- Page 1 26 Ward Hill Ave., Bradford, MA 01835 Phone: 978-241-8260 Fax: 978-241-8262 USER MANUAL HPP-1000 thru 6000-XX-YY-ZZ XX= Ioutmax YY = Maximum Compliance Voltage ZZ = Max Pulse Width in µsec 02001346 Rev 1 HPP-1000/6000 User Manual Page 1 of 19...
-
Page 2: Table Of Contents
Figure 4, Pulse Output ......................6 Figure 5, Repetition Rate ....................6 Figure 6, Connection Diagram .................... 8 Figure 7, HPP Mechanical Outline Drawing ..............16 Figure 7, HPP Connections ....................17 02001346 Rev 1 HPP-1000/6000 User Manual Page 2 of 19... -
Page 3: Warnings
The output of the HPP is floating and therefore, neither side of the laser diode is allowed to be connected to the same ground as signal ground (Program, Monitor). WARNING: Only Lumina Power, Inc. qualified service personnel are allowed to remove the covers and service this equipment. -
Page 4: Description Of Hpp System
2. Description of HPP System Lumina Power’s HPP power supplies are designed for pulsing diode lasers in Quasi-CW applications. Before operating this unit, it is important to understand the operation. A block diagram of the power supply is shown below. -
Page 5: Pulsing Characteristics
Output Current. 100Amp/V Channel 2: Pulse Command Signal Channel 3: Current Monitor Figure 3, Typical Fall Time Channel 1: Output Current. 100Amp/V Channel 2: Pulse Command Signal Channel 3: Current Monitor 02001346 Rev 1 HPP-1000/6000 User Manual Page 5 of 19... - Page 6 Output Current. 100Amp/V Channel 2: Pulse Command Signal Channel 3: Current Monitor Figure 5, Repetition Rate Channel 1: Output Current. 100Amp/V Channel 2: Pulse Command Signal Channel 3: Current Monitor 02001346 Rev 1 HPP-1000/6000 User Manual Page 6 of 19...
-
Page 7: Dc Power Supply For Hpp
HPP demand. However, this version has a voltage adjust control input on pin 2 of the control interface to allow the user to match the LDN output voltage to the HPP load requirements. 02001346 Rev 1 HPP-1000/6000 User Manual Page 7 of 19... -
Page 8: Supply Interface Connections
HPP to break the ground loop. Please refer to document 33001346, HPP-LDD Interconnection Instructions. Figure 6, Connection Diagram * Note, the voltage control feedback is only available when using a LDD-3000/6000 with the HP option. 02001346 Rev 1 HPP-1000/6000 User Manual Page 8 of 19... -
Page 9: Ldd/Hpp Integration And Theory Of Operation
6. LDD/HPP integration and theory of operation The HPP was designed to work with Lumina Power’s LDD power supplies with the HP option, which is the output voltage programmable feature. The complete system includes: 1 LDD-pp-xx-yy-HP where pp is max power, xx is max current, yy is max output voltage and HP designates output voltage program feature. - Page 10 Another option is to run the HPP at 100% duty cycle. In this case, we can turn the HPP current program to 105% and control the output current by the LDD. 02001346 Rev 1 HPP-1000/6000 User Manual Page 10 of 19...
-
Page 11: Ldd With Hp Option
Duty Cycle: 500us/400Hz = 20%. Setting on LDD: Vout ~55V I-out = 105% * P/Vload = 1.05 * (2000/50) = 42 Amp. The LDD interface is listed below for reference. 02001346 Rev 1 HPP-1000/6000 User Manual Page 11 of 19... -
Page 12: Ldn With Vp Option
HPP is not used, the customer can set the V- program on pin 2 of the LDN to match the voltage requirements for operating the HPP. Please consult the factory for further information. 02001346 Rev 1 HPP-1000/6000 User Manual Page 12 of 19... -
Page 13: Hpp-6000 Specifications
2000 meters maximum, 80 to 103 kPa Dimensions Please see Figure 7, HPP Mechanical Outline Drawing Outline 13.8 inch length, 8.15 inch wide, 3.93 inch high (does not include mounting flanges or electrical terminals) 02001346 Rev 1 HPP-1000/6000 User Manual Page 13 of 19... -
Page 14: Hpp Interface
Iprogram(+). The Interlock function can be connected to external Open = OFF Interlock interlock switches such as a door. Ground to pin 2 or 3 GND = Operate to operate. 02001346 Rev 1 HPP-1000/6000 User Manual Page 14 of 19... -
Page 15: Operation Of The Hpp
(Output, TTL, Pin 7) When the voltage compliance of the diode laser load is 8V lower than the DC input voltage. This fault may be cleared via the Enable signal. 02001346 Rev 1 HPP-1000/6000 User Manual Page 15 of 19... - Page 16 Figure 7, HPP Mechanical Outline Drawing 02001346 Rev 1 HPP-1000/6000 User Manual Page 16 of 19...
- Page 17 Figure 8, HPP Connections 02001346 Rev 1 HPP-1000/6000 User Manual Page 17 of 19...
-
Page 18: Product Limited Warranty
12. Product Limited Warranty Lumina Power, Inc., as Seller, warrants that each Product sold by it is free of defects in materials and workmanship. Duration of warranty is as follows: a. All Chassis enclosed products are covered for twenty four (24) months from date of shipment. Products included but are not limited to the following product families: CCPF, CCHP, LDY, LDYHC, LDQCW, XLB (excluding XLB-300), and MLB. -
Page 19: Service
13. Service This unit contains no user serviceable parts. Service and repair should be performed only by qualified personnel from Lumina Power, Inc. For more information contact Lumina Power, Inc. 26 Ward Hill Ave., Bradford, MA 01835 Ph: 978-241-8260 Fx: 978-241-8262 Email: sales@luminapower.com...
