[3] UPACKING AND INSTALLATION
1. Unpacking
1
4
1
Upper cushion
3
LCC
5
Packing case
2. Installation procedure
Parts included
Mounting plate
(1 pc.)
Upper mounting plates
(2 pcs.)
Screws A (6 pcs.)
Screw B (1 pc.)
Remove the power cord from the copier and then
perform the following procedure.
1. Mount the upper mounting plates and the mounting
plate.
Make 6 holes for mounting (indicated with
lower part of the stand using a Phillips screwdriver, etc. and remove
burs using a flat-blade screwdriver, etc.Mount the upper mounting
plates using screws A (two for each plate).
2
3
4
2
Installation manual
4
Lower cushion
Connecting plate
Securing plate
(1 pc.)
(1 pc.)
Screws C (2 pcs.)
) on the copier and
1
5
Then remove 2 screws from the LCC cover on the copier and remove
the LCC cover.
Hole for mounting
Upper
mounting plate
Hole for mounting
3 – 1
LCC cover
Screw
Screws A
Screw
Upper
mounting plate
Screws A
Mounting plate
Screws A
