Summary of Contents for Rear view safety RVS-96D

Page 2: Table Of Contents
Making RVS-96D Connections ........
Page 3 RVS-96D System Configuration ........
Page 4 RVS-96D User Management ........
Page 5 RVS-96D Installation and Setup Guide System Information, Disk and File Management ......74 System Info ..............75 Backup and Restore .
Page 6: Introduction
RVS-96D Installation and Setup Guide Introduction This document introduces the the RVS-96D Six-Channel DVR Monitor and provides instructions for its installation and system configuration. The RVS-96D: Enables you to connect and record up to 6 cameras simultaneously. Supports NTSC and PAL standards.
Page 16: Connections Overview
Connections Connections Overview Camera Connection Connect up to 6 cameras to the RVS-96D using camera connectors CH1 through CH6. Channels 2, 3, and 4 are special purpose cameras. To ensure full functionality, assign these channels appropriately, as defined in the legend in the following table.
Page 17: Camera Trigger Connections
RVS-96D Installation and Setup Guide Reverse. Color back-up guides superimposed on view. Left turn signal. Delayed cancellation of image display/record. Right turn signal. Delayed cancellation of image display/record. Camera Trigger Connections Camera trigger wires must be connected to the vehicle's outputs.
Page 18 RVS-96D Installation and Setup Guide Recommended RVS-96D Camera Locations and Settings Optimal camera configuration will ultimately depend customer preference the requirements involved for the various types of waste collection. As a guideline, Rear View Safely proposes the following configurations based on actual installations performed by our installation team.
Page 21 RVS-96D Installation and Setup Guide RVS-96D Electrical Tapping Points Reference Guide The material presented here is provided solely for the purposes of locating DC voltage source locations within various vehicle types. The equipment depicted in the images is not relevant within this context and, as such, may vary from that being used in your installation.
Page 22: Quick Links - Sample Vehicle Installations
RVS-96D Installation and Setup Guide Quick Links - Sample Vehicle Installations Mack - MRU Mack - MR Mack - LEU600 Mack - CT713 Autocar Peterbilt International - 7600 Freightliner - M2 12yd Minimax 2014 Sterling - Condor American - LaFrance Electrical Requirements The 12v tap must be after the battery disconnect (i.e., turning battery disconnect off eliminates 12v...
Page 38: Lift Signal Tap Points
RVS-96D Installation and Setup Guide Lift signal tap points Peterbilt The white wire on the camera harness is usually connected to a proximity switch on the arm assembly. White wire (1753 212) in a large bundled harness near the rear of the cab, leading to the joystick.
Page 39: Accessing The System Configuration Menus
RVS-96D Installation and Setup Guide RVS-96D System Configuration Accessing the System Configuration Menus In order to set up system configuration parameters, you must use the system menus. Touch and hold the lower area of the screen to display the control panel.
Page 40 RVS-96D Installation and Setup Guide Use the Admin user name and, If required, enter the password. For first-time access, the default password "456789" is defined. You can change the password later using the User Accounts menu. The Main Menu displays.
Page 41: Setting Date/Time And Operating Language
RVS-96D Installation and Setup Guide Setting Date/Time and Operating Language Select System Settings The System Settings menu displays. Select General Settings The General Settings menu enables you to set date and time parameters and choose an operating language. COPYRIGHT © 2017 Rear View Safety...
Page 42 RVS-96D Installation and Setup Guide You can set the date and time: Manually Automatically To set date and time manually: Touch their respective fields to display the numeric keypad. Use the keypad to specify new values; use the arrow keys to move the cursor position forward and backward.
Page 43: Setting Video Parameters
RVS-96D Installation and Setup Guide For Example USA Eastern time is either UTC -5 or UTC -4, depending whether DST is in effect. Choose a date format. Select a time format. Select a language. Setting Video Parameters From the System Settings menu, select Video Settings COPYRIGHT ©...
Page 44 RVS-96D Installation and Setup Guide The Video Settings menu enables you to specify video properties for each of the six channels, which are selectable from the channel pull-down menu. After you select a channel from the menu, you can apply properties for that channel as described in the following steps.
Page 45 Select the frame rate—number of frames per second (fps). Generally, the higher the FPS, the smoother the motion appears. Set the bit stream rate. Set overlay positions. RVS-96D provides 4 overlays for video that can be turned on or off and repositioned on the screen: time (license) plate channel Use the check boxes to turn on or off the overlays.
Page 46: Copying Your Video Settings To Other Channels
RVS-96D Installation and Setup Guide Choose set position. The screen refreshes, showing a preview image. Touch a new position on the screen. The overlay moves to the new position. Press the Back button to return to the Video Settings screen.
Page 47 RVS-96D Installation and Setup Guide The Record Settings menu enables you to set recording properties for each of the six channels, which are selectable from the channel pull-down menu. After you select a channel from the menu, you can apply properties for that channel as described in the following steps.
Page 48 RVS-96D Installation and Setup Guide Choose a video format, NTSC or PAL. NTSC is the most commonly used video system or standard used in North America and most of South America, while PAL is common in Europe and parts of Asia.
Page 49: Copying Your Record Settings To Other Channels
RVS-96D Installation and Setup Guide Once you have finished specifying all settings, press Save to preserve your changes. Copying Your Record Settings to Other Channels To copy your settings from one channel to one or more of the other ones:...
Page 50 RVS-96D Installation and Setup Guide After you select a channel from the menu, you can apply properties for that channel as described in the following steps. Enable Status: use the check box to enable and disable alarms. Dev type: choose...
Page 51: Copying Your Alarm Settings To Other Channels
RVS-96D Installation and Setup Guide Alarm output. Both options can be selected. I/O output can be used, for example, to send a signal to an additional device such as a beeper. Copying Your Alarm Settings to Other Channels To copy your settings from one channel to one or more of the other ones:...
Page 52 RVS-96D Installation and Setup Guide The Motion Detection menu enables you to set motion detection properties for each of the six channels, which are selectable from the channel pull-down menu. After you select a channel from the menu, you can apply properties for that channel as described in the following steps.
Page 53 RVS-96D Installation and Setup Guide Press the button. A grid displays on a green screen, where you can select detection regions by touching squares on the grid. After making your selection (one or multiple squares), press the Back button to return to the Motion Detection screen.
Page 54: Copying Your Motion Detection Settings To Other Channels
RVS-96D Installation and Setup Guide As with alarms, both options can be selected. I/O output displays a yellow "motion" icon on the screen.. Copying Your Motion Detection Settings to Other Channels To copy your settings from one channel to one or more of the other ones:...
Page 55 RVS-96D Installation and Setup Guide Enter all information in the text fields. This information is made available to the MDVR player software for viewing in the status window during playback. COPYRIGHT © 2017 Rear View Safety...
Page 56: Specifying G-Sensor Settings
RVS-96D Installation and Setup Guide Select Save when done. Specifying G-Sensor Settings From the Main menu, select Vehicle Settings. From the Vehicle settings menu, select G-Sensor. COPYRIGHT © 2017 Rear View Safety...
Page 57: System Setup Menus
RVS-96D Installation and Setup Guide The G-sensor menu enables you to specify accelerometer thresholds for the X, Y, and Z axes. These are the thresholds at which the cameras will detect a sudden change in direction, which could be caused by hard braking or impact from collision.
Page 58 RVS-96D Installation and Setup Guide System Setup Menus This section provides an overview of the RVS-96D System Menu hierarchy, along with images of all menus and their options. COPYRIGHT © 2017 Rear View Safety...
Page 71 RVS-96D Installation and Setup Guide RVS-96D User Management RVS-96D provides two built-in user accounts, neither of which can be deleted: Admin, a full-privilege administrator account. Privileges for this user account cannot be modified. Default, an account whose access privileges can be limited to certain functions.
Page 72 Select a user name from the list. To modify or create a password, select Modify Password The RVS-96D is configured before shipping with the default password 456789. Make your required changes, and then select COPYRIGHT © 2017 Rear View Safety...
Page 73 RVS-96D Installation and Setup Guide To modify access privileges (for Default account only), select Modify Access Make your required changes, and then select COPYRIGHT © 2017 Rear View Safety...
Page 81 RVS-96D Installation and Setup Guide Select a saved video from the list, and press play Video plays in the currently selected view (i.e.,two/four/six-panel view or full-screen). COPYRIGHT © 2017 Rear View Safety...
