Customer Service Information; Safety Warnings - advanced scale models P-61 Black Widow Assembly Instructions Manual

in the USA
global Services
18480 bandilier Circle
Fountain valley, CA 92708
phone: (714) 963-0329
Fax: (714) 964-6236
email: service@globalhobby.net
ThiS R/C MoDel iS DeSigNeD FoR expeRieNCeD piloTS oNly! iF yoU ARe NoT AN expeRieNCeD piloT
CoMFoRTAble wiTh FlyiNg high-peRFoRMANCe MoDel AiRCRAFT, Do NoT CoNTiNUe.
like The MoDel, TheSe iNSTRUCTioNS ARe wRiTTeN wiTh The expeRieNCeD MoDeleR iN MiND. All
MAjoR STepS ARe oUTliNeD; howeveR, The iNSTRUCTioNS ARe wRiTTeN keepiNg iN MiND ThAT yoU'Re
expeRieNCeD iN bASiC MoDel ASSeMbly TeChNiqUeS AND AiRCRAFT SeTUp. iF yoU hAve qUeSTioNS
DURiNg ASSeMbly, pleASe CoNTACT yoUR loCAl DiSTRibUToR USiNg The CUSToMeR SeRviCe
iNFoRMATioN Above.
This R/C airplane is not a toy! If misused or abused, it can cause serious bodily injury and/or damage to property. Fly only in open areas and
preferably at a dedicated R/C flying site. We suggest having a qualified instructor carefully inspect your airplane before its first flight. Please carefully
read and follow all instructions included with this airplane, your radio control system and any other components purchased separately.
ADDITIONAL ITEMS NEEDED TO COMPLETE ASSEMBLY
1 x 5 - 6 Channel or More Radio Control System
●
2 x .52 - .61 4-Stroke Engines and 12 x 6" or 13 x 6" Propellers
●
2 x High-Torque, Low-Profile Servos for Ailerons
●
2 x High-Torque, Standard Servos for Flaps
●
5 x Standard Servos for Throttles, Rudders and Steering
●
1 x 24" and 36" Servo Extension Leads for Elevator Servo
●
6 x 12" Servo Extension Leads for Aileron and Flap Servos
●
4 x 12" Servo Extension Leads for Throttle and Rudder Servos
●
4 x Y-Harnesses for Ailerons, Flaps, Rudders and Throttles
●
1 x 5 Cell (6 Volt) 1100mAH or greater Capacity Receiver Battery
●
2 x Remote Fueling Valves
●
Five and Thirty Minute Epoxy
●
Thin and Thick C/A
●
C/A Debonder and Rubbing Alcohol
●
Assorted Modeling Tools (i.e., Modeling Knife, Screwdriver, Hex Wrenches, Etc.)
●
Assorted Modeling Supplies (i.e., Sandpaper, Sanding Block, Airplane Stand, Paper Towels, Etc.)
●
Optional Phneumatic Retract Installation
1 x ASM Retract Set and Control System for P-61 Black Widow (P/N ASM-ARS02)
●
1 x ASM Landing Gear Strut Set for P-61 Black Widow (P/N ASM-CSS02)
●
1 x Standard Servo for Retract Air Control Valve
●

CuSTOMER SERVICE INFORMATION

in the eU
Ripmax ltd.
241 green Street
enfield, U.k. eN3 7Sj
phone: (0) 20 8282-7500
Fax: (0) 20 8282-7501
email: mail@ripmax.com

SAFETY WARNINGS

Because of the number of servos and servo extension leads used, we strongly suggest the use
of a 5 cell (6 Volt) 1100mAH or greater capacity receiver battery.
As an alternative to purchasing multiple servo extension leads, you may want to purchase a bulk
spool of servo wire and connectors and make your own custom-length extension leads.
