  • Page 1: User Manual

    CT-5374 Multi-DSL WLAN Router User Manual Version A2.1, April 30, 2010 261099-005...
  • Page 2 Copyright Copyright©2010 Comtrend Corporation. All rights reserved. The information contained herein is proprietary to Comtrend Corporation. No part of this document may be translated, transcribed, reproduced, in any form, or by any means without prior written consent of Comtrend Corporation.
  • Page 3 NOTE: This document is subject to change without notice. Protect Our Environment This symbol indicates that when the equipment has reached the end of its useful life, it must be taken to a recycling centre and processed separate from domestic waste. The cardboard box, the plastic contained in the packaging, and the parts that make up this router can be recycled in accordance with regionally established regulations.

  • Page 4: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ......................5 1.1 F ............................5 EATURES 1.2 A ........................... 6 PPLICATION CHAPTER 2 INSTALLATION ......................7 2.1 H .......................... 7 ARDWARE ETUP 2.2 LED I ..........................9 NDICATORS CHAPTER 3 WEB USER INTERFACE ....................11 3.1 D ........................11 EFAULT...
  • Page 5 5.15 C ..........................61 ERTIFICATE 5.15.1 Local ..........................62 5.15.2 Trusted CA ........................63 5.16 P ........................ 65 OWER ANAGEMENT CHAPTER 6 WIRELESS ........................66 6.1 B ............................66 ASIC 6.2 S ............................68 ECURITY 6.2.1 WPS............................70 6.3 MAC F ..........................

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction The CT-5374 Multi-DSL WLAN Router provides wired and wireless access for high-bandwidth applications in the home or office. It includes four fast Ethernet ports and supports ADSL2/2+ and VDSL2 connections with DSLAM switching. ADSL2+ connections support multiple simultaneous Internet connections while VDSL2 connections are suitable for triple play (Video + Voice + Data) applications.

  • Page 7: Application

    1.2 Application The following diagrams depict typical applications of the CT-5374.

  • Page 8: Chapter 2 Installation

    Indicators for details). NOTE: If pressed down for more than 20 seconds, the CT-5374 will go into a firmware update state (CFE boot mode). The firmware can then be updated using an Internet browser pointed to the default IP address.
  • Page 9 Ethernet (LAN) Ports Use 10/100 BASE-T RJ-45 cables to connect up to four network devices. These ports are auto-sensing MDI/X; so either straight-through or crossover cable can be used. DSL Port Connect to an ADSL2/2+ or VDSL with this RJ11 Port. This device contains a micro filter which removes the analog phone signal.

  • Page 10: Led Indicators

    2.2 LED Indicators The front panel LED indicators are shown below and explained in the following table. This information can be used to check the status of the device and its connections. Color Mode Function IP connected and no traffic detected. If an IP or PPPoE session is dropped due to an idle timeout, the light will remain green if an ADSL connection is still present.
  • Page 11 transmitting. slow: xDSL training failed. Powered device connected to the associated port. Green No activity, modem powered off, no cable (for 10/100 or no powered device connected to the Base-T) associated port. Blink Traffic is passing. GbETH Powered device connected to the associated port.

  • Page 12: Chapter 3 Web User Interface

    3.2 IP Configuration DHCP MODE When the CT-5374 powers up, the onboard DHCP server will switch on. Basically, the DHCP server issues and reserves IP addresses for LAN devices, such as your PC. To obtain an IP address from the DCHP server, follow the steps provided below.
  • Page 13 STEP 4: Click OK to submit these settings. If you experience difficulty with DHCP mode, you can try static IP mode instead.
  • Page 14 STATIC IP MODE In static IP mode, you assign IP settings to your PC manually. Follow these steps to configure your PC IP address to use subnet 192.168.1.x. NOTE: The following procedure assumes you are running Windows XP. However, the general steps involved are similar for most operating systems (OS).

  • Page 15: Login Procedure

    3.3 Login Procedure Perform the following steps to login to the web user interface. NOTE: The default settings can be found in 3.1 Default Settings. STEP 1: Start the Internet browser and enter the default IP address for the device in the Web address field.
  • Page 16 STEP 3: After successfully logging in for the first time, you will reach this screen.

  • Page 17: Chapter 4 Device Information

    Chapter 4 Device Information The web user interface window is divided into two frames, the main menu (at left) and the display screen (on the right). The main menu has several options and selecting each of these options opens a submenu with more selections. NOTE: The menu items shown are based upon the configured connection(s) and user account privileges.

  • Page 18: Wan

    4.1 WAN Select WAN from the Device Info submenu to display the configured PVC(s). Heading Description Interface Name of the interface for WAN Description Name of the WAN connection Type Shows the connection type VlanMuxId Shows 802.1Q VLAN ID IPv6 Shows WAN IPv6 address IGMP Shows Internet Group Management Protocol (IGMP) status...

  • Page 19: Lan Statistics

    4.2.1 LAN Statistics This screen shows data traffic statistics for each LAN interface. Heading Description Interface LAN interface(s) Received/Transmitted: - Bytes Number of Bytes - Pkts Number of Packets - Errs Number of packets with errors - Drops Number of dropped packets 4.2.2 WAN Statistics This screen shows data traffic statistics for each WAN interface.

  • Page 20: Atm Statistics

    Heading Description Interface WAN interfaces Description WAN service label Received/Transmitted - Bytes Number of Bytes - Pkts Number of Packets - Errs Number of packets with errors - Drops Number of dropped packets 4.2.3 ATM Statistics The following figure shows Asynchronous Transfer Mode (ATM) statistics. ATM Interface Statistics Heading Description...
  • Page 21 Heading Description Out Octets Number of transmitted octets over the interface In Errors Number of cells dropped due to uncorrectable HEC errors In Unknown Number of received cells discarded during cell header validation, including cells with unrecognized VPI/VCI values, and cells with invalid cell header patterns.

  • Page 22: Xdsl Statistics

    Heading Description Oversized SDUs Number of PDUs discarded because the corresponding SDU was too large Short Packet Number of PDUs discarded because the PDU length was less Errors than the size of the AAL5 trailer Length Errors Number of PDUs discarded because the PDU length did not match the length in the AAL5 trailer 4.2.4 xDSL Statistics...
  • Page 23 ADSL Click the Reset Statistics button to refresh this screen. Field Description Mode G.Dmt, G.lite, T1.413, ADSL2, ADSL2+,VDSL, VDSL2 Traffic Type Channel type Interleave or Fast Status Lists the status of the DSL link Link Power State Link output power state.
  • Page 24 Line Coding (Trellis) Trellis On/Off SNR Margin (0.1 dB) Signal to Noise Ratio (SNR) margin Attenuation (0.1 dB) Estimate of average loop attenuation in the downstream direction. Output Power Total upstream output power (0.1 dBm) Attainable Rate (Kbps) The sync rate you would obtain. Rate (Kbps) Current sync rates downstream/upstream In VDSL mode, the following section is inserted.
  • Page 25 OH Frames Total number of OH frames OH Frame Errors Number of OH frames received with errors RS Words Total number of Reed-Solomon code errors RS Correctable Errors Total Number of RS with correctable errors RS Uncorrectable Total Number of RS words with uncorrectable errors Errors HEC Errors Total Number of Header Error Checksum errors...
  • Page 27 xDSL TONE GRAPH Click Draw Tone Graph on the xDSL Statistics screen and a pop-up window will display the xDSL bits per tone status, as shown below.

  • Page 28: Route

    4.3 Route Choose Route to display the routes that the CT-5374 has found. Field Description Destination Destination network or destination host Gateway Next hub IP address Subnet Mask Subnet Mask of Destination Flag U: route is up !: reject route...

  • Page 29: Arp

    4.4 ARP Click ARP to display the ARP information. Field Description IP address Shows IP address of host pc Flags Complete, Incomplete, Permanent, or Publish HW Address Shows the MAC address of host pc Device Shows the connection interface...

  • Page 30: Dhcp

    4.5 DHCP Click DHCP to display all DHCP Leases. Field Description Hostname Shows the device/host/PC network name MAC Address Shows the Ethernet MAC address of the device/host/PC IP Address Shows IP address of device/host/PC Expires In Shows how much time is left for each DHCP Lease...

  • Page 31: Chapter 5 Advanced Setup

    Chapter 5 Advanced Setup Click on the link to jump to a specific section: 5.1 Layer 2 Interface 5.9 Routing 5.2 WAN 5.10 DNS 5.3 LAN 5.11 DSL 5.4 IPv6 LAN Host 5.12 UPnP 5.5 NAT 5.13 Print Server 5.6 Security 5.14 Interface Grouping 5.7 Parental Control 5.15 Certificate...

  • Page 32: Ptm Interface

    5.1.2 PTM Interface Add or remove PTM interface connections here. Click Add to create a new connection (see Appendix G - Connection Setup). To remove a connection, select its Remove column radio button and click Remove. 5.1.3 ETH WAN INTERFACE This screen displays the Ethernet WAN Interface configuration.

  • Page 33: Wan

    5.2 WAN This screen allows for the configuration of WAN interfaces. Click the Add button to create a new connection. For connections on ATM or ETH WAN interfaces see Appendix G - Connection Setup. NOTE: ETH and ATM service connections cannot coexist. In Default Mode, up to 8 WAN connections can be configured;...

  • Page 34: Lan

    5.3 LAN Configure the LAN interface settings and then click Apply/Save. Consult the field descriptions below for more details. GroupName: Select an Interface Group. LAN INTERFACE IP Address: Enter the IP address for the LAN port. Subnet Mask: Enter the subnet mask for the LAN port. Enable IGMP Snooping: Enable by ticking the checkbox Standard Mode: In standard mode, multicast traffic will flood to all bridge ports when no client subscribes to a multicast...
  • Page 35 Enable LAN side firewall: Enable by ticking the checkbox DHCP Server: To enable DHCP, select Enable DHCP server and enter Start and End IP addresses and the Leased Time. This setting configures the router to automatically assign IP, default gateway and DNS server addresses to every PC on your LAN.

  • Page 36: Ipv 6 Lan Host

    IP Address: Enter the secondary IP address for the LAN port. Subnet Mask: Enter the secondary subnet mask for the LAN port. 5.4 IPv6 LAN Host Configure the IPv6 LAN Host options (see below) and then click Save/Apply. DHCPv6 Server: To enable DHCP for IPv6, select the Enable DHCPv6 server checkbox .

  • Page 37: Nat

    Enable MLD Snooping: Enable by ticking the checkbox Standard Mode: In standard mode, multicast traffic will flood to all bridge ports when no client subscribes to a multicast group – even if snooping is enabled. Blocking Mode: In blocking mode, the multicast data traffic will be blocked and not flood to all bridge ports when there are no client subscriptions to any multicast group.
  • Page 38 Consult the table below for field and header descriptions. Field/Header Description Use Interface Select a WAN interface from the drop-down box. Select a Service User should select the service from the list. Custom Service User can enter the name of their choice. Server IP Address Enter the IP address for the server.

  • Page 39: Port Triggering

    5.5.2 Port Triggering Some applications require that specific ports in the firewall be opened for access by the remote parties. Port Triggers dynamically 'Open Ports' in the firewall when an application on the LAN initiates a TCP/UDP connection to a remote party using the 'Triggering Ports'.

  • Page 40: Dmz Host

    Field/Header Description Trigger Port Start Enter the starting trigger port number (when you select custom application). When an application is selected, the port ranges are automatically configured. Trigger Port End Enter the ending trigger port number (when you select custom application). When an application is selected, the port ranges are automatically configured.

  • Page 41: Security

    5.6 Security To display this function, you must enable the firewall feature in WAN Setup. For detailed descriptions, with examples, please consult Appendix A - Firewall. 5.6.1 IP Filtering This screen sets filter rules that limit IP traffic (Outgoing/Incoming). Multiple filter rules can be set and each applies at least one limiting condition.
  • Page 42 Consult the table below for field descriptions. Field Description Filter Name The filter rule label Protocol TCP, TCP/UDP, UDP, or ICMP. Source IP address Enter source IP address. Source Subnet Mask Enter source subnet mask. Source Port (port or port:port) Enter source port number or range.

  • Page 43: Mac Filtering

    Each network device has a unique 48-bit MAC address. This can be used to filter (block or forward) packets based on the originating device. MAC filtering policy and rules for the CT-5374 can be set according to the following procedure. The MAC Filtering Global Policy is defined as follows. FORWARDED means that all MAC layer frames will be FORWARDED except those matching the MAC filter rules.
  • Page 44 FORWARDED. It can be changed by clicking the Change Policy button. Choose Add or Remove to configure MAC filtering rules. The following screen will appear when you click Add. Create a filter to identify the MAC layer frames by specifying at least one condition below. If multiple conditions are specified, all of them must be met.

  • Page 45: Parental Control

    5.7 Parental Control This selection provides WAN access control functionality. 5.7.1 Time Restriction This feature restricts access from a LAN device to an outside network through the device on selected days at certain times. Make sure to activate the Internet Time server synchronization as described in 8.5 Internet Time, so that the scheduled...

  • Page 46: Url Filter

    5.7.2 URL Filter This screen allows for the creation of a filter rule for access rights to websites based on their URL address and port number. Click Add to display the following screen. Enter the URL address and port number then click Save/Apply to add the entry to the URL filter.

  • Page 47: Quality Of Service (Qos)

    5.8 Quality of Service (QoS) NOTE: QoS must be enabled in at least one PVC to display this option. (see Appendix G - Connection Setup for detailed PVC setup instructions). 5.8.1 Queue Management Configuration To Enable QoS tick the checkbox and select a Default DSCP Mark.

  • Page 48: Qos Classification

    Click Enable to activate the QoS Queue. Click Add to display the following screen. Name: Identifier for this Queue entry. Enable: Enable/Disable the Queue entry. Interface: Assign the entry to a specific network interface (QoS enabled). Precedence: Configure precedence for the Queue entry. Lower integer values for precedence imply higher priority for this entry relative to others.
  • Page 49 Click Add to configure a network traffic class rule and Enable to activate it. To delete an entry from the list, click Remove. This screen creates a traffic class rule to classify the upstream traffic, assign queuing priority and optionally overwrite the IP header DSCP byte. A rule consists of a class name and at least one logical condition.

  • Page 50: Routing

    Field Description Source MAC Address A packet belongs to SET-1, if a binary-AND of its source MAC address with the Source MAC Mask is equal to the binary-AND of the Source MAC Mask and this field. Source MAC Mask This is the mask used to decide how many bits are checked in Source MAC Address.
