Icom PMR446 Service Manual page 13

SECTION 6
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1140008770 S.IC
IC2 1110002820 S.IC
IC3 1140008350 S.IC
IC5 1110004710 S.IC
IC6 1180001150 S.IC
IC9 1110002810 S.IC
Q1 1590000720 S.TRANSISTOR
Q2 1590001440 S.TRANSISTOR
Q3 1590002920 S.TRANSISTOR
Q5 1510000580 S.TRANSISTOR
Q6 1560000840 S.FET
Q7 1530002280 S.TRANSISTOR
Q10 1530002280 S.TRANSISTOR
Q11 1530003090 S.TRANSISTOR
Q12 1530002280 S.TRANSISTOR
Q14 1590001330 S.TRANSISTOR
Q18 1510000770 S.TRANSISTOR
Q23 1590001390 S.FET
Q25 1590002490 S.TRANSISTOR
Q27 1530002280 S.TRANSISTOR
Q28 1520000200 S.TRANSISTOR
Q29 1590000680 S.TRANSISTOR
Q101 1590002630 S.TRANSISTOR
D2 1750000550 S.DIODE
D4 1750000550 S.DIODE
D5 1750000550 S.DIODE
X1 6050010450 S.XTAL
R2 7030003670 S.RESISTOR
R4 7030003670 S.RESISTOR
R5 7030003810 S.RESISTOR
R6 7030003710 S.RESISTOR
R7 7030003450 S.RESISTOR
R9 7030003680 S.RESISTOR
R10 7030003310 S.RESISTOR
R12 7030003200 S.RESISTOR
R13 7030003520 S.RESISTOR
R14 7030003500 S.RESISTOR
R22 7030003620 S.RESISTOR
R23 7030003580 S.RESISTOR
R24 7030003820 S.RESISTOR
R25 7030003570 S.RESISTOR
R26 7030003560 S.RESISTOR
R27 7030003320 S.RESISTOR
R30 7030003580 S.RESISTOR
R31 7030003800 S.RESISTOR
R32 7030003780 S.RESISTOR
R33 7030003540 S.RESISTOR
R34 7030003540 S.RESISTOR
R35 7030003530 S.RESISTOR
R36 7030003560 S.RESISTOR
R37 7030003600 S.RESISTOR
R38 7030003600 S.RESISTOR
R39 7030003670 S.RESISTOR
R40 7030003680 S.RESISTOR
R41 7030003530 S.RESISTOR
R42 7030003500 S.RESISTOR
R43 7030003650 S.RESISTOR
R45 7030003840 S.RESISTOR
R46 7030003320 S.RESISTOR
R49 7030003320 S.RESISTOR
R50 7030003520 S.RESISTOR
R51 7030003760 S.RESISTOR
R52 7030003740 S.RESISTOR
R53 7030003820 S.RESISTOR
R54 7030003450 S.RESISTOR
R55 7030003330 S.RESISTOR
R56 7030004050 S.RESISTOR
R57 7030003580 S.RESISTOR
PARTS LIST
DESCRIPTION
µPD753036GK-559-BE9
NJM2100M-T1
AT24C02N-10SI-2.7
S-80928ANMP-DDR-T2
S-81230SG-QB-T1
NJM2070M-T1
DTA144EUA T106
UN9214 (TX)
DTA123JUA T106
2SA1362-GR (TE85R)
2SK1829 (TE85R)
2SC4081 T107 S
2SC4081 T107 S
2SC4213-B (TE85R)
2SC4081 T107 S
DTA114EUA T106
2SA1586-GR (TE85R)
2SJ144-Y (TE85R)
UMZ2N TR
2SC4081 T107 S
2SB798-T2 DK
DTC114EUA T106
UMZ1N TR
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
CR-627 (5.8368 MHz)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 125 V (1.2 MΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 820 V (82 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 155 V (1.5 MΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 684 V (680 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 155 V (1.5 MΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 121 V (120 Ω)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 153 V (15 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R58 7210001970 VARIABLE
R59 7030003680 S.RESISTOR
R61 7030003280 S.RESISTOR
R62 7030003680 S.RESISTOR
R63 7030003530 S.RESISTOR
R64 7030003590 S.RESISTOR
R65 7030003590 S.RESISTOR
R66 7030003590 S.RESISTOR
R67 7030003590 S.RESISTOR
R68 7030003590 S.RESISTOR
R69 7030003590 S.RESISTOR
R70 7030003660 S.RESISTOR
R71 7030003620 S.RESISTOR
R72 7030003800 S.RESISTOR
R74 7030003560 S.RESISTOR
R76 7030003680 S.RESISTOR
R77 7030003400 S.RESISTOR
R78 7030003560 S.RESISTOR
R79 7030003720 S.RESISTOR
R80 7030003680 S.RESISTOR
R81 7030003560 S.RESISTOR
R86 7030003680 S.RESISTOR
R87 7030003800 S.RESISTOR
R88 7030003680 S.RESISTOR
R89 7030003440 S.RESISTOR
R90 7030003440 S.RESISTOR
R94 7030003720 S.RESISTOR
R95 7030003520 S.RESISTOR
R96 7030003680 S.RESISTOR
R97 7030003680 S.RESISTOR
R98 7030003680 S.RESISTOR
R99 7030003680 S.RESISTOR
R100 7030003680 S.RESISTOR
R101 7030003680 S.RESISTOR
R102 7030003680 S.RESISTOR
R103 7030003680 S.RESISTOR
R105 7030003560 S.RESISTOR
R106 7030003560 S.RESISTOR
R108 7030003620 S.RESISTOR
R110 7030003800 S.RESISTOR
R112 7030003560 S.RESISTOR
R114 7030003500 S.RESISTOR
R115 7030003410 S.RESISTOR
R117 7030003680 S.RESISTOR
R118 7030003520 S.RESISTOR
R119 7030003680 S.RESISTOR
R200 7030003840 S.RESISTOR
R201 7030003370 S.RESISTOR
R202 7030003320 S.RESISTOR
R203 7030003550 S.RESISTOR
R204 7030003540 S.RESISTOR
C1 4030008470 S.CERAMIC
C3 4030011600 S.CERAMIC
C4 4030011600 S.CERAMIC
C5 4030006850 S.CERAMIC
C6 4030008680 S.CERAMIC
C7 4030011600 S.CERAMIC
C8 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C9 4030006850 S.CERAMIC
C10 4030006850 S.CERAMIC
C11 4030006850 S.CERAMIC
C15 4030011600 S.CERAMIC
C17 4550006880 S.TANTALUM
C18 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C20 4030011600 S.CERAMIC
C21 4030011600 S.CERAMIC
C24 4030008900 S.CERAMIC
C25 4030006850 S.CERAMIC
C26 4030006850 S.CERAMIC
C27 4030011600 S.CERAMIC
C28 4030008920 S.CERAMIC
C29 4030007150 S.CERAMIC
C31 4030008880 S.CERAMIC
C32 4030011600 S.CERAMIC
6 - 1
DESCRIPTION
RV-244
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 562 V (5.6 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
C1608 JB 1H 272K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 471K-T-A
C2012 JF 1C 105Z-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1C 104KT-N
TEMSVD2 0J 157M-12R
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 333K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 473K-T-A
C1608 CH 1H 151J-T-A
C1608 JB 1C 223K-T-A
C1608 JB 1C 104KT-N
S.=Surface mount
