Summary of Contents for Magnadyne AT449150
- Page 1 AT449150 Operation and Installation Manual AM/FM AUX/BT CLOCK ALARM MUTE TUNER MENU...
- Page 2 Introduction Please take the time to read all of the information in this manual. Familiarity with operation and installation procedures will help you obtain the best possible performance from your new Entertainment Center. Index Button Locations and Functions ........... . . General Operation .
-
Page 3: Button Locations And Functions
Button Locations and Functions AM/FM AUX/BT CLOCK ALARM MUTE TUNER MENU Power/Mute Button ( MUTE): 6. Track Buttons: Radio Mode: Press for automatic seek up or Power: Press to turn the unit on when seek down of radio stations. Press and hold the unit is off, press and hold the button to activate manual tuning. -
Page 4: General Operations
General Operations Power On: Press the mute button to turn the entertain ment center on. AM/FM AUX/BT CLOCK ALARM Power Off: MUTE Press and hold the Mute button for 2 TUNER sec onds to turn the unit off. Mute: MENU When the unit is on press and release this button to mute the audio, press again to restore the audio. - Page 5 Sound Controls (Continued) Fader: Select the Fader mode by pressing the MENU button until “FAD F_R” appears in the display. Adjust the Fader to the front speakers by pressing the VOL+ button. Adjust the Fader to the Rear speakers by pressing the VOL- button. F - R = Equal sound Front and Rear.
-
Page 6: Bluetooth Operation
Bluetooth Operation Pairing Bluetooth Devices: 1. Open the Bluetooth setup program on the mobile device and activate the Bluetooth feature. 2. Press the button to turn on the entertainment AM/FM AUX/BT CLOCK ALARM center. MUTE 3. From you mobile device scan for available devices. Select ”AT JD ”... - Page 7 Radio Operations Tuning in a Radio Station Using Seek: Higher Press the TUNER+ button and the tuner will AM/FM AUX/BT CLOCK ALARM seek up to the next strong station and stop MUTE seeking, then start playing. Press the TUNER- button and the tuner will TUNER seek down to the next strong station and stop seeking, then start playing.
-
Page 8: Setting The Alarm
ALARM Reception Operation: Setting the ALARM : 1:Hold press MENU button until display ALARM OFF, than press VOL (+/-) to open ALARM ON. LCD on display“ ALARM” AM/FM ALARM AUX/BT CLOCK 2: press ALARM button to display time, MUTE 3: hold press ALARM button again, when TUNER ARLAM blink, adjustment hour VOL (+) and minute VOL (-) to setting correct time. -
Page 9: Speaker Connections
Speaker Connections White/Black Wire Gray/Black Wire Left Right Front Front Speaker Speaker White Wire Gray Wire Wiring Harness 10 Amp Model: SPA-HAR Fuse (Sold Separately) Gray Wires Audio Out Right Left Red Wire (+) to 12 Volt Ignition Black Wire Ground Blue WireTrigger for Amp (+12VDC) Violet/Black Wire Left... - Page 10 FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
