Summary of Contents for RC4WD Z-RTR0035
-
Page 2: Warranty
This warranty lasts 30 days after arrival for original pur- chaser. In the event of a defect under this warranty, RC4WD will, at our discretion, replace the product, provided our inspection indicates that an original defect exists. -
Page 3: Battery Charging
BATTERY CHARGING 1. Only change batteries that are cool to the touch and are not damaged (swollen, bent, broken or punctured). 2. Connect the charger to the proper wall receptacle noting proper polarity. 3. Plug the battery’s connector into the charger’s connector. The LED will light red as it is charging. - Page 4 Failure to follow instructions associated with this symbol risks injury or even death! Avoid battery liquid contact with skin and clothing. If contact occurs, remove contaminated clothing and wash skin thoroughly with water. Before Use: Read and understand the battery and charger operating instructions before recharging. ONLY use genuine charger unit for NEVER place a battery into water.
-
Page 5: Basic Specifications
RC4WD O utcry II Waterproof ESC BASIC SPECIFICATIONS Type Brushed Motor ESC Model Z-E0089 Specification 1/10 Electric ESC Lipo 2-3S 4-9 PCS NiMH (1.2V/PCS) BEC Output Voltage (V) - Current (A) 5V/2A Max Length (mm/in) 45.40mm [1.79in] Max Height (mm/in) 24.70mm [0.97in]... - Page 6 INSTRUCTIONS Product Features and Characteristics I. NiMH/Lipo Option BATT BATT Lipo NiMH II. Drag Brake/Standard Option TYPE TYPE DRAG BRAKE STANDARD III. Micro Controller (MCU) Automatic Learning Center Point WARNING: Prior to proceeding, be sure to either remove the pinion from the motor or elevate the truck so the wheels are not able to touch the ground.
- Page 7 Channel 3 Servo RC4WD Throttle Servo Warning: Please replace batteries when the Connect to power indicator blinks or the buzzer beeps. Power Switch Receiver Battery Steering Servo RC4WD USA 100-0012 Trail Finder 2 RTR w/Chevrolet Blazer Body Set (Limited Edition)
-
Page 8: Step 6. Transmitter Adjustments
3C Transmitter / Radio Step 5. Fail Safe Function Settings Step 4. Binding the Transmitter and Receiver 1. Turn on the receiver power. Press the SW switch. The receiver’s LED should start flashing. 1. Set the TH, ST switches to the norm position. 2. - Page 9 TF2 Limited Edition RTR Truck Electronic Manual This is a step by step overview of your new TF2 Limited Edition RTR Truck electrical items and how they connect. 1. Outcry II Waterproof ESC (Z-E0089) 2. Shows the ESC connected to the Brushed 45T Crawler Motor (Z-E0004) viii Trail Finder 2 RTR w/Chevrolet Blazer Body Set (Limited Edition)
- Page 10 3. This shows the ESC to radio’s receiver (Z-R0008) connected to the CH2 port 4. Connect the ESC to the radio's receiver Channel 2 (CH2) You may use this channel on the radio to control the throttle. Trail Finder 2 RTR w/Chevrolet Blazer Body Set (Limited Edition)
- Page 11 5. Shows the battery (Z-E0090) connected to the ESC 6. This final step shows all the items as they are connected on the truck Trail Finder 2 RTR w/Chevrolet Blazer Body Set (Limited Edition)
-
Page 12: Spare Parts
Spare Parts Z-S0028 RC4WD Superlift Dual Front Shock Mount for Trail Finder 2 Z-S1224 RC4WD 1/8 Warn Scale Manual Locking Hubs Z-S0756 RC4WD Drive Flange Wheel Nut Cover Z-S0779 1.9"/2.2" 6 Lug Steel Wheel Hex Hub +6 Offset Z-T0086 Prowler XS Scale 1.9" Tires Z-W0189 RC4WD Raceline Monster 1.9"... - Page 13 Z-B0114 RC4WD Chevrolet Blazer Main Cab Clear Window Parts Tree Z-B0116 RC4WD Chevrolet Blazer Main Body Z-B0118 RC4WD Chevrolet Blazer Topper Z-S1564 RC4WD Chevrolet Blazer Functional Hood and Tailgate Hardware Z-S1560 RC4WD Chevrolet Blazer Metal Emblem Set Z-S1562 RC4WD Magnet and Metal Mounts...
- Page 14 Z-S1773 RC4WD Radiator and Hose for V8 Motor Z-S1537 RC4WD Pulley Kit w/Belt for V8 Scale Engine Z-S1749 RC4WD V8 Engine Cover with Metal Intake Set for R3 Transmission Z-S1719 RC4WD Water Pump for V8 Scale Engine Z-S1739 Thermostat Housing for V8 Motor...
- Page 15 VVV-C0356 Roll Bar Rack w/Spare Mount for RC4WD Chevy Blazer Body (Red) VVV-C0354 Roll Bar Rack for RC4WD Chevy Blazer Body (Red) VVV-C0358 Roof Rack, Rollbar, Light Bar Combo for RC4WD Chevy Blazer Body (Red) VVV-C0357 Roof Rack, Rollbar, Light Bar Combo for RC4WD Chevy Blazer Body (Black)
- Page 16 Z-W0185 RC4WD Raceline Monster 1.9" Beadlock Wheels (Black) Z-W0189 RC4WD Raceline Monster 1.9" Beadlock Wheels (Black/Silver) Z-W0198 RC4WD Mickey Thompson Classic Lock 1.55" Internal Beadlock Wheels Z-W0199 RC4WD Raceline Revolver 1.55" Beadlock Wheels Z-W0200 RC4WD Fuel Offroad Maverick 1.9" Beadlock Wheels Z-W0201 RC4WD Raceline Monster 1.7"...
- Page 17 Z-W0237 RC4WD Mickey Thompson Metal Series MM-366 1.9" Beadlock Wheels Z-W0238 RC4WD Mickey Thompson Street Comp SC-5 1.9" Beadlock Wheels (Hyper Silver) Z-W0239 RC4WD RBP Glock 1.9" Beadlock Wheels Z-W0240 Deceptive 1.9" Beadlock Wheels Z-W0242 5 Lug Deep Dish Wagon 1.9" Steel Stamped Beadlock Wheels (White) Z-W0243 5 Lug Deep Dish Wagon 1.9"...
- Page 18 618 Blossom Hill Rd. Ste 201 618 Blossom Hill Rd. Ste. 201 San Jose, CA 95123 San Jose, CA 95123 Web: www.RC4WD.com - Email: support@rc4wd.com Web: www.rc4wd.com - Email: support@rc4wd.com 100-0024...
