Huawei USG6305 Quick Start-Up page 3

Item Port
WAN GE0/0/4 WAN Mode
Cellular WAN Mode
0/0/0
LAN GE0/0/6 LAN Mode
Wlan- LAN Mode
Radio 0/0/0
1. Set the IP address to 192.168.0.2 (or any other in the range of 192.168.0.2 to 192.168.0.254) and subnet mask to
255.255.255.0 of the corresponding network interface on the administration PC.
2. Open a web browser and navigate to https://192.168.0.1:8443.
3. Enter the user name (admin) and password (Admin@123) in the login dialog box, and then click Login. You need to
change the user password as instructed after the first login.
4. In the Startup Wizard page that is displayed, click Next to access the Basic Configuration page. Change the device
name and click Next.
If the Startup Wizard page is not displayed, click the System tab and choose Wizard > Startup Wiz-
ard in the navigation tree.
5. In the Time Settings step, configure the system clock of the device according to your local time zone, and click Next.
6. In the WAN Mode step, select a WAN mode and click Next.
7. In the WAN Settings step, set the parameters and click Next.
Description
Static IP IP Address: 1.1.1.1
Subnet Mask: 255.255.255.0
Default Gateway:
Primary DNS: 2.2.2.2
(Optional) Secondary DNS:
PPPoE User name/Password:
DHCP -
4G APN: example
User name/Password:
Dial string: *99#
Wired IP Address: 10.0.0.1
LAN
Subnet Mask: 255.255.255.0
IP address assigned by the DHCP Server:
10.0.0.1 to 10.0.0.254
WLAN SSID: example
Security Protocol:
Password: Admin@123
Service VLAN Interface:
IP address assigned by the DHCP Server:
10.1.0.1 to 10.1.0.254
3
Request your ISP or
network administrator
to provide the data.
1.1.1.254
2.2.3.3
user/Password123
The device functions
as a DHCP client.
Request your ISP or
network administrator
user01/Admin123
to provide the data.
The LAN IP address range
shall be pre-determined.
The WLAN parameters
shall be pre-determined.
WPA2
Vlanif10
