Gas Fireplaces and Chimney System
Installation, Operation, Maintenance and Owner's Manual
IMPORTANT: This manual contains assembly rules, installation steps and guidelines, and use and maintenance in-
structions for Isokern B-VENT gas appliances (BVETTO). This manual must become the property of and be reviewed
by all current and future users of this product. It is the responsibility of the distributor, general contractor and the
installer of this product that the instructions in this manual are followed exactly and, further that the allowed gas log
appliance used in this product be installed in strict accordance with the gas log manufacturer's listing and explicit
installation and operation instructions.
Be Sure to Read Entire Manual Before Beginning Construction.
Contents of this manual may change without prior notification.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warning exactly could
result in serious injury, death, or property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Leave the building immediately.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
THESE FIREPLACES ARE DESIGNED for USE with:
PROPANE (LP) or NATURAL GAS (NG), ONLY
THIS MANUAL CAN ONLY BE REPRODUCED IN ITS ENTIRETY
Isokern
®
Isokern BVETTO Models 80B36 & 80B46
A PRODUCT OF EARTHCORE
INSTALLER: Leave this manual with the appliance
CONSUMER: Retain this manual for future reference
BVETTO
TM
INDUSTRIES, LLC
®
Do not install the BVETTO B-Vent Gas Fireplace in a
manufactured home or mobile home or recreational
vehicle.
—
This appliance complies with National Safety and
is tested and listed to ANSI Z21.50 - 2014 as
vented gas fireplaces.
—
Installation must conform to local codes. Check
local codes prior to installation. In the absence of
local codes, installation must conform with
current National Fuel Gas Code, ANSI Z223.1.
B-Vent
PFS Report No. 09-79
USA: ANSI Z21.50 - 2014
Canadian: CSA 2.22- 2014
©2017 Earthcore Industries, LLC
SAP No. 506022-03
Issued: August 2017
Revision: 005
