Icom A25C SPORT 66 USA Navigation Manual

NAVIGATION GUIDE
VHF AIR BAND TRANSCEIVERS
Iç-A25N
Iç-A25NE
D Operating Bluetooth
The IC-A25N and IC-A25NE have a built-in Bluetooth unit.
You can connect Bluetooth headsets, or other Bluetooth
devices to use some of navigation functions.
The communication range of Bluetooth is approximately
10 meters (33 ft).
Bluetooth
IC-A25N or
IC-A25NE
NOTE:
• The Bluetooth communication range may vary,
depending on the environment where you operate the
device.
• The key beep sound may distorts when using the
transceiver with a Bluetooth headset. Reduce the key
beep level to prevent the distortion.
([MENU] > Sounds Settings > Beep)
• You cannot switch the optional VS-3 Bluetooth headset
to other devices, if the VOX level is set to 6.
([MENU] > Radio Settings > VOX Level)
D Electromagnetic Interference
When you use a Bluetooth device, pay attention to the
following:
Bluetooth devices operate in the 2.4 GHz band. The 2.4
GHz band is also used by other devices, such as Wireless
LAN products, microwave ovens, RFID systems, amateur
radio stations, and so on.
When using this device near such devices, interference may
occur, causing a decrease in communication speed, and an
unstable connection.
In such cases, use this device away from the other devices,
or stop using those devices.
Bluetooth ®
®
Bluetooth headset
®
(Example: Optional VS-3 )
Thank you for choosing this Icom product.
READ ALL INSTRUCTIONS carefully and completely
before using this product.
OPERATION
D Pairing with a device
You can pair Bluetooth headsets and data devices to the
transceiver, as shown below:
• A maximum of 5 Bluetooth headsets and data devices.
• A maximum of 2 Low Energy (LE) devices.
L These instructions describe pairing with the VS-3 Bluetooth
, as an example.
headset
1. Turning ON the transceiver's Bluetooth function
1. Push [MENU].
2. Select "Bluetooth Set," and then push [ENT].
(Bluetooth > Settings > Bluetooth Set)
3. Select "ON," and then push [ENT].
4. Push [MENU] to return to the Main screen.
2. Entering the VS-3 Pairing mode
Refer to the VS-3's instruction manual for details.
3. Pairing and connecting the Bluetooth headset
1. Push [MENU].
2. Select "Search Device," and then push [ENT].
(Bluetooth > Pairing/Connect > Search Device)
L The transceiver cannot search for a new headset or device if
it is connected with more than 2 headsets or devices.
3. Select "Headset."
• The transceiver searches for a headset.
L Push [CLR] to cancel searching.
4. Select the headset to pair, and then push [ENT].
L "No Device Found" is displayed if no headsets or devices
are found.
L A passkey or PIN code may be required to pair, depending
on the headset or device. Refer to your headset or device's
instructions for details.
L The headset or device name changes to its Bluetooth device
address in 5 seconds.
5. Push [MENU] to return to the Main screen.
• " " is displayed if the headset or device is correctly
connected.
- 1 -
®
