26 Ward Hill Ave., Bradford, MA 01835
Ph: 978-241-8260 Fx: 978-241-8262
1. Description of CCPF-1500/2000
2. Explanation of Symbols
3. Specifications
4. Block Diagram
5. Typical Applications
6. Warnings
7. Installation
8. Service
02001055-01 Rev 1
CCPF-1500/2000-XX
OPERATION MANUAL
Operation Manual:
CCPF-1500/2000-XX
Page 1 of 14
Advertisement
Related Manuals for Lumina Power CCPF-1500
Summary of Contents for Lumina Power CCPF-1500
- Page 1 26 Ward Hill Ave., Bradford, MA 01835 Ph: 978-241-8260 Fx: 978-241-8262 CCPF-1500/2000-XX OPERATION MANUAL 1. Description of CCPF-1500/2000 2. Explanation of Symbols 3. Specifications 4. Block Diagram 5. Typical Applications 6. Warnings 7. Installation 8. Service Operation Manual: 02001055-01 Rev 1...
- Page 2 4000V. XX is the model designation which indicates the maximum output voltage. As an example, a CCPF-1500 configured for 1000V maximum output voltage is designated as a CCPF-1500-1P, where the P indicates a positive output. Positive output is the standard polarity.
- Page 3 Only service personnel of Lumina Power, Inc., are qualified to service this equipment. Only qualified service personnel are permitted to install this power supply. Section Intentionally left blank Operation Manual: 02001055-01 Rev 1 CCPF-1500/2000-XX Page 3 of 14...
- Page 4 XX = .2P to 4P (Units can be configured for Vout from 200V to 4000V) Input Voltage: CCPF-1500: 100-240 VAC, 50Hz to 60Hz CCPF-2000: 200-240 VAC, 50Hz to 60Hz Current: CCPF-1500: 20A @100VAC, 7.8 @240VAC CCPF-2000: 12.5A @200VAC, 11A @240VAC...
- Page 5 4. Interface Information CCPF-1500/2000-XX INTERFACE (15 Pin “D” Sub Connector Female) PIN # TITLE/DESCRIPTION INHIBIT/FAULT RESET- (Input) This pin is the basic ON/OFF control pin for the power supply. Grounding pin 1 enables power supply operation if all faults are clear. Applying +15V to pin 1 prevents the inverter from operating.
- Page 6 CCPF-1500/2000-XX INTERFACE (continued) PIN # TITLE/DESCRIPTION +15V (Output) Maximum output current is 100mA. This pin is internally tied to pins 11. N/C. Do not use +15V (Output) Maximum output current is 100mA. This pin is internally tied to pins 9.
- Page 7 CCPF-1500/2000-XX INTERFACE SCHEMATIC Figure 4.1 CCPF-1500/2000 Interface Schematic Operation Manual: 02001055-01 Rev 1 CCPF-1500/2000-XX Page 7 of 14...
- Page 8 PFN circuitry. Operation Manual: 02001055-01 Rev 1 CCPF-1500/2000-XX Page 8 of 14...
- Page 9 The IGBT will deliver short, high current pulses to the flashlamp. The power supply is not INHIBITED during this process and continuously tops the capacitor bank. Operation Manual: 02001055-01 Rev 1 CCPF-1500/2000-XX Page 9 of 14...
- Page 10 The diodes must have voltage rated at least 300V higher than the max voltage and 2 times the current. The resistor values are calculated as follows: R (in Ohm) >= 100 * Vout. P (in Watts) >= V^2 /R. Multiple PFN system. Operation Manual: 02001055-01 Rev 1 CCPF-1500/2000-XX Page 10 of 14...
- Page 11 Warning: Equipment is not suitable for use in presence of a flammable Anesthetic mixture with air or with oxygen or nitrous oxide. Operation Manual: 02001055-01 Rev 1 CCPF-1500/2000-XX Page 11 of 14...
-
Page 12: Installation
Only qualified technicians or qualified assemblers may install these power supplies into their lasers. Only qualified Lumina Power personnel may service these power supplies. There are no user serviceable parts in this equipment. Required wire and connectors: Refer to the Figure7.1 below for an the locations of connections. - Page 13 Figure 7.1 CCPF-1500/2000-XX Outline Drawing Operation Manual: 02001055-01 Rev 1 CCPF-1500/2000-XX Page 13 of 14...
- Page 14 8. SERVICE This unit contains no user serviceable parts. Service and repair should be performed only by qualified personnel from Lumina Power, Inc. For more information contact Lumina Power, Inc. 26 Ward Hill Ave.,...
