Page 1: User Guide
HUAWEI HG622 Home Gateway User Guide HUAWEI TECHNOLOGIES CO., LTD. - Page 2 User Guide Issue Date 2010-06-25 Part Number 202193 Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang...
- Page 3 Thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.
-
Page 4: Table Of Contents
Contents 1 Warnings and Precautions ............... 1 2 Connecting the Cables and Powering On..........4 2.1 Simple Connection ..................4 2.2 Connecting One Telephone ................5 2.3 Connecting Multiple Telephones ..............6 2.4 Powering On ....................7 3 Setting the Internet Access Parameters........... 7 3.1 Configuring the HSPA uplink ..............7 3.2 Configuring the DSL uplink.................8 4 Configuring the Wireless Network Connection........ - Page 5 7.2 Interfaces and Buttons................21 7.3 Default Settings..................22 7.4 Technical Specifications................22...
-
Page 6: Warnings And Precautions
1 Warnings and Precautions To use the device properly and safely, read these warnings and precautions carefully and strictly observe them during operation. Unless otherwise specified, the term "device" refers to the device and its accessories. Basic Requirements During storage, transportation, and operation of the device, keep it dry and prevent it from colliding with other objects. - Page 7 Precautions for Using Wireless Devices When using the device, ensure that the antenna of the device is at least 20 cm away from all persons. Do not use the device where using wireless devices is prohibited or may cause interference or danger. The radio waves generated by the device may interfere with the operation of electronic medical devices.
- Page 8 Maintenance If the device is not used for a long time, power it off, and then remove all the cables connected to it. If any exception occurs, for example, if the device emits any smoke or unusual sound or smell, stop using the device immediately, power it off, remove all the cables connected to it, and then contact an authorized service center.
-
Page 9: Connecting The Cables And Powering On
LAN4 LAN3 LAN2 LAN1 RESET POWER 1. Telephone jack on the wall 2. Computer 3. Power adapter If the wireless network function is used on the HG622 for the network access, you do not need to connect the cables. -
Page 10: Connecting One Telephone
2.2 Connecting One Telephone If your telephone line is used for both the broadband network access and a telephone connection, take the following figure as a reference for connecting the cables. LAN4 LAN3 LAN2 LAN1 RESET POWER LINE MODEM PHONE 1. -
Page 11: Connecting Multiple Telephones
2.3 Connecting Multiple Telephones If your telephone line is used for the broadband network access, telephone connections, and fax connections, take the following figure as a reference for connecting the cables. LAN4 LAN3 LAN2 LAN1 RESET POWER LINE MODEM PHONE 1. -
Page 12: Powering On
When the HG622 is working through the Huawei HSPA data card, you need to install the Huawei HSPA data card on the HG622 so that your PC can connect to the Internet through HSPA uplink. To create a HSPA uplink connection, do as follows: Step 1 Log in to the Web-based configuration utility. -
Page 13: Configuring The Dsl Uplink
Using the PPP Dial-Up Software on Your Computer Using the Embedded PPP Dial-Up Software on the HG622 If you select this method for accessing the network, the HG622 starts to set up a dial-up connection automatically after the startup. You can access the network after you power on your computer. - Page 14 Set the working mode of the HG622 to Bridge. For details, refer to the procedure for enabling the embedded dial-up function described in Step 3 in section "Using the Embedded PPP Dial-Up Software on the HG622." Note that Bridge is selected from the Connection mode drop-down list box.
-
Page 15: Configuring The Wireless Network Connection
7. Select AES from the WPA encryption drop-down combo box. 8. Click Submit to save the settings. Step 2 Press the WPS button of the HG622 to enable the HG622 to enter the WPS negotiation state. Step 3 Enable the WPS negotiation function of the wireless network adapter on your PC within two minutes, and then wait for a moment (typically 10s and at most 120s). -
Page 16: Setting Up A Wireless Connection Manually
The WPS indicator of the HG622 becomes on from the blinking state, indicating that the HG622 is connected to your PC through the WLAN. This state lasts 300s. Then the WPS indicator turns off. If the WPS indicator does not blink, it indicates that the WPS function cannot be enabled. -
Page 17: Basic Configuration
After the password is authenticated, Connected is displayed in the upper right corner of the WLAN icon in the WLAN list, indicating that a wireless connection is set up between you PC and the HG622. 8. Close the Wireless Network Connection dialog box. -
Page 18: Enabling Or Disabling The Wireless Network Function
You can quickly enable or disable the wireless network function by pressing the WLAN button on the HG622. To enable the wireless network function, press and hold the WLAN button for over one second, and then release the button. You can disable the wireless network function in the same way. -
Page 19: Changing The Login Ip Address
Internet Explorer, and then enter the new IP address in the address bar. Ensure that the IP address of the computer is in the same network segment as that of the HG622 so that the computer can access the Web-based configuration utility. -
Page 20: Restoring Default Settings
To restore the default settings, press and hold the RESET button for over six seconds after the HG622 is powered on, and then release the button. In addition, you can restore the default settings of the HG622 through the Web-based configuration utility. - Page 21 Ensure that the term inal is properly connected to the socket through the power adapter. If the P OWER indicator is still off, contact an authorized maintenance center. Step 2 After powering on the terminal, wait for about three min utes.
- Page 22 operator. Step 6 Check whether you can use the PPP dial-up software to dial successfully. If you cannot use the PPP dial-up software to dial successfully, perform further checks as follows: Stop the PPP dial-up software and then power off the terminal. After five minutes, power on the terminal, and the n use the PPP dial-up software to dial again.
- Page 23 If the problem persists, contact your service provider. What can I do if sometimes the terminal cannot access the Internet through a WLAN connection or if the WLAN connection is unsteady? Step 1 Check the positions of your terminal and your computer. Ensure that they are far from the electric appliances, such as microwave ovens, refrigerators, o r cordless telephones, that generate strong magnetic or...
-
Page 24: Appendix
LAN3 LAN4 2 3 4 5 6 7 8 9 10 Indicator Status Description POWER The HG622 is powered on. The HG622 is powered off. The HG622 is activated. Blinking The HG622 is being activated. The HG622 is powered off. - Page 25 HG622 and a wireless client through the WPS function. This state lasts 300s. Blinking The HG622 is attempting to set up a wireless connection with a wireless client (such as a PC on which a wireless network adapter is installed) through the WPS function.
-
Page 26: Interfaces And Buttons
POWER 2 3 4 5 Interface or Description Button Used to connect HG622 to the MODEM interface on the splitter or to the telephone jack on the wall. Used to connect Ethernet devices, such as PCs and LAN1–LAN4 switches. RESET Used to restore the factory settings. -
Page 27: Default Settings
WLAN Used to enable or disable wireless network function quickly. Used to set up a wireless connection between the HG622 and a wireless terminal easily and safely. Used to connect a USB device, such as a Huawei HSPA data card. - Page 28 Item Specification Weight About 350 g Standards VDSL2 G.993.2 Annex B PSD Mask standards ITU G.994.1 (G.hs) ADSL2+ ITU G.992.5 (G.dmt.bitplus) Annex A standard ADSL2 ITU G.992.3 (G.dmt.bis) Annex A standards ITU G.992.3 (G.dmt.bis) Annex L ADSL ITU G.992.1 (G.dmt) Annex A standards ITU G.994.1 (G.lite) ANSI T1.413 Issue 2...
- Page 29 HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China www.huawei.com Part Number: 202193...
