLK HDA_SYNC/I2S0_SFRM R376 33_04 AY22 HDA_BITCLK...
  • Page 56 Schematic Diagrams Processor 6/10 LPSS EDP & LVDS Detect 3.3VA STRAP PIN 3.3VS HIGH (Default) PCH_GPP_B15 3.3VA R404 10K_04 T_INT No Reboot GPP_B15/GSPI0_CS# PCH_GPP_B16 R127 *1K_04 GPP_D9 EDP_DET GPP_B16/GSPI0_CLK R405 10K_04 LVDS PCH_GPP_B17 20171213 delete GPP_D10 HIGH Enable “ No Reboot” mod e PCH_GPP_D11 SW I#_R...
  • Page 57 Schematic Diagrams Processor 7/10 RESERVED SIGNALS-1 CFG0 BB68 CFG[0] RSVD_TP_BB68 CFG1 BB69 CFG[1] RSVD_TP_BB69 CFG2 CFG[2] CFG3 AK13 CFG[3] RSVD_TP_AK13 CFG4 AK12 CFG[4] RSVD_TP_AK12 CFG5 CFG[5] CFG6 CFG[6] RSVD_BB2 CFG7 CFG[7] RSVD_BA3 CFG[8] CFG[9] CFG[10] CFG[11] CFG[12] CFG[13] CFG[14] RSVD_D5 CFG[15] RSVD_D4 RSVD_B2...
  • Page 58 Schematic Diagrams Processor 8/10 VCCIN VCCIN PROCESSOR CORE POWER c p u C110 C109 C144 C140 C124 C130 C132 C128 C127 1u_6.3V_X5R_04: 6-07-10521-2A0 1u_6.3V_X6S_04: 6-07-10521-5A0 CPU POWER 1 OF 4 10u_6.3V_X5R_06: 6-07-10611-2G0 10u_4V_X6S_06: 6-07-1061Q-5G0 VCC_A30 VCC_G32 VCC_A34 VCC_G33 C118 C112 C131 C100 C104...
  • Page 59 Schematic Diagrams Processor 9/10 0.696 A 1.0VA C212 C203 C211 C134 1u_6.3V_X5R_04 2.574 A 1.0VA CPU POWER 4 OF 4 C220 1u_6.3V_X5R_04 C440 22u_6.3V_X5R_06 AB19 VCCPRIM_1P0 0.020 A 3.3VA_GPP C224 10u_6.3V_X5R_06 AB20 AK15 *28mil short-p 3.3VA VCCPRIM_1P0 VCCPGPPA AG15 0.004 A VCCPRIM_1P0 VCCPGPPB 3/20 follow N740WU change to 10u...
  • Page 60 Schematic Diagrams Processor 10/10 VCCGT VCCGT 31 A 31 A CPU POWER 2 OF 4 GND 1 OF 3 GND 2 OF 3 VCCGT VCCGT A5_L AL65 AT63 BA49 VCCGT VCCGT A67_L AL66 AT68 BA53 VCCGT VCCGT A70_L AA63 AM13 AT71 BA57 VCCGT...

  • Page 61: Ddr4 So-Dimm_0

    Schematic Diagrams DDR4 SO-DIMM_0 VDDQ_VTT JDIMM1A V_VCCDDQ JDIMM1B M_A_DQ[63:0] M_A_DQ2 M_A_CLK_DDR0 CK0_T VDD19 M_A_DQ0 2.5V M_A_CLK_DDR#0 CK0_C M_A_DQ1 VDD18 M_A_CLK_DDR1 CK1_T VDD17 M_A_DQ3 M_A_CLK_DDR#1 CK1_C VDD16 VPP2 M_A_DQ5 VDD15 VPP1 M_A_DQ4 V_VCCDDQ W>  >K^ dK ^K/DD M_A_CKE0 CKE0 M_A_DQ6 VDD14 3.3VS M_A_CKE1...

  • Page 62: Ddr4 So-Dimm_1

    Schematic Diagrams DDR4 SO-DIMM_1 VDDQ_VTT V_VCCDDQ JDIMM2A JDIMM2B M_B_DQ[63:0] M_B_DQ11 M_B_CLK_DDR0 CK0_T VDD19 M_B_DQ13 2.5V M_B_CLK_DDR#0 CK0_C SO-DIMM B VDD18 M_B_DQ10 M_B_CLK_DDR1 CK1_T M_B_DQ9 VDD17 M_B_CLK_DDR#1 CK1_C VDD16 VPP2 M_B_DQ8 VDD15 VPP1 M_B_DQ12 M_B_CKE0 CKE0 VDD14 M_B_DQ15 3.3VS M_B_CKE1 CKE1 VDD13 M_B_DQ14 M_B_DQ5...

  • Page 63: Hdmi

    Schematic Diagrams HDMI HDMI CONNECTOR ( W/O LEVELSHIFT) HDMI_5VS C430 *10u_6.3V_X5R_06 VOUT C444 C443 22u_6.3V_X5R_08 18,32,34 SUSB 22u_6.3V_X5R_08 J_HDMI1 uP7549UMA5-20 M-SOT23-5 SY6288D20AAC: 6-02-62882-9C0 uP7549UMA5-20: 6-02-75495-9C0 HDMI_HPD-C R394 20K_04 HOT PLUG DETECT BY PLATF R O M BY PLATF R O M R100 HDMI_SDA-C DDC/CEC GND...

  • Page 64: Panel

    Schematic Diagrams Panel PANEL CONNECTOR (For coaxial cable) PANEL POWER PLVDD PLVDD 3.3VS >100 mil >100 mil J_LCD1 VOUT C569 3.3VS C535 C547 C557 C729 R522 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 10u_6.3V_X5R_06 *10u_6.3V_X5R_06 100K_04 UP7553PMA5-25 11/17 Val u e Cap NEAR PIN4,5 R553 LVDS-U0N 100K_04...

  • Page 65: Rtd2136N

    Schematic Diagrams RTD2136N VCCK_V12 L V D S Power L V D S 3.3VS AVCC33 3.3VS DVCC33 : 3 3 p c s R496 0_06 LVDS R283 0_06 LVDS C309 LVDS 40mils 40mils C528 80mils 80mils 0.1u_10V_X7R_04 C527 LVDS C340 C312 ENBLT ENBLT...

  • Page 66: Ps8338B

    Schematic Diagrams PS8338B PS8338B_PEQ R433 3URJUDPPDEOH LQSXW HTXDOL]DWLRQ OHYHOV ,QWHUQDO SXOO GRZQ DW a. , *4.7K_04 3 Levels Input: 3.3VS R167 PC10 *4.7K_04 W /TBT 3.3V I/O. 3.3VS W /TBT L: Low L: default, LEQ, compensate channel loss up to11.5dB @ HBR2 R437 *4.7K_04 H: High...

  • Page 67: Minidp

    Schematic Diagrams miniDP From PS8338B 3.3VS Near Mini DP Conn For Safety LPS. MDP_PW R D_MDP_D0 C247 0.1u_16V_X7R_04 W /TBT OUT1_D0p D_MDP_D0# C251 0.1u_16V_X7R_04 W /TBT OUT1_D0n VOUT D_MDP_D1 C253 0.1u_16V_X7R_04 W /TBT OUT1_D1p C447 D_MDP_D1# C256 0.1u_16V_X7R_04 W /TBT C518 OUT1_D1n *10u_6.3V_X5R_06...

  • Page 68: Ar_Tbt

    Document Number R e v R e v R e v 6-71-N13W0-D04 6-71-N13W0-D04 6-71-N13W0-D04 20,21 VCC3V3_SX_SYS Custom Custom Custom N140WU N140WU N140WU Date: Date: Date: Wednesday, December 13, 2017 Wednesday, December 13, 2017 Wednesday, December 13, 2017 Sheet Sheet Sheet...

  • Page 69: Ar_Power

    Schematic Diagrams AR_Power VCC0V9_DP VCC3V3_LC VCC3V3_SX_SYS VCC3V3_S0_SYS VCC3V3_S0 C287 C548 C288 C303 C292 C553 C530 1u_6.3V_X5R_04 VCC0V9_DP 0.1u_10V_X7R_04 W /TBT 1u_6.3V_X5R_04 10u_6.3V_X5R_06 10u_6.3V_X5R_06 10u_6.3V_X5R_06 10u_6.3V_X5R_06 W /TBT W /TBT W /TBT W /TBT W /TBT W /TBT VCC0P9_DP VCC3P3_SVR C568 C550 C565 C544...

  • Page 70: Tps65982

    Schematic Diagrams TPS65982 VCC5V0_SYS TBT_VBUS 80Ohm, 0.01Ohm DCR, 8A Idc C561 C583 C539 C574 HCB2012KF-800T80 22u_6.3V_X5R_08 W /TBT TBTA_LDO_BMC W /TBT 22u_6.3V_X5R_08 22u_6.3V_X5R_08 22u_6.3V_X5R_08 VCC1V8D_TBTA_LDO W /TBT W /TBT W /TBT C320 VCC1V8A_TBTA_LDO 1u_25V_X5R_06 W /TBT C375 C365 C377 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 close to pin,1/14...

  • Page 71: Asm1543

    Schematic Diagrams ASM1543 TYPE C (MUX) close to connector TBT_VBUS 100 MIL 2'nd:G517G1TO1U 6-02-51711-9C0 C390 C605 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 W /O-TBT SY6288E1AAC 3.3V_MUX 3.3V 6-02-62881-9C0 3.3V_MUX 5V_MUX m-sot23-5a W /O-TBT HCB1608KF-121T30 W /O-TBT R179 4.7K_04 5V_MUX 3.3V_MUX W /O-TBT U12_Pin1/ 2 ASM1543_PW R_EN C496 C484...
  • Page 72 Schematic Diagrams Type C Colay Near J_TYPEC1 TBT_VBUS From ASM 1543 TBTA_CA2HD_1_P_R R317 0_1%_02 W /O-TBT TBTA_CA2HD_0_N_R TBTA_CA2HD_1_N_R A_URXN_SW 1 TBTA_CA2HD_0_P_R R318 0_1%_02 W /O-TBT A_URXP_SW 1 C597 22u_6.3V_X5R_08 TBTA_HD2CA_0_N_R C612 22u_6.3V_X5R_08 TBTA_HD2CA_0_N_R TBTA_HD2CA_0_P_R C609 0.22u_10V_X5R_02 W /O-TBT A_UTXN_SW 1 3/16 ME change C608 0.22u_10V_X5R_02...

  • Page 73: Card Reader & Lan_Rtl8411B

    Schematic Diagrams Card Reader & LAN_RTL8411B Crystal 503 2 SI Z E Switching Regulator close to PIN48 meet realtek Freq tolerance <50ppm 2.49K_1%_04 VCC_CARD *1K_04 (>20mil) XTAL2 R370 10K_04 REGOUT *28mil short-p VDD10 AVDD33 (>20mil) FOR S5 WAKE UP ON LAN C122 C120 R362...

  • Page 74: Audio Codec

    Schematic Diagrams Audio Codec AUDIO CODEC ALC269-VC2 PVDD1_2 HCB1005KF-121T20 CLOSE TO PVDD1 C329 C319 Layout note: 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 GND and AUDG space is DVDD_IO For 3.3V HDA Link. 60mils ~ 100mils R287 0_04 3.3VS_AUD CLOSE TO PVDD2 C595 C594 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 C338 C313...

  • Page 75: Kbc Ite It8587

    Schematic Diagrams KBC ITE IT8587 VDD3 KBC_AVDD BAV99: 6-06-00993-011 HCB1005KF-121T20 VDD3 VDD3 IT8587 26,39 SMC_BAT C117 C181 C126 C182 C172 BAV99 RECTIFIER 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 26,39 SMD_BAT Connect VAULE FOR REFERENCE BY PROJECT BAV99 RECTIFIER KBC_AGND OPTION E X E C L 10K_04 E X E C L...

  • Page 76: Wlan/Bt, 3G

    Schematic Diagrams WLAN/BT, 3G CURRENT 2A ,DON'T DROP BELOW 3.135V 3G_3.3V 3G CARD 80 mils 220u,6.3V,ESR=15m ,H=1.9mm J_3G1 3GLTE C407 EEFCX0J221YR 3GLTE 3G POWER CHECK EC, 1.8V LEVEL C431 0.1u_16V_Y5V_04 3GLTE Ra,Ca CONFIG_2 3.3V4 3G_3.3V GND10 3.3V3 Ra,Ca C432 0.1u_16V_Y5V_04 3GLTE GND9 3.3V2...

  • Page 77: M Key Pcie Ssd

    Schematic Diagrams M Key PCIE SSD NGFF_M (M2) SSD (PCIE 4X) 3.3VS >120 mil SATAGP2 3.3VS J_SSD1 L: SATA 10K_04 C215 C254 C498 H: PCIe GND13 0.1u_10V_X5R_04 0.1u_10V_X5R_04 22u_6.3V_X5R_08 GND12 3.3V8 FOR OPTANE SUPPORT GND11 3.3V7 PCIE_SATA R103 1K_04 SATAGP2 PEDET(NC-PCIe/GND-SATA) 3.3V6 NC18...

  • Page 78: Sata, Led, Lid, Sw

    Schematic Diagrams SATA, LED, LID, SW RTD3 POWER HDD BOARD PJ31 *OPEN-3mm J_HDD1 SATA_TXP0 C507 0.01u_16V_X7R_04 SATATXP0 SATA_5VS SATA_TXN0 VOUT C491 0.01u_16V_X7R_04 SATATXN0 C523 C522 SATA_RXN0 C505 C508 C502 0.01u_16V_X7R_04 VOUT SATARXN0 SATA_RXP0 10u_6.3V_X5R_06 10u_6.3V_X5R_06 C503 0.01u_16V_X7R_04 SATARXP0 Optane Optane VOUT 10u_6.3V_X5R_06 10u_6.3V_X5R_06...

  • Page 79: Usb Port / Tpm

    Schematic Diagrams USB Port / TPM USB PORT Charge USB 3.0 port (CHARGER) USB3.0 Max Trace length C582 22u_6.3V_X5R_08 C540 22u_6.3V_X5R_08 Follow Design Guide 80 MIL Smart CDP C524 *22u_6.3V_X5R_08 USBVCC_CH C525 *22u_6.3V_X5R_08 pin8 pin4 Function CLOSE TO CONNECTOR J_USB3_1 DCP autodetect with TVUDF1004AD0 USB3_1TXPC...

  • Page 80: Conn, Ccd, Fan, Tp, Led Kb

    Schematic Diagrams Conn, CCD, Fan, TP, LED KB TP_VCC CPU FAN CONN TP Connect 20171201 X7R->X5 R R274 *20mil short-p 3.3VS T / P C341 C355 C347 J_TP1 R290 R291 TP_SMB_CLK_J 1u_6.3V_X5R_04 0.1u_10V_X5R_04 *10u_6.3V_X5R_06 TP_SMB_DATA_J 10K_04 10K_04 CPU_FAN To T/P TP_CLK_J TP_CLK TP_CLK...

  • Page 81: 3V, 5V, 3Vs, 5Vs, 1.8Vs Ctl

    Schematic Diagrams 3V, 5V, 3VS, 5VS, 1.8VS CTL DD_ON# SUSB VDD3 VDD3 R562 R558 100K_04 10K_04 20171103 UK3018 change 2SK3018S3 SUSB SUSB 14,18,34 DD_ON# 20171103 UK3018 change 2SK3018S3 DD_ON# 30,31 2SK3018S3 2SK3018S3 C593 6,15,19,30,32,35,38 SUSB# DEL J9 C591 22,26,30,32,33 DD_ON *CV-40mil *30p_50V_NPO_04 *0.1u_10V_X7R_04...

  • Page 82: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF_VDD PR70 0_04 PC59 1u_6.3V_X5R_04 PR182 PR183 EN_3V EN_5V PC55 1000p_50V_X7R_04 130K_1%_04 100K_1%_04 PC48 0824 08 COLAY B2 PC138 PC156 PC58 1000p_50V_X7R_04 B2 08 Size Colay VREG3 PC57 PC155 PC139 PC153 PC46 VCC_3P3DSW _PW RGD 1u_6.3V_X5R_04 PR67 *10K_04 VDD3...

  • Page 83: Vddq, Vddq_Vtt, 1.5Vs, 1.8Va

    Schematic Diagrams VDDQ, VDDQ_VTT, 1.5VS, 1.8VA PC63 PC70 PC71 PC62 VDDQ_VTT(0.6V) VDDQ *RB0540S2 G5616BRZ1U VDDQ(1.2V) 4/12 power change , layout QM3004M3 PC79 VDDQ_VBST PC109 10u_6.3V_X5R_04 VDDQ_VTT Short VLDOIN VBST PR95 VDDQ_DRVH_R 0.1u_10V_X5R_04 VTT_MEM_R VDDQ_DRVH 0_04 DRVH V_VCCDDQ VDDQ OPEN-2mm BCIHP0730-1R0M PR102 VDDQ_L VTTGND...

  • Page 84: 1.0V Series

    Schematic Diagrams 1.0V Series For CV test 1.0V PJ15 *CV-40mil PR55 100K_04 VDD3 JUMP-1MM 0905 change footprint PR71 820K_1%_06 1.0VA_EN PC56 PC154 PC161 PQ21A PJ13 *OPEN-1mm QM3202M3 VTT_SELECT 6,15,19,30,32,35,38 VTT VR Output Voltages SUSB# PR68 PC47 1.1 V 0_06 0.1u_10V_X7R_04 high (V1.1S_VTT) 1.05 V EN_PSV...

  • Page 85: Rt3602Ae

    Size Document Number Document Number Document Number R ev R ev R ev 9,11,38 VCCIN 6-71-N13W0-D04 6-71-N13W0-D04 6-71-N13W0-D04 N140WU N140WU N140WU 11,37 VCCGT 9,37 VCCSA Date: Date: Date: Wednesday, December 13, 2017 Wednesday, December 13, 2017 Wednesday, December 13, 2017...

  • Page 86: Vcc_In/Out, Vccgt, 2.5V

    Schematic Diagrams VCC_In/Out, VCCGT, 2.5V PC290 PC291 PC292 s'd PR384 PC289 2.2_06 0.1u_25V_X7R_06 20171212 Modify VCCGT 1Phase PU20 0V~1.5V VCCGT_L VCCGT PR385 0_04 H-line 42 BOOT UGATE 20171108 Del PJ49 Loadline=2.65mr PL18 20171106 Modify 0 Ohm PR525 0_04 PW M_VCCGT PHASE TMPC0603H-R15MG-0M9-D ^,KZd...

  • Page 87: Vccsa, 2.5V

    Schematic Diagrams VCCSA, 2.5V hi side RDSON=6.8mR lowi side RDSON=2.8mR PC267 PC268 PC269 PC270 VCCIN OUTPUT PC266 power ,S M T 0.1u_25V_X7R_06 PR370 2.2_06 VCORE 2Phase 20171108 Modify PU18 VCCIN_L VCCIN 4/12 power Add PL16 PR371 PCMB104T-R15MS 20171108 Del PJ47 BOOT UGATE 0_04...

  • Page 88: Charger, Dc In

    Document Number Document Number 6-71-N13W0-D04 6-71-N13W0-D04 6-71-N13W0-D04 R e v R e v R e v Custom Custom Custom N140WU N140WU N140WU Date: Date: Date: Friday, December 15, 2017 Friday, December 15, 2017 Friday, December 15, 2017 Sheet Sheet Sheet...

  • Page 89: Usb Board

    Schematic Diagrams USB Board Z3.3V USB3.0 PORT4 ZUSBVCC 100 MIL VOUT 0.01u_16V_X7R_04 0.1u_10V_X7R_04 1u_6.3V_X5R_04 ZC12 ZC13 *0_04 Z3.3V 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 2K_1%_04 *4.7K_04 ZGND *4.7K_04 ZGND uP7549UMA5-20 20171108 Modify ZGND PCB Footprint = M-SOT23-5 ZGND 2A/90mohm ZGND ASM1464 ZDD_ON# ZR20 *0402_short Z_SCK_P4 Z_SDA_P4 *4.7K_04...

  • Page 90: Audio Board

    Size Size Size Document Number Document Number Document Number R e v R e v R e v 6-71-N1308-D02A 6-71-N1308-D02A 6-71-N1308-D02A N140WU N140WU N140WU A_AUDG A_AUDG A_AUDG A_AUDG Date: Date: Date: Wednesday, November 29, 2017 Wednesday, November 29, 2017 Wednesday, November 29, 2017...

  • Page 91: Click Board

    Schematic Diagrams Click Board CLICK BOARD To T/P To M/B CJ_TP1 CTP_VCC CTP_CLK_J CTP_CLK CJ_MB1 CTP_DATA_J CTP_DATA CTP_SMB_CLK CTPBUTTON_L CTP_SMB_DATA 20mil CGND CGND CTPBUTTON_R CTP_SMB_CLK 20mil CGND CTP_SMB_DATA CTP_CLK CTP_SMB_CLK_J CTP_DATA CTP_SMB_DATA_J CTP_VCC ONLY 3.3V FP225H-008S11M FP225H-006S10M *TVUDF1004AD0 fp225h-008gxxxm PCB Footprint = fp225h-006xxxm P/N = 6-20-94K30-108 P/N = 6-20-94K00-006 0.1u_10V_X5R_04...

  • Page 92: Led Board

    Schematic Diagrams LED Board LED BOARD LGND L_LED_ACIN L_LED_BAT_FULL L_LED_PWR L_LED_BAT_CHG L3.3VS LJ_LED1 *TVUDF1004AD0 L_LED_BAT_CHG L_LED_BAT_FULL L_LED_ACIN L_LED_PWR L_LED_HDD# L_AIRPLAN_LED# LGND Sheet 43 of 45 220_04 220_04 220_04 FP225H-010S10M 220_04 *V15AVLC0402 FP225H-010-xxxM LGND LGND LED Board RY-SP155HYYG4-1 RY-SP155HYYG4-1 POWER ON LED/ AC IN FULL LED/ BAT CHARGE LGND LGND...

  • Page 93: Dc Jack Board

    Schematic Diagrams DC Jack Board KJ_DC_JACK1 KJ_DC_IN1 KVIN Sheet 44 of 45 50278-00201-001 GND1 DC Jack Board PCB Footprint = 50278-002xx-xxx_l GND2 P/N = 6-21-63100-002 TDC-114HSR2-H-105-1AG PCB Footprint = DC090H-005-P KGND P/N = 6-20-B3Y10-004 *H7_0D2_3 *H6_0D2_3 *H5_0D2_2 *H5_0D2_2 H7_0D2_3 H6_0D2_3 H5_0D2_2 H5_0D2_2 KGND...
  • Page 94 Schematic Diagrams B - 46...

  • Page 95: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 96: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
