TR7500 series

Online Manual

Basic Operation
Network
Maintenance
Overview of the Machine
Information about Paper
Printing
Copying
Scanning
Faxing
Frequently Asked Questions
List of Support Code for Error
English

Advertisement

Table of Contents

   Summary of Contents for Canon TR7500 Series

  • Page 1: Online Manual

    TR7500 series Online Manual Basic Operation Network Maintenance Overview of the Machine Information about Paper Printing Copying Scanning Faxing Frequently Asked Questions List of Support Code for Error English...
  • Page 2: Table Of Contents

    Contents Using Online Manual..........11 Symbols Used in This Document.
  • Page 3 Checking Ink Status on the Touch Screen..........89 Ink Tips.
  • Page 4 Unplugging the Printer............148 Using the Operation Panel.
  • Page 5 Canon IJ Status Monitor Description........
  • Page 6 Making Copies............295 Setting Items for Copying.
  • Page 7 Starting Up Speed Dial Utility2........... Speed Dial Utility2 Dialog box.
  • Page 8 Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)- Checking Power Status........... . . 439 Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)- Checking PC Network Connection.
  • Page 9 Faxing Problems............489 Problems Sending Faxes.
  • Page 10 1600..............542 1660.
  • Page 11: Using Online Manual

    Using Online Manual Operating Environment Symbols Used in This Document Touch-enabled Device Users (Windows) Printing Online Manual Trademarks and Licenses Screenshots in This Manual...
  • Page 12: Symbols Used In This Document

    Symbols Used in This Document Warning Instructions that, if ignored, could result in death or serious personal injury caused by incorrect operation of the equipment. These must be observed for safe operation. Caution Instructions that, if ignored, could result in personal injury or material damage caused by incorrect operation of the equipment.
  • Page 13: Touch-enabled Device Users (windows)

    Touch-enabled Device Users (Windows) For touch actions, you need to replace "right-click" in this document with the action set on the operating system. For example, if the action is set to "press and hold" on your operating system, replace "right-click" with "press and hold."...
  • Page 14: Trademarks And Licenses

    Adobe Systems Incorporated in the United States and/or other countries. • Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A. and licensed to Canon Inc. • Autodesk and AutoCAD are registered trademarks or trademarks of Autodesk, Inc., and/or its subsidiaries and/or affiliates in the USA and/or other countries.
  • Page 15 Apache License Version 2.0, January 2004 http://www.apache.org/licenses/ TERMS AND CONDITIONS FOR USE, REPRODUCTION, AND DISTRIBUTION 1. Definitions. "License" shall mean the terms and conditions for use, reproduction, and distribution as defined by Sections 1 through 9 of this document. "Licensor" shall mean the copyright owner or entity authorized by the copyright owner that is granting the License.
  • Page 16 2. Grant of Copyright License. Subject to the terms and conditions of this License, each Contributor hereby grants to You a perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable copyright license to reproduce, prepare Derivative Works of, publicly display, publicly perform, sublicense, and distribute the Work and such Derivative Works in Source or Object form. 3.
  • Page 17 7. Disclaimer of Warranty. Unless required by applicable law or agreed to in writing, Licensor provides the Work (and each Contributor provides its Contributions) on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied, including, without limitation, any warranties or conditions of TITLE, NON-INFRINGEMENT, MERCHANTABILITY, or FITNESS FOR A PARTICULAR PURPOSE.
  • Page 18 Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.
  • Page 19 Use is subject to license terms below. This distribution may include materials developed by third parties. Sun, Sun Microsystems, the Sun logo and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
  • Page 20 TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. ---- Part 6: Cisco/BUPTNIC copyright notice (BSD) ----- Copyright (c) 2004, Cisco, Inc and Information Network Center of Beijing University of Posts and Telecommunications.
  • Page 21 SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
  • Page 22 FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
  • Page 23 MIT License Copyright (c) 1998, 1999, 2000 Thai Open Source Software Center Ltd Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions:...
  • Page 24 * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer. * Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. * Neither the name of the University nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission.
  • Page 25: Basic Operation

    Basic Operation Printing Photos from a Computer Printing Photos from a Smartphone/Tablet Copying Faxing...
  • Page 26: Printing Photos From A Computer

    Printing Photos from a Computer This section describes how to print photos with My Image Garden. 1. Open the rear tray cover (A) and then pull up the paper support (B). 2. Open the feed slot cover (C). 3. Load paper vertically WITH THE PRINT SIDE FACING UP. 4.
  • Page 27 5. Close the feed slot cover (E) gently. After closing the feed slot cover, the paper information registration screen for the rear tray is displayed on the touch screen. 6. Select the size and type of the loaded paper in the rear tray at Page size and Type, and then select Register.
  • Page 28 7. Open the operation panel (F), pull out the paper output tray (G) and paper output support (H), and open the output tray extension (I). Be sure to open the operation panel before printing. If the operation panel is close, the printer does not start printing.
  • Page 29 10. Click the folder (L) with photos you want to print. 11. Click the photos (M) you want to print. For Windows: To select two or more photos at a time, click photos while pressing the Ctrl key. For Mac OS: To select two or more photos at a time, click photos while pressing the command key.
  • Page 30 For Mac OS: Specify the number of copies. 14. Start printing. For Windows: Click Print. For Mac OS: Click Print. When the Print dialog starts, specify your printer name, paper size, etc., then click Print. Note • My Image Garden lets you use images on your computer, such as photos taken with a digital camera, in a number of ways.
  • Page 31: Printing Photos From A Smartphone/tablet

    Printing Photos from a Smartphone/Tablet This section describes how to print photos with Canon PRINT Inkjet/SELPHY. For details on how to download Canon PRINT Inkjet/SELPHY, see below. Print Easily from a Smartphone or Tablet with Canon PRINT Inkjet/SELPHY 1. Open the rear tray cover (A) and then pull up the paper support (B).
  • Page 32 5. Close the feed slot cover (E) gently. After closing the feed slot cover, the paper information registration screen for the rear tray is displayed on the LCD. 6. Select the size and type of the loaded paper in the rear tray at Page size and Type, and then select Register.
  • Page 33 8. Start (Canon PRINT Inkjet/SELPHY) from your smartphone/tablet. 9. Select Photo Print on Canon PRINT Inkjet/SELPHY. The list of photos saved on your smartphone/tablet is displayed. 10. Select a photo. You can also select multiple photos at once.
  • Page 34: Copying

    Copying This section describes how to load originals and copy them to plain paper loaded in the cassette. 1. Pull out the cassette (A) from the printer. 2. Remove the cassette cover (B). 3. To load A4 sized paper in the cassette, press down the lock (C) on the cassette, then extend the cassette.
  • Page 35 Important • Do not extend the cassette when loading other than A4 sized paper in the cassette. 4. Load the paper stack WITH THE PRINT SIDE FACING DOWN. 5. Align the paper guides (D) with the paper length and width. 6.
  • Page 36 After inserting the cassette into the printer, the paper information registration screen for the cassette is displayed on the touch screen. 7. Select the size of the loaded paper in the cassette at Page size, and then select Register. 8. Open the operation panel (E), pull out the paper output tray (F) and paper output support (G), and open the output tray extension (H).
  • Page 37 9. Press the HOME button (I). 10. Select Copy (J). 11. Select Standard copy. 12. Open the document cover (K). 13. Load the original WITH THE SIDE TO COPY FACING DOWN and align it with the alignment mark (L).
  • Page 38 14. Close the document cover. 15. Confirm the paper settings, then press the Black button (M) or Color button (N). Important • Do not open the document cover until copying is complete. Note • Your printer is equipped with many other convenient copy features. Copying...
  • Page 39: Faxing

    Faxing Fax multiple documents in black and white as follows. 1. Open the document tray (A). 2. Insert the document WITH THE SIDE TO SCAN FACING UP. 3. Adjust the document guide (B). 4. Press the HOME button (C). 5. Select Copy (D).
  • Page 40 6. Select Enter the number (E). 7. Enter the fax number (F) and select OK (G). 8. Press the Black button (H). Note • Many other convenient faxing features are available. Faxing...
  • Page 41: Network

    Network Available Connection Methods The following connection methods are available on the printer. • Wireless Connection Connect the printer and devices (e.g. computer/smartphone/tablet) using a wireless router. If you have a wireless router, we recommend you use one for wireless connection. ◦...
  • Page 42 Changing Wireless LAN Connection Method Changing Connection Mode • To add computer/smartphone/tablet to the printer: Connecting to Another Computer via LAN/Changing from USB to LAN Connection • To use Wireless Direct temporarily: Printing/Scanning with Wireless Direct IJ Network Device Setup Utility IJ Network Device Setup Utility checks or diagnoses the settings of the printer and those of computer and restores the status of them if anything is wrong with network connection.
  • Page 43: Restrictions

    Restrictions When connecting another device while a device (such as a smartphone) is already connected to the printer, connect it using the same connection method as the connected device. If you connect using a different connection method, the connection to the device in use will be disabled. Connect via wireless router •...
  • Page 44 • In Wireless Direct mode, you can connect up to five devices at the same time. If you try to connect a sixth device while five devices are already connected, an error will appear. If an error appears, disconnect a device that does not use the printer, then configure settings again. •...
  • Page 45: Network Connection Tips

    Network Connection Tips Default Network Settings Another Printer Found with Same Name Connecting to Another Computer via LAN/Changing from USB to LAN Connection Printing Network Settings Changing Wireless LAN Connection Method...
  • Page 46: Default Network Settings

    Enable/disable IPv6 Enable Enable/disable WSD Enable Timeout setting 15 minutes Enable/disable Bonjour Enable Service name Canon TR7500 series LPR protocol setting Enable RAW protocol Enable LLMNR Active PictBridge communication Enable ("XX" represents alphanumeric characters.) * Default value depends on printer. To check value, use operation panel.
  • Page 47 *1 "ab" is specified at random and "XX" represents last two digits of printer's MAC address. (The value is specified when the printer is turned on for the first time.) *2 The password is specified automatically when the printer is turned on for the first time.
  • Page 48: Another Printer Found With Same Name

    Another Printer Found with Same Name When the printer is found during setup, other printers with the same name may appear on the results screen. Select a printer with checking the printer settings against those on detection result screen. • For Windows: Check the printer's MAC address or serial to select the correct printer from the results.
  • Page 49: Connecting To Another Computer Via Lan/changing From Usb To Lan Connection

    Connecting to Another Computer via LAN/Changing from USB to LAN Connection For Windows: For Mac OS: For Windows: To add a computer to connect to the printer on a LAN or to change from USB to LAN connection, perform setup using the Setup CD-ROM or from the web page. For Mac OS: To connect an additional computer to the printer via LAN, or to change from USB to LAN connection, perform setup from the web page.
  • Page 50: Printing Network Settings

    Printing Network Settings Use the operation panel to print the printer's current network settings. Important • The network settings printout contains important information about your network. Handle it with care. Make sure printer is turned on. Load three sheets of A4 or Letter-sized plain paper. 3.
  • Page 51 Result Codes Result codes XXXXXXXX Result Code Details Result code details http://canon.com/ijnwt Wireless LAN Wireless LAN Enable/Disable Infrastructure Infrastructure Enable/Disable 3-2-1 Signal Strength Signal strength 0 to 100 [%] 3-2-2 Link Quality Link quality 0 to 100 [%] 3-2-3 Frequency...
  • Page 52 3-2-22 Stateless Address3 Stateless address 3 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-23 Stateless Prefix Stateless prefix length Length3 3-2-24 Stateless Address4 Stateless address 4 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-25 Stateless Prefix Stateless prefix length Length4 3-2-26 Default Gateway1 Default gateway 1 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-2-27 Default Gateway2 Default gateway 2 XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX...
  • Page 53 3-3-13 Link Local Address Link local address XXXX:XXXX:XXXX:XXXX XXXX:XXXX:XXXX:XXXX 3-3-14 Link Local Prefix Link local prefix length XXX Length 3-3-15 IPsec IPsec setting Active 3-3-16 Security Protocol Security method – Other Settings Other settings – Printer Name Printer name Printer name (Up to 15 alphanumeric characters) WSD Printing WSD printing setting Enable/Disable...
  • Page 54 Bluetooth Bluetooth settings ― Bluetooth Setting Bluetooth Enable/Disable Bluetooth PIN Code Bluetooth PIN code XXXXXXXX Bluetooth Device Ad- Bluetooth device ad- XXXXXXXX dress dress of the printer Peer Device Address Device address of XXXXXXXX paired device Bluetooth Device Bluetooth device XXXXXXXX Name name of the printer...
  • Page 55: Changing Wireless Lan Connection Method

    Changing Wireless LAN Connection Method Follow either procedure below to change wireless LAN connection method (infrastructure or Wireless Direct). • For Windows: ◦ Redo setup using the Setup CD-ROM or from the web page. ◦ Perform settings on the Network Settings screen on IJ Network Device Setup Utility. Important •...
  • Page 56: Handling Paper, Originals, Ink Tanks, Etc

    Handling Paper, Originals, Ink Tanks, etc. Loading Paper Loading Originals Replacing Ink Tanks...
  • Page 57: Loading Paper

    Loading Paper Paper Sources Loading Paper in the Rear Tray Loading Paper in the Cassette Loading Envelopes...
  • Page 58: Paper Sources

    Paper Sources The printer has two paper sources for feeding paper, the rear tray (A) and cassette (B). You can load all supported paper on the rear tray. Supported Media Types You can load A4, B5, A5, or Letter-sized plain paper in the cassette. Note •...
  • Page 59: Loading Paper In The Rear Tray

    For details on the Canon genuine paper, see Supported Media Types. • You can use general copy paper or Canon Red Label Superior WOP111/Canon Océ Office Colour Paper SAT213. For the page size and paper weight you can use for this printer, see Supported Media Types.
  • Page 60 2. Open the feed slot cover (C). 3. Slide the paper guides to open them, and load the paper in the center of the rear tray WITH THE PRINT SIDE FACING UP. 4. Slide the paper guides (D) to align them with both sides of the paper stack. Do not slide the paper guides too hard against the paper.
  • Page 61 Important • Always load paper in the portrait orientation (E). Loading paper in the landscape orientation (F) can cause paper jams. Note • Do not load sheets of paper higher than the load limit mark (G). 5. Close the feed slot cover (H) gently. Important •...
  • Page 62 After closing the feed slot cover, the paper information registration screen for the rear tray is displayed on the touch screen. 6. Select the size and type of the loaded paper in the rear tray at Page size and Type, and then select Register.
  • Page 63 Note • When printing, select the size and type of the loaded paper on the print settings screen of the operation panel or the computer. • There are various types of paper, such as paper with a special surface coating for printing photos at optimal quality and paper suitable for documents.
  • Page 64: Loading Paper In The Cassette

    Note • In the cassette, be sure to load only plain paper. • You can use general copy paper or Canon Red Label Superior WOP111/Canon Océ Office Colour Paper SAT213. For the page size and paper weight you can use for this printer, see Supported Media Types.
  • Page 65 3. Remove the cassette cover (B). 4. To load A4 sized paper in the cassette, press down the lock (C) on the cassette, then extend the cassette. Important • Do not extend the cassette when loading other than A4 sized paper in the cassette. 5.
  • Page 66 6. Load the paper stack WITH THE PRINT SIDE FACING DOWN, and place it in the center of the cassette. Important • Always load paper in the portrait orientation (F). Loading paper in the landscape orientation (G) can cause paper jams. Note •...
  • Page 67 7. Align the paper guide (I) in front with the paper stack. Align the paper guide (I) with where it clicks into place. 8. Slide the paper guide (J) on the right to align with the paper stack. Do not slide the paper guide too hard against the paper. The paper may not be fed properly. Note •...
  • Page 68 11. Open the operation panel (M), pull out the paper output tray (N) and paper output support (O), and open the output tray extension (P). Be sure to open the operation panel before printing. If the operation panel is close, the printer does not start printing.
  • Page 69: Loading Envelopes

    Loading Envelopes You can load Envelope DL and Envelope Com 10 on the rear tray. The address is automatically rotated and printed according to the envelope's direction by specifying with the printer driver properly. Important • Printing of envelopes from the operation panel or from a PictBridge (Wireless LAN) compliant device is not supported.
  • Page 70 2. Open the feed slot cover (C). 3. Slide the paper guides (D) to open them, and load the envelopes in the center of the rear tray WITH THE PRINT SIDE FACING UP. Fold flap of the envelope and load the envelope in the portrait orientation with the address side facing up. Up to 10 envelopes can be loaded at once.
  • Page 71 Note • Do not load envelopes higher than the load limit mark (E). 5. Close the feed slot cover (F) gently. Important • If the feed slot cover is open, paper cannot be fed. Be sure to close the feed slot cover.
  • Page 72 After closing the feed slot cover, the paper information registration screen for the rear tray is displayed on the touch screen. 6. Select the size and type of the loaded envelopes in the rear tray at Page size and Type, and then select Register.
  • Page 73: Loading Originals

    Loading Originals Where to Load Originals Loading Originals on the Platen Glass Loading Documents in the ADF (Auto Document Feeder) Loading Based on Use Supported Originals...
  • Page 74: Where To Load Originals

    Where to Load Originals The printer has two positions to load originals: platen glass and ADF (Auto Document Feeder). Select the position to load the original according to the size, type, or usage. Note • For details on the supported originals, see below. Supported Originals Loading Documents, Photos, or Book on the platen glass Loading Two or More Sheets of Document of the Same Size and Thickness...
  • Page 75: Loading Originals On The Platen Glass

    Loading Originals on the Platen Glass 1. Open the document cover. 2. Load the original WITH THE SIDE TO SCAN FACING DOWN on the platen glass. Loading Based on Use Important • Be sure to observe the following when loading the original on the platen glass. •...
  • Page 76 Important • After loading the original on the platen glass, be sure to close the document cover before starting to copy or scan.
  • Page 77: Loading Documents In The Adf (auto Document Feeder)

    Loading Documents in the ADF (Auto Document Feeder) Note • To scan a document at optimum quality, load it on the platen glass. 1. Make sure that any original has been removed from the platen glass. 2. Open the document tray. 3.
  • Page 78: Loading Based On Use

    Loading Based on Use Load the original in the correct position on the platen glass according to the function to use. If you do not load the original correctly, it may not be scanned properly. Originals Function How to Load Copying or Faxing Scanning by detecting the type and size of the original automatically...
  • Page 79 Scanning from Computer (AirPrint) Loading the Original to Be Aligned with the alignment mark Place the original WITH THE SIDE TO SCAN FACING DOWN on the platen glass and align it with the alignment mark . Portions placed on the diagonally striped area cannot be scanned. Important •...
  • Page 80 Loading Two or More Originals on the platen glass Place the originals WITH THE SIDE TO SCAN FACING DOWN. Allow 0.40 inches (1 cm) or more space between the edges (diagonally striped area) of the platen glass and the originals, and between the originals.
  • Page 81: Supported Originals

    Supported Originals platen glass Item Details Types of originals - Text document, magazine, or newspaper - Printed photo, postcard, business card, or disc (BD/DVD/CD, etc.) - Documents that are not suitable for the ADF Size (width x height) Max. 8.5 x 11.7 inches (216 x 297 mm) Quantity One or more sheets* Thickness...
  • Page 82 • Documents on coated paper • Documents on onion skin or other thin paper • Photos or excessively thick documents...
  • Page 83: Replacing Ink Tanks

    Replacing Ink Tanks Replacing Ink Tanks Checking Ink Status on the Touch Screen Ink Tips...
  • Page 84: Replacing Ink Tanks

    Replacing Ink Tanks When remaining ink cautions or errors occur, the message will appear on the touch screen to inform you of the error. In this state, the printer cannot print or scan. Take appropriate action according to the message. An Error Occurs Note •...
  • Page 85 Important • Do not touch other parts besides the ink tanks. • Handle the ink tank carefully to avoid staining of clothing or the surrounding area. • Discard the empty ink tank according to the local laws and regulations regarding disposal of consumables.
  • Page 86 6. Lift up the tab on the orange protective cap (E) to remove it off GENTLY. Important • Do not push the sides of the ink tank. If you push the sides of the ink tank with the Y-shape air hole (D) blocked, ink may splash.
  • Page 87 8. Press on the top of the ink tank until the ink tank snaps firmly into place. Important • You cannot print if the ink tank is installed in the wrong position. Be sure to install the ink tank in the correct position according to the label on the print head holder.
  • Page 88 Note • If the error message appears after the scanning unit / cover is closed, take appropriate action. An Error Occurs • When you start printing after replacing the ink tank, the printer starts cleaning the print head automatically. Do not perform any other operations until the printer completes the cleaning of the print head.
  • Page 89: Checking Ink Status On The Touch Screen

    Checking Ink Status on the Touch Screen 1. Make sure that the power is turned on, and display the HOME screen. If the HOME screen is not displayed, press the HOME button to display it. 2. Select Setup on the HOME screen. Using the Operation Panel The setup menu screen will appear.
  • Page 90: Ink Tips

    Ink may be used for purposes other than printing. When you use the Canon printer for the first time after you install the bundled ink tanks, the printer consumes a small amount of ink in the amount to enable printing by filling the nozzles of the Print Head with ink.
  • Page 91: Maintenance

    Maintenance If Printing Is Faint or Uneven Performing Maintenance Functions from Your Computer (Windows) Performing Maintenance Functions from Your Computer (Mac OS) Cleaning...
  • Page 92: If Printing Is Faint Or Uneven

    If Printing Is Faint or Uneven Maintenance Procedure Printing the Nozzle Check Pattern Examining the Nozzle Check Pattern Cleaning the Print Head Deep Print Head Cleaning Aligning the Print Head...
  • Page 93: Maintenance Procedure

    Maintenance Procedure If print results are blurred, colors are not printed correctly, or print results are unsatisfactory (e.g. misaligned printed ruled lines), perform the maintenance procedure below. Important • Do not rinse or wipe the print head and ink tank. This can cause trouble with the print head and ink tank.
  • Page 94 From the printer Cleaning the Print Head From the computer • For Windows: Cleaning the Print Heads • For Mac OS: Cleaning the Print Heads After cleaning the print head, print and examine the nozzle check pattern: Step1 If the problem is not resolved after performing from step 1 to step 3 twice: Clean the print head deeply.
  • Page 95: Printing The Nozzle Check Pattern

    Printing the Nozzle Check Pattern Print the nozzle check pattern to determine whether the ink ejects properly from the print head nozzle. Note • If the remaining ink level is low, the nozzle check pattern will not be printed correctly. Replace the ink tank whose ink is low.
  • Page 96 The confirmation screen will appear. 7. Select Yes. The nozzle check pattern will be printed and two pattern confirmation screens will appear on the touch screen. Examine the nozzle check pattern.
  • Page 97: Examining The Nozzle Check Pattern

    Examining the Nozzle Check Pattern Examine the nozzle check pattern, and clean the print head if necessary. 1. Check if there are missing lines in the pattern C or horizontal white streaks in the pattern D. A: No missing lines/No horizontal white streaks B: Lines are missing/Horizontal white streaks are present 2.
  • Page 98 The printer starts cleaning the print head. Cleaning the Print Head If the pattern D or any color in the pattern C is not printed: (Example: Magenta pattern is not printed) The cleaning is required. Select Also B, then select Yes on the cleaning confirmation screen. The printer starts cleaning the print head.
  • Page 99: Cleaning The Print Head

    Cleaning the Print Head Clean the print head if lines are missing or if horizontal white streaks are present in the printed nozzle check pattern. Cleaning unclogs the nozzles and restores the print head condition. Cleaning the print head consumes ink, so clean the print head only when necessary. You need to prepare: a sheet of A4 or Letter-sized plain paper 1.
  • Page 100 The confirmation screen will appear. 7. Select Yes. The printer starts cleaning the print head. Do not perform any other operations until the printer completes the cleaning of the print head. This takes about 1 minute. The pattern print confirmation screen will appear. 8.
  • Page 101: Deep Print Head Cleaning

    Deep Print Head Cleaning If print quality does not improve by the standard cleaning of the print head, clean the print head deeply. Cleaning the print head deeply consumes more ink than the standard cleaning of the print head, so clean the print head deeply only when necessary.
  • Page 102 The confirmation screen will appear. 7. Select Yes. The printer starts cleaning the print head deeply. Do not perform any other operations until the printer completes the deep cleaning of the print head. This takes about 1 to 2 minutes. The pattern print confirmation screen will appear.
  • Page 103: Aligning The Print Head

    Aligning the Print Head If printed ruled lines are misaligned or print results are otherwise unsatisfactory, adjust the print head position. Note • If the remaining ink level is low, the print head alignment sheet will not be printed correctly. Replace the ink tank whose ink is low.
  • Page 104 6. Select Auto head alignment. The confirmation screen will appear. 7. Confirm the message, then select Yes. The print head alignment sheet will be printed. Important • Do not touch any printed part on the print head alignment sheet. If the sheet is stained or wrinkled, it may not be scanned properly.
  • Page 105 9. Close the document cover gently, then select OK. The printer starts scanning the print head alignment sheet, and the print head position will be adjusted automatically. Important • Do not open the document cover or move the print head alignment sheet on the platen glass until adjusting the print head position is complete.
  • Page 106: Cleaning

    Cleaning Cleaning Exterior Surfaces Cleaning the Platen Glass and Document Cover Cleaning the ADF (Auto Document Feeder) Cleaning Paper Feed Rollers Cleaning Inside the Printer (Bottom Plate Cleaning) Cleaning Cassette Pads...
  • Page 107: Cleaning Paper Feed Rollers

    Cleaning Paper Feed Rollers If the paper feed roller is dirty or paper powder is attached to it, paper may not be fed properly. In this case, clean the paper feed roller. Cleaning will wear out the paper feed roller, so perform this only when necessary.
  • Page 108 9. Make sure that the paper feed roller has stopped rotating, then follow the message to load the three sheets of A4 or Letter-sized plain paper. 10. Open the operation panel, then pull out the paper output tray. 11. Select OK. The printer starts cleaning.
  • Page 109: Cleaning Inside The Printer (bottom Plate Cleaning)

    Cleaning Inside the Printer (Bottom Plate Cleaning) Remove stains from the inside of the printer. If the inside of the printer becomes dirty, printed paper may get dirty, so we recommend performing cleaning regularly. You need to prepare: a sheet of A4 or Letter-sized plain paper* * Be sure to use a new piece of paper.
  • Page 110 10. Load only this sheet of paper in the cassette with the ridges of the creases facing up and the edge of the half with no crease facing to the far side. 11. Mount the cassette cover, and then insert the cassette into the printer. 12.
  • Page 111 Note • When performing Bottom Plate Cleaning again, be sure to use a new piece of paper. If the problem is not resolved after performing cleaning again, the protrusions inside the printer may be stained. Wipe off any ink from the protrusions using a cotton swab or the like. Important •...
  • Page 112: Overview

    Overview Safety Safety Precautions Regulatory Information WEEE (EU & EEA) Handling Precautions Canceling Print Jobs Legal Restrictions on Scanning/Copying Transporting Your Printer When repairing, lending, or disposing of the printer Keeping Print Quality High Main Components and Their Use Main Components Power Supply Using the Operation Panel Entering Numbers, Letters, and Symbols...
  • Page 113: Safety

    Safety Safety Precautions Regulatory Information WEEE (EU&EEA)
  • Page 114: Safety Precautions

    Safety Precautions Choosing a location • Do not install the printer in a location that is unstable or subject to excessive vibration. • Do not install the printer in locations that are very humid or dusty, in direct sunlight, outdoors, or close to a heating source.
  • Page 115: Regulatory Information

    Regulatory Information IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 116: Connection Of The Equipment

    20cm between the radiator and persons body (excluding extremities: hands, wrists, feet and ankles) and must not be colocated or operated with any other antenna or transmitter. Canon U.S.A., Inc. One Canon Park Melville, New York 11747...
  • Page 117: In Case Of Equipment Malfunction

    Manual, disconnect the equipment from the telephone line cable, turn off the power and disconnect the power cord. The telephone line cable should not be reconnected or the main power switch turned ON until the problem is completely resolved. Users should contact their local authorized Canon Facsimile Service Dealer for the servicing of equipment.
  • Page 118: Users In Canada

    Users in Canada This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules.
  • Page 119: Environmental Information

    of the product by Spark, nor does it provide any sort of warranty. Above all, it provides no assurance that any item will work correctly in all respects with another item of Telepermitted equipment of a different make or model, nor does it imply that any product is compatible with all of Spark's network services. This equipment is not capable, under all operating conditions, of correct operation at the higher speeds for which it is designed.
  • Page 120: Weee (eu&eea)

    For more information about where you can drop off your waste equipment for recycling, please contact your local city office, waste authority, approved WEEE scheme or your household waste disposal service. For more information regarding return and recycling of WEEE products, please visit www.canon- europe.com/weee.
  • Page 121 U kunt ook het schema voor de afvoer van afgedankte elektrische en elektronische apparatuur (AEEA) raadplegen. Ga voor meer informatie over het inzamelen en recyclen van afgedankte elektrische en elektronische apparatuur naar www.canon- europe.com/weee.
  • Page 122 Si desea más información acerca de la devolución y reciclado de RAEE, visite la web www.canon-europe.com/weee. Només per a la Unió Europea i a l’Espai Econòmic Europeu (Noruega, Islàndia i Liechtenstein) Aquest símbol indica que aquest producte no s’ha de llençar a les escombraries de la llar, d’acord amb la...
  • Page 123 Yderligere oplysninger om, hvor du kan bortskaffe dit elektronikaffald med henblik på genanvendelse, får du hos de kommunale renovationsmyndigheder. Yderligere oplysninger om returnering og genanvendelse af affald af elektrisk og elektronisk udstyr får du ved at besøge www.canon- europe.com/weee.
  • Page 124 Du kan få mer informasjon om hvor du kan avhende utrangert utstyr til resirkulering ved å kontakte lokale myndigheter, et godkjent WEEE-program eller husholdningens renovasjonsselskap. Du finner mer informasjon om retur og resirkulering av WEEE-produkter på www.canon-europe.com/weee. Vain Euroopan unionin sekä ETA:n (Norja, Islanti ja Liechtenstein) alueelle.
  • Page 125 úřad vaší obce, správní orgán vykonávající dozor nad likvidací odpadu, sběrny OEEZ nebo služba pro odvoz komunálního odpadu. Další informace týkající se vracení a recyklace OEEZ naleznete na adrese www.canon-europe.com/weee. Csak az Európai Unió és az EGT (Norvégia, Izland és Liechtenstein) országaiban...
  • Page 126 WEEE lub skontaktować się z przedsiębiorstwem zajmującym się wywozem odpadów domowych. Więcej informacji o zwracaniu i recyklingu zużytego sprzętu elektrycznego i elektronicznego znajduje się w witrynie www.canon-europe.com/weee. Platí len pre štáty Európskej únie a EHP (Nórsko, Island a Lichtenštajnsko) Tento symbol znamená, že podľa Smernice 2012/19/EÚ...
  • Page 127 į savo miesto valdžios institucijas, atliekų tvarkymo organizacijas, patvirtintų EEĮ atliekų sistemų arba jūsų buitinių atliekų tvarkymo įstaigų atstovus. Išsamesnės informacijos apie EEĮ atliekų grąžinimo ir perdirbimo tvarką galite rasti apsilankę tinklalapyje www.canon- europe.com/weee. Samo za Evropsko unijo in EGP (Norveška, Islandija in Lihtenštajn)
  • Page 128 OEEO. Če želite več informacij o vračanju in recikliranju izdelkov v skladu z direktivo OEEO, obiščite www.canon-europe.com/weee. Само за Европейския съюз и ЕИП (Норвегия, Исландия и Лихтенщайн) Този...
  • Page 129 şi reciclarea produselor DEEE, vizitaţi www.canon-europe.com/ weee. Samo za Europsku uniju i EEZ (Norveška, Island i Lihtenštajn) Ovaj simbol pokazuje da se ovaj proizvod ne smije odlagati s kućnim otpadom sukladno WEEE Direktivi (2012/19/EC) i vašem nacionalnom zakonu. Ovaj proizvod je potrebno predati na posebno mjesto za sakupljanje otpada, npr.
  • Page 130: Handling Precautions

    Handling Precautions Canceling Print Jobs Legal Restrictions on Scanning/Copying Transporting Your Printer When repairing, lending, or disposing of the printer Keeping Print Quality High...
  • Page 131: Legal Restrictions On Scanning/copying

    Legal Restrictions on Scanning/Copying Scanning, printing, copying, or modifying copies of the following may be punishable under law. This list is non-exhaustive. When in doubt, check with a local legal representative. • Paper money • Money orders • Certificates of deposit •...
  • Page 132: Transporting Your Printer

    Transporting Your Printer When relocating the printer, make sure of the following. Important • Pack the printer in a sturdy box so that it is placed with its bottom facing down, using sufficient protective material to ensure safe transport. • With the print head and ink tank left installed in the printer, press the ON button to turn off the power. This allows the printer to automatically cap the print head, thus preventing it from drying.
  • Page 133: When Repairing, Lending, Or Disposing Of The Printer

    For printers with fax capabilities, user information and speed dial numbers can be backed up to a computer by utilizing the Speed Dial Utility2 software before resetting the printer or deleting data. Backed up data can be restored to the repaired printer or another Canon printer. Registering Recipients Using Speed Dial Utility2 (Windows)
  • Page 134: Keeping Print Quality High

    Keeping Print Quality High The key to printing with the optimal printing quality is to prevent the print head from drying or clogging. Always observe the following rules for optimal printing quality. Note • Depending on the type of paper, ink may blur if you trace the printed area with a highlight pen or paint- stick, or bleed if water or sweat comes in contact with the printed area.
  • Page 135: Main Components And Their Use

    Main Components and Their Use Main Components Power Supply Using the Operation Panel Entering Numbers, Letters, and Symbols...
  • Page 136: Main Components

    Main Components Front View Rear View Inside View Operation Panel...
  • Page 137: Front View

    Front View (1) operation panel Use to change the settings of the printer or to operate it. Operation Panel (2) ADF (Auto Document Feeder) Load a document here. The documents loaded in the document tray are scanned automatically one sheet at a time. Loading Documents in the ADF (Auto Document Feeder) (3) document feeder cover Open when clearing jammed documents.
  • Page 138 (8) rear tray Load paper here. Two or more sheets of the same size and type of paper can be loaded at the same time, and fed automatically one sheet at a time. Loading Paper in the Rear Tray Loading Envelopes (9) paper guides Align with both sides of the paper stack.
  • Page 139 (19) platen glass Load an original here.
  • Page 140: Rear View

    Rear View (1) rear cover Detach when removing jammed paper. (2) transport unit cover Open when removing jammed paper. (3) power cord connector Plug in the supplied power cord. (4) USB port Plug in the USB cable to connect the printer with a computer. (5) telephone line jack Connect the telephone line.
  • Page 141: Inside View

    Inside View (1) scanning unit / cover Scans originals. Also, lift and open it to replace an ink tank or to remove jammed paper inside the printer. (2) print head holder The print head is pre-installed. Note • For details on replacing an ink tank, see Replacing Ink Tanks.
  • Page 142: Operation Panel

    Operation Panel * All lamps on the operation panel are shown lit in the figure below for explanatory purposes. (1) ON button/ON lamp Turns the power on or off. Lights after flashing when the power is turned on. Before turning on the power, make sure that the document cover is closed.
  • Page 143: Power Supply

    Power Supply Confirming that the Power Is On Turning the Printer On and Off Checking the Power Plug/Power Cord Unplugging the Printer...
  • Page 144: Confirming That The Power Is On

    Confirming that the Power Is On The ON lamp is lit when the printer is turned on. Even if the touch screen is off, if the ON lamp is lit, the printer is on. Note • It may take a while for the printer to start printing immediately after you turn on the printer. •...
  • Page 145: Turning The Printer On And Off

    Turning the Printer On and Off Turning on the printer 1. Press the ON button to turn on the printer. The ON lamp flashes and then remains lit. Confirming that the Power Is On Note • It may take a while for the printer to start printing immediately after you turn on the printer. •...
  • Page 146 Important • When you unplug the power cord after turning off the printer, be sure to confirm that the ON lamp is off. Note • You can set the printer to automatically turn off when no operations are performed or no print jobs are sent to the printer for a certain interval.
  • Page 147: Checking The Power Plug/power Cord

    Checking the Power Plug/Power Cord Unplug the power cord once a month to confirm that the power plug/power cord does not have anything unusual described below. • The power plug/power cord is hot. • The power plug/power cord is rusty. •...
  • Page 148: Unplugging The Printer

    Unplugging the Printer To unplug the power cord, follow the procedure below. Important • When you unplug the power cord, press the ON button, then confirm that the ON lamp is off. Unplugging the power cord while the ON lamp is lit or flashing may cause drying or clogging of the print head and print quality may be reduced.
  • Page 149: Using The Operation Panel

    Using the Operation Panel The operation panel consists of the touch screen (A) and buttons (B). Touch the HOME screen on the touch screen with your finger tip to select menus for copying, scanning, and other functions. Operations on the Home Screen A: touch screen Basic Operation of the touch screen B: Buttons on the operation panel...
  • Page 150 Touch Touch lightly with your finger tip. To move forward (or go back) menus or photos continuously, keep touching the forward (or back) mark. Flick Flick your finger on the screen up, down, left, or right. Use to switch menus or move forward or backward through photos. Drag While lightly touching the screen, move your finger up, down, left, or right.
  • Page 151 Operations on the Home Screen Display the menu screen or the settings screen from the Home screen. C. Basic menu Select to copy or scan using the operation panel. After selecting a basic menu, the particular menus are displayed. D. Network status Displays the current network status.
  • Page 152 (Signal strength: 50 % or less): The problem such as the printer cannot print may occur. Place the printer near the wireless router. Wireless LAN is enabled but the printer is not connected to the wireless router. Wireless Direct is enabled. Wireless LAN is disabled.
  • Page 153: Entering Numbers, Letters, And Symbols

    Entering Numbers, Letters, and Symbols When entering user or recipient names or other information, you can enter or edit characters by selecting them on the screen. Switching the Input Mode The printer has one input mode for letters and another for numbers and symbols. To switch modes, tap (A) in the lower left.
  • Page 154 Entering or Editing Numbers, Letters, and Symbols Enter information as follows. • To move the insertion point (cursor position) in the input field (C) (D). • To delete an entered character Move the cursor to the character to delete, and then tap (E).
  • Page 155: Changing Settings

    Changing Settings Changing Printer Settings from Your Computer (Windows) Changing Printer Settings from Your Computer (Mac OS) Changing Settings from Operation Panel...
  • Page 156: Changing Printer Settings From Your Computer (windows)

    Changing Printer Settings from Your Computer (Windows) Changing the Print Options Registering a Frequently Used Printing Profile Setting the Ink Tank to be Used Managing the Printer Power Changing the Printer Operation Mode...
  • Page 157: Changing The Print Options

    Changing the Print Options You can change the detailed printer driver settings for print data that is sent from an application software. Check this check box if part of the image data is cut off, the paper source during printing differs from the driver settings, or printing fails.
  • Page 158 The Page Setup tab is displayed again.
  • Page 159: Registering A Frequently Used Printing Profile

    Registering a Frequently Used Printing Profile You can register the frequently used printing profile to Commonly Used Settings on the Quick Setup tab. Unnecessary printing profiles can be deleted at any time. Registering a Printing Profile 1. Open the printer driver setup window 2.
  • Page 160 Quick Setup tab. The name and icon are displayed in Commonly Used Settings. Important • To save the page size, orientation, and number of copies that was set in each sheet, click Options..., and check each item. Note • When you re-install the printer driver or upgrade the printer driver version, the print settings that are already registered will be deleted from Commonly Used Settings.
  • Page 161: Setting The Ink Tank To Be Used

    Setting the Ink Tank to be Used This feature enables you to specify the most appropriate ink tank among installed ink tanks according to an intended use. 1. Open the printer driver setup window 2. Click Print Options... on the Page Setup tab The Print Options dialog box appears.
  • Page 162: Managing The Printer Power

    Managing the Printer Power This function allows you to manage the printer power from the Canon IJ Printer Assistant Tool. Power Off The Power Off function turns off the printer. When you use this function, you will not be able to turn the printer on from the Canon IJ Printer Assistant Tool.
  • Page 163 Note • When the printer is turned off, the Canon IJ Status Monitor message varies depending on the Auto Power On setting. When the setting is Enable, "Printer is standing by" is displayed. When the setting is Disable, "Printer is offline"...
  • Page 164: Changing The Printer Operation Mode

    Check this check box to prevent paper abrasion. Align heads manually Usually, the Print Head Alignment function in the Canon IJ Printer Assistant Tool is set to automatic head alignment, but you can change it to manual head alignment. If the printing results of automatic print head alignment are not satisfactory, perform manual head alignment.
  • Page 165 Ink Drying Wait Time You can set the length of the printer rest time until printing of the next page begins. Moving the slider to the right increases the pause time, and moving the slider to the left decreases the time. If the paper gets stained because the next page is ejected before the ink on the printed page dries, increase the ink drying wait time.
  • Page 166: Changing Settings From Operation Panel

    Changing Settings from Operation Panel Changing Settings from Operation Panel Setting Items on Operation Panel FAX settings Print settings LAN settings Device user settings PictBridge print settings Language selection Firmware update Feed settings Reset setting Web service setup System information ECO settings Quiet setting...
  • Page 167: Changing Settings From Operation Panel

    Changing Settings from Operation Panel This section describes the procedure to change the settings in the Device settings screen, taking the steps to specify Extended copy amount as an example. Make sure printer is turned on. 2. Select Setup on the HOME screen. Using the Operation Panel 3.
  • Page 168 For more on setting items on the operation panel: Setting Items on Operation Panel...
  • Page 169: Setting Items On Operation Panel

    Setting Items on Operation Panel Items for Printer FAX settings Device user settings Web service setup Language selection ECO settings Quiet setting Items for Paper/Printing Print settings Feed settings PictBridge print settings Items for Maintenance/Management System information Firmware update LAN settings Reset setting...
  • Page 170: Fax Settings

    FAX settings FAX user settings Advanced FAX settings Auto print settings Security control Easy setup Note • Before changing the settings, you can confirm the current settings by printing USER'S DATA LIST. Summary of Reports and Lists FAX user settings •...
  • Page 171 If you select ON, you can specify the maximum number of redial attempts and the length of time the printer waits between redial attempts. • Dial tone detect Avoids mistransmission when reception and transmission occur at the same time. If you select ON, the printer transmits the fax after confirming the dial tone. Note •...
  • Page 172 When the telephone line condition or connection is poor, selecting a lower transmission start speed may solve transmission problems. ◦ RX start speed Selects the fax reception speed. The fax reception start speed will be faster as the value is bigger. When the telephone line condition or connection is poor, selecting a lower reception start speed may solve reception problems.
  • Page 173: Easy Setup

    Security control • FAX number re-entry If you select ON, you can set the printer to send faxes after entering the number twice. By using this setting, you can avoid the mistransmission of faxes. Preventing Mistransmission of Faxes • Check RX FAX information If you select ON, the printer checks whether the recipient's fax device information matches the dialed number.
  • Page 174: Print Settings

    Print settings • Prevent paper abrasion Use this setting only if the print surface becomes smudged. Important • Be sure to set this back to OFF after printing since it may result in lower printing speed or lower print quality. •...
  • Page 175: Lan Settings

    LAN settings Wireless LAN Wireless Direct Common settings Wireless LAN • WLAN active/inactive Enables/disables wireless LAN. • Wireless LAN setup Selects the setup method for wireless LAN connection. ◦ Easy wireless connect Select if you specify the settings of the access point information to the printer directly from a device (e.g.
  • Page 176 Items Setting SSID XXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXX (up to 32 characters) Wireless LAN security Inactive/WEP(64bit)/WEP(128bit)/WPA-PSK(TKIP)/WPA-PSK(AES)/ WPA2-PSK(TKIP)/WPA2-PSK(AES) Signal strength (%) IPv4 address XXX. XXX. XXX. XXX (12 characters) IPv4 subnet mask XXX. XXX. XXX. XXX (12 characters) IPv4 default gateway XXX. XXX. XXX. XXX (12 characters) IPv6 address XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX: XXXX (32 characters)
  • Page 177: Common Settings

    • Wireless Direct setting list The list of Wireless Direct settings of this printer is displayed on the touch screen. Select Print details and then Yes to print the list. Printing Network Settings Important • The network settings printout contains important information about your network. Handle it with care.
  • Page 178 Specifies the printer name. You can use up to 15 characters for the name. Note • You cannot use the same printer name as that already used for other LAN connected devices. • You cannot use a hyphen for the initial or last character of the printer name. •...
  • Page 179 • RAW protocol Enables/disables RAW printing. • LLMNR Enables/disables LLMNR (Link-Local Multicast Name Resolution). Selecting Active allows the printer to detect printer's IP address from the printer name without a DNS server. • PictBridge communication Setting items for printing from a PictBridge (Wireless LAN) compliant device. ◦...
  • Page 180: Device User Settings

    Device user settings • Date/time setting Sets the current date and time. For more on the procedure: Setting Sender Information • Date display format Changes the display format of dates. • Daylight saving time setting Enables/disables the summer time setting. If you select ON, you can select additional sub-settings. This setting may not be available depending on the country or region of purchase.
  • Page 181 • Device info sending settings Selects whether you will send the printer usage information to Canon server. The information sent to Canon will be utilized to develop better products. Select Agree to send the printer usage information to Canon server.
  • Page 182 Allows you to check the PIN code and change it. Important • When you change the PIN code, pairing with all Bluetooth compatible devices is canceled. ◦ Set Bluetooth device name Specifies the printer name for Bluetooth connection. Note • If the printer cannot be paired to the Bluetooth compatible device after you changed some settings in Bluetooth settings see below.
  • Page 183: Language Selection

    Language selection Changes the language for the messages and menus on the touch screen.
  • Page 184: Firmware Update

    Firmware update You can update the firmware of the printer, check the firmware version, or perform settings of a notification screen, a DNS server and a proxy server. Note • Only Check current version is available when Inactive is selected for WLAN active/inactive of Wireless LAN in LAN settings.
  • Page 185: Feed Settings

    Feed settings By registering the paper size and the media type loaded on the rear tray or in the cassette, you can prevent the printer from misprinting by displaying the message before printing starts when the paper size or the media type of the loaded paper differs from the print settings.
  • Page 186: Reset Setting

    LAN settings and the telephone/fax number are not returned back to the default. • Device info sending settings only Applies the setting not to send the device information to Canon. • FAX settings only Returns all fax settings back to the default. Disconnect the telephone line from the printer before you return this setting item back to the default.
  • Page 187: Web Service Setup

    ◦ IJ Cloud Printing Center setup Registers/Deletes the printer to/from Canon Inkjet Cloud Printing Center. ◦ Check Web service setup Make sure whether the printer is registered to Google Cloud Print or Canon Inkjet Cloud Printing Center. • DNS server setup Performs settings for a DNS server.
  • Page 188: System Information

    System information To display this menu, select System information on Setup. • Current version Displays the current firmware version. • Printer name Displays the printer name currently specified. • Serial number Displays the printer serial number. • MAC address of wireless LAN Displays the MAC address for wireless LAN.
  • Page 189: Eco Settings

    ECO settings This setting allows you to use automatic duplex printing as a default to save paper and to turn on/off the printer automatically to save electricity. Using Duplex Printing Using Power Saving Function Using Duplex Printing Follow the procedure below to use duplex printing. Make sure printer is turned on.
  • Page 190 2. Select Setup on the HOME screen. Using the Operation Panel 3. Select Settings. 4. Select ECO. 5. Select Energy saving settings. 6. Check on-screen instructions and select Next. 7. Specify settings as necessary. A. Specify the length of time to turn the printer off automatically when no operation is made or no printing data is sent to the printer.
  • Page 191: Quiet Setting

    Quiet setting Enables this function on the printer if you want to reduce the operating noise, such as when printing at night. Follow the procedure below to perform setting. Make sure printer is turned on. 2. Select Setup on the HOME screen. Using the Operation Panel 3.
  • Page 192 You can specify the hour from 0 to 24. 2. Confirms starting time. After specifying the starting time, specify the ending time following the same procedure. B. Confirms the time to start and to end. The confirmation screen is displayed and the icon appears as the Quiet setting menu icon.
  • Page 193: Specifications

    Specifications General Specifications Printing resolution (dpi) 4800* (horizontal) x 1200 (vertical) * Ink droplets can be placed with a pitch of 1/4800 inch at minimum. Interface USB Port: Hi-Speed USB *1 LAN Port: Wireless LAN: IEEE802.11n / IEEE802.11g / IEEE802.11b *2 *1 A computer that complies with Hi-Speed USB standard is required.
  • Page 194: Copy Specifications

    • Letter: 0.26 inches (6.4 mm) • Other sizes: 0.14 inches (3.4 mm) -Right margin: • Letter: 0.25 inches (6.3 mm) • Other sizes: 0.14 inches (3.4 mm) Operating environment Temperature: 41 to 95 °F (5 to 35 °C) Humidity: 10 to 90 % RH (no condensation) * The performance of the printer may be reduced under certain temperature and humidity conditions.
  • Page 195: Scan Specifications

    (Automatic fallback) Transmission speed Black: Approx. 3 seconds/page at 33.6 kbps (Based on ITU-T No.1 chart for US specifications and Canon FAX Standard chart No.1 for others, both in standard mode.) Color: Approx. 1 minute/page at 33.6 kbps (Based on Canon COLOR FAX TEST SHEET.)
  • Page 196: Network Specifications

    Dialing Automatic dialing - Recipient (max. 100 destinations) - Group dial (max. 99 destinations) Regular dialing Automatic redialing Manual redialing (max. 10 destinations) Others Activity report (after every 20 transactions) Sequential broadcasting (max. 101 destinations) Rejected numbers (max. 10 destinations) Error reduction setting (VoIP) * * For details, see "Error reduction setting (VoIP)"...
  • Page 197 XGA 1024 x 768 Other Supported OS iOS, Android, Windows 10 Mobile Some functions may not be available with the supported OS. Refer to the Canon web site for details. Mobile Printing Capability Apple AirPrint Google Cloud Print PIXMA Cloud Link •...
  • Page 198: Information About Paper

    Information about Paper Supported Media Types Paper Load Limit Unsupported Media Types Handling Paper Print Area...
  • Page 199: Supported Media Types

    • For details on page sizes and media types, access the Canon website. • Genuine Canon paper is not available in some countries or regions. Note that in the United States, Canon paper is not sold by model number. Instead, purchase paper by name.
  • Page 200: Page Sizes

    - Maximum size: 8.50 x 11.69 inches (215.9 x 297.0 mm) Paper Weight You can use paper in the following weight range. • 17 to 28 lb (64 to 105 g /m ) (plain paper other than genuine Canon paper)
  • Page 201: Paper Load Limit

    Rear Tray Cassette Tray Canon Red Label Superior <WOP111> Approx. 100 sheets Approx. 100 sheets Approx. 50 sheets Canon Océ Office Colour Paper <SAT213> Approx. 80 sheets Approx. 80 sheets Approx. 50 sheets High Resolution Paper <HR-101N>*1 Approx. 80 sheets Approx.
  • Page 202 Paper other than Genuine Canon Paper Paper Output Common Name Rear Tray Cassette Tray Plain Paper (including recycled paper)*1 Approx. 100 sheets (10 Approx. 100 sheets Approx. 50 sheets: Legal) sheets (10 sheets: Legal) Envelopes 10 envelopes T-Shirt Transfers 1 sheet : A4...
  • Page 203: Unsupported Media Types

    • Paper that is too thin (weighing less than 17 lb (64 g /m • Paper that is too thick (plain paper weighing more than 28 lb (105 g /m ), except for Canon genuine paper) • Paper thinner than a postcard, including plain paper or notepad paper cut to a small size (when printing on paper smaller than A5) •...
  • Page 204: Handling Paper

    Handling Paper • Be careful not to rub or scratch the surfaces of any types of paper when handling. • Hold the paper as closely as possible to its edges and try not to touch the printing surface. The print quality may be degraded if the printing surface is smudged with sweat or oil that comes from your hands.
  • Page 205: Printing

    Printing Printing from Computer Printing from Smartphone/Tablet Printing from Digital Camera Printing Using Operation Panel Paper Settings...
  • Page 206: Printing From Computer

    Printing from Computer Printing from Application Software (Windows Printer Driver) Printing from Application Software (AirPrint) Printing Using Canon Application Software Printing Using a Web Service...
  • Page 207: Printing From Application Software (windows Printer Driver)

    Printing from Application Software (Windows Printer Driver) Basic Printing Setup Basic Various Printing Methods Changing the Print Quality and Correcting Image Data Overview of the Printer Driver Printer Driver Description Updating the MP Drivers...
  • Page 208: Basic Printing Setup

    Basic Printing Setup This section describes settings on the Quick Setup tab used for basic printing. Basic Printing Setup Check that printer power is on Load paper in printer 3. Open printer driver's setup screen 4. Select frequently used settings On the Quick Setup tab, use Commonly Used Settings to select from predefined print settings.
  • Page 209 Important • The print quality selections will differ depending on which print setting you select. 6. Select paper source For Paper Source, select Automatically Select, Rear Tray, or Cassette, whichever matches your purpose. Important • The paper source settings that can be selected may differ depending on the paper type and size.
  • Page 210 7. Click OK The printer will now print using these settings. Important • When you select Always Print with Current Settings, the settings on the Quick Setup, Main, and Page Setup tabs are saved, and those settings are used in subsequent printings. •...
  • Page 211 From Paper Source, check the setting or select a new paper source. The current printer settings appear in Media Type and Page Size. 4. Apply settings To apply the printer settings to the printer driver, click Set. Note • If the Type on the printer is set to Ink Jet Hagaki, Hagaki K, or Hagaki, or if the Page size on the printer is set to 2L/5"x7"(13x18), click Set to display the dialog box.
  • Page 212: Paper Settings On The Printer Driver And The Printer (media Type)

    Canon Red Label Superior <WOP111> Plain Paper Plain paper Canon Océ Office Colour Paper <SAT213> Plain Paper Plain paper Canon genuine papers (Photo Printing) Paper information registered Media name <Model No.> Media Type in the printer driver on the printer Photo Paper Plus Glossy II <PP-201/PP-301>...
  • Page 213: Paper Settings On The Printer Driver And The Printer (paper Size)

    Paper Settings on the Printer Driver and the Printer (Paper Size) When you use this printer, selecting a paper size that matches the print purpose will help you achieve the best print results. You can use the following paper sizes on this printer. Printer Paper Size in the printer driver Cassette paper information registered on the printer Letter 8.5"x11"...
  • Page 214: Various Printing Methods

    Various Printing Methods Setting a Page Size and Orientation Setting the Number of Copies and Printing Order Execute Borderless Printing Scaled Printing Page Layout Printing Tiling/Poster Printing Duplex Printing Setting Up Envelope Printing Printing on Postcards...
  • Page 215: Setting A Page Size And Orientation

    Setting a Page Size and Orientation The paper size and orientation are essentially determined by the application software. When the page size and orientation set for Page Size and Orientation on the Page Setup tab are same as those set with the application software, you do not need to select them on the Page Setup tab.
  • Page 216: Setting The Number Of Copies And Printing Order

    Setting the Number of Copies and Printing Order You can also set the number of copies on the Quick Setup tab. 1. Open the printer driver setup window 2. Specify the number of copies to be printed For Copies on the Page Setup tab, specify the number of copies to be printed. 3.
  • Page 217 • Print from Last Page: /Collate: • Print from Last Page: /Collate: 4. Click OK When you execute print, the specified number of copies will be printed with the specified printing order. Important • When the application software that you used to create the document has the same function, specify the settings on the printer driver.
  • Page 218: Execute Borderless Printing

    Execute Borderless Printing The borderless printing function allows you to print data without any margin by enlarging the data so that it extends slightly off the paper. In standard printing, margins are created around the document area. However, in borderless printing function, these margins are not created. When you want to print data such as a photo without providing any margin around it, set borderless printing.
  • Page 219 Check the Page Size list. When you want to change it, select another page size from the list. The list displays only sizes that can be used for borderless printing. 4. Adjust the amount of extension from the paper If necessary, adjust the amount of extension using the Amount of Extension slider. Moving the slider to the right increases the amount extending off the paper, and moving the slider to the left decreases the amount.
  • Page 220 Important • When the amount of extension is decreased, an unexpected margin may be produced on the print, depending on the size of the paper. Note • When the Amount of Extension slider is set to the leftmost position, image data will be printed in the full size.
  • Page 221: Scaled Printing

    Scaled Printing 1. Open the printer driver setup window 2. Set scaled printing Select Scaled from the Page Layout list on the Page Setup tab. 3. Select the paper size of the document Using Page Size, select the page size that is set with your application software. 4.
  • Page 222 • Specify a scaling factor Directly type in a value into the Scaling box. The current settings are displayed in the settings preview on the left side of the printer driver. 5. Click OK When you execute print, the document will be printed with the specified scale. Important •...
  • Page 223 Note • Selecting Scaled changes the printable area of the document.
  • Page 224: Page Layout Printing

    Page Layout Printing The page layout printing function allows you to print more than one page image on a single sheet of paper. 1. Open the printer driver setup window 2. Set page layout printing Select Page Layout from the Page Layout list on the Page Setup tab. The current settings are displayed in the settings preview on the left side of the printer driver.
  • Page 225 Page Layout To change the number of pages to be printed on a single sheet of paper, select the number of pages from the list. Page Order To change the page arrangement order, select a placement method from the list. Page Border To print a page border around each document page, check this check box.
  • Page 226: Tiling/poster Printing

    Tiling/Poster Printing The tiling/poster printing function allows you to enlarge image data, divide it into several pages, and print these pages on separate sheets of paper. You can also paste the pages together to create a large print like a poster. Setting Tiling/Poster Printing 1.
  • Page 227 If necessary, click Specify..., specify the following settings in the Tiling/Poster Printing dialog box, and then click OK. Image Divisions Select the number of divisions (vertical x horizontal). As the number of divisions increases, the number of sheets used for printing increases. If you are pasting pages together to create a poster, increasing the number of divisions allows you to create a larger poster.
  • Page 228 Note • Click the deleted pages to display them again. • Right-click the settings preview to select Print all pages or Delete all pages. 2. Complete the setup After completing the page selection, click OK. When you execute print, only specified pages will be printed. Important •...
  • Page 229: Duplex Printing

    Duplex Printing You can also set duplex printing in Additional Features on the Quick Setup tab. Performing Automatic Duplex Printing You can perform the duplex printing without having to turn over the paper. 1. Open the printer driver setup window 2.
  • Page 230 Use normal-size printing Print without reducing the page. Use reduced printing Reduce the page slightly during printing. 5. Specify the side to be stapled The best Stapling Side is selected automatically from the Orientation and Page Layout settings. To change the setting, select another stapling side from the list. 6.
  • Page 231 3. Select the layout Select Normal-size, Fit-to-Page, Scaled, or Page Layout from the Page Layout list. 4. Specify the side to be stapled The best Stapling Side is selected automatically from the Orientation and Page Layout settings. To change the setting, select another stapling side from the list. 5.
  • Page 232 • After printing the front page, there is an ink drying wait time before starting to print the back page (Operation stops temporarily). Do not touch the paper during this time. You can change the ink drying wait time at Custom Settings in the Canon IJ Printer Assistant Tool. Related Topic...
  • Page 233: Setting Up Envelope Printing

    • If Envelope Com 10, Envelope DL, Yougata 4 4.13"x9.25", or Yougata 6 3.86"x7.48" is selected for Printer Paper Size, the printer rotates the paper 90 degrees to the left to print, regardless of the Rotate 90 degrees left when orientation is [Landscape] setting for Custom Settings in the Canon IJ Printer Assistant Tool.
  • Page 234 6. Select the print quality Select High or Standard that matches your purpose for Print Quality. 7. Click OK When you execute print, the information is printed on the envelope. Note • If the paper settings in the printer driver differ from the paper information registered on the printer, an error may occur.
  • Page 235: Printing On Postcards

    Printing on Postcards Load postcard on the printer 2. Open the printer driver setup window 3. Select commonly used settings Display the Quick Setup tab, and for Commonly Used Settings, select Standard. 4. Select the media type For Media Type, select Ink Jet Hagaki (A), Ink Jet Hagaki, Hagaki K (A), Hagaki K, Hagaki (A), or Hagaki.
  • Page 236 To display guide messages again, open the Maintenance tab and click View Printer Status to start the Canon IJ Status Monitor. On the Option menu, choose Display Guide Message and click Hagaki Printing to enable the setting.
  • Page 237: Overview Of The Printer Driver

    Overview of the Printer Driver Canon IJ Printer Driver Opening Printer Driver's Setup Screen Canon IJ Status Monitor Checking Ink Status from Your Computer Instructions for Use (Printer Driver)
  • Page 238: Canon Ij Printer Driver

    Canon IJ Printer Driver The Canon IJ printer driver (simply called printer driver below) is software that you install onto your computer so that it can communicate with the printer. The printer driver converts the print data created by your application software into data that your printer can understand, and sends the converted data to the printer.
  • Page 239: Opening Printer Driver's Setup Screen

    Opening Printer Driver's Setup Screen You can display the printer driver's setup screen from your application software or by clicking the printer icon. Displaying the Printer Driver's Setup Screen from Your Application Software Perform this procedure to set up the print settings during printing. 1.
  • Page 240: Canon Ij Status Monitor

    Canon IJ Status Monitor The Canon IJ Status Monitor is an application software that shows the status of the printer and the progress of printing. You will know the status of the printer with graphics, icons, and messages. Launching the Canon IJ Status Monitor The Canon IJ Status Monitor launches automatically when print data is sent to the printer.
  • Page 241 In such cases, take the appropriate action as described.
  • Page 242: Checking Ink Status From Your Computer

    On the Maintenance tab, click View Printer Status. 3. Display Estimated ink levels Ink status is displayed as an illustration. Note • The information displayed on the Canon IJ Status Monitor may differ depending on the country or region where you are using your printer.
  • Page 243: Instructions For Use (printer Driver)

    Instructions for Use (Printer Driver) This printer driver is subject to the following restrictions. Keep the following points in mind when using the printer driver. Restrictions on the Printer Driver • Depending on the document type to be printed, the paper feed method specified in the printer driver may not operate correctly.
  • Page 244 ◦ When Page Size in Word is set to "XXX Enlarge/Reduce", the document may not print normally in certain versions of Word. If this happens, follow the procedure below. 1. Open Word's Print dialog box. 2. Open the printer driver setup window, and on the Page Setup tab, set Page Size to the same paper size that you specified in Word.
  • Page 245: Printer Driver Description

    Printer Driver Description Quick Setup tab Description Main tab Description Page Setup tab Description Maintenance tab Description Canon IJ Status Monitor Description...
  • Page 246: Quick Setup Tab Description

    Quick Setup tab Description The Quick Setup tab is for registering commonly used print settings. When you select a registered setting, the printer automatically switches to the preset items. Commonly Used Settings The names and icons of frequently used printing profiles are registered. When you select a printing profile according to the purpose of the document, settings that match the purpose are applied.
  • Page 247 Check this check box to display a preview before printing. Uncheck this check box if you do not want to display a preview. Important • To use the Canon IJ XPS Preview, you must have Microsoft .NET Framework 4.5.2 or later installed on your computer. Additional Features Displays the frequently used, convenient functions for the printing profile that you selected for Commonly Used Settings on the Quick Setup tab.
  • Page 248 Important • Depending on the printing profiles, certain function may be grayed out and you will not be able to change them. 2-on-1 Printing Prints two pages of the document, side by side, on one sheet of paper. To change the page sequence, click the Page Setup tab, select Page Layout for Page Layout, and click Specify..
  • Page 249 Prints the document by rotating it 90 degrees relative to the paper feed direction. You can change the rotation direction by going to the Canon IJ Printer Assistant Tool, opening the Custom Settings dialog box, and then using Rotate 90 degrees left when orientation is [Landscape] check box.
  • Page 250 Important • When the application software that you used to create the document has the same function, specify the settings on the printer driver. However, if the print results are not acceptable, specify the function settings on the application software. Always Print with Current Settings Prints documents with the current settings starting from the next print execution.
  • Page 251 Save the paper size setting Saves the paper size to the printing profile in Commonly Used Settings. To apply the saved paper size when the printing profile is selected, check this check box. If this check box is unchecked, the paper size is not saved, and consequently the paper size setting is not applied when the printing profile is selected.
  • Page 252 Setting the Number of Copies and Printing Order Execute Borderless Printing Duplex Printing Setting Up Envelope Printing Printing on Postcards Switching the Paper Source to Match the Purpose Displaying the Print Results before Printing Setting Paper Dimensions (Custom Size) Printing a Color Document in Monochrome Specifying Color Correction Adjusting Color Balance Adjusting Color Balance Using Sample Patterns (Printer Driver)
  • Page 253: Main Tab Description

    Main tab Description The Main tab allows you to create a basic print setup in accordance with the media type. Unless special printing is required, normal printing can be performed just by setting the items on this tab. Settings Preview The paper illustration shows how the original will be laid out on a sheet of paper.
  • Page 254 Print Quality Selects your desired printing quality. Select one of the following to set the print quality level that is appropriate for the purpose. Important • Depending on the Media Type settings, the same print results may be produced even if the Print Quality is changed.
  • Page 255: Color Adjustment Tab

    Important • To use the Canon IJ XPS Preview, you must have Microsoft .NET Framework 4.5.2 or later installed on your computer. Defaults Restores all the settings you have changed to their default values. Clicking this button restores all the settings on the current screen to their default values (factory settings).
  • Page 256 Important • When Grayscale Printing is checked on the Main tab, Cyan, Magenta, and Yellow appear grayed out and are unavailable. Brightness Selects the brightness of your print. You cannot change the levels of pure white and black. However, the brightness of the colors between white and black can be changed.
  • Page 257 Important • When Grayscale Printing is checked on the Main tab, Color Correction appears grayed out and is unavailable. Driver Matching With Canon Digital Photo Color, you can print sRGB data with color tints that most people prefer.
  • Page 258 ICM (ICC Profile Matching) Adjusts the colors by using an ICC profile when printing. Specify the rendering intent to be used. Important • If the application software is set so that ICM is disabled, ICM (ICC Profile Matching) is unavailable for Color Correction and the printer may not be able to print the image data properly.
  • Page 259 Specifying Color Correction Adjusting Colors with the Printer Driver Printing with ICC Profiles Printing a Color Document in Monochrome Displaying the Print Results before Printing...
  • Page 260: Page Setup Tab Description

    Prints the document by rotating it 90 degrees relative to the paper feed direction. You can change the rotation direction by going to the Canon IJ Printer Assistant Tool, opening the Custom Settings dialog box, and then using Rotate 90 degrees left when orientation is...
  • Page 261 To rotate the document 90 degrees to the left when printing, select the Rotate 90 degrees left when orientation is [Landscape] check box. Rotate 180 degrees Prints the document by rotating it 180 degrees against the paper feed direction. The width of print area and the amount of extension that are configured in other application software will be reversed vertically and horizontally.
  • Page 262 Page Layout Multiple pages of document can be printed on one sheet of paper. Specify... Opens the Page Layout Printing dialog box. Click this button to set details on page layout printing. Tiling/Poster This function enables you to enlarge the image data and divide the enlarged data into several pages to be printed.
  • Page 263 Important • If the application used to create your document has a similar function, specify the number of copies with the application without specifying it here. Print from Last Page Check this check box when you want to print from the last page in order. If you do this, you do not need to sort the pages into their correct order after printing.
  • Page 264 Page Layout Printing dialog box This dialog box allows you to select the number of document pages to be placed on one sheet of paper, the page order, and whether a page border line is to be printed around each document page. The settings specified in this dialog box can be confirmed in the settings preview on the printer driver.
  • Page 265 Note • If some of the pages have not been printed well, specify the pages that do not need to be printed by clicking them in the settings preview of the Page Setup tab. Only the pages shown on the screen will be printed this time.
  • Page 266 • When this function is enabled, normally the paper feeding method cannot be changed from the Canon IJ Preview. However, if you are using the XPS printer driver, you will be able to change the paper feeding method from the Canon IJ XPS Preview.
  • Page 267 Ungroup Papers Sets the display method of Media Type, Page Size, and Printer Paper Size. To display the items separately, select the check box. To display the items as a group, clear the check box. Do not allow application software to compress print data Compression of the application software print data is prohibited.
  • Page 268 Important • A large amount of memory may be used for certain settings. Do not change the setting if your computer has a small amount of memory. Note • Unit of Print Data Processing tab cannot be used with the XPS printer driver. Print With Specify the ink tank to be used from the installed ink tanks.
  • Page 269: Stamp Tab

    Print semitransparent stamp Sets how the stamp is to be printed over the document. Check the Stamp check box to enable this. Check this check box to print a semi-transparent stamp over the printed document page. Uncheck this check box to print the stamp over the document data. The printed data may be hidden behind the stamp.
  • Page 270 Important • Stamp Text appears grayed out and is unavailable if Date/Time/User Name is selected. TrueType Font Selects the font for the stamp text string. Style Selects the font style for the stamp text string. Size Selects the font size for the stamp text string. Outline Selects a frame that encloses the stamp text string.
  • Page 271 Orientation Specifies the angle of rotation for the stamp. The angle can be set by entering the number of degrees. Negative values rotate the stamp clockwise. Note • Orientation is enabled only when Text or Date/Time/User Name is selected for Stamp Type on the Stamp tab.
  • Page 272 Intensity Adjusts the intensity of the bitmap to be used as a background. Moving the slider to the right increases the intensity, and moving the slider to the left decreases the intensity. To print the background at the original bitmap intensity, move the slider to the rightmost position.
  • Page 273: Maintenance Tab Description

    Maintenance tab Description The Maintenance tab allows you to start the Canon IJ Printer Assistant Tool or check the status of the printer. Maintenance and Preferences Canon IJ Printer Assistant Tool is started. You can perform printer maintenance or change the settings of the printer.
  • Page 274 About dialog box When you click About, the About dialog box is displayed. This dialog box displays the version, copyright, and module list of the printer driver. You can select the language to be used and switch the language displayed in the setup window. Modules Lists the printer driver modules.
  • Page 275: Canon Ij Status Monitor Description

    Overview of the Canon IJ Status Monitor The Canon IJ Status Monitor uses images and messages to display the printer status and the ink status. During printing, you can check information about the document being printed and the print progress.
  • Page 276 Ink Model Number You can look up the correct ink tank for your printer. Option Menu If a printer message appears, select Enable Status Monitor to start the Canon IJ Status Monitor. Select Enable Status Monitor to use the following commands: Always Display Current Job Displays the Canon IJ Status Monitor whenever a document is being printed.
  • Page 277 Display Warning Automatically When a Low Ink Warning Occurs Starts the Canon IJ Status Monitor window automatically and displays it in front of the other windows when a low ink warning occurs. Start when Windows is Started Automatically starts the Canon IJ Status Monitor when Windows is started.
  • Page 278: Installing The Mp Drivers

    Installing the MP Drivers You can access our web site through the Internet and download the latest MP Drivers and XPS printer driver for your model. 1. Turn off the printer 2. Start the installer Double-click the icon of the downloaded file. The installation program starts.
  • Page 279: Printing From Smartphone/tablet

    Printing from Smartphone/Tablet Printing from iPhone/iPad/iPod touch (iOS) Printing from Smartphone/Tablet (Android) Printing from Windows 10 Mobile Device Printing/Scanning with Wireless Direct...
  • Page 280: Printing/scanning With Wireless Direct

    Printing/Scanning with Wireless Direct You can connect devices (e.g. smartphone, or tablet) to the printer by two methods below. • Wireless connection (connecting devices via a wireless router) • Direct wireless connection (connecting devices using Wireless Direct) This section describes Wireless Direct, which allows you to print or scan by connecting the devices to the printer directly.
  • Page 281 7. Select Wireless Direct active/inactive. 8. Select ON. The confirmation screen asking if you display the password information appears. 9. Select Yes or No. The list of Wireless Direct settings is displayed. The device detects the printer by the identifier (SSID). Note •...
  • Page 282 • For more on printing or scanning from a device via wireless LAN, refer to the device's or application's instruction manual. • You can print/scan from your smartphone or tablet by installing Canon PRINT Inkjet/SELPHY. Download it from App Store and Google Play.
  • Page 283 4. Select Device settings. 5. Select LAN settings. 6. Select Wireless Direct. 7. Select a setting item. • To change the identifier (SSID) for Wireless Direct Select A to display the setting screen of the identifier (SSID). The identifier (SSID) is the printer's name (device name) displayed on a Wi-Fi Direct compatible device.
  • Page 284 • To change the confirmation screen setting when a Wi-Fi Direct compatible device is connecting to the printer Select C to display the confirmation screen. If you want the printer to display the screen to inform you a Wi-Fi direct compatible device is connecting to the printer, select Yes. Important •...
  • Page 285: Printing Using Operation Panel

    Printing Using Operation Panel Printing Templates Such as Lined or Graph Paper...
  • Page 286: Printing Templates Such As Lined Or Graph Paper

    Printing Templates Such as Lined or Graph Paper You can print a template form such as lined paper, graph paper, or checklist, etc. on A4, B5, or Letter-sized plain paper. Printable template forms Printing template forms Printable template forms The following templates are available: •...
  • Page 287 • Staff paper You can print staff paper with 10 or 12 staves. Setting on the touch screen: ◦ Staff paper 1 (10 staves) ◦ Staff paper 2 (12 staves) • Handwriting paper You can print handwriting paper. Setting on the touch screen: Handwriting paper (3 lines) •...
  • Page 288 4. Select Templates. 5. Select template you want to print. Printable template forms 6. Specify settings as necessary. You can specify the following setting items. • Copies Specify the number of copies. • Page size Select the page size depending on the loaded paper. Note •...
  • Page 289 • Notebook paper 2 (7 mm) • Notebook paper 3 (6 mm) • Graph paper 1 (5 mm grid) • Graph paper 2 (3 mm grid) • Handwriting paper (3 lines) Press the Black button for printing following forms. • Checklist •...
  • Page 290: Paper Settings

    Paper Settings By registering the paper size and the media type loaded on the rear tray or in the cassette, you can prevent the printer from misprinting by displaying the message before printing starts when the paper size or the media type of the loaded paper differs from the print settings.
  • Page 291 • When you insert the cassette: The screen to register the cassette paper information is displayed. Register the paper size and the media type according to the loaded paper. * You can load only plain paper in the cassette. Important •...
  • Page 292 When you start printing or copying, a message is displayed. Selecting OK on the touch screen displays the paper setting specified for printing or copying under the message. Check the message and select OK. When the screen to select the operation is displayed, select one of the operations below.
  • Page 293 For example, when the paper setting for printing or copying is A5 and the paper information registered to the printer is A4, you load A5 sized paper before you start printing or copying. The paper information registration screen is displayed after replacing the paper and closing the feed slot cover or inserting the cassette.
  • Page 294: Copying

    Copying Reducing/Enlarging Copies Making Copies Basics Two-Sided Copying Collated Copying Special Copy Menu Copying Using Smartphone or Tablet...
  • Page 295: Making Copies

    Making Copies This section describes the procedure to copy with Standard copy. Make sure printer is turned on. Load paper. 3. Select Copy on the HOME screen. Using the Operation Panel 4. Select Standard copy. The Copy standby screen is displayed. Load original document on platen glass or in ADF.
  • Page 296 F. Flick to specify the number of copies. G. Specifies the number of copies. If you keep touching here, the number scrolls by 10. C. Displays the print setting items. For more on the setting items: Setting Items for Copying D.
  • Page 297 Important • If you load the original on the platen glass, do not open the document cover or remove the original while Scanning document... is displayed on the touch screen. • If you load the original in the ADF, do not move the original until copying is complete. Note •...
  • Page 298: Setting Items For Copying

    Setting Items for Copying You can change the copy settings such as magnification and intensity. Print Settings Screen Note • For more on the print setting screen or the setting item for Photo copy, see Copying Photos. How to display the print setting screen varies with the copy menu. •...
  • Page 299 displayed on the touch screen. In this case, select on the upper left on the touch screen to check the message and change the setting. • The settings of the page size, media type, etc. are retained even if the printer is turned off. •...
  • Page 300 Important • If you use Draft with Type set to Plain paper and the quality is not as good as expected, select Standard or High for Print qlty and try copying again. • Select High for Print qlty to copy in grayscale. Grayscale renders tones in a range of grays instead of black or white.
  • Page 301: Scanning

    Scanning Scanning from Computer (AirPrint) Scanning from Computer (Windows) Scanning from Operation Panel Scanning Using Smartphone/Tablet...
  • Page 302: Scanning From Computer (windows)

    Scanning from Computer (Windows) Scanning According to Item Type or Purpose (IJ Scan Utility) IJ Scan Utility Features Scanning Easily (Auto Scan) Basics Scanning Documents and Photos Scanning Using Application Software (ScanGear) Scanning Tips Positioning Originals (Scanning from Computer) Network Scan Settings IJ Network Scanner Selector EX2 Menu and Setting Screen...
  • Page 303: Scanning According To Item Type Or Purpose (ij Scan Utility)

    Scanning According to Item Type or Purpose (IJ Scan Utility) IJ Scan Utility Features Scanning Easily (Auto Scan) Basics Scanning Documents and Photos...
  • Page 304: Ij Scan Utility Features

    IJ Scan Utility Features Use IJ Scan Utility to scan and save documents, photos, or other items at one time by simply clicking the corresponding icon. Multiple Scanning Modes Auto allows for one click scanning with default settings for various items. Document will sharpen text in a document or magazine for better readability, and Photo is best suited for scanning photos.
  • Page 305 Note • To set the applications to integrate with, see Settings Dialog Box.
  • Page 306: Scanning Easily (auto Scan)

    Scanning Easily (Auto Scan) Auto Scan allows for automatic detection of the type of the item placed on the platen or ADF (Auto Document Feeder). Important • The following types of items may not be scanned correctly. In that case, adjust the cropping frames (scan areas) in whole image view of ScanGear (scanner driver), and then scan again.
  • Page 307: Scanning Documents And Photos

    Scanning Documents and Photos Scan items placed on the platen with settings suitable for documents or photos. Save documents in formats such as PDF and JPEG, and photos in formats such as JPEG and TIFF. 1. Place the item on the platen. Positioning Originals (Scanning from Computer) 2.
  • Page 308: Scanning Using Application Software (scangear)

    Scanning Using Application Software (ScanGear) What Is ScanGear (Scanner Driver)? Starting ScanGear (Scanner Driver) Scanning in Basic Mode ScanGear (Scanner Driver) Screens General Notes (Scanner Driver) Important • Available functions and settings vary depending on your scanner or printer.
  • Page 309: What Is Scangear (scanner Driver)

    What Is ScanGear (Scanner Driver)? ScanGear (scanner driver) is software required for scanning documents. Use the software to specify the output size, image corrections, and other settings. ScanGear can be started from IJ Scan Utility or applications that are compatible with the standard TWAIN interface.
  • Page 310: Advanced Mode

    Advanced Mode Use the Advanced Mode tab to scan by specifying the color mode, output resolution, image brightness, color tone, and other settings.
  • Page 311: Starting Scangear (scanner Driver)

    Starting ScanGear (Scanner Driver) Use ScanGear (scanner driver) to make image corrections and color adjustments when scanning. Start ScanGear from IJ Scan Utility or other applications. Note • If you have more than one scanner or have a network compatible model and changed the connection from USB connection to network connection, set up the network environment.
  • Page 312: Scanning In Basic Mode

    Scanning in Basic Mode Use the Basic Mode tab to scan easily by following these simple on-screen steps. To scan multiple documents at one time from the Platen, see Scanning Multiple Documents at One Time with ScanGear (Scanner Driver). When scanning from the ADF (Auto Document Feeder), preview is not available. Important •...
  • Page 313 Important • Some applications do not support continuous scanning from the ADF. For details, see the application's manual. Note • To scan magazines containing many color photos, select Magazine (Color). 3. Click Preview. Preview image appears in the Preview area. Important •...
  • Page 314 7. Set Image corrections as needed. 8. Click Scan. Scanning starts. Note • Click (Information) to display a dialog box showing the document type and other details of the current scan settings. • How ScanGear behaves after scanning is complete can be set from Status of ScanGear dialog after scanning on the Scan tab of the Preferences dialog box.
  • Page 315: Scangear (scanner Driver) Screens

    ScanGear (Scanner Driver) Screens Basic Mode Tab Advanced Mode Tab...
  • Page 316: Basic Mode Tab

    Basic Mode Tab Use the Basic Mode tab to scan easily by following these simple on-screen steps. This section describes the settings and functions available on the Basic Mode tab. (1) Settings and Operation Buttons (2) Toolbar (3) Preview Area Note •...
  • Page 317 Document (Grayscale) ADF Duplex (only for models supporting ADF duplex scanning) Scan both sides of documents from the ADF in black and white. Important • Some applications do not support continuous scanning from the ADF. For details, see the application's manual. Note •...
  • Page 318 Output Size Select an output size. Output size options vary by the item selected in Destination. Flexible Adjust the cropping frames (scan areas) freely. In thumbnail view: Drag the mouse over a thumbnail to display a cropping frame. When a cropping frame is displayed, the portion within the cropping frame will be scanned.
  • Page 319 Important • Predefined output sizes such as A4 and 1024 x 768 pixels cannot be deleted. Note • Save up to 10 items. • An error message appears when you enter a value outside the setting range. Enter a value within the setting range.
  • Page 320 Important • Be sure to see Gutter Shadow Correction for precautions and other information on using this function. Color Pattern... Adjust the image's overall color. Correct colors that have faded due to colorcast or other reasons and reproduce natural colors while previewing color changes. Adjusting Colors Using a Color Pattern Important •...
  • Page 321 (Rotate Right) Rotates the preview image 90 degrees clockwise. • The result will be reflected in the scanned image. • The image returns to its original state when you preview again. (Auto Crop) Displays and adjusts the cropping frame automatically to the size of the document displayed in the Preview area.
  • Page 322 When (Thumbnail) is displayed on Toolbar: Cropping frames are specified according to the document size, and thumbnails of scanned images appear. Only the images with the checkbox selected will be scanned. Note • When multiple images are previewed, different outlines indicate different selection status. •...
  • Page 323 Note • Create cropping frame(s) on the displayed image. In thumbnail view, one cropping frame can be created per image. In whole image view, multiple cropping frames can be created. Adjusting Cropping Frames (ScanGear) Related Topic Scanning in Basic Mode...
  • Page 324: Advanced Mode Tab

    Advanced Mode Tab This mode allows you to make advanced scan settings such as the color mode, output resolution, image brightness, and color tone. This section describes the settings and functions available on the Advanced Mode tab. (1) Settings and Operation Buttons (2) Toolbar (3) Preview Area Note...
  • Page 325 Enter Setting Name and click Add; the name appears in Favorite Settings List. When you click Save, the item appears in the Favorite Settings list and can be selected, along with the predefined items. To delete an item, select it in Favorite Settings List and click Delete. Click Save to save the settings displayed in Favorite Settings List.
  • Page 326 Note • Zoom rescans the document and displays high-resolution image in Preview. • (Enlarge/Reduce) on the Toolbar zooms in on the preview image quickly. However, the resolution of the displayed image will be low. Preview Performs a trial scan. Scan Starts scanning.
  • Page 327 In thumbnail view: In whole image view: (Thumbnail) / (Whole Image) Switches the view in the Preview area. (3) Preview Area (Clear) Deletes the preview image from the Preview area. It also resets the Toolbar and color adjustment settings. (Crop) Allows you to specify the scan area by dragging the mouse.
  • Page 328 (Uncheck All Frames) Available when two or more frames are displayed. Deselects the checkboxes of the images in thumbnail view. (Select All Frames) Available when two or more frames are displayed. Selects the images in thumbnail view and outlines them in blue. (Select All Cropping Frames) Available when two or more cropping frames are specified.
  • Page 329 Note • When multiple images are previewed, different outlines indicate different selection status. • Focus Frame (thick blue outline): The displayed settings will be applied. • Selected Frame (thin blue outline): The settings will be applied to the Focus Frame and Selected Frames simultaneously.
  • Page 330: General Notes (scanner Driver)

    General Notes (Scanner Driver) ScanGear (scanner driver) is subject to the following restrictions. Keep these points in mind when using it. Scanner Driver Restrictions • When using the NTFS file system, the TWAIN data source may not be invoked. This is because the TWAIN module cannot be written to the winnt folder for security reasons.
  • Page 331 • Images may not be scanned correctly in some applications. In that case, increase the operating system's virtual memory and retry. • When image size is too large (such as when scanning large images at high resolution), your computer may not respond or the progress bar may remain at 0 % depending on the application. In that case, cancel the action (for example by clicking Cancel on the progress bar), then increase the operating system's virtual memory or reduce the image size/resolution and retry.
  • Page 332: Scanning Tips

    Scanning Tips Positioning Originals (Scanning from Computer) Network Scan Settings IJ Network Scanner Selector EX2 Menu and Setting Screen...
  • Page 333: Positioning Originals (scanning From Computer)

    Positioning Originals (Scanning from Computer) This section describes how to load originals on the platen or ADF (Auto Document Feeder) for scanning. If items are not placed correctly they may not be scanned correctly. Important • Do not place objects on the document cover. When you open the document cover, the objects may fall into your scanner or printer, resulting in malfunction.
  • Page 334 Important Important • Large items (such as A4 size photos) that cannot be • For the portions in which items cannot be scan- placed away from the edges/arrow (alignment mark) of ned, see Loading Originals. the platen may be saved as PDF files. To save in a for- mat other than PDF, scan by specifying the data format.
  • Page 336: Network Scan Settings

    • If the icon is not displayed in the notification area on the desktop, follow the procedure below to start. • Windows 10: From the Start menu, click All apps > Canon Utilities > IJ Network Scanner Selector EX2. • Windows 8.1:...
  • Page 337 Search charm, then search for "IJ Network Scanner Selector EX". • Windows 7: From the Start menu, click All Programs > Canon Utilities > IJ Network Scanner Selector EX2 > IJ Network Scanner Selector EX2. The icon appears in the notification area on the desktop, and the Scan-from-PC Settings screen appears.
  • Page 338 • If the icon is not displayed in the notification area on the desktop, follow the procedure below to start. • Windows 10: From the Start menu, click All apps > Canon Utilities > IJ Network Scanner Selector EX2. • Windows 8.1: Click IJ Network Scanner Selector EX2 on the Start screen.
  • Page 339 4. Select your scanner or printer from Scanners and click OK. Select the MAC address of your scanner or printer. Note • When multiple scanners are connected via a network, you can select up to three scanners. 5. In the Scan-from-PC Settings screen, click OK. Note •...
  • Page 340: Faxing

    Faxing Preparing for Faxing Registering Recipients Sending Faxes Using Operation Panel of Sending Faxes from Computer (Windows) Printer Sending Faxes from Computer (Mac OS) Receiving Faxes Other Useful Fax Functions...
  • Page 341: Preparing For Faxing

    Preparing for Faxing Connect the printer to the telephone line and set up the printer before using the faxing functions. Then specify the basic setting such as sender information, date/time, and daylight saving time. Important • If the Power Disconnects: If there is a power failure or if you accidentally unplug the power cord, the date/time settings will be reset.
  • Page 342: Connecting Telephone Line

    Connecting Telephone Line The connection method differs depending on your telephone line. • If you connect the printer to wall telephone line directly/If you connect the printer with the xDSL splitter: Basic Connection • If you connect the printer to another line such as an xDSL: Connecting Various Lines If the connection is incorrect, the printer cannot send/receive faxes.
  • Page 343 Important • Be sure to connect the telephone line before the printer is turned on. If you connect the telephone line when the printer is turned on, turn the printer off and unplug the power cord. Wait for 1 minute, and then connect the power plug. Note •...
  • Page 344 A. Digital Subscriber Line B. xDSL modem (splitter may not be built-in to the modem) C. Broadband router compatible with Internet Telephone D. Computer E. Telephone or answering device F. WAN (Wide Area Network) port G. LAN (Local Area Network) port H.
  • Page 345 • Connecting to an ISDN Line For details on ISDN (Integrated Service Digital Network) connection and settings, refer to the manuals supplied with your terminal adapter or dial-up router.
  • Page 346: Setting Telephone Line Type

    Setting Telephone Line Type Before using your printer, make sure you set the correct telephone line type for your telephone line. If you are unsure of your telephone line type, contact your telephone company. For xDSL or ISDN connections, contact the telephone company or service provider to confirm your line type. Important •...
  • Page 347 Rotary pulse Select when your telephone line type is pulse dialing. Touch tone Select when your telephone line type is tone dialing. Setting the Telephone Line Type Manually in China This section describes the procedure to set the telephone line type manually in China. Make sure that printer is turned on.
  • Page 348 10. Select a telephone line type. Rotary pulse Select when your telephone line type is pulse dialing. Touch tone Select when your telephone line type is tone dialing.
  • Page 349: Setting Receive Mode

    Setting Receive Mode Set the receiving operation (receiving mode). For details on how to set the receive mode: Setting Receive Mode You can select the appropriate mode. For details on the selectable receive mode: About Receive Mode For details on the advanced settings of the receive mode: Advanced Settings of Receive Mode Note •...
  • Page 350 • For details on the receive mode: About Receive Mode • DRPD is available only in the US and Canada. • Network switch may not be available depending on the country or region of purchase. • Refer to Receiving Faxes for information on receiving faxes or the procedure for each receive mode.
  • Page 351 If you select Manual/auto switch: ON, the printer automatically receives faxes after the external device rang a specified length of time. You can specify the length of time until automatic reception is started. ◦ RX start time You can specify the length of time until automatic reception is started when Manual/auto switch: ON is selected.
  • Page 352 • Advanced setting in Network switch You can specify the following setting item. ◦ Ring count You can specify the number of times the external device rings when incoming. Specify the number of time and select OK. Setting DRPD Ring Pattern (US and Canada only) If you have subscribed to a Distinctive Ring Pattern Detection (DRPD) service provided by your telephone company, your telephone company will assign two or more telephone numbers with distinctive ring patterns to your single telephone line, allowing you to have different numbers for fax calls and voice calls...
  • Page 353 8. Specify number of time and select OK. 9. Select OK. The Function list screen is displayed.
  • Page 354: Setting Sender Information

    Setting Sender Information You can set the sender information such as date/time, unit name, and unit fax/telephone number. About Sender Information Setting Date and Time Setting Daylight Saving Time (Summer Time) Registering User Information About Sender Information If the unit name and unit fax/telephone number are registered, they are printed with date and time as sender information on the recipient's fax.
  • Page 355: Setting Date And Time

    Setting Date and Time This section describes the procedure to set the date and time. Make sure that printer is turned on. 2. Select Setup on the HOME screen. Using the Operation Panel 3. Select Settings. 4. Select Device settings. 5.
  • Page 356 8. Set time. 1. Select a setting item to change. 2. Select number to enter. Enter the date and time in 24-hour format. 3. Select OK. 4. Select OK again when all settings are completed. 9. Press HOME button to return to HOME screen. Setting Daylight Saving Time (Summer Time) Some countries adopt the daylight saving time (summer time) system that shifts the clock time forward at certain periods of the year.
  • Page 357 2. Select Setup on the HOME screen. Using the Operation Panel 3. Select Settings. 4. Select Device settings. 5. Select Device user settings. 6. Select Daylight saving time setting. 7. Select ON. To disable summer time, select OFF. 8. Set date and time when summer time starts. 1.
  • Page 358 9. Set date and time when summer time ends. 1. Set date when summer time ends. Select a setting item to change, and then specify the setting. Select OK again when all settings are completed. 2. Set time (in 24-hour format) when summer time ends. Select a setting item to change, and then specify the setting.
  • Page 359 4. Select Device settings. 5. Select FAX settings. 6. Select FAX user settings. 7. Select User information settings. The screen to register the unit name and the unit fax/telephone number is displayed. 8. Enter unit name. 1. Select entry field under Unit name. The screen to enter the character is displayed.
  • Page 360 2. Enter unit fax/telephone number. 3. Select OK. Note • You can enter the fax/telephone number up to 20 digits, including spaces. • For details on how to enter or delete characters: Entering Numbers, Letters, and Symbols 10. Select Register to finalize registration.
  • Page 361: Registering Recipients

    Registering Recipients Registering Recipients Using Operation Panel of Printer Registering Recipients Using Speed Dial Utility2 (Windows) Registering Recipients Using Speed Dial Utility2 (Mac OS)
  • Page 362: Registering Recipients Using Operation Panel Of Printer

    Registering Recipients Using Operation Panel of Printer Registering recipients in the printer's directory in advance allows you to dial fax/telephone numbers simply. The following methods to register are available: • Recipient registration Registering the recipient's fax/telephone number and name allows you to send a fax by selecting a registered recipient in the printer directory.
  • Page 363: Registering Fax/telephone Number Of Recipients

    Registering Fax/Telephone Number of Recipients Before you can use the printer's directory, you need to register the recipients' fax/telephone numbers. Follow the procedure below to register the recipients' fax/telephone numbers. Make sure that printer is turned on. 2. Select FAX on the HOME screen. Using the Operation Panel The Fax standby screen is displayed.
  • Page 364 8. Select a registration method. 9. Register recipients' fax/telephone number. Register the recipients' fax/telephone number depending on the registration method selected. • By entering the number The screen to register the recipient's fax/telephone number and name is displayed. Go to next step.
  • Page 365 Note • This registration method may not be available depending on the country or region of purchase. 10. Enter recipient's name. If you select From incoming call log as a registration method, the recipient's name may be already entered. If you do not change the name, go to next step. 1.
  • Page 366 Note • You can enter the fax/telephone number up to 60 digits (40 digits for the US, Canada, Korea and some regions of Latin America), including spaces. Entering Numbers, Letters, and Symbols • When Telephone line type in FAX user settings under FAX settings is set to Rotary pulse, you can enter a tone ("T") by selecting the Tone key.
  • Page 367: Registering Recipients In Group Dial

    Registering Recipients in Group Dial If you register two or more registered recipients to a group dial, you can send the same document successively to all recipients registered to the group dial. Make sure that printer is turned on. 2. Select FAX on the HOME screen.
  • Page 368 8. Enter group name. 1. Select entry field of group name. The screen to enter the character is displayed. 2. Enter group name. 3. Select OK. Note • You can enter the name up to 16 characters, including spaces. Entering Numbers, Letters, and Symbols 9.
  • Page 369 Display by ID number A. Select to switch the display by name and by ID number. B. Select to display the screen to select an initial. You can search the registered recipient by initial. By selecting the initial, the registered recipients are displayed in alphabetical order from the selected character.
  • Page 370 Note • To delete the recipient from the group dial, select a recipient that you want to delete from the list. After the confirmation screen is displayed, select Yes to delete the recipient from the group dial. 3. To add another member, select Add member again. The printer's directory is displayed.
  • Page 371: Changing Registered Information

    Changing Registered Information To change information registered for recipient and group dial, follow the procedure below. Make sure that printer is turned on. 2. Select FAX on the HOME screen. Using the Operation Panel The Fax standby screen is displayed. 3.
  • Page 372 When the confirmation screen is displayed, select Yes to delete the recipient from the group dial. 5. Select Complete to finalize changing.
  • Page 373: Deleting Registered Information

    Deleting Registered Information To delete information registered for recipient and group dial, follow the procedure below. Make sure that printer is turned on. 2. Select FAX on the HOME screen. Using the Operation Panel The Fax standby screen is displayed. 3.
  • Page 374: Printing List Of Registered Destinations

    Printing List of Registered Destinations You can print a list of the fax/telephone numbers and can keep it near the printer to refer to when dialing. Make sure that printer is turned on. Load paper. 3. Select FAX on the HOME screen. Using the Operation Panel The Fax standby screen is displayed.
  • Page 375: Registering Recipients Using Speed Dial Utility2 (windows)

    Registering Recipients Using Speed Dial Utility2 (Windows) About Speed Dial Utility2 Speed Dial Utility2 is a utility for forwarding the telephone directory registered on the printer to a computer and registering/changing it on the computer. In addition, you can register the telephone directory edited on the computer to the printer.
  • Page 376: Starting Up Speed Dial Utility2

    1. Make sure printer is turned on. 2. Start up Speed Dial Utility2. • For Windows 10, click Start button and select All apps, Canon Utilities, and then Speed Dial Utility2. • For Windows 8.1 or Windows 8, select Speed Dial Utility2 on the Start screen to start Speed Dial Utility2.
  • Page 377: Speed Dial Utility2 Dialog Box

    Speed Dial Utility2 Dialog box The following items are on the Speed Dial Utility2 dialog box. 1. Printer Name: Selects the printer for editing the telephone directory using Speed Dial Utility2. Behind printer name, printer's MAC address is displayed. Note •...
  • Page 378 Note • By clicking on the item name, you can sort the display order. 5. Edit.../Select All/Delete Edits the item that selected for Setting Item List:, or deletes the item, or selects all the items. When multiple items on the registered information list are selected, you cannot use the Edit... button. 6.
  • Page 379: Saving Registered Telephone Directory On Printer To Your Computer

    Saving Registered Telephone Directory on Printer to Your Computer Follow the procedure below to save the telephone directory (includes recipients' name, recipients' fax/ telephone number, group dial, user's name, user's fax/telephone number, and rejected numbers) that registered on the printer to the computer. Start up Speed Dial Utility2.
  • Page 380: Registering A Fax/telephone Number Using Speed Dial Utility2

    Registering a Fax/telephone Number Using Speed Dial Utility2 Follow the procedure below to register fax/telephone numbers. Note Before you register fax/telephone numbers using Speed Dial Utility2, make sure that no fax operations are in progress. Start up Speed Dial Utility2. 2.
  • Page 381 1. Enter group name. 2. Select a code you want to add to group dial, and then click Add >>. Note • You can only add the numbers that have already been registered. 6. Click OK. To continue registering fax/telephone numbers or a group dial, repeat steps 4 to 6. •...
  • Page 382: Changing A Fax/telephone Number Using Speed Dial Utility2

    Changing a Fax/telephone Number Using Speed Dial Utility2 Follow the procedure below to change fax/telephone numbers. Note • Before you change fax/telephone numbers using Speed Dial Utility2, make sure that no fax operations are in progress. Start up Speed Dial Utility2. 2.
  • Page 383 2. Add or delete a member to/from group dial. To add a member: Select a code to add to group dial, and then click Add >>. To delete a member: Select a code to delete from group dial, and then click << Delete. 5.
  • Page 384: Deleting A Fax/telephone Number Using Speed Dial Utility2

    Deleting a Fax/telephone Number Using Speed Dial Utility2 Follow the procedure below to delete fax/telephone numbers. Note • Before you delete fax/telephone numbers using Speed Dial Utility2, make sure that no fax operations are in progress. Start up Speed Dial Utility2. 2.
  • Page 385: Changing Sender Information Using Speed Dial Utility2

    Changing Sender Information Using Speed Dial Utility2 Follow the procedure below to change the user's name or fax/telephone number. Start up Speed Dial Utility2. 2. Select a printer from Printer Name: list box, and then click Display Printer Settings. 3. Click User Information Setting from Setting Item List:. The user's information is displayed.
  • Page 386: Registering/changing Rejected Number Using Speed Dial Utility2

    Registering/Changing Rejected Number Using Speed Dial Utility2 Follow the procedure below to register, change, or delete rejected numbers. Start up Speed Dial Utility2. 2. Select a printer from Printer Name: list box, and then click Display Printer Settings. 3. Click Rejected Number Setting from Setting Item List:. The list of rejected numbers is displayed.
  • Page 387: Registering Telephone Directory Has Been Saved On Your Computer To Printer

    Registering Telephone Directory Has been Saved on Your Computer to Printer You can load the data of the telephone directory (RSD file, *.rsd) and register it to your printer. The data of the telephone directory (RSD file, *.rsd) that is exported from other printer can be loaded and registered to your printer.
  • Page 388: Sending Faxes Using Operation Panel Of Printer

    Sending Faxes Using Operation Panel of Printer Sending Faxes by Entering Fax/Telephone Number Basic Resending Faxes (Redialing Busy Number) Setting Items for Sending Faxes...
  • Page 389: Sending Faxes By Entering Fax/telephone Number

    Sending Faxes by Entering Fax/Telephone Number This section describes dialing and sending faxes directly by entering the fax/telephone numbers. Important • It may be possible that faxes will reach unintended recipients due to the misdialing or incorrect registration of fax/telephone numbers. When you send important documents, we recommend that you send them after speaking on the telephone.
  • Page 390 E. Redial Select to send faxes with redialing. Resending Faxes (Redialing Busy Number) F. On hook dial Select to send faxes with the on hook dial function. Using On Hook Dial Function G. Directory You can select a registered fax/telephone number. Sending Fax to Registered Recipient H.
  • Page 391 Enters the number. B. Pause Enters a pause "P". C. Delete Deletes the entered number. D. Blank space Enters a blank space. 3. Select OK. The touch screen returns to the Fax standby screen. 5. Press Color button for color transmission, or Black button for black & white transmission. The printer starts scanning the document.
  • Page 392 • If documents remain in the ADF after the Stop button is pressed while scanning is in progress, Document in ADF. Remove the document from the document tray and tap [OK]. is displayed on the touch screen. By selecting OK, the remaining documents are automatically ejected.
  • Page 393: Resending Faxes (redialing Busy Number)

    Resending Faxes (Redialing Busy Number) There are two methods of redialing: Automatic redialing and Manual redialing. • Automatic Redialing If you send a document and the recipient's line is busy, the printer will redial the number after a specified interval. Automatic Redialing •...
  • Page 394 Make sure that printer is turned on. Load documents on platen glass or in ADF. 3. Select FAX on the HOME screen. Using the Operation Panel The Fax standby screen is displayed. 4. Change send settings as necessary. Setting Items for Sending Faxes 5.
  • Page 395: Setting Items For Sending Faxes

    Setting Items for Sending Faxes You can change the send settings such as the scan contrast or the scan resolution on the Fax standby screen. Select to change the send settings. • ScanRes. The following settings of the scan resolution are selectable. Standard Suitable for text-only documents.
  • Page 396 The touch screen returns to the Fax standby screen when you finish specifying the setting and selecting OK.
  • Page 397: Sending Faxes From Computer (windows)

    Sending Faxes from Computer (Windows) Sending a FAX (Fax Driver) Basic Creating an Address Book (Fax Driver) Edit or Remove a Recipient from an Address Book (Fax Driver) Search for a Recipient in an Address Book (Fax Driver) Cannot Send Faxes from Computer How to Open the Setting Screen of the Fax Driver General Notes (Fax Driver)
  • Page 398: Sending A Fax (fax Driver)

    2. Open the document you want to fax with an application (such as Notepad), and then click the Print command. (The command is Print... on the File menu.) 3. In Select Printer or Name in the Print dialog box, select Canon XXX series FAX (where "XXX" is the model name).
  • Page 399 6. Select a recipient from Recipient Name in the Select Recipient from Address Book dialog box, then click Set as Recipient. The selected recipient is reflected in Recipient in the Send FAX dialog box. Important • You cannot specify a recipient if there is no recipient registered in the address book. Register the recipient in the address book and reopen the address book.
  • Page 400: Canceling Transmission

    Note • You can also specify Recipient by entering the Recipient Name and Fax Number in Direct Entry in the Send FAX dialog box and then clicking Set as Recipient. • For details on valid characters, see "General Notes (Fax Driver)."...
  • Page 401: Creating An Address Book (fax Driver)

    Creating an Address Book (Fax Driver) By using the address book, you can send a fax by simply specifying a recipient from it. You can register the recipient's name, fax number and other information in the address book. Registering a recipient (WAB contact) in the address book You can register an individual recipient (Contact) in the address book.
  • Page 402 4. Select Contact in the New Entry dialog box, then click OK. Note • For faxing, you can only specify the Contact (one recipient). You cannot specify a Distribution List. 5. On Name and E-mail tab of Properties dialog box, enter First and Last. The recipient's name will be printed at the top of the fax received by the recipient.
  • Page 403 6. Enter the fax number on the Home or Work tab, then click OK. An individual recipient (Contact) is registered in the address book. Note • You can also register a recipient by clicking the Add to Address Book... button on the Send FAX dialog box after entering the recipient.
  • Page 404 Advanced settings, then click OK. 3. From the Start menu, select XXXX (user name), then double-click AppData > Roaming > Canon > MP5 to open the folder. 4. Double-click the ".wab" file. The address book will be reflected in Windows Vista automatically.
  • Page 405: Edit Or Remove A Recipient From An Address Book (fax Driver)

    Edit or Remove a Recipient from an Address Book (Fax Driver) You can change the recipients' names, fax numbers and other information, or delete recipients registered in the address book. Editing Recipients in an address book Open the print settings dialog box of the fax driver. 2.
  • Page 406 Removing Recipients from an address book Open the print settings dialog box of the fax driver. 2. Click Address Book... in the displayed dialog box. 3. Select the recipient you want to delete from the Address Book dialog box, then click Delete.
  • Page 407 4. When a confirmation message is displayed, click Yes.
  • Page 408: Search For A Recipient In An Address Book (fax Driver)

    1. Open the document you want to fax with an application (such as Notepad), and then click the Print command. (The command is Print... on the File menu.) 2. In Select Printer or Name in the Print dialog box, select Canon XXX series FAX (where "XXX" is the model name).
  • Page 409 5. Enter the name of the recipient you want to search for in Search by Recipient in the Select Recipient from Address Book dialog box. If the entered name is found, the recipient will be displayed in the contact list with its name selected. While the name is selected, click Set as Recipient to enter it as the recipient.
  • Page 410: Cannot Send Faxes From Computer

    Cannot Send Faxes from Computer Is the power turned on? Check 1 You cannot send faxes if the power is turned off. Press the ON button to turn the power on. If you disconnected the power cord without turning off the power (one of the buttons on the operation panel is lit), reconnecting it turns on the power.
  • Page 411 Note • For details on how to change the recipients registered in the address book, see "Edit or Remove a Recipient from an Address Book (Fax Driver)." Does an error occur during transmission? Check 6 Check if a message is displayed in the computer screen. If displayed, check the message, then resolve the error.
  • Page 412: How To Open The Setting Screen Of The Fax Driver

    1. Click the Settings charm > Control Panel > Hardware and Sound > Devices and Printers. 2. Right-click the Canon XXX series Printer icon or Canon XXX series FAX icon and select Printing Preferences, then Canon XXX series FAX. (Where "XXX" is the model name.)
  • Page 413 1. Click the Settings charm > Control Panel > Hardware and Sound > Devices and Printers. 2. Right-click the Canon XXX series Printer icon or Canon XXX series FAX icon and select Printer Properties, then Canon XXX series FAX. (Where "XXX" is the model name.)
  • Page 414: General Notes (fax Driver)

    • The fax driver does not work correctly if you uncheck the Enable printer pooling option on the Ports tab of the Canon XXX series FAX Properties dialog box (where "XXX" is the model name). Check that the option is checked.
  • Page 415: Receiving Faxes

    Receiving Faxes Receiving Faxes Changing Paper Settings Memory Reception...
  • Page 416: Receiving Faxes

    Receiving Faxes This section describes the preparation necessary for receiving a fax and how to receive a fax. Preparing for Receiving Fax Prepare for receiving a fax according to the following procedure. Make sure that printer is turned on. 2. Select FAX on the HOME screen.
  • Page 417 Note • For details on the receive mode: Setting Receive Mode • You can specify the advanced settings of each receive mode. For details on the advanced settings of the receive mode: Advanced Settings of Receive Mode • If the printer was not able to print a received fax, the printer stores the unprinted fax temporarily in its memory (memory receiving).
  • Page 418 The number of times to ring the telephone until switching to fax reception can be changed. • Set the printer to enable you to initiate fax reception from a connected telephone (remote reception). Remote Reception • When the answering device is connected to the printer: •...
  • Page 419 Note • If a telephone is connected to the printer, the telephone will ring when a call incomes. • You can change the number of times to ring the telephone with Ring count in Advanced. When DRPD or Network switch is selected: •...
  • Page 420 Note • To use this feature, you need to subscribe to a compatible service provided by your telephone company. • For DRPD You need to select the appropriate ring pattern on the printer. Setting DRPD Ring Pattern (US and Canada only) •...
  • Page 421: Changing Paper Settings

    Changing Paper Settings This printer prints received faxes to paper loaded in the printer beforehand. You can use the operation panel to change the paper settings for printing faxes. Make sure that the settings are appropriate for the loaded paper. Important •...
  • Page 422 A. Page size Select the page size from A4, Letter, or Legal. B. Type (Media type) The paper type is set to Plain paper. C. Paper src Select a paper source (Rear tray/Cassette/Auto) where paper is loaded. Note • When Auto is selected, paper is fed from the paper source where the paper that matches the paper settings (page size and media type) is loaded.
  • Page 423: Memory Reception

    Memory Reception If the printer was not able to print the received fax, the received fax is stored in the printer's memory. The FAX Memory lamp is lit and Received in memory. is displayed at the Fax standby screen. Important •...
  • Page 424 Auto print settings ◦ Paper has run out: Load the paper and select OK on the touch screen. ◦ A different size of paper from that specified by Page size in FAX paper settings is loaded: Load the same size of paper as that specified by Page size in FAX paper settings, and then select OK on the touch screen.
  • Page 425: Other Useful Fax Functions

    Other Useful Fax Functions Document Stored in Printer's Memory...
  • Page 426: Document Stored In Printer's Memory

    Document Stored in Printer's Memory If the sending faxes is not complete or the printer was not able to print the received faxes, these faxes are stored in the printer's memory. If an error occurred during a fax transmission, the document is not stored in the printer's memory. In the following cases, the printer is not able to print the received fax and will automatically store the fax in its memory.
  • Page 427: Printing Document In Printer's Memory

    Printing Document in Printer's Memory You can print a specified document in the printer's memory or print all the received documents in its memory at a time. When printing a specified document, you specify it by its transaction number. If you do not know the transaction number for your target document, print the list of documents (MEMORY LIST) first.
  • Page 428 6. Select a print menu. • To print the memory list (MEMORY LIST): You can print a list of the documents in the printer's memory by selecting Print doc. list. When the print confirmation screen is displayed, select Yes. The printing starts. MEMORY LIST shows the transaction number of the unsent or unprinted fax (TX/RX NO.), transaction mode, recipient's number, and the date and time of the transaction.
  • Page 429: Deleting Document In Printer's Memory

    Deleting Document in Printer's Memory You can delete a specified document in the printer's memory or delete all the documents in its memory at a time. Note • When deleting a specified document, you specify it by its transaction number. If you do not know the transaction number for your target document, print the list of documents (MEMORY LIST) first.
  • Page 430 5. Select a delete menu. • To specify a document to delete: Select a document to delete on the Memory list screen, select Delete specified doc.. Note • If the specified document is not stored in the printer's memory, There is no document that can be deleted.
  • Page 431: Frequently Asked Questions

    Frequently Asked Questions Cannot Find Printer on Network Cannot Find Printer while Using Wireless LAN Network Key Unknown Network Cannot Print or Connect For other questions about network, click here. Printing Does Not Start Paper Is Blank/Printing Is Blurry/Colors Are Wrong/White Streaks Appear Print Results Are Unsatisfactory Print List of Support Code for Error (Paper Jams)
  • Page 432 Paper Does Not Feed Properly/"No Paper" Error Automatic Duplex Printing Problems Print Results Are Unsatisfactory Scanning Problems (Windows) Scanning Problems (Mac OS) Scan Results Are Unsatisfactory (Windows) Scan Results Are Unsatisfactory (Mac OS) Cannot Print/Scan from Smartphone/Tablet Errors Often Occur When You Send a Fax Quality of Received Fax is Poor Cannot Dial Telephone Disconnects During a Call...
  • Page 433 Installation and Download Problems Errors and Messages If You Cannot Solve a Problem...
  • Page 434: Network Settings And Common Problems

    Network Settings and Common Problems Here are frequently asked questions on network. Select a connection method you are using, or you want to use. Wireless LAN Wireless Direct Wireless LAN Cannot Find Printer Cannot Find Printer while Using Wireless LAN Cannot Find Printer on Check Printer Settings Screen During Setup (Windows) Cannot Proceed beyond Printer Connection Screen Cannot Find Printer after Searching it on Printer Detection Screen During Setup...
  • Page 435 Cannot Connect Smartphone/Tablet to Wireless Router Checking Wireless Router SSID for Smartphone/Tablet Setting Up Using Smartphone/Tablet Cannot Print/Scan from Smartphone/Tablet Downloading Canon PRINT Inkjet/SELPHY Problems while Using Printer Message Appears on Computer During Setup Printing Is Slow Ink Level Not Shown on Printer Status Monitor (Windows)
  • Page 436: Network Communication Problems

    Network Communication Problems Cannot Find Printer on Network Network Connection Problems Other Network Problems...
  • Page 437: Cannot Find Printer On Network

    Cannot Find Printer on Network While performing printer setup: Cannot Find Printer on Check Printer Settings Screen During Setup (Windows) Cannot Proceed beyond Printer Connection Screen While using printer: Cannot Find Printer while Using Wireless LAN...
  • Page 438: Cannot Find Printer On Check Printer Settings Screen During Setup (windows)

    Cannot Find Printer on Check Printer Settings Screen During Setup (Windows) If the printer cannot be found and the Check Printer Settings screen appears after searching the printer by Automatic search on the Search for Printers screen, click Redetect and search for the printer again by the IP address on the Search for Printers screen.
  • Page 439: Checking Power Status

    Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)-Checking Power Status Are printer and network device (router, etc.) turned on? Make sure the printer is turned on. Confirming that the Power Is On Make sure network device (router, etc.) is turned on. If printer or network device is off: Turn on printer or network device.
  • Page 440: Checking Pc Network Connection

    Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)-Checking PC Network Connection Can you view any web pages on your computer? Make sure the computer and network device (router, etc.) are configured and the computer is connected to the network.
  • Page 441: Cannot Find Printer On Check Printer Settings Screen During Wireless Lan Setup (windows)-checking Printer's Wireless Lan Settings

    Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)-Checking Printer's Wireless LAN Settings Is printer set to allow wireless communication? Make sure the icon is displayed on the touch screen. If icon is not displayed: The printer is not set to allow wireless communication. Turn on wireless communication on the printer. If icon is displayed: Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)- Checking Wireless LAN Environment...
  • Page 442: Cannot Find Printer On Check Printer Settings Screen During Wireless Lan Setup (windows)-checking Wireless Lan Environment

    Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)-Checking Wireless LAN Environment Is printer connected to wireless router? Use the icon on the touch screen to make sure the printer is connected to the wireless router. icon is displayed: •...
  • Page 443: Cannot Find Printer On Check Printer Settings Screen During Wireless Lan Setup (windows

    Important • Depending on the wireless router, note that different SSID is assigned for a bandwidth (2.4 GHz or 5 GHz) or its usage (for PC or game machine) using alphanumeric characters at the end of SSID. Check the SSID of the wireless router for the printer on the touch screen. Tap the icon on the lower left, select Yes, and then check SSID.
  • Page 444: Checking Printer's Ip Address

    Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)-Checking Printer's IP Address Is printer's IP address specified correctly? If printer's IP address is not specified correctly, the printer may not be found. Make sure whether printer's IP address is not used for another device.
  • Page 445: Cannot Find Printer On Check Printer Settings Screen During Wireless Lan Setup (windows)-checking Security Software Settings

    • If no message appears: Cancel the setup, and then set the security software to allow Canon software to access the network. The file Setup.exe or Setup64.exe in the win > Driver > DrvSetup folder on the Setup CD-ROM After setting the security software, redo the network communication setup from the beginning.
  • Page 446: Cannot Find Printer On Check Printer Settings Screen During Wireless Lan Setup (windows)-checking Wireless Router Settings

    Cannot Find Printer on Check Printer Settings Screen During Wireless LAN Setup (Windows)-Checking Wireless Router Settings Check wireless router settings. Check wireless router network connection settings, such as IP address filtering, MAC address filtering, encryption key, and DHCP function. Make sure the same radio channel is assigned to the wireless router and the printer. To check the settings of the wireless router, see the instruction manual supplied with the wireless router or contact the manufacturer.
  • Page 447: Cannot Proceed Beyond Printer Connection Screen

    Cannot Proceed beyond Printer Connection Screen If you cannot proceed beyond the Printer Connection screen, check the following. Make sure USB cable is securely plugged in to printer and computer. Check1 Connect the printer and the computer using a USB cable as the illustration below. The USB port is located at the back of the printer.
  • Page 448 4. Turn off printer. 5. Restart computer. 6. Make sure you have no application software running. 7. Perform setup on web page. Note • You can use the Setup CD-ROM to redo setup. • For Mac OS: 1. Click Next. ◦...
  • Page 449: Cannot Find Printer While Using Wireless Lan

    Cannot Find Printer while Using Wireless LAN Make sure the printer is turned on. Check1 Check the (Network status) icon on the touch screen. Check2 If the icon is displayed, wireless LAN is disabled. Select Active on WLAN active/inactive in Wireless LAN under LAN settings. If the icon is displayed, see Check 3 or later checking items to make sure whether printer setup is complete or the settings of wireless router to connect are correct.
  • Page 450 Printing Network Settings Note • IJ Network Device Setup Utility allows you to diagnose and repair the network status. Select the link below to download IJ Network Device Setup Utility and install it. Checking Printer Connection Status Using IJ Network Device Setup Utility See below for starting up IJ Network Device Setup Utility.
  • Page 451 Make sure security software's firewall is off. Check9 If your security software's firewall is on, a message may appear warning you that Canon software is attempting to access the network. If this warning message appears, set security software to always allow access.
  • Page 452: Network Connection Problems

    Network Connection Problems Printer Suddenly Cannot Be Used Network Key Unknown Printer Cannot Be Used After Replacing Wireless Router or Changing Its Settings...
  • Page 453: Printer Suddenly Cannot Be Used

    Printer Suddenly Cannot Be Used Cannot Communicate with Printer Following Network Settings Change Cannot Communicate with Printer via Wireless LAN Cannot Communicate with Printer Using Wireless Direct Cannot Print, Scan, or Fax from a Computer Connected to the Network Cannot Communicate with Printer Following Network Settings Change It may take a while for the computer to obtain an IP address, or you may need to restart your computer.
  • Page 454 To check the settings of the wireless router, refer to the instruction manual provided with it or contact its manufacturer. To check the current network settings of the printer, print out the network setting information. Printing Network Settings Note • IJ Network Device Setup Utility allows you to diagnose and repair the network status. Select the link below to download IJ Network Device Setup Utility and install it.
  • Page 455 Make sure security software's firewall is off. Check9 If your security software's firewall is on, a message may appear warning you that Canon software is attempting to access the network. If this warning message appears, set security software to always allow access.
  • Page 456 Make sure wireless LAN is enabled on your device. For details, refer to your device's instruction manual. Make sure printer is selected as connection for device (e.g. smartphone or Check4 tablet). Select the identifier for Wireless Direct (SSID) specified for the printer as the connection destination for devices.
  • Page 457 If MP Drivers are not installed, install them. (Windows) Check2 Install the MP Drivers using the Setup CD-ROM or install them from the Canon website. Make sure wireless router does not restrict which computers can access it. Check3 For more on connecting to and setting up your wireless router, see the wireless router instruction manual or contact its manufacturer.
  • Page 458: Network Key Unknown

    Network Key Unknown WPA/WPA2 or WEP Key Set for Wireless Router Unknown, Cannot Connect Setting an Encryption Key WPA/WPA2 or WEP Key Set for Wireless Router Unknown, Cannot Connect For more on setting up a wireless router, see the instruction manual provided with the wireless router or contact its manufacturer.
  • Page 459 Selecting WPA, WPA2, or WPA/WPA2 is recommended for security reason. If your wireless router is compatible with WPA/WPA2, you can also use WPA2 or WPA. • Using WPA/WPA2 The authentication method, passphrase, and dynamic encryption type must be the same for the wireless router, the printer, and your computer.
  • Page 460: Printer Cannot Be Used After Replacing Wireless Router Or Changing Its Settings

    Printer Cannot Be Used After Replacing Wireless Router or Changing Its Settings When you replace a wireless router, redo the network setup for the printer. • For Windows: Perform setup using the Setup CD-ROM or from the web page. • For Mac OS: Perform setup from the web page.
  • Page 461 If filtering MAC addresses or IP addresses at wireless router, check that MAC Check2 addresses or IP addresses for computer, network device, and printer are registered. If using WPA/WPA2 or WEP key, make sure encryption key for computer, Check3 network device, and printer matches key set for wireless router. Not only the WEP key itself, but also the key length, key format, the key ID to use, and the authentication method must be the same for the printer, the wireless router, and the computer.
  • Page 462: Other Network Problems

    Other Network Problems Checking Network Information Restoring to Factory Defaults...
  • Page 463: Checking Network Information

    • Print the network settings. Printing Network Settings For Windows, you can check the network setting information on the computer screen. Canon IJ Network Device Setup Utility Screen You can display the printer's MAC address on the touch screen. System information Checking Computer IP Address or MAC Address To check the IP Address or MAC address of your computer, follow the instructions below.
  • Page 464 Make sure Wi-Fi is selected as network interface. 3. Check the IP address or MAC address. Click TCP/IP to check the IP address. Click Hardware to check the MAC address. Checking Communication Between the Computer, the Printer, and the Wireless Router Perform a ping test to check if communication is taking place.
  • Page 465 3 packets transmitted, 3 packets received, 0% packet loss If packet loss is 100%, communication is not taking place. Otherwise, computer is communicating with target device. Checking Network Setting Information To check the printer's network settings information, print out the network settings information or use the operation panel to display it.
  • Page 466: Restoring To Factory Defaults

    Restoring to Factory Defaults Important • For Windows: Initialization erases all network settings on the printer, making printing, scanning, or faxing operation from a computer over a network impossible. To use the printer over a network again after restoring it to the factory defaults, redo setup using the Setup CD-ROM or from the web page.
  • Page 467: Printing Problems

    Printing Problems Printing Does Not Start No Ink Comes Out Paper Does Not Feed Properly/"No Paper" Error Print Results Are Unsatisfactory...
  • Page 468: Printing Does Not Start

    Printing Does Not Start Make sure printer is securely plugged in and press ON button to turn it on. Check1 The ON lamp flashes while the printer is initializing. Wait until the ON lamp stops flashing and remains lit. Note •...
  • Page 469 The printer will not print properly if you are using a printer driver for a different printer. • For Windows: Make sure "Canon XXX series" (where "XXX" is your printer's name) is selected in the Print dialog box. Note • To make the printer the one selected by default, select Set as Default Printer.
  • Page 470: No Ink Comes Out

    24 hours later. • If problem is not resolved after performing print head deep cleaning twice: If print head deep cleaning does not resolve the problem, the print head may be damaged. Contact your nearest Canon service center to request a repair.
  • Page 471: Paper Does Not Feed Properly/"no Paper" Error

    Paper Does Not Feed Properly/"No Paper" Error Make sure paper is loaded. Check1 Loading Paper When loading paper, consider the following. Check2 • When loading two or more sheets of paper, align the edges of the sheets before loading the paper. •...
  • Page 472 If the paper tears in the rear tray, see List of Support Code for Error (Paper Jams) to remove it. If there are any foreign objects in the rear tray, be sure to turn off the printer, unplug it from the power supply, then remove the foreign object.
  • Page 473 Are transport unit cover and rear cover attached properly? Check9 Rear View for the positions of the transport unit cover and the rear cover. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
  • Page 474: Print Results Are Unsatisfactory

    Print Results Are Unsatisfactory If the print results are unsatisfactory due to white streaks, misaligned lines, or uneven colors, check the paper and print quality settings first. Do page size and media type settings match size and type of loaded paper? Check1 If these settings do not match, it is not possible to obtain the proper result.
  • Page 475 See also the sections below: Paper Is Blank/Printing Is Blurry/Colors Are Wrong/White Streaks Appear Lines Are Misaligned Paper Is Smudged / Printed Surface Is Scratched Cannot Complete Printing Vertical Line Next to Image Part of Page Is Not Printed (Windows) Lines Incomplete or Missing (Windows) Images Incomplete or Missing (Windows) Ink Blots / Paper Curl...
  • Page 476: Paper Is Blank/printing Is Blurry/colors Are Wrong/white Streaks Appear

    Paper Is Blank/Printing Is Blurry/Colors Are Wrong/White Streaks Appear Printing Is Blurry Colors Are Wrong...
  • Page 477 White Streaks Appear Check paper and print quality settings. Check1 Print Results Are Unsatisfactory Check status of ink tanks. Replace ink tank if ink has run out. Check2 Replacing Ink Tanks Is orange tape or protective film still on ink tank? Check3 Make sure all the protective film is peeled off to expose the Y-shaped air hole, as shown below (A).
  • Page 478 • If problem is not resolved after performing print head deep cleaning twice: If print head deep cleaning does not resolve the problem, the print head may be damaged. Contact your nearest Canon service center to request a repair. When using paper with one printable surface, check the correct printable side Check5 of the paper.
  • Page 479: Lines Are Misaligned

    Lines Are Misaligned Check paper and print quality settings. Check1 Print Results Are Unsatisfactory Perform print head alignment. Check2 If printed lines are misaligned or print results are otherwise unsatisfactory, adjust the print head position. Aligning the Print Head Note •...
  • Page 480: Paper Is Smudged / Printed Surface Is Scratched

    Paper Is Smudged / Printed Surface Is Scratched Paper Is Smudged Smudged Edges Smudged Surface Printed Surface Is Scratched Check paper and print quality settings. Check1 Print Results Are Unsatisfactory Check paper type. Check2 Make sure you are using the right paper for what you are printing. Supported Media Types Correct curl before loading paper.
  • Page 481 1. Roll up paper in opposite direction to paper curl as shown below. 2. Check that paper is now flat. We recommend printing curl-corrected paper one sheet at a time. Note • Depending on paper type, the paper may smudge or may not feed properly even if it is not curled inward. Follow the instructions below to curl the paper outward up to 0.1 inch / 3 mm (B) in height before printing.
  • Page 482 Opening Printer Driver's Setup Screen 3. Click Maintenance tab and Custom Settings. 4. Select Prevent paper abrasion check box and click OK. ◦ For Mac OS: Adjust the setting to prevent paper abrasion from Remote UI. Opening Remote UI for Maintenance If intensity is set high, reduce intensity setting and try printing again.
  • Page 483 Set longer ink drying time. Check10 This allows the printed surface to dry, preventing smudges and scratches. • For Windows: 1. Make sure printer is turned on. 2. Open printer driver setup window. Opening Printer Driver's Setup Screen 3. Click Maintenance tab and Custom Settings. 4.
  • Page 484: Vertical Line Next To Image

    Vertical Line Next to Image Is loaded paper size correct? Check If the loaded paper is larger than the size you specified, a vertical line may appear in the margin. Set the paper size to match the loaded paper. Print Results Are Unsatisfactory Note •...
  • Page 485: Scanning Problems (windows)

    Scanning Problems (Windows) Scanning Problems...
  • Page 486: Scanning Problems

    Scanning Problems Scanner Does Not Work ScanGear (Scanner Driver) Does Not Start...
  • Page 487: Scanner Does Not Work

    Scanner Does Not Work Make sure that your scanner or printer is turned on. Check 1 Connect the USB cable to a different USB port on the computer. Check 2 If the USB cable is connected to a USB hub, remove it from the USB hub and Check 3 connect it to a USB port on the computer.
  • Page 488: Scangear (scanner Driver) Does Not Start

    ScanGear (Scanner Driver) Does Not Start Make sure MP Drivers is installed. Check 1 If not installed, install MP Drivers from the Setup CD-ROM or our website. Select your scanner or printer on the application's menu. Check 2 Important • If your scanner or printer name is displayed multiple times, select the one that does not include WIA. Note •...
  • Page 489: Faxing Problems

    Faxing Problems Problems Sending Faxes Problems Receiving Faxes Telephone Problems...
  • Page 490: Problems Sending Faxes

    Problems Sending Faxes Cannot Send a Fax Errors Often Occur When You Send a Fax...
  • Page 491: Cannot Send A Fax

    Cannot Send a Fax Is power turned on? Check1 • You cannot send faxes if the power is turned off. Press the ON button to turn the power on. • If you unplugged the power cord without turning off the power (the ON lamp is lit), reconnecting it turns on the power automatically.
  • Page 492 FAX settings Is Dial tone detect set to ON? Check6 Resend the fax after a while. If you still cannot send the fax, select OFF for Dial tone detect in Advanced FAX settings under FAX settings. FAX settings Is fax number registered correctly in printer's directory? Check7 Check the recipient's fax/telephone number, correct the fax/telephone number registered in the printer's directory, and then send the document again.
  • Page 493 If the telephone line is connected correctly, there is a problem with your telephone line. Contact your telephone company and the manufacturer of your terminal adapter or telephone adapter.
  • Page 494: Errors Often Occur When You Send A Fax

    Errors Often Occur When You Send a Fax Check telephone line condition or connection. Check If errors occur frequently when using an Internet telephone, it is possible that they can be reduced by selecting Reduce for Error reduction setting (VoIP) on Advanced FAX settings under FAX settings. For details, see Error reduction setting (VoIP).
  • Page 495: Problems Receiving Faxes

    Problems Receiving Faxes Cannot Receive a Fax, Cannot Print a Fax Quality of Received Fax is Poor...
  • Page 496: Cannot Receive A Fax, Cannot Print A Fax

    Cannot Receive a Fax, Cannot Print a Fax Is the power turned on? Check1 • You cannot receive faxes if the power is turned off. Press the ON button to turn the power on. • If you unplugged the power cord without turning off the power (the ON lamp is lit), reconnecting it turns on the power automatically.
  • Page 497 Is telephone line cable connected to external device jack? Check4 Reconnect it to the telephone line jack. Connecting Telephone Line Is a different size of paper from that specified by Page size in FAX paper Check5 settings loaded? If a different size of paper from that specified by Page size is loaded for printing faxes, the received faxes will not be printed and will be stored in the printer's memory (Memory Reception).
  • Page 498 For details on how to set, see Rejecting Fax Reception. Are there setting items set Reject in Caller rejection? Check10 If you select Reject for any setting items in Caller rejection in Security control under FAX settings, the printer rejects calls for setting item selected Reject. For details on how to set, see Using Caller ID Service to Reject Calls.
  • Page 499: Quality Of Received Fax Is Poor

    Quality of Received Fax is Poor Check scan settings of sender's fax device. Check1 Ask the sender to adjust the scan settings of the fax device. Is ECM RX set to OFF? Check2 Select ON for ECM RX in Adv. communication settings in Advanced FAX settings under FAX settings. If ECM RX is enabled, the sender's fax device resends the fax after correcting errors automatically.
  • Page 500: Telephone Problems

    Telephone Problems Cannot Dial Telephone Disconnects During a Call...
  • Page 501: Cannot Dial

    Cannot Dial Is telephone line cable connected correctly? Check1 Check that the telephone line cable is connected correctly. Connecting Telephone Line Is telephone line type of printer or external device set correctly? Check2 Check the telephone line type setting and change it as necessary. Setting Telephone Line Type...
  • Page 502: Telephone Disconnects During A Call

    Telephone Disconnects During a Call Is telephone line cable or telephone (or a peripheral device such as an external Check telephone, an answering machine, or a computer modem) connected correctly? Check that the telephone line cable and the telephone (or a peripheral device such as an external telephone, an answering machine, or a computer modem) are connected correctly.
  • Page 503: Mechanical Problems

    Mechanical Problems Power Does Not Come On Power Shuts Off By Itself USB Connection Problems Cannot Communicate with Printer via USB Touch Screen Shows Wrong Language...
  • Page 504: Power Does Not Come On

    Make sure power plug is securely connected to printer, and then turn it back on. Check2 Unplug printer, leave it for at least 2 minutes, and then plug it back in and turn it Check3 on again. If this does not solve the problem, contact your nearest Canon service center to request a repair.
  • Page 505: Power Shuts Off By Itself

    The setting to shut off the power automatically is disabled. • To disable the setting from the computer: For Windows, use Canon IJ Printer Assistant Tool or ScanGear (scanner driver) to disable the setting. Follow the procedure below to disable the setting using Canon IJ Printer Assistant Tool.
  • Page 506: Usb Connection Problems

    USB Connection Problems Printing or Scanning Is Slow/Hi-Speed USB Connection Does Not Work/"This device can perform faster" Message Appears (Windows) If your system environment does not support Hi-Speed USB, the printer operates at the slower speed of USB 1.1. In this case, the printer works properly but printing or scanning speed may slow down due to the communication speed.
  • Page 507: Cannot Communicate With Printer Via Usb

    Cannot Communicate with Printer via USB Make sure printer is turned on. Check1 Connect USB cable properly. Check2 As the illustration below, the USB port is at the back of the printer. Important • Connect the "Type-B" terminal to the printer with the notched side facing RIGHT. For details, refer to the instruction manual supplied with the USB cable.
  • Page 508: Installation And Download Problems

    Installation and Download Problems Cannot Install MP Drivers (Windows) Updating MP Drivers in Network Environment (Windows)
  • Page 509: Cannot Install Mp Drivers (windows)

    CD-ROM icon in the window that appears. If the contents of the CD-ROM appear, double-click MSETUP4.EXE. If you cannot install the MP Drivers with the Setup CD-ROM, install them from the Canon website. Note • If the CD-ROM icon does not appear, try the following: •...
  • Page 510 MP Drivers. Deleting the Unnecessary MP Drivers Reinstall the MP Drivers with the Setup CD-ROM or install them from the Canon website. Note • If the installer was stopped due to a Windows error, Windows operation may be unstable, and you...
  • Page 511: Updating Mp Drivers In Network Environment (windows)

    Updating MP Drivers in Network Environment (Windows) Download the latest MP Drivers. Download the latest MP Drivers for your model on the download page of the Canon website. Uninstall the existing MP Drivers and follow the installation instructions to install the latest MP Drivers that you downloaded.
  • Page 512: Errors And Messages

    Errors and Messages An Error Occurs Message (Support Code) Appears...
  • Page 513: An Error Occurs

    An Error Occurs If an error occurs in printing, for example if the paper runs out or jams, an error message appears on the computer screen and the touch screen. When a Support Code and a message are displayed on the computer screen (Windows): When a Support Code and a message are displayed on the touch screen: A support code and action for the error appears on the touch screen.
  • Page 514: Message (support Code) Appears

    Message (Support Code) Appears This section describes some of the errors and messages that may appear. Note • A support code (error number) is displayed on the computer for some errors. For details on errors that have support code, see List of Support Code for Error.
  • Page 515 After selecting OK, the list of the faxes deleted from the printer's memory (MEMORY CLEAR REPORT) will be printed. For details, refer to Summary of Reports and Lists. • Cannot connect to the server. Please wait a while and try again. The printer cannot connect to the server due to a communication error.
  • Page 516 Check3 Uninstall the MP Drivers following the procedure described in Deleting the Unnecessary MP Drivers and reinstall them from the Setup CD-ROM or the Canon website. When printer is connected to your computer with a USB cable, check device Check4 status from your computer.
  • Page 517 Inkjet Printer/Scanner/Fax Extended Survey Program Screen Is Displayed (Windows) If the Inkjet Printer/Scanner/Fax Extended Survey Program is installed, a screen appears asking for permission to send the printer and application usage information every month for about ten years. Read the information on the screen and follow the instructions below. •...
  • Page 518 If you are logged in on an account with administrator privileges, follow the on-screen instructions. 2. Select Canon Inkjet Printer/Scanner/Fax Extended Survey Program. 3. Select Change. If you select Yes after you have followed the on-screen instructions, the confirmation screen will appear at the time of the next survey.
  • Page 519 • If you agree to participate in survey program: Click Agree and follow the on-screen instructions. The printer usage information is sent via the Internet. Once you have completed the procedure, the information is subsequently sent automatically and the confirmation screen does not reappear. Note •...
  • Page 520 2. Select Applications from Go menu of Finder, double-click the Canon Utilities folder and Inkjet Extended Survey Program folder. 3. Move Canon Inkjet Printer/Scanner/Fax Extended Survey Program.app to Trash. 4. Restart computer. Empty Trash and restart your computer. • Changing setting: To display the confirmation screen every time the printer usage information is sent or to resume surveying, follow the procedure below.
  • Page 521: List Of Support Code For Error

    List of Support Code for Error Support code appears on the touch screen and your computer screen when errors occur. A "support code" is an error number, and appears along with an error message. When an error occurs, check the support code displayed on the touch screen and computer screen and take the appropriate action in response.
  • Page 522 • 6000 to 6ZZZ 6000 6001 6004 6500 6502 6800 6801 6830 6831 6832 6833 6900 6901 6902 6910 6911 6930 6931 6932 6933 6936 6937 6938 6939 693A 6940 6941 6942 6943 6944 6945 6946 6951 6A80 6A81 • 8000 to 8ZZZ 8300 •...
  • Page 523: List Of Support Code For Error (paper Jams)

    List of Support Code for Error (Paper Jams) If paper jams, remove it following the appropriate procedure as shown below. • If you can see the jammed paper at the paper output slot or the rear tray: ◦ If the paper fed from the rear tray is jammed: 1300 •...
  • Page 524 1300 Cause Paper is jammed when feeding paper from rear tray. What to Do If the paper fed from the rear tray is jammed, remove the jammed paper from the paper output slot or from the rear tray following the instructions below. Important •...
  • Page 525 • We recommend using paper sizes other than A5 to print documents with photos or graphics. A5 paper may curl and jam as it leaves the printer. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
  • Page 526 1303 Cause Paper is jammed when feeding paper from cassette. What to Do 1. Remove jammed paper. • If the paper is jammed at the paper output slot: 1300 • If the paper is jammed inside the printer: Paper Is Jammed inside Printer •...
  • Page 527 2. Press down lock (B) on cassette. 3. Pull cassette back and forth while holding down lock (B). Loading Paper in the Cassette 2. Perform printing or copying again.
  • Page 528 1304 Cause Paper is jammed when performing automatic duplex printing. What to Do 1. Remove jammed paper. • If the paper is jammed at the paper output slot: 1300 • If the paper is jammed inside the printer: Paper Is Jammed inside Printer •...
  • Page 529 2. Press down lock (B) on cassette. 3. Pull cassette back and forth while holding down lock (B). Loading Paper in the Cassette 2. Perform printing or copying again.
  • Page 530 1313 Cause Paper is jammed as printer pulled in printed paper. What to Do If the paper is jammed as the printer pulled in the printed paper, try to remove the paper from the following locations. • Paper output slot 1300 •...
  • Page 531: Paper Is Jammed Inside Printer

    Paper Is Jammed inside Printer If the jammed paper tears and you cannot remove the paper from the paper output slot, or if the jammed paper remains inside the printer, remove the paper following the instructions below. Important • The printer cannot be turned off while it is sending or receiving a fax, or when the received fax or the unsent fax is stored in the printer's memory.
  • Page 532 3. Check if jammed paper is under print head holder. If the jammed paper is under the print head holder, move the print head holder to the far right or left, whichever makes it easier to remove the paper. When moving the print head holder, hold the top of the print head holder and slide it slowly to the far right or left.
  • Page 533 Check the printer again for any remaining bits of paper. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
  • Page 534: Removing Jammed Paper From Rear Side

    Removing Jammed Paper from Rear Side Important • The printer cannot be turned off while it is sending or receiving a fax, or when the received fax or the unsent fax is stored in the printer's memory. Turn off the printer after making sure it has completed sending or receiving all the faxes. Do not unplug when turning off the printer.
  • Page 535 4. Slowly pull out paper. Note • Do not touch the inner parts of the printer. If you were not able to remove the paper in this step, detach the transport unit cover and remove the paper by following these steps. 1.
  • Page 536 2. Slowly pull out paper. Note • Do not touch the inner parts of the printer. 3. Make sure all jammed paper is removed. 4. Attach transport unit cover. Insert the transport unit cover slowly all the way into printer and take down the transport unit cover.
  • Page 537 Insert the projections of the right side of the rear cover into the printer, and then push the left side of the rear cover until it is closed completely. If the measures above do not solve the problem, contact your nearest Canon service center to request a repair.
  • Page 538 1000 Cause Possible causes include the following. • There is no paper in the rear tray. • Paper is not loaded in the rear tray properly. What to Do Take the corresponding actions below. • Load paper in the rear tray. •...
  • Page 539 1003 Cause Possible causes include the following. • There is no paper in the cassette. • Paper is not loaded in the cassette properly. What to Do Take the corresponding actions below. • Load paper in the cassette. • Align the paper guides with the both edges of the paper when you load paper in the cassette. •...
  • Page 540 1200 Cause Scanning unit/cover is open. What to Do Close the scanning unit / cover and wait for a while. Do not close it while you are replacing an ink tank.
  • Page 541 What to Do Turn off the printer and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • If you unplug the power cord, all the faxes stored in the printer's memory are deleted.
  • Page 542 1600 Cause Ink may have run out. What to Do Replacing the ink tank is recommended. If printing is in progress and you want to continue printing, tap OK on the printer with the ink tank installed. Then printing can continue. Replacing the ink tank is recommended after the printing. The printer may be damaged if printing is continued under the ink out condition.
  • Page 543 1660 Cause The ink tank cannot be recognized. What to Do Printing cannot be performed because the ink tank is not installed or is not compatible with this printer. Check the ink tank. If you want to cancel printing, press the printer's Stop button.
  • Page 544 With this operation, disabling the function for detecting the remaining ink level is memorized. Please be advised that Canon shall not be liable for any malfunction or trouble which may be caused by continuation of printing under the ink out condition.
  • Page 545 With this operation, disabling the function for detecting the remaining ink level is memorized. Please be advised that Canon shall not be liable for any malfunction or trouble caused by continuation of printing under the ink out condition or by using refilled ink tanks.
  • Page 546 Cause Ink absorber is almost full. What to Do Select OK on the touch screen to continue printing. Contact your nearest Canon service center to request a repair. Important • If you unplug the power cord, all the faxes stored in the printer's memory are deleted.
  • Page 547 Open the scanning unit / cover and make sure the tape for securing the print head holder during transportation has been removed. If the tape is still there, remove it and close the scanning unit / cover. If this does not solve the problem, contact your nearest Canon service center to request a repair.
  • Page 548 2110 Cause Paper settings for printing or copying do not match cassette paper information set on printer. Note • See below for the correct correspondence between paper settings made on the printer driver or on the touch screen. Paper Settings on the Printer Driver and the Printer (Media Type) (Windows) Paper Settings on the Printer Driver and the Printer (Paper Size) (Windows)
  • Page 549 What to Do Select OK on the touch screen again to display the screen below. Select the appropriate action. Note • Depending on settings, some of the options below may not appear. Print with the loaded paper. Select this option to print or copy onto the paper in the cassette without changing the paper settings. For example, if the print or copy paper setting is A5, and cassette paper information is set to A4, the A5 size setting is used to print or copy onto the paper in the cassette.
  • Page 550 • To change the message view setting when printing or copying using the operation panel of the printer: Feed settings • To change the message view setting when printing using the printer driver: Changing the Printer Operation Mode (Windows) Changing the Printer Operation Mode (Mac OS)
  • Page 551 2900 Cause Scanning print head alignment sheet failed. What to Do Select OK on the printer's touch screen and check the following. • Make sure the print head alignment sheet is set in the correct position and orientation on the platen glass.
  • Page 552 2901 Cause Print head alignment pattern has been printed and printer is waiting to scan sheet. What to Do Scan the printed alignment pattern. 1. Load print head alignment sheet on platen glass. Place the printed side down and align the mark in the bottom right corner of the sheet with the alignment mark 2.
  • Page 553 4103 Cause Cannot perform printing with current print settings. What to Do Press the printer's Stop button to cancel printing. Then change the print settings and retry printing.
  • Page 554 Turn off printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • If you unplug the power cord, all the faxes stored in the printer's memory are deleted.
  • Page 555 Turn off printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • If you unplug the power cord, all the faxes stored in the printer's memory are deleted.
  • Page 556 Press ink tanks until they click into place. Turn the printer back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • When clearing an impediment to print head holder motion, be careful not to touch white belt (A).
  • Page 557 Turn off printer and unplug it. After a while, plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • If you unplug the power cord, all the faxes stored in the printer's memory are deleted.
  • Page 558 5B00 Cause Printer error has occurred. What to Do Contact your nearest Canon service center to request a repair. Important • If you unplug the power cord, all the faxes stored in the printer's memory are deleted. Note • In the case of warnings or errors caused by remaining ink levels, the printer cannot print or scan.
  • Page 559 Turn off printer and unplug it. Plug in the printer again and turn it back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • If you unplug the power cord, all the faxes stored in the printer's memory are deleted.
  • Page 560 Press ink tanks until they click into place. Turn the printer back on. If this does not solve the problem, contact your nearest Canon service center to request a repair. Important • When clearing an impediment to print head holder motion, be careful not to touch white belt (A).
