Summary of Contents for Mosebach Bug Killers BK15
-
Page 2: Table Of Contents
Bug Killers Read all instructions before using the bug killer Contents 1) Components ..........................3 Total Assembly ........................... 3 2) Specifications ..........................4 BK10 ............................. 5 BK15 ............................. 5 BK20 ............................. 5 3) Receiving ............................5 4) Safety ............................6 Power connections ....................... -
Page 3: Components
Bug Killers IMPORTANT INSTRUCTIONS 120VAC 240VAC Receptacles 1) Components Receptacle Lifting Handles Air Intake Remote Connection Hot Air Exhaust Mobility Kit (Optional) Figure 1a Figure 1b Total Assembly Bug Killers (BK20 Shown) -
Page 4: Specifications
Bug Killers 2) Specifications Blower 120VAC, single phase, 60Hz powered internally Control power 120VAC, single phase, 60 Hz Rating Continuous duty Power factor Load elements The current at each step is subject to a manufacturing tolerance of ±5%. Electro-statically powder coat, Blue: PPG PCTZ50108 Touch up paint is Pantone 280-c color. -
Page 5: A) Bk10
Bug Killers BK10 Circuit Number Total Voltage (VAC) Current (Amps) Power (kW) 1.57 1.57 1.57 1.57 1.57 1.57 9.36 Table 1a Figure 2a b) BK15 Circuit Number Total Voltage (VAC) Current (Amps) Power (kW) 1.57 1.57 1.57 1.57 3.84 3.84 13.92 Figure 2b Table 1b... -
Page 6: Safety
Bug Killers 4) Safety This bug killer is designed for a variety of loads. Because of this, it is possible that voltages higher that those applied can be present inside the bug killer and at external connections of the bug killer. -
Page 7: A) Power Connections
Bug Killers 16) Always plug bug killers directly into a wall outlet/receptacle. Never use with a re- locatable power tap (outlet/power strip). 17) This bug killer includes a visual alarm to warn that parts of the bug killer are getting excessively hot. -
Page 8: D) Exhaust Temperature
Bug Killers d) Exhaust temperature WARNING! FIRE AND BURN HAZARD. Keep flammable material at least 40 feet away from the bug killer. A great deal of heat is expelled from the bug killer. Temperatures inside the bug killer are sufficient to ignite flammable fumes or materials. -
Page 9: B) Startup And Operation
Bug Killers b) Startup and Operation 1. Connect the 120VAC plug to the right most receptacle to power the controls (See Figure 2. Determine where you will get power from Each plug utilized will draw the current shown in table 1a, 1b, or 1c. Carefully select power sources as to not overload and trip breakers or fuses. -
Page 10: C) Shutdown
This cooling period will extend the life of your bug killer. 3. Turn POWER button OFF 4. Remove all 120VAC plugs and 240VAC plugs (BK15 and BK20 ONLY) from the bug killer. 5. Put cables back into the storage box. (Not supplied by Mosebach) 6. Move the unit to storage. -
Page 11: Bug Killing Conditions
Bug Killers Bug Killing Conditions The conditions below represent the recommended run time once the entire area has become fully heated. Enclosed spaces, such as clothes, beds, couches and drawers may take significantly longer to reach desired temperatures than exposed surfaces in the space being heated. -
Page 12: Replacing Fuses
Bug Killers OTS Open @ 150°F Figure 5. Thermal Switch Replacing Fuses Turn the fuse holder cap counter clockwise and pull the cap with the fuse attach out of the panel. Replace fuse with appropriate fuse size as shown on the fuse panel overlay. Insert fuse cap into appropriate hole and twist clockwise to lock in place. -
Page 13: Replacing Resistors
Bug Killers Replacing Resistors Consult Mosebach Manufacturing Co. 10) Preventative Maintenance of the Bug killer 1. Do not use a power washer to clean off the exterior of the unit. It is high voltage electrical equipment. Component Action Frequency Entire Unit... -
Page 14: Faq
Bug Killers 11) FAQ requently sked uestions About BK Heaters (BK10, BK15, and BK20) How many different models of the BK Heater are there? There are (3) different models: the BK10, the BK15, and the BK20. The BK10 has (6) 120V inputs. Each input draws 13A for a total of 79A. The BK15 has (4) 120V inputs and (2) 240V inputs. - Page 15 50 feet and #12 wire for anything above 50ft. For 240 volt, minimum wire size is a #6 for up to 100 feet. For other lengths, please contact Mosebach Manufacturing. What size space can be treated with a BK Heater? Treatment times will vary depending on the type of construction and the conditions of the treatment area, the objects in the treatment area, and the voltage supplied to the unit.
- Page 16 I want to use a generator. What kind of generator do you recommend? For our recommended generator, please refer to the BK Accessories quote. If you have not received an Accessories quote, contact a Mosebach sales representative. I hear a continuous clicking sound, what’s wrong? Clicking means that there is not enough air being moved through the heater.
- Page 17 Lastly, verify the power supply / voltage to the master / control plug is correct. Who can I contact with additional questions? If you have any additional questions or concerns, please contact Mosebach Manufacturing at support@mosebachresistors.com. Please provide the serial number, part number, contact...
-
Page 18: Treatment Suggestions
Bug Killers 12) Treatment Suggestions: Adjustments must be made to treatment procedures for the given conditions in a treatment area. Effective treatment may require larger or multiple heaters depending on the size and conditions of a given treatment area. Correct power must be supplied to the unit. Please refer to the quote for rated voltages and amperages. -
Page 19: Optional Equipment
Bug Killers 13) Optional Equipment Description Part Number CS-BK20 25’ Cable Set CS-BK15 CS-BK10 Mobility Kit MK-1 Hard Protective Case Case-BK 14) Service Parts BK10 BK15 BK20 Part Number BLWR-0055-0023 RA-0400-0031-1 RA-0400-0031-1 RA-0400-0031-1 RA-0400-0031-2 RA-0400-0033-1 RA-0400-0031-2 Resistor RA-0400-0033-2 RA-0400-0031-3 Elements RA-0400-0033-3 RA-0400-0031-4 RA-0400-0033-4... -
Page 20: Save These Instructions
ECN 3494 – Added FAQ and Treatment suggestions section 4/13/16 Rev. Description Rev. By Date Copyright © 2013 Mosebach Manufacturing Company MOSEBACH MANUFACTURING COMPANY 1417 McLaughlin Run Road • Pittsburgh, PA 15241-3103 USA T: 412.220.0237 Customer Care F: 412-220-0236 www.mosebachresistors.com OM-BK.doc July 23, 2015...
