FRONT OPERATING PANEL:

2
3
4
1
5
8
Figure 1, Front of Pump
Key Function
7
6
1. POWER ON/OFF BUTTON
2. MODE BUTTON
3. INCREASE BUTTON
4. DECREASE BUTTON
5. LED DISPLAY
6. CHAMBER NUMBER LED
7. RECEPTOR PORTS FOR TUBING LATCH CONNECTORS
PORTS #5-8 PORTS #1-4
Figure 2, Latch Connectors on the ends of the garment tubing
8. AUXILIARY AIR SUPPLY PORT FOR BILATERAL USE (WITH BLOCKER BARS INSTALLED)
Figure 3, Blocker Bars placed on auxiliary ports for single garment use
