Instruction Manual 9" TFT LCD Digital Single View Color Monitor (3 Channel) RVS-97 Reverse With Confidence ™... -
Page 2: Table Of Contents
Warranty....... 18 Disclaimer....... 19 Rear View Safety... - Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
-
Page 4: Safety Information
Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety... - Page 5 INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified.
- Page 6 If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
-
Page 7: Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot/moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly. -
Page 8: Introduction
Monitor Introduction Monitor Introduction 1) Digital Color LCD Screen 2) Power Indicator/Remote Control Sensor 3) Power Switch 4) Toggle Brightness Down 5) Toggle Brightness Down 6) Channel Selection 7) Menu 8) Toggle AV1/AV2/AV3 9) Speaker 10) Mounting Bracket Rear View Safety... -
Page 9: Wiring
Wiring 1) To Monitor 2) White 5 Pin Male 3) Blue 5 Pin Male 4) Brown 5 Pin Male 5) Red Power (DC 10-32V) 6) White Wire (Trigger Wire For Left Turn Signal) 7) Black (GND) 8) Blue Wire (Trigger Wire For Left Turn Signal) 9) Brown Wire (Trigger Wire For Reverse) 10) Camera Cable (Not Included) 11) Camera Cable (Not Included) -
Page 10: Remote Introduction
Remote Introduction 1) MUTE - Enable/disable sound 2) POWER - Turn monitor on/off 3) HORIZONTAL FLIP: Toggle picure horizontally 4) CHANNEL UP: Toggle Selection Up 5) VERTICAL FLIP: Toggle picure vertically 6) BRIGHTNESS DECREASE: Toggle brightness down Rear View Safety... - Page 11 7) MENU: Show menu 8) BRIGHTNESS INCREASE: Toggle brightness up 9) CHANNEL DOWN: Toggle Selection Down 10) PICTURE MODE: Toggle picture modes: Personal/Standard/ Soft/Vivid/Light 11) CALL: Display video channel source 12) TIMER: Toggle timer to shut down monitor: 10/20/30/40/90mins 13) LANGUAGE: Toggle language: English, Deutsch, Français, Es- pañol, Português, Italiano, Nederlands, Русский...
-
Page 12: Trigger Introduction
CAM3 (backup camera) when the vehicle is put into reverse. The distance grid lines will also display. Press M to display the following options and settings. 1) PICTURE 2) OPTION 3) SYSTEM 4) AUTO SCAN Rear View Safety... -
Page 13: Menu Options
Picture BRIGHT,CONTRAST, COLOR, VOLUME, AUTO DIM and SCALE ADJUST options will display on the screen as illustrated be- low: Reverse With Confidence ™... - Page 14 Option LANG , SCALE , CAM1 , CAM2, CAM3 options display on the screen as illustrated on next page. Rear View Safety...
- Page 15 Reverse With Confidence ™...
- Page 16 System Auto Scan Rear View Safety...
-
Page 17: Troubleshooting
Troubleshooting Reverse With Confidence ™... -
Page 18: Warranty
OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC. SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES. -
Page 19: Disclaimer
FOR ANY INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL REAR VIEW SAFETY AND/OR ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES (WHETHER DIRECT OR INDIRECT, IN... - Page 20 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
