DRX402 Accessory Handset and Ultra-Range Charger User's Guide What's in the box? DRX402 accessory handset Charger AC Ultra-Range charger adapter (PS-0 Battery cover Belt clip Desk stan wall moun Rechargeable bracket (T battery pack already be (BT-1018) If any items are missing or damaged, contact our Customer Care Line immediately.
What's in the manual? Important Safety Precautions!... 2 Placing the Ultra-Range charger 8 Wall Mounting the Ultra- Setting Up Your Handset....3 Range charger......9 Install the Battery ...... 3 Connect the Charger....3 Important Information....11 Registering the Handset .... 4 ......
Setting Up Your Handset Install the Battery Unpack the handset, battery pack, and battery cover. If the battery cover is already on the handset, press in on the notch and slide the cover down and off. Line up the battery pack connector with the jack inside the handset.
Ultra-Range charger. You can use the handset normally even if the charger is not registered. Compatible Bases This handset is designed for use with Uniden's DECT4066, DECT4086, and DECT4096 bases. Other Uniden DECT6.0 bases might be compatible with this handset. For the most up-to-date list of compatible bases for this handset, see our website.
All features and operation for the handset are described in the user's guide for one of the bases listed under the Compatible Bases section. User guides for all Uniden phones are available on our website for free downloading.
Using the Ultra-Range Charger How it Works The DRX402 Ultra-Range charger extends the range of your base in all directions, including up and down. Each handset will automatically connect to the charger or the base, depending on which signal is stronger. (The handset operates exactly the same way whether it's connected to the base or to the Ultra-Range charger.)
Each of these bases can support up to two DRX402 Ultra- Range chargers, including any that were supplied with your phone. Usually, you can't tell when a handset switches between the base and the charger in the middle of a call, but sometimes, you might notice a brief pause in your conversation.
charger automatically erases the link to the old base when it registers to the new one. Only register chargers to one base at a time. If more than one base is in registration mode at the same time, you can't control which base the charger registers to. Placing the Ultra-Range charger Here are a few tips for placing your Ultra-Range charger so that you get the clearest signal and the maximum range:...
Continue walking away from the base. Make a note where the signal strength icon drops from 3 bars to 2 or if you start to hear noise on the line (which indicates the signal is getting weaker). Place the charger anywhere inside the range where the signal strength icon showed 3 bars and the handset had a clear signal with no noise.
Page 10
Align the stand with the notches on the charger. Slide the stand onto the notches until it clicks into place. Insert two #10 screws into the wall, 30 mm apart. (For best results, use a level to ensure the screws are even.) Remember to use appropriate...
Important Information Part number PS-0033 AC Adapter Input voltage 120V AC, 60 Hz Output voltage 6.5V AC @ 350mA Part number BT-1018 Battery pack Capacity 500mAh, 2.4V DC Use only the supplied AC adapter. Be sure to use the proper adapter for the base and any chargers.
Page 12
Rechargeable batteries must be recycled or disposed of properly. Uniden works to reduce lead content in PVC coated cords in our products and accessories. Warning! The cords on this product and/or...
