ICOP Technology VEX-6225 User Manual

With dm&p vortex86ex 400mhz processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEX-6225 and is the answer not in the manual?

Questions and answers

Carlos Bengoechea
June 25, 2025

I need price and availability on the following : 1-piece ISATA-8G-H-M-X & 1-piece ISATA-32G-H-M-X Thanks, Carlos Bengoechea / Sales Manager /Purchase Inn Solutions 1-915-726-0797

0

Subscribe to Our Youtube Channel

Related Manuals for ICOP Technology VEX-6225

Summary of Contents for ICOP Technology VEX-6225

  • Page 2 User Manual VEX-6225 with DM&P Vortex86EX 400MHz processor Version 1.0...
  • Page 3 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior to written permission of ICOP Technology Inc. ⓒCopyright 2017 ICOP Technology Inc Trademarks Acknowledgement Vortex86EX is the registered trademark of DM&P Electronics Inc.

  • Page 4: Revision History

    VEX-6225 User Manual Revision History Revision Date Remark May 22, 2017 First version release ICOP Technology Inc.

  • Page 5: Table Of Contents

    1.1 Overview ............................1 1.2 Block diagram ..........................2 1.3 Specifications ..........................4 1.4 Ordering Information ........................6 1.4.1 VEX-6225 ..........................6 1.4.3 SATA DOM ..........................6 Hardware Information ..................7 2.1 Dimension ............................. 7 2.2 Board Outline ..........................9 2.3 Connector Location ........................
  • Page 6 J22: Expansion I/O ......................... 5 J24: Power ............................5 J28: LCD Backlight .......................... 5 Software Resources ................... 16 3.1 ICOP Technical Resource Website ....................16 Technical Support Directly from ICOP ..............17 User Manual Feedback ..................... 17 Warranty ........................18 ICOP Technology Inc.

  • Page 7: General Information

    3.5” controller. In addition, the VEX-6225 family of controller is designed as a plug in replacement, with backward compatibility to support legacy software to help extend existing product life cycle without heavy re-engineering.

  • Page 8: Block Diagram

    VEX-6225 User Manual 1.2 Block diagram VEX-6225-43VE ICOP Technology Inc.
  • Page 9 VEX-6225 User Manual VEX-6225-43EE ICOP Technology Inc.

  • Page 10: Specifications

    USB port (Ver. 2.0) x2 Micro SD slot x1 RS232 port x1 SIM Card slot x1 RS232/485 port x1 I/O Interface VGA port x1 CAN BUS port x1 LCD connector x1 C port x1 8-CH 11-bit ADC port x1 ICOP Technology Inc.
  • Page 11 +12V DC Input @ 200mA (Typical) Weight 165g Dimensions 102mm x 146mm (4.01 x 5.75 inches) Operating -20℃ ~ +70℃ Temperature. -40℃ ~ +85℃ (Optional) Operating DOS, Windows CE6.0/Embedded Compact 7 System Support X-Linux, Linux, QNX, VxWorks, FreeBSD ICOP Technology Inc.

  • Page 12: Ordering Information

    VEX-6225 User Manual 1.4 Ordering Information 1.4.1 VEX-6225 Product Name MiniPCI Express VEX-6225-43VE VEX-6225-43EE 1.4.3 SATA DOM Product Name 0℃ ~ +70℃ -40℃ ~ +85℃ SDM-SST-2G-H-M SDM-SST-4G-H-M SDM-SST-2G-H-S-X SDM-SST-4G-H-S-X SDM-SST-8G-H-S-X ISATA-8G-H-M ISATA-16G-H-M ISATA-32G-H-M ISATA-8G-H-M-X ISATA-16G-H-M-X ISATA-32G-H-M-X ISATA-1G-H-S ISATA-2G-H-S ISATA-4G-H-S ISATA-8G-H-S...

  • Page 13: Hardware Information

    VEX-6225 User Manual 2 Hardware Information 2.1 Dimension Front ICOP Technology Inc.
  • Page 14 VEX-6225 User Manual Back ICOP Technology Inc.

  • Page 15: Board Outline

    CAN Bus SOM200EX Module PS/2 Mouse MiniPCI Express (Optional) SIM Card Slot Connector Extension I/O (Optional) SATA DoM Power Connector SATA DoM Connector RS232/485 Switch for COM2 COM1 Reset +12~24V DC In COM2 MiniPCI Express (Optional) Micro SD ICOP Technology Inc.

  • Page 16: Connector Location

    VEX-6225 User Manual 2.3 Connector Location Front J26A J26B ICOP Technology Inc.
  • Page 17 VEX-6225 User Manual Back ICOP Technology Inc.

  • Page 18: Connector And Jumper Summary

    Box Header, 2.54mm, 1x5 Pin Header, 2.0mm, 8x2 Box Header, 2.0mm, 5x2 Box Header, 2.0mm, 22x2 LCD Back Light Control Expansion I/O Box Header, 2.0mm, 28x2 Power Terminal Block, 2x1 RJ45 Connector LCD Backlight Pin Header, 2.0mm, 1x2 ICOP Technology Inc.

  • Page 19: Pin Assignments & Jumper Settings

    J9: CAN BUS Pin# Single Name Pin # Single Name Pin# Single Name CAN_H CAN_L J5: USB1 Pin# Single Name Pin # Single Name LUSBD1- LUSBD1+ J6: SATA DOM POWER Pin# Single Name Pin # Single Name ICOP Technology Inc.
  • Page 20 +.3.3VAUX GPIO_0 UIM_PWR UIM_DATA REFCLK- REFCLK- UIM_CLK REFCLK+ REFCLK+ UIM_RESET UIM_VPP W_DISABLE# PERST# PERST# PERn0 +3.3VAUX PERn0 +3.3VAUX PERp0 PERp0 +1.5V PETn0 PETn0 PETp0 PETp0 USB_D- USB_D+ +3.3VAUX +3.3VAUX +3.3VAUX +3.3VAUX LED_WWAN# GPIO_1 GPIO_3 GPIO_2 +3.3VAUX VDD3 ICOP Technology Inc.
  • Page 21 Pin # Single Name Pin# Single Name +3.3VAUX VCC3 S_SCL S_SDA REFCLK- REFCLK+ J15: PS/2 Keyboard PERST# Pin# Single Name PERn0 +3.3VAUX KBCLK PERp0 KBDATA PETn0 PETp0 J16: PS/2 Mouse +3.3VAUX Pin# Single Name +3.3VAUX MSCLK MSDATA +3.3VAUX ICOP Technology Inc.

  • Page 22: J20: Lcd Backlight Control

    Single Name ADC_0 ADC_1 ADC_2 ADC_3 ADC_4 ADC_5 ADC_6 ADC_7 J18: VGA Pin# Single Name Pin # Single Name ROUT GOUT BOUT HSYNC VSYNC XCLK HSYNC VSYNC VDDEN J20: LCD Backlight Control Pin# Single Name ENVDD JPENEE VCC3 ICOP Technology Inc.

  • Page 23: J22: Expansion I/O

    +12 ~ 24V DC In GP80 GP81 GP82 GP83 GP84 GP85 GP86 GP87 GP20 GP21 GP22 GP23 GP24 GP25 GP26 GP27 GP30 GP31 GP32 GP33 GP34 GP35 GP36 GP37 GP40 GP41 GP42 GP43 GP44 GP45 GP46 GP47 ICOP Technology Inc.

  • Page 24: Software Resources

    In the following website, you will find our latest user manuals, including OS support resources systems such as evaluation images for Windows Embedded Compact 7, Windows Embedded CE 6.0, Windows Embedded CE 5.0, and Windows XP Embedded (Win XPe). For details, please kindly visit the following link: http://tech.icop.com.tw/ ICOP Technology Inc.

  • Page 25: Technical Support Directly From Icop

    —Any complement or technical situations you want ICOP more focusing on User Manual Feedback To make this user manual more complete, if you have any comments or feedbacks to this manual, please feel free to write to info@icop.com.tw contact your ICOP sales representative. ICOP Technology Inc.

  • Page 26: Warranty

    Returned goods should always be accompanied by a clear problem description. Should you have questions about warranty and RMA service, please contact us directly. ICOP Technology Inc. Address: No. 15 Wugong 5th Road, Xinzhuang Dist. New Taipei City, Taiwan (R.O.C.) 24890...
