- Page 1 Grid Solutions F485 Communications Converter Instruction Manual F485 Communications Converter Manual P/N: 1601-0073-A5 GE publication code: GEK-119569A *1601-0073-A5*...
-
Page 2: Revision History
The contents of this manual are the property of GE Multilin Inc. This documentation is furnished on license and may not be reproduced in whole or in part without the permission of GE Multilin. The content of this manual is for informational use only and is subject to change without notice. -
Page 3: Contact Information
Website: http://www.gegridsolutions.com/multilin Warranty For products shipped as of 1 October 2013, GE warrants most of its GE manufactured products for 10 years. For warranty details including any limitations and disclaimers, see our Terms and Conditions at https://www.gegridsolutions.com/multilin/warranty.htm For products shipped before 1 October 2013, the standard 24-month warranty applies. -
Page 4: Typical Configurations
Typical Configurations Figure 1: RS232 to RS485 connection F485 COMMUNICATIONS CONVERTER – INSTRUCTION MANUAL... - Page 5 Figure 2: RS232 to FIBER and FIBER to RS485 F485 COMMUNICATIONS CONVERTER – INSTRUCTION MANUAL...
-
Page 6: Order Code
Order code Connections Figure 3: Connections F485 COMMUNICATIONS CONVERTER – INSTRUCTION MANUAL... -
Page 7: Baud Rates
Two-wire RS485 is half duplex and requires a means for switching between a receive or transmit state. The F485 converter uses the incoming data to control the direction and therefore requires no control signals from the master device (RS232 or fiber) to switch from transmit to receive mode after the last character has been transmitted. -
Page 8: Dte/Dce Control
DCE should be selected. Another application which requires DCE is when two F485 converters are connected back-to-back i.e. converting RS232 to RS485 or fiber and then converting the RS485 or fiber back to RS232. In this case, the second F485 must be set to DCE control. - Page 9 Wiring Figure 4: Wiring diagram F485 COMMUNICATIONS CONVERTER – INSTRUCTION MANUAL...
- Page 10 Dimensions Figure 5: Dimensions F485 COMMUNICATIONS CONVERTER – INSTRUCTION MANUAL...
