Summary of Contents for SMART Wallbox A0009069206
- Page 1 Wallbox >> Instruction Manual.
-
Page 2: Important Addresses
Mercedesstraße 137 70327 Stuttgart, Germany In case of technical questions, please contact your local smart technical support. This manual, in its entirety or in parts, must not be reproduced, stored electronically or otherwise transmitted electronically, electrically, mechanically, optically, chemically, by photocopy or as an audio recording without express written permission. -
Page 3: Table Of Contents
5 Introducing the product. 5 Unpacking and components included. 6 Identifying your model variant. 7 Charging procedure. 7 Charging procedure with the smart Wallbox. 10 Resolving errors. 10 Error messages during the charging procedure. 11 Operational disruptions and solutions. 11 Taking the product out of and back into operation. -
Page 5: Important Information
‡ Important information. About this manual. This manual is delivered as an original component of your smart Wallbox and documents the steps and options necessary for set up and operation of your wallbox. For quick and easy reference, certain sec- tions of this manual are specially formatted. -
Page 6: Safety Notices On The Device
> Only use accessories intended and sold for the device by smart. > Do not operate this wallbox in close vicinity to running water or water jets: However, the smart Wall- box is sufficiently protected against water splashes and sprays according to the respective protec- tion degrees. -
Page 7: General Product Information
> Please note that, in some countries, a different tripping characteristic (e.g. Type B) for the upstream residual current circuit breaker (residual current device, in the following called RCCB, see also 'Glos- sary & Definitions' on page 28) may be required. In this case, please contact your local smart techni- cal support. -
Page 8: User Information
User information. To operate your wallbox, please note these instructions: > The device must always be connected to the protective earth conductor of your electricity supply. The protective earth connection will be made and checked by the installing contractor. After instal- lation, only qualified specialist electrical contractors may make changes. -
Page 9: Introduction
Wallbox Introduction 5 ‡ Introduction. Thank you for choosing this wallbox to charge your smart electric vehicle. With this smart Wallbox, you have selected an innovative and future proof solution. eMobility helps save natural resources and protect the environment sustainably – e.g. with Electric Drive models by smart. -
Page 10: Identifying Your Model Variant
PLEASE NOTE! The carton in which the smart Wallbox is delivered offers optimal protection against ex- ternal influences during transport and storage. If possible, keep this carton and use it to pack the wallbox, should you need to send it to the manufacturer or otherwise transport it because of a malfunction or similar. -
Page 11: Charging Procedure
Wallbox Charging procedure 7 ‡ Charging procedure. The mechanical and electrical installation of the smart Wallbox model variants described in this man- ual must always be carried out by qualified specialist personnel: Preparation of the domestic power supply, and electrical connection to your domestic power supply in particular, must be carried out by a specialist electrical contractor, and subsequently inspected and approved as part of the process of taking the device into operation. - Page 12 Please follow these steps to charge your smart vehicle using the wallbox: 1. Park your vehicle so that the vehicle charging socket can be easily reached with the charging con- nector of the charging cable: The charging cable must not be stretched tight or placed under strain during the charging procedure.
- Page 13 Wallbox Charging procedure 9 PLEASE NOTE! In principle, the charging procedure is always terminated by the vehicle, not by the wallbox. An illuminated green LED indicates, on the basis of communication with the vehicle, that the charging procedure has been either paused or completed: Distinguishing these two op- erating states is only possible by checking the battery charge indicator inside the vehicle.
-
Page 14: Resolving Errors
For most error states, the wallbox reinitiates the charging procedure, checking communications with the smart vehicle. However, in practice, it is, in case of an error, advisable to manually reinitiate the charging procedure by unplugging and reconnecting the cable as not all errors can be resolved by the automatic restart. -
Page 15: Operational Disruptions And Solutions
Wallbox Resolving errors 11 Operational disruptions and solutions. For secure operation, the smart Wallbox must be protected during operation by (an) upstream fuse(s) and an external residual current circuit breaker. To take suitable measures and restore operation in case of malfunction, you must first clearly identify the type of error. -
Page 16: Frequently Asked Questions
How must the smart Wallbox electrical circuits be protected? > Every phase of the smart Wallbox must be protected in the domestic power supply and at least one residual current circuit breaker (Type A) must be installed. Always observe all local regulations for operating electrical devices, which may prescribe a different residual current circuit breaker (e.g. - Page 17 Wallbox Resolving errors 13 permanently, please take the wallbox out of operation (see page 11) and contact your local smart technical support. The key for opening the housing or for unblocking the charging procedure has been lost. Can I order a replacement key? >...
-
Page 18: Appendix
‡ Appendix. Technical specifications. Model Variant A0009069206 A0009069306 Compliance IEC 61851-1 / 61439-7 Grid connection for supply cable sizes of max. 5 x 16 mm² Rated voltage see product label Rated current 16 A, 3-phase 32 A, 3-phase Rated frequency 50 Hz Max. -
Page 19: Scale Drawings And Dimensions
Wallbox Appendix 15 Scale drawings and dimensions. The smart Wallbox is delivered fully assembled and quality checked. All dimensions are indicated in the scale drawings below. Wallbox with fixed charging cable. Plan and elevation (all dimensions in mm) -
Page 20: Standards & Guidelines
Wallbox with charging socket. Plan and elevation (all dimensions in mm) Standards & guidelines. The smart Wallbox complies with the following standards and protection ratings: General guidelines. Guideline Explanation 2014/30/EU EMC Guideline 2011/65/EU RoHS 2 guideline 2012/19/EU WEEE Guideline 2014/35/EU... -
Page 21: Ce Certification And Compliance Declaration
IP 54 tities and protection from splashing water (model variant: A0009069206) CE certification and compliance declaration. The smart Wallbox carries the CE mark. The associated declaration of compliance is avail- able for download in electronic format at www.yourwallbox.de. Maintenance. After installation, your wallbox is mostly maintenance-free. However, because the wallbox processes high electrical voltages internally, it is recommended to conduct a visual inspection of the housing and check the externally accessible components and accessories at certain intervals (e.g. -
Page 22: Cleaning And Care
> Do not use abrasive cleaning agents or sponges as these can scratch the surface of the housing cover. DANGER! The smart Wallbox must under no circumstances be cleaned with a pressure cleaner or any similar device where liquids or steam could enter the openings in the housing because of high pressure. -
Page 23: Disposal Advice
Wallbox Appendix 19 Disposal advice. For the preservation and protection of the environment, the prevention of pollution and in order to improve the recycling of resources, the European Commission has is- sued a guideline (WEEE-Guideline 2002/96/EC and EAG-VO) according to which elec- trical and electronic devices are taken back by the manufacturer in order to have them properly disposed of or recycled. - Page 24 The manufacturer may have made minor technical modifications to the product after publication of this instruction manual. This may also have led to minor discrepancies in the appearance of the product. Any color differences are a result of the printing process. www.smart.com smart – a Daimler Brand Daimler AG, smart/MM, H336, Mercedesstr. 137, 70327 Stuttgart...
