Model No. WCTL84090
Serial No.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or find that there are
missing or damaged parts, we
will guarantee you complete sat-
isfaction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-936-4266
Mon.–Fri. 8 am–6:30 pm EST
(excluding holidays)
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
®
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo WCTL84090
Summary of Contents for Weslo WCTL84090
- Page 1 ® Model No. WCTL84090 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete cus- tomer satisfaction. If you have questions, or find that there are missing or damaged parts, we will guarantee you complete sat- isfaction through direct assis- tance from our factory.
-
Page 2: Table Of Contents
® TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 11. Keep the power cord and the surge protec- that all users of this treadmill are adequately tor away from heated surfaces. - Page 4 21. Always unplug the power cord before per- 22. This treadmill is intended for in-home use forming the maintenance and adjustment only. Do not use this treadmill in any com- procedures described in this manual. Never mercial, rental, or institutional setting. remove the motor hood unless instructed to do so by an authorized service representa- SAVE THESE INSTRUCTIONS...
-
Page 5: Before You Begin
The advanced technology with innovative design to offer model number of the treadmill is WCTL84090. The you an excellent form of cardiovascular exercise, in the serial number can be found on a decal attached to the convenience and privacy of your home. -
Page 6: Assembly
ASSEMBLY Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Refer to the drawings below to identify the small parts used in assembly. Assembly requires a standard screwdriver and an adjustable wrench (not included). - Page 7 4. Remove the paper backing from the Adhesive Clip (16). Press the Adhesive Clip onto the Right Endcap (45) in the indicated location. Press the Allen Wrench (41) into the Adhesive Clip. 5. The Console (5) requires two "AA" batteries (not included);...
-
Page 8: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT resistance for electric current to reduce the risk of elec- tric shock. This product is equipped with a cord having Your treadmill features a walking belt coated with an equipment-grounding conductor and a grounding PERFORMANT LUBE , a high-performance lubricant. - Page 9 DIAGRAM OF THE CONSOLE Speed Control Monitor Display Pulse Display Pulse Sensor On/Off Mode Button Button Note: If there is a thin sheet of clear Clip plastic on the face of the console, remove it. Insert the key fully into the power switch. CAUTION: Before operating the Note: The displays will not be activated when the...
- Page 10 Press the mode button to select the desired Measure your pulse, if desired. monitor mode. To use the pulse sensor, stand on the foot rails The monitor features five different modes to and place your thumb on the pulse sensor as provide instant exercise feedback: shown.
-
Page 11: Trouble-Shooting And Maintenance
HOW TO CHANGE THE INCLINE shown in draw- ing 1. Adjust To vary the intensity of your exercise, the incline of the the Incline Leg treadmill can be changed. There are three different to the desired Incline Pin incline settings. Before changing the incline, remove height and fully the key and unplug the power cord. - Page 12 3. SYMPTOM: THE DISPLAYS OF THE CONSOLE DO NOT FUNCTION PROPERLY a. Check the batteries in the console. (See assembly step 5 on page 7). Most problems are the result of drained batteries. 4. SYMPTOM: THE WALKING BELT SLOWS WHEN WALKED ON a.
-
Page 13: Storage
STORAGE Unplug the power cord when the treadmill is not in use. Remove the bolt and nut from the lower end of each handrail. Remove Remove the bolt from the upper end of each handrail. Slide the handrails out of the console housing. Remove Remove the bolt and washer from the lower end of the upright. -
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES You can find your training zone in the table at the left. Training zones are listed according to age and physical WARNING: Before beginning condition. this or any exercise program, consult your physician. This is especially important for Burning Fat individuals over the age of 35 or individuals with pre-existing health problems. - Page 15 EXERCISE FREQUENCY cise, you may complete up to five workouts each week if desired. To maintain or improve your condition, complete three workouts each week, with at least one day of rest The key to success is to make exercise a regular and between workouts.
-
Page 16: Part List
PART LIST—Model No. WCTL84090 R0799A Qty. Description Qty. Description Handrail Rear Roller Potentiometer Rear Roller Adjustment Bolt Cage Nut Ground Wire Console Housing Right Endcap Console Frame Screw Motor Pivot Bolt 3/8” x 1” Bolt Roller Guard Screw 6” Cable Loom... -
Page 17: Exploded Drawing
EXPLODED DRAWING—Model No. WCTL84090 R0799A... -
Page 18: Customer Record
CUSTOMER RECORD Model No.: Serial No.: Retailer Name: Purchase Date: Retailer Address:... -
Page 19: Ordering Replacement Parts
Friday, 8 a.m. until 6:30 p.m. Eastern Standard Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: • The MODEL NUMBER of the product (WCTL84090). • The NAME of the product (WESLO ®... -
Page 20: Limited Warranty
This warranty gives you specific legal rights. You may also have other rights which vary from province to province or so specified by the retailer of your equipment. ICON OF CANADA, 900 de l’Industrie, St. Jérôme, QC J7Y 4B8 WESLO is a registered trademark of ICON Health & Fitness, Inc. ™ ®...
