Page 1: Instruction Manual
Instruction Manual 3.5" HUD Heads Up Display RVS-SA150 Reverse With Confidence ™... -
Page 2: Table Of Contents
Warranty....... 14 Disclaimer....... 15 Rear View Safety... -
Page 3: Introduction
Improper installation will void manufacturer’s warranty. Congratulations on purchasing a RVS-SA150 Heads Up Display With this manual you will be able to properly install and operate the unit. Please read the entire manual and follow the instructions and warnings carefully. -
Page 4: Safety Information
If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. - Page 5 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot/moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly.
-
Page 6: Display Functions
2) Voltage icon 3) Driver fatigue alarm 4) Water temperature Icon 5) Speed unit (KM/H) 6) Speed unit (MPH) 7) RPM (1 circle is 200R) 8) Speaker (can be turned on/off) 9) Speed, water temperature, voltage (can be toggled) Rear View Safety... -
Page 7: System Introduction
HUD Installation 1. RVS-SA150 is compatible with ODBII/EUODB vehicles (see below) 2. Find vehicle 16 pin diagnostic link and connect it to the Heads Up Dis- play HUD Function 1. OBDII cable input 2. Power button 3. Rotatable Control Switch A. - Page 8 Vertical long press in (5 seconds) to enter the menu setting. Vertical short press to toggle menu option, toggle up/down the rotatable con- trol switch to increase/decrease the parameter value. After adjustment, vertical long press (5 seconds) to save and exit. Rear View Safety...
-
Page 9: System Adjustment
Menu Parementers Adjustement Range Explanation Default State Display Menu Parementers Adjustement Range Explanation Default State Display Speed Speed 50-150 50-150 Move up/ Move up/ down to down to toggle toggle speed speed Brightness Brightness 0: Auto 0: Auto Adjustment Adjustment brightness brightness 5: Brightest... - Page 10 Speed Unit 1-2 1: KM 2: MPH Power on 0-150 If HUD can- Voltage not power off, adjust to 13.2 - 14.0 v Delayed 10-180 Alarm will Shutdown alert user when volt- age is less than 11v Rear View Safety...
-
Page 11: Reflective Film
Reflective Film Installation Follow these instructions if a double image appears when installed. 1.Place the mounting mat in the desired position on the dashboard with the HUD on top. 2.Observe where the HUD reflects & place the reflective film in posi- tion. -
Page 12: Troubleshooting
Vertical press the setting button for 5 seconds to enter into the menu options, find menu 1, the parameter will show 107, toggle the setting button to increase/decrease the value according to the difference until it shows correct one. After adjustment, vertical press in 5 seconds to save it. Rear View Safety... - Page 13 6. Setting for Automatic start/stop system The default value for HUD shutdown time is 10 seconds. When the car is gas-electric hybrid and automatic start/stop system, you can delay the shutdown time in menu 10 (Between 10 seconds to 180 seconds.) If still not working set voltage at 13.2v or 13.6v, which automativally turns off when the car voltage is less then 13.2v.
-
Page 14: Warranty
OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC. SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES. -
Page 15: Disclaimer
FOR ANY INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL REAR VIEW SAFETY AND/OR ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES (WHETHER DIRECT OR INDIRECT, IN... - Page 16 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
