Arkon SLIM-GRIP SM511 User Manual

SM427 | Bicycle Handlebar Mount with Universal Holder SM511 |
Slim-Grip™ Universal Holder with Auto Sun Visor Mount
CM011-2 CM011-2
Sun Visor Mount Sun Visor Mo
SP-SBH-KIT
with AP2T17MM
Swivel Ball Head
Adapter
Sun Visor Mounting
!
Note: Arkon strongly recommends using the visor mount
on the passenger side sun visor. Using this mount on the
driver's side visor will reduce the driver's view of the road.
Do not place device car charger cords in or near an air bag
deployment zone.
Step 1. Lower the vehicle sun visor and place the clip mount over
the top of the visor. Slide the mount left or right to adjust
the location on the visor.
Connecting the Swivel Ball Adapter to the Dual T-Tab Mount
Step 1. Connect the dual T-slots (A) on swivel ball adapter to the dual
T-tabs (B) on the sun visor mount.
B
Safety Precautions
!
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
82 mm
expandable to
118.5 mm
SM050-2
Universal Phone
Holder
A
B
Package Contents:
(1) SM050-2 Universal phone and portable device holder
(1) CM011-2 - Sun visor mount
(1) SP-SBH-KIT - Swivel Ball Head
(1) AP2T17MM - Dual T-Tab Swivel Ball Adapter
• Compatible with most smartphones, mobile phones, and cell phones having
heights between 80mm and 115mm tall
• Apple iPhone - All models
• RIM BlackBerry - All non-fl ip models
• HTC Phones - All non-fl ip models
• Motorola Phones - All non-fl ip models
• Nokia Mobile Phones - All non-fl ip models
• Palm - All non-fl ip models
• LG Mobile Phones - All non-fl ip models
• Samsung - All non-fl ip models
• Sony Ericsson - All non-fl ip models
• Sanyo - All non-fl ip models
• Pantech - All non-fl ip models
• Google - All non-fl ip models
Install the Support Legs to the Holder
Step 1. Insert the holder support legs (C) by sliding them into the
support leg grooves (D) on the top and bottom of the holder.
C
C
Connecting the Slim-Grip™ Holder to the Swivel Head Adpater
Step 1. Connect the dual T-slots (E) on holder to the dual T-tabs (F) on
the pedestal head.
Optional Cord Optional Cord
Catcher Catcher
®
Consumer Hotline:
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
*All brand names and product
names are trademarks or registered
trademarks of their respective owners.
D
C
C
D
F
E
Continued on other side...
The Mobile Mounting Specialists™
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2010 Arkon Resources, Inc.
