12
SPECIFICATIONS AND OPTIONS
Specifications
All stated specifications are subject to change without notice or obligation.
D General
• Frequency range:
IC-A25N/IC-A25NE
IC-A25C/IC-A25CE
• Channel spacing:
• Mode:
• Number of memory channels:
• Antenna impedance:
• Antenna connector:
• Power supply requirement:
• Current drain:
• Operating temperature range:
IC-A25N/IC-A25C
IC-A25NE/IC-A25CE
• Dimensions (projections not included): 58.9 (W) × 148.4 (H) × 31.8 (D) mm, 2.3 (W) × 5.8 (H) × 1.3 (D) inches
• Weight (approximately):
D Transmitter
• Output power:
• Modulation limiting:
• Audio harmonic distortion:
• Ham and Noise ratio:
• Spurious emissions:
• Frequency stability:
D Receiver
• Receive system:
• Intermediate frequencies:
• Sensitivity:
VOR/COM
WX
• Squelch sensitivity (Threshold):
VOR/COM
WX
• Spurious response rejection ratio:
VOR/COM
WX
• Audio output power:
* 1 For only the IC-A25N and IC-A25C.
* 2 Except operating frequency ±62.5 kHz in 25 kHz channel spacing.
* 3 Except operating frequency ±20.825 kHz in 8.33 kHz channel spacing.
* 4 When the GPS, Bluetooth, and Backlight are OFF.
TX 118.000 ~ 136.99166 MHz
RX 108.000 ~ 136.99166 MHz
WX 161.650 ~ 163.275 MHz
TX 118.000 ~ 136.99166 MHz
RX 118.000 ~ 136.99166 MHz
WX 161.650 ~ 163.275 MHz
25 kHz/8.33 kHz
6K00A3E/5K60A3E
300 channels
50 ˘ nominal
BNC type
7.2 V DC standard or 11.0 V DC at the external DC jack
TX Less than 1.8 A
RX 90 mA typical (at standby), Less than 500 mA (at AF maximum)*
–10˚C to +60˚C, 14˚F to +140˚F
–20˚C to +55˚C
384 g, 13.6 oz with antenna and BP-288
6.0 W (PEP) typical
70 to 100%
Less than 10% (at 60% modulation)
More than 35 dB
More than 46 dB *2 *3
±0.4 kHz
Double conversion superheterodyne
1st 46.35 MHz, 2nd 450 kHz
Less than 0 dBu (at 6 dB S/N)
Less than –8 dBu (at 12 dB SINAD)
Less than 0 dBu
Less than –5 dBu
More than 60 dB
More than 30 dB
More than 350 mW at 10% distortion into an 8 ˘ load
12-2
*1
*1
4
