- Page 1 Atrust t100 ’ ’...
-
Page 3: Limitation Of Liability
Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer. Version 1.0, May 2008 Trademarks Other product names mentioned herein are used for identification purposes only... -
Page 4: Table Of Contents
Table of Contents About This User’s Manual -------------------------------------------------- 3 Notes for This Manual ------------------------------------------------------- 3 Safety Precautions ----------------------------------------------------------- 3 GETTING TO KNOW YOUR Atrust t100 ........... 7 Out of the Box ----------------------------------------------------------------- 7 Optional Items ------------------------------------------------------------------ 8 Front View ---------------------------------------------------------------------- 9... -
Page 5: About This User's Manual
TC1 and how to use them. The following are the major sections of this User’s Manual: Getting to Know Your Atrust t100–introduces you to the Atrust t100 and it’s components. Getting Started–provides information on getting started with your Atrust t100. -
Page 6: Safety Precautions
DO NOT place or drop objects on top of the Atrust t100. DO NOT dispose of the Atrust t100 in municipal waste. Check local regulations for disposal of electronic products. DO NOT carry or cover the Atrust t100 with any materials that reduce air circulation when powered ON. - Page 7 錯 誤 尚 未 定 義 樣 式 。 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 8 Atrust t100 User’s Manual IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
-
Page 9: Getting To Know Your Atrust T100
錯 誤 尚 未 定 義 樣 式 。 Getting to Know Your Atrust t100 Out of the Box Unpack the Atrust t100 package and ensure the following items are included. Atrust t100 Power Adapter and Cable Desktop Bracket LCD Bracket... -
Page 10: Optional Items
Atrust t100 User’s Manual User’s Manual Recovery CD If any item is missing or damaged, contact your dealer. Optional Items Keyboard Mouse... -
Page 11: Front View
Refer to the following diagram to identify the components on the front of the Atrust t100. Item Description Power button Press to power the Atrust t100 on or off Power LED Lights blue when Atrust t100 is powered on USB Ports Connect USB devices, such as a keyboard or... -
Page 12: Rear View
Atrust t100 User’s Manual Rear View Refer to the following diagram to identify the I/O ports on the rear of the Atrust t100. Item Description DC Jack Connect the supplied power cable to this port LAN Port Connect an RJ-45 Ethernet cable to this port... -
Page 13: Hardware Features
錯 誤 尚 未 定 義 樣 式 。 Hardware Features Item Specification Remarks VIA Eden ULV 500MHz/1W, Eden Optional 1GHz/5W Chipset VIA VX800/VX800U Memory DRAM: One SODIMM Module, Optional 512MB/1GB Flash: Disk On Module (DOM), Optional 4GB/8GB Display Resolution: Max 1600x1200 Communications LAN: Integrated 10/100 Ethernet VIA VT-6107... - Page 14 Atrust t100 User’s Manual Item Specification Remarks Power Supply Input/Output DC +9V 2.315A Adapter, 100-240V, 50- 60Hz (PIE) Power Consumption 22W LED Indicators Power LED: Front Blue – Power On/S1 Stage Orange – S3 Stage Off – Power OFF/S4/S5 stage...
-
Page 15: Getting Started
Desktop Setup You can place the Atrust t100 directly on your desktop, supported by the four rubber feet or by placing the Atrust t100 in the desktop bracket you can install the Atrust t100 upright to save desk space. To install the desktop bracket, perform the following steps: Place the cradle on a dust-free, level surface. -
Page 16: Using The Lcd Bracket
Atrust t100 User’s Manual Using the LCD Bracket Using the discrete LCD bracket, you can install the Atrust t100 behind a standard LCD display, hiding unsightly cables and maximizing desktop space. To install the LCD bracket, perform the following steps: Install the LCD bracket on the rear of the LCD display using the supplied mounting screws. -
Page 17: Making Connections
錯 誤 尚 未 定 義 樣 式 。 Making Connections The following diagram illustrates the basic requirements for Atrust t100 connection, including LCD display, keyboard, mouse, network, and audio I/O. Powering On Your Atrust t100 After making the required connections, perform the following steps to power on the Atrust t100: Connect the power adapter to the power cable as shown. - Page 18 Atrust t100 User’s Manual Connect the power adapter to the rear of Atrust t100 and the power cable to a power outlet. Press the power button on the Atrust t100 front panel. The Power LED lights blue and the Atrust splash screen displays.
-
Page 19: Bios Introduction
錯 誤 尚 未 定 義 樣 式 。 BIOS Introduction BIOS Overview The following table describes the first, second, and third level Atrust t100 BIOS options. Top Level Menu Level Menu Level Menu Main Version Build Data Processor Speed... - Page 20 Atrust t100 User’s Manual Top Level Menu Level Menu Level Menu Boot Boot Setting Quick Boot Configuration Quiet Boot Hit ‘DEL’ Message Display Security Change Supervisor Password Change User Password Exit Save Changes and Exit Discard Changes and Exit Discard Changes...
- Page 21 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
