INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
W797 / W798SS
Model Numbers/ No. de Modelos:
PORTABLE WASHER
LAVADORA PORTATIL
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página 23.
Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications
without notice.
Avanti Products, A Division of the Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 331 52
www.avantiproducts.com
Advertisement
Table of Contents
Related Manuals for Avanti W797
Summary of Contents for Avanti W797
-
Page 1: Instruction Manual
INSTRUCTIONS. La sección en español empieza en la página 23. Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of the Mackle Co., Inc. -
Page 2: Registration Information
P.O. Box 520604 - Miami, Florida 33152 USA Protect your product: We will keep the model number and date of purchase of your new Avanti product on file to help you refer to this information in the event of an insurance claim such as fire or theft. -
Page 4: Help Us Help You
Keep it handy to answer your questions. If you don't understand something or you need more assistance, please call: Avanti Customer Service 800-220-5570 Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period. -
Page 5: Table Of Contents
AUTOMATIC WASH PROGRAMS MANUAL FUNCTIONS FUNCTIONS DELAY START SETTING CHILDREN-PROOF SETTINGS CARE AND MAINTENANCE CLEANING YOUR PORTABLE WASHER TROUBLESHOOTING GUIDE SERVICE FOR YOUR PORTABLE WASHER YOUR AVANTI PRODUCTS WARRANTY WIRING DIAGRAM INSTRUCCIONES EN ESP AÑOL T ABLE OF CONTENTS 22~30... -
Page 6: Parts & Features
PARTS & FEATURES 1. DETERGENT CASE 2. SOFTENER DISPENSER 3. INNER TUB 4. CONTROL PANEL 5. BASE 6. NOISE PROOF PLATE 7. INLET HOSE (2 PCS) 8. LINT FILTER 9. PULSATOR 10. POWER SUPPLY CORD 11. DRAIN HOSE (1 PC) 12. -
Page 7: Important Safety Instructions
Do not reach into the washer if the agitator or inner tub is moving. Do not tamper with controls. Do not repair or replace any part of the washer o r attempt any servicing unless specifically recommended in the user -maintenance instructions or in published user -repair instructions. -
Page 8: Selecting A Location
Put your laundry into the washer evenly. Uneven laundry may cause noise or vibration. Don’t use excessively hot water (50°C or more). Plastic parts may be deformed or damaged. Also, clothing may be deformed or bleached. Before washing, check all pockets. If nails or pins remain in pockets, they may damage the washer or clothes. -
Page 9: Installing The Noise Proof Plate
INSTALLING THE NOISE PROOF PLATE The opening of the Take the noise proof plate out of the noise proof plate is at the bottom of package . the machine. Insert the noise proof Lay down the machine and secure the noise proof plate into the washing plate by fastening the two machine base. -
Page 10: Connecting The Water Supply Hose
CONNECTING THE WATER SUPPLY HOSE The water supply hose must be connected to the washing machine at one end and to the water faucet at the other. Do not stretch the water supply hose. If the hose is too short and you do not wish to move the water faucet, replace the hose with a longer, high-pressure hose. -
Page 11: Water Connection
Make sure the rubber ring is inserted and connect to your sink. If water leaks from faucet connection or washer connection, turn off water and tighten fully using a wrench. Be careful not to over tighten and damage water connection. -
Page 12: Electrical Connection
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by an authorized Avanti Products service center. This portable washer should be properly grounded for your safety. The power cord of this portable washer is equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock. -
Page 13: Operating Your Portable Washer
When washing very large articles, do not fill inner tub as full as with other loads. The water level in your washer should fit the size of your wash load. Small load will use lower water levels. There must be enough water in the inner tub to allow articles to move and turn over freely. Overloading the inner tub can result in poor washing and rinsing. -
Page 14: Operation Instructions
When the cold-water indicator and the hot - water indicator turn on simultaneously, which means you chose the warm water. NOTE: The washer will provide a cold rinse in all TEMPERATURE settings. IMPORTANT: A single cold hose system does not allow the washing machine to automatically (select) regulate incoming water temperatures to match those listed on the control panel such as WARM or HOT. - Page 15 SOAK – For dirty laundry Press down the power button. Press the functions button to select the SOAK function until the SOAK indicator is ON. Press the water supply button to select the water temperature. Press the water level button to select the appropriate water level setting. Press the START/HOLD to start the course.
-
Page 16: Manual Functions
MANUAL FUNCTIONS WASH ONLY Press down the power button. Press the functions button to select the appropriate program. Press the water supply button to select the water temperature. Press the water level button to select the appropriate water level setting. Press the wash button to select the wash time. -
Page 17: Delay Start Setting
CARE AND MAINTENANCE CLEANING YOUR PORTABLE WASHER Clean the surface of your portable washer regularly with soft fabric. Clean the inner tub regularly, especially immediately after starch or bleach operation. Clean the filter in the inlet valve or inlet hose regularly in order to prevent it from clogging. - Page 18 Clean the lint filter. Pull upward to remove the lint filter. Vacation time Clean and rinse it thoroughly.
-
Page 19: Troubleshooting Guide
PROBLEMS WITH YOUR PORTABLE WASHER? You can solve many common portable washer problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. TROUBLESHOOTING GUIDE PROBLEM Washer does not operate. -
Page 20: Service For Your Portable Washer
We are proud of our customer service organization an d the network of professional service technicians that provide service on your Avanti portable washers. With the purchase of your Avanti portable washer, you can be confident that if you ever need additional information or assistance, the Avanti Products Customer Service Team will be here for you. -
Page 21: Your Avanti Products Warranty
LIMITED ONE-YEAR WARRANTY For one year from the date of purchase by the original owner, Avanti Products will, at its option, repair or replace any part of the appliance that proves to be defective in material or workmanship under normal use. -
Page 22: Wiring Diagram
WIRING DIAGRAM... -
Page 23: Instrucciones En Español
INSTRUCCIONES EN ESPAÑOL LAVADORA AUTOMATICA DE ROPA LEA TODAS LAS INSTRUCCIONES ANTES DE USAR ESTA LAVADORA Y GUARDE ESTE MANUAL EN UN LUGAR SEGURO PARA REFERENCIA FUTURA. CONOCIENDO LAS PARTES DE SU LAVADORA AUTOMATICA 1. DISPENSADOR DEL DETERGENTE 2. DISPENSADOR DEL SUAVIZANTE DE ROPA 3. - Page 24 DEL ENCHUFE (CONEXION A TIERRA). DIRIJA CUALQUIER PREGUNTA RELACIONADA CON LA ELECTRICIDAD O CONEXION A TIERRA A UN ELECTRICISTA CERTIFICADO O A UN CENTRO DE SERVICIO AUTORIZADO POR AVANTI. SELECCIONE UN LUGAR ANTES DE INSTALAR SU LAVADORA, SELECCIONE UN LUGAR CON LAS SIGUIENTES CARACTERISTICAS: ? SUPERFICIE PLANA Y DURA (SI LA SUPERFICIE ES IRREGULAR, VEA "AJUSTE DE...
- Page 25 AJUSTE DE PATAS NIVELADORAS SI EL PISO ES IRREGULAR, AJUSTE LAS PATAS (NO INSERTE PEDAZOS DE MADERA U OTROS OBJETOS BAJO LAS PATAS). DESENROSQUE EL TORNILLO GIRANDOLO CON LA MANO HASTA QUE LLEGUE A LA ALTURA DESEADA. AJUSTE LA TUERCA CON LA LLAVE INGLESA. COLOQUE LA LAVADORA EN UNA SUPERFICIE PLANA Y FIRME.
- Page 26 EL USO INAPROPIADO DEL ENCHUFE ELECTRICO PUEDE RESULTAR EN UN CORTO CIRCUITO. SI EL CORDON ESTA DAÑADO, REEMPLACELO EN UN CENTRO DE SERVICIO AUTORIZADO POR AVANTI PRODUCTS. PARA SU SEGURIDAD, ESTA LAVADORA PORTATIL DEBE SER CONECTADA A TIERRA. EL CORDON ELECTRICO ESTA EQUIPADO CON UN ENCHUFE DE TRES PUNTAS, PARA SER USADO EN LOS ENCHUFES DE PARED CON CONEXION A TIERRA ESTANDAR, MINIMI ZANDO LA POSIBILIDAD DE CHOQUE ELECTRICO.
- Page 27 MANGUERA CON UNA MAS LARGA, DE ALTA PRESION. SELECCIONE EL GRIFO ADECUADO TAL COMO SE MUESTRA EN LAS FIGURAS ABAJO. SI NINGUNO DE ESTOS GRIFOS ESTA DISPONIBLE, USE EL ADAPTADOR INCLUIDO. EL LARGO DEL GRIFO DEBE SER DE MAS DE 10 MM (0.4”), DE OTRA MANERA EL CONECTOR NO PODRA SER AJUSTADO APROPIADAMENTE Y PODRIA PRODUCIR GOTEO.
- Page 28 4. RETIRE LAS MANGUERAS GIRANDO LAS TUERCAS DEL CONECTOR HACIA LA IZQUIERDA SI LA LAVADORA ES USADA FRECUENTEMENTE, NO RETIRE LAS CONEXIONES PARA EVITAR POSIBLES DAÑOS. COLOCANDO LA MANGUERA DE DRENAJE CONECTE LA MANGUERA DE DRENAJE A LA SALIDA DE AGUA DE LA LAVADORA Y AJUSTELA CON UNA GRAMPA AJUSTABLE.
- Page 29 FUNCION (FUNCTION): PRESIONE EL BOTON FUNCTION HASTA QUE SE ILUMINE LA FUNCION DESEADA. INICIAR / DETENER (START/STOP): PRESIONE EL BOTON START/STOP UNA VEZ PARA INICIAR EL FUNCIONAMIENTO. PARA DETENERLO, PRESIONE START/STOP NUEVAMENTE. SI CONTINUA FUNCIONANDO, PRESIONELO OTRA VEZ. EL NIVEL DE AGUA PUEDE SER MODIFICADO DURANTE LA OPERACIÓN. SI DESEA UN NIVEL MAS ALTO DE AGUA, LA LAVADORA EMPEZARA A FUNCIONAR UNA VEZ QUE HAYA LLEGADO AL NIVEL DE AGUA DESEADO.
- Page 30 ? NO AÑADA DETERGENTE PARA EL CICLO DE ENJUAGUE Y DESAGÜE. ? SI DESEA BOTAR EL AGUA DURANTE EL CICLO DE LAVADO, PRESIONE EL BOTON “START/STOP”, LUEGO PRESIONE EL BOTON DE “RINSE”. NUEVAMENTE PRESIONE EL BOTON “START/STOP”. MANTENIMIENTO LIMPIE REGULARM ENTE LA SUPERFICIE DE SU LAVADORA CON UN PAÑO SUAVE. LIMPIE EL CILINDRO INTERNO DE LAVADO CON UN PAÑO SUAVE, ESPECIALMENTE DESPUES DE LAVAR CON ALMIDON O CLORO.
- Page 31 SI TIENE PROBLEMAS CON SU LAVADORA PORTATIL UD. PUEDE RESOLVER MUCHOS PROBLEMAS FACILMENTE, AHORRANDOSE EL COSTO DEL SERVICIO TECNICO. PRUEBE LAS SIGUIENTES SUGERENCIAS PARA VER SI PUEDE RESOLVER LOS PROBLEMAS, ANTES DE LLAMAR AL SERVICIO TECNICO. GUIA PARA LA SOLUCION DE PROBLEMAS PROBLEMA LA LAVADORA NO FUNCIONA NO ENTRA AGUA O EL NIVEL ES MUY BAJO...
