Operating Manual
MX-120T
PUBLIC ADDRESS
AMPLIFIER
Please follow the instructions in this manual to obtain the optimum
results from this unit.
We also recommend that you keep this manual handy for future reference
Check our website for any updates of this manual: www.artsound.be
House of Music nv
Ronse, Belgium
www.artsound.be
Tel. +32 9 380 81 80
Fax. +32 9 386 12 35
info@artsound.be
Advertisement
Table of Contents
Related Manuals for Artsound MX-120T
Summary of Contents for Artsound MX-120T
- Page 1 Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference Check our website for any updates of this manual: www.artsound.be House of Music nv Ronse, Belgium www.artsound.be...
-
Page 2: Table Of Contents
MX-120T Table of contents 1. Safety precautions 2. General description 3. Features 4. Nomenclature and functions Front panel Rear panel 5. Connections 6. Applications 7. Block diagram 8. Specifications 9. Dimensional diagram... -
Page 3: Safety Precautions
AC outlet and contact your components inside the unit. Refer all servicing to your nearest ArtSound dealer. Make no further attempt to nearest ArtSound dealer. operate the unit in this condition as this may cause fire •... -
Page 4: General Description
2. General description. The MX-120T will be right at home in large retail, appreciate the room combining and remote volume commercial, and industrial paging and background control features that this product provides. -
Page 5: Nomenclature And Functions
Pressing it again switches the unit off. This knob controls the volume level of the input POWER LED connected to the rear-panel Aux Input. This LED will illuminate when the MX-120T is turned TUNER 10. CHIME AND CHIME LEVEL Tuner volume control BASS CONTROL Pressing this switch activates the chime circuitry. -
Page 6: Rear Panel
MX-120T 4.2 Rear panel. SPEAKER OUTPUT SPEAKER OUTPUT CO O M 4ｦｸ 4ｦｸ 8ｦｸ 8ｦｸ 100V 10 0 0V FM M A A M LOOP LOOP ~230V 50Hz ~230V 50Hz UNBAL/75ｦｸ UNBAL/75ｦｸ T3.15AL/250V T3.15AL/250V LINK LINK AUX1 IN AUX1 IN... -
Page 7: Connections
MX-120T 5. Connections. Speaker connections Notes • Both the 4 Ω / 8 Ω x and 70 V / 100 V terminals cannot be used at the same time. • Impedances indicated in the fi gures represent the total speaker system (load) impedances Warning Be sure to attach the supplied terminal cover after connection completion. -
Page 8: Applications
MX-120T 6. Applications. -
Page 9: Block Diagram
MX-120T 7. Block diagram. -
Page 10: Specifications
MX-120T 8. Specifications. PUBLIC ADDRESS AMPLIFIER Model MX-120T Rated power output 120 W Speaker line input 4 Ω , 8 Ω, 70 V / 100 V Frequency response 60Hz~20KHz 2 mV / 10 K Ω, Balanced Mic 1 and mic 2 2 mV / 600 Ω, XLR connector... -
Page 11: Dimensional Diagram
MX-120T Dimensional diagram. UNIT : mm Keep the unit’s all sides over 10 cm away from objects that may obstruct air fl ow to prevent the unit’s internal temperature rise. UNIT : mm... - Page 12 Art_Sound House Of Music NV Ronse, Belgium www.artsound.be Tel. +32 9 380 81 80 Discover the complete ArtSound Fax. +32 9 386 12 35 range at www.artsound.be info@artsound.be...
