Atrust t68WD Thin Client
User's Manual
Internal Draft 0.01
© 2015 Atrust Computer Corp.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the t68WD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atrust t68WD

Summary of Contents for Atrust t68WD

  • Page 1 Atrust t68WD Thin Client User’s Manual Internal Draft 0.01 © 2015 Atrust Computer Corp.
  • Page 2 UM-t68WD-EN-15110915...

  • Page 3: Copyright And Trademark Statements

    Corp. Disclaimer Atrust Computer Corp. (“Atrust”) makes no representations or warranties with respect to the contents or use of this document, and specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose. Atrust is not liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.

  • Page 4: About This User's Manual

    About This User’s Manual This manual provides detailed instructions on how to set up, use, manage, and maintain Atrust t68WD thin clients. Manual Structure and Subjects Chapter Subject Provides an overview of Atrust t68WD thin clients. Provides detailed instructions on how to set up Atrust t68WD thin clients.

  • Page 5: Style Conventions

    Style Conventions The following styles are used throughout this manual while referring to operational items on input devices, hardware panels, or application interfaces. Item Style Example keys on the keyboard bold Ctrl + F2, Ctrl + Alt + F9, Alt + Tab application windows or first letter ICA Connection list, RDP Connection list, View Connection list...

  • Page 6: Safety And Regulatory Information

    Safety and Regulatory Information Regulatory Statement Federal Communications Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 7: Regulatory Information

    Regulatory Information WEEE (Waste Electrical and Electronic Equipment) Directive In the European Union, this symbol indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. For proper disposal, please contact your local recycling or hazardous waste center.

  • Page 9: Table Of Contents

    Configuring Client Settings 31 Atrust Client Setup 4.1.1 Interface Overview 4.1.2 Client Settings at a Glance Configuring System Settings 4.2.1 System Tab Overview 4.2.2 Available Settings at a Glance 4.2.3 Configuring the Access Privileges and Password of Atrust Client Setup...
  • Page 10 Configuring Advanced ICA Connection Settings 4.5.9 Configuring Basic VMware View Connection Settings 4.5.10 Accessing VMware View or Horizon View Services 4.5.11 Configuring Advanced View Connection Settings 4.5.12 Configuring Web Browser Settings Appendices Resetting Your t68WD 123 Restoring Your Operating System Specifications...

  • Page 11: Overview

    Overview This chapter provides an overview of Atrust t68WD thin clients. 1.1 Introduction Desktop virtualization and simple endpoint devices 1.2 Features Key features of Atrust t68WD 1.3 Package Contents Check your package contents 1.4 Exterior Views Overview of thin client outside elements 1.5 Panel Components...

  • Page 13: Introduction

    Citrix® XenApp™, XenDesktop®, and VDI-in-a-Box™ Ź VMware® View™ and Horizon View™ • Support for high-definition technologies: Ź Microsoft® RemoteFX® Ź Citrix® HDX™ Ź VMware® View™ PCoIP® • Simple click-access to various applications/desktops • Built-in Atrust Client Setup as the local client management console...

  • Page 14: Package Contents

    1.3 Package Contents Please check your package contents. Ensure that all of the items are present in your package. If any items are missing or damaged, please contact your dealer immediately. Atrust t68WD AC adapter Quick Start Guide DVI-I to VGA adapter...

  • Page 15: Panel Components

    Overview Panel Components 1.5 Panel Components Front Panel Components Sign Name Description Power LED Indicates the status of power. • Press to power on / off the thin client. Power button • Press to exit the System Sleep mode. Microphone port Connects to a microphone.
  • Page 16 Overview Panel Components Rear Panel Components Sign Component Name Description DC IN Connects to an AC adaptor. USB port (USB 2.0) Connects to a USB device. USB port (USB 3.0) Connects to a USB device. LAN port Connects to a network. DisplayPort Connects to a monitor.

  • Page 17: Led Indicators

    Overview LED Indicators 1.6 LED Indicators Your t68WD is equipped with a Power LED to indicate the state of power. The meanings of LED signals are described as follows: Signal Meaning The client is off. Power LED Blue The client is on.

  • Page 18: Before Getting Started

    This is due to a special feature called UWF (Unified Write Filter) in your Windows Embedded-based system. By default, your t68WD is UWF-enabled. Unified Write Filter (UWF) is a sector-based write filter intercepting all write attempts to a protected volume and redirecting those write attempts to a virtual overlay. With UWF, all system changes will only affect the session where the changes are made.

  • Page 19: Service Access With Your T68Wd

    With Atrust t68WD, you can simply access desktop virtualization solutions from Microsoft, Citrix, and VMware, by mouse-clicking. Two types of access shortcuts are available: standard and customized. The former is available on the desktop of Windows Embedded by default; the latter can be created and customized through the Atrust Client Setup console.
